EZG Grip Hog PM-1AIR User manual

Grip Hog
PM-1AIR
Owner’s Manual
EZG MANUFACTURING
1-800-417-9272
PM-1AIR
EZG Manufacturing
405 Watertown Road
Waterford, Ohio 45786
[phone] or 1-800-417-9272
Fax [phone] www.ezgmfg.com
Before using this PM-1AIR, study and
understand the entire Owner’s Manual.

EZG Manufacturing 1-800-417-9272 ezgmfg.com
Revision Number-002 11-09-2021 - Present
23
Revision Number-00211-09-2021 - Present
EZG Manufacturing 1-800-417-9272 ezgmfg.com
This symbol, either used alone or with a signal word, is used to call your attention
to instructions involving your safety and/or the safety of others. Failure to follow
these instructions will likely result in personal injury or death.
DANGER This signal word is used to identify a hazard which, if not avoided, will result in
death or serious injury.
WARNING This signal word is used to identify a hazard which, if not avoided, could result in
death or serious injury.
CAUTION This signal word is used to identify a hazard which, if not avoided, could result in
minor or moderate injury.
NOTICE
This signal word is used to identify a hazard which, if not avoided, could result in
property or equipment damage. It also may be used for special instructions
related to performance, maintenance or general items.
INTRODUCTION.................................................................................................................................3
ABOUT THIS MANUAL.......................................................................................................................3
GENERAL INFORMATION..................................................................................................................3
SAFETY INFORMATION.....................................................................................................................3
SAFETY PRECAUTIONS..................................................................................................................4
MACHINE DESCRIPTION.....................................................................................................................5
OPERATING SAFETY.......................................................................................................................6
DAILYMAINTENANCE / INSPECTION.......................................................................................................................6
ASSEMBLY INSTRUCTIONS..........................................................................................................6
OPERATING INSTRUCTION……….............................................................................................7
TROUBLESHOOTING......………………………..................................................................................7
PM-1AIR…………………………………………………………………………………………………………8-9
NOTES / SERVICE RECORDS...................................................................................................................10
WARRANTY.........................................................................................................................................11
WARRANTY REGISTRATION............................................................................................................12
INTRODUCTION
Congratulations on purchasing one of the nest pieces of construction equipment on the market today!
If this is your rst EZG Manufacturing product, you will not be disappointed. If you have previously
owned an EZG Manufacturing product, you will nd the same high quality and dependability that you
have come to expect from EZG Manufacturing.
The purpose of this manual is to inform the owner/employer/and the operator, how to safely operate
this piece of equipment, and make them aware of any hazards. It also contains important information
regarding assembly, set up, operation, and maintenance. It is the Owner/Employer’s responsibility
to make sure that anyone who operates this machine understands all safety warnings. If you do not
understand any items in this manual, please contact the dealer where this product was purchased, or
the manufacturer at the number listed throughout this manual. If you have any suggestions about how
to make this manual easier to understand, contact the manufacturer. Keep this manual available for
reference wherever this piece of equipment is being used and make it available to any operators.
Illustrations in this manual may show details or components that may not be the same as your
machine. Continuing improvements to the design of this machine may have caused changes that are
not included in this manual. The information in this document is subject to change without notice.
The following safety symbols and signal words will be used throughout this manual and on the
product, for your safety and the safety of others, please become familiar with their meaning and heed
their warnings.
ABOUT THIS MANUAL
GENERAL INFORMATION
SAFETY INFORMATION
TABLE OF CONTENTS

EZG Manufacturing 1-800-417-9272 ezgmfg.com
Revision Number-002 11-09-2021 - Present
45
Revision Number-00211-09-2021 - Present
EZG Manufacturing 1-800-417-9272 ezgmfg.com
WARNING
Failure to obey the following safety instructions could result in DEATH or
SERIOUS INJURY.
Read and understand entire manual before operating the PM-1AIR.
For your safety and the safety of others, replace any missing or damaged warning decals by
contacting the manufacturer at 1-800-417-9272.
Make sure anyone operating the PM-1AIR is thoroughly familiar with its operation. Keep all
unauthorized and untrained personnel, especially children, away from PM-1AIR.
Improper maintenance can be hazardous. Read and understand this section before you perform
any maintenance, service or repairs.
• Always wear the proper PPE. Eye protection, hearing protection, and steel toed boots with
metatarsal guards must be worn when using this device.
• The PM-1AIR is capable of lifting 75 lbs. Do not lift any materials heavier than 75 lbs.
• Compressed air is hazardous.
o Only use compressed air for its intended purpose.
o Before using compressed air, inspect all equipment hoses and ttings for damage.
o Never exceed the recommended pressure.
o Never apply compressed air to the skin or clothing.
o Never direct compressed air at your own body or towards another person.
• Do not overtighten threaded connections. Overtightening can damage threads.
• Do not place hands or any body part over the air exhaust. Ensure air exhaust is pointed in a safe
direction prior to engaging control valve handle.
• Only use the PM-1AIR for its intended purpose of handling material.
OPERATING SAFETY
SAFETY PRECAUTIONS MACHINE DESCRIPTION
PM-1AIR
The Grip Hog PM-1AIR is the most versatile tool - a real back, knee and knuckle saver - when it comes to
installing pavers and other supported materials. The vacuum pick-up venturi with a control valve installed
on the T-handle allows operators to lift material up to 75 lbs. using the provided 6” vinyl head or 6” x 8” foam
head. A 120 PSI at 6 CFM compressor is suggested to operate.
* May not function normally on porous material

EZG Manufacturing 1-800-417-9272 ezgmfg.com
Revision Number-002 11-09-2021 - Present
67
Revision Number-00211-09-2021 - Present
EZG Manufacturing 1-800-417-9272 ezgmfg.com
ASSEMBLY INSTRUCTIONS
The PM-1AIR is equipped with (1) T-Handle, (1) 24” threaded pipe, (1) 6” vinyl cup, (1) 6” x 8” Head
To assemble the PM-1AIR:
1. Ensure threads are clean before assembly
2. Thread the 24” threaded pipe onto the T-Handle. Thread until tight (about 4 full turns). Do not
overtighten threaded connections.
3. Thread the 6” vinyl cup onto the 24” threaded pipe.Thread until tight (about 4 full turns). Do not
overtighten threaded connections.
4. When tightening threaded connections, the connection should be easily turned by hand. If the
connection does not turn easily by hand, stop tightening and ensure the threads are started correctly.
The PM-1AIR works by applying air ow through a specialized valve. The airow generates vacuum to
the vinyl suction cup. The PM-1AIR weighs 7 lbs. Before operating the PM-1AIR, it should be assembled
and properly set up.
To Operate the PM-1AIR:
1. Verify that the material to be lifted is 75 lbs. or less
2. Position the PM-1AIR on top of the material that will be lifted
3. Connect the PM 1-Air to a 120 psi, 6 cfm or higher air supply
4. Position cup on top of the material to be lifted.
5. Depress the control valve as vacuum is applied to material surface
6. Keep control valve depressed and use both hands to lift by the handles.
7. Lower the material in desired position and release the control valve (Note: Safe operating height
should be no higher than 5” above working surface)
8. Repeat steps 2-8 as needed to complete moving of material
DAILY MAINTENANCE / INSPECTION
• Perform a daily inspection prior to using this device.
• Inspect the unit for any loose ttings or damaged parts.
• Inspect threads for damage prior to assembly.
• Inspect the vinyl cup or foam strip for tears or damage that would prevent a proper seal to
material.
• If any defects are found, discontinue use of the device immediately.
• Only use the PM-1AIR for its intended purpose of handling material.
OPERATING INSTRUCTIONS
TROUBLESHOOTING
If the PM-1AIR will not lift material:
1. Check vinyl cup or foam for damage
2. Check air supply for damage or operating issue
3. Check material porosity (material may be too porous to lift)
4. Check material weight (material may be too heavy to lift)
5. Unit may need to be cleaned to remove debris
• Connect to proper air supply
•Remove 6” vinyl cup or memory foam pad from 24” pipe
•Place 24” pipe into 5 gallon bucket of warm water
•Depress control valve and suction water through the unit - water will be expelled through control
valve end so point in a safe direction.
•Continue depression of control valve until all water is suctioned through the unit
• Repeat if necessary

EZG Manufacturing 1-800-417-9272 ezgmfg.com
Revision Number-002 11-09-2021 - Present
89
Revision Number-00211-09-2021 - Present
EZG Manufacturing 1-800-417-9272 ezgmfg.com
PM-1AIR PM-1AIR
ITEM NO. QTY. DESCRIPTION
17-111 1 1/2”x24” NIPPLE GALV.
17-100 2 HONEYCOMB GRIP HANDLE
17-101 1 1/4” BLOW GUN CONTROL VALVE
17-102 1 1/4” MALE PLUG M STYLE
17-105 1 1/2” GALV. MERCHANT COUPLING
17-110 1 1/2”x1 1/ 2” NIPPLE SS
17-117 2 4” CLOSE NIPPLE SS
PNCV-34 16" VACCUM HEAD
17-106 1 1/2”x1/4” REDUCING COUPLING SS
IVI-MU-FF-8G-ALU-UR-SPL 1 VENTURI (NEW DESIGN)
IVI-MU-FF-16N-ALU-PN-SPL 1 PIPE - HANDLE
PM-6X8SFX 1 6” X 8” HEAD WITH GASKET 1/2” NPT.

EZG Manufacturing 1-800-417-9272 ezgmfg.com
Revision Number-002 11-09-2021 - Present
10 11
Revision Number-00211-09-2021 - Present
EZG Manufacturing 1-800-417-9272 ezgmfg.com
NOTES
SERVICE PERFORMED DATE INITIALS
SERVICE RECORDS
WARRANTY
Limited Warranty
The manufacturer warrants that products manufactured shall be free from defects in material and
workmanship that develop under normal use for a period of two years on all products from the date
of shipment. The foregoing shall be the exclusive remedy of the buyer and the exclusive liability of
the manufacturer. Our warranty excludes normal replaceable wear items, i.e. gaskets, wear parts,
seals, O-rings, belts, drive chains, clutches, etc. Any equipment, part or product which is furnished
by the manufacturer but manufactured by another, bears only the warranty given by such other
manufacturer. (Manufacturer agrees to furnish free of charge a written description of problem or
cause.) Warranty is voided by product abuse, alterations, use of equipment in applications for
which it was not intended, use of non-manufacturer parts, or failure to follow documented service
instructions. The foregoing warranty is exclusive of all other warranties whether written or oral,
expressed or implied. No warranty of merchantability or tness for a particular purpose shall apply.
The agents, dealers, and employees of Manufacturer are not authorized to make modications
to this warranty, or additional warranties binding on the Manufacturer. Therefore, additional
statements, whether oral or written, do not constitute warranty and should not be relied upon.
The Manufacturer’s sole responsibility for any breach of the foregoing warranty provisions, with
respect to any product or part not conforming to the Warranty or the description herein contained,
is at its option (a) to repair, replace, or refund such product or parts upon the prepaid return there of
to location designated specically by the Manufacturer. Product returns not shipped prepaid will be
refused (b) as an alternative to the foregoing modes of settlement - the Manufacturer’s dealer may
repair defective units with reimbursement for expenses. A written description of problem or cause
must accompany all warranty claims.
Except as set forth here in above and without limitation of the above, there are no warranties or
other a󰀩rmation which extend beyond the description of the products on the fact here of, or as to
operational e󰀩ciency, product reliability, or maintainability or compatibility with products furnished
by others. In no event, whether as a result of breach of contract or warranty or alleged negligence,
shall the Manufacturer, be liable for special or consequential damages including but not limited to:
Loss of prots or revenue, loss of use of the product or any associated product, cost of capital, cost
of substitute products, facilities or services or claims of customers. Manufacturer does not assume
responsibility for any accident due to equipment modication.
No claim will be allowed for products lost or damaged in transit. Such claims should be led with the
carrier within fteen days.
E󰀨ective July 20, 2005
EZG Manufacturing is the exclusive manufacturer of the patented Grout Hog® Grout Delivery
System the Mud Hog® Hydraulic Mixing Station, the Hog Trough® mud pan, the Hog Cart™, the
Hog Slopper™, the Booger Hog® Wall Scrubber, the Hog Leg® Wall Brace System, and the Hog
Crusher™ Material Recycling System.

EZG Manufacturing 1-800-417-9272 ezgmfg.com
Revision Number-002 11-09-2021 - Present
12 EZG Manufacturing 1-800-417-9272 ezgmfg.com
WARRANTY REGISTRATION
Fax Warranty Registration form to 740-962-2037
or submit online by visiting ezgmfg.com/serial-registration.
CONTACT:
COMPANY:
ADDRESS:
CITY: STATE ZIP
PHONE: FAX CELL
EMAIL:
PURCHASED FROM: Direct Distribution
PURCHASED DATE: SERIAL NO.
PLEASE COMPLETE THIS WARRANTY CARD AND RETURN VIA MAIL, FAX OR E-MAIL
WITHIN 30 DAYS OF PURCHASE TO VALIDATE YOUR MANUFAVTURER’S WARRANTY
FOR ALL EZG MANUFACTURING PRODUCTS.
WARRANTY PROVISIONS OF THIS MACHINE ARE HANDLED DIRECTLY THROUGH
THE MANUFATURER.
EZG MANUFACTURING * 1833 North Riverview Road, Malta, OH 43758 *
PHONE [phone] * Email: [e-mail] * FAX [phone]
Please take a minute to ll out the survey below so that we better serve our customers.
EZ Survey
1. WHERE DID YOU FIRST HEAR ABOUT EZG MANUFACTURING (CHECK ONE)
Masonry Magazine Website Newsletter Referral Masonry Construction
Other:
2. WHAT INFLUENCED YOU TO BUY? QUALITY PRICE EASY TO USE OTHER
3. WHO IS YUR SALES REPRESENTATIVE?
4. ARE YOU SATISFIED WITH THE CUSTOMER SERVICE YOU RECEIVED? YES NO
Explain:
5. WHAT OTHER EZG MANUFACTURING PRODUCTS DO YOU OWN?
6. WOULD YOU LIKE TO BE FEATURED IN OUR NEWSLETTER? YES NO
If yes, where can we reach you and what is the best time?
Comments:
