FAAFTECH INSTALLATION MANUAL User manual

Installation chart
REV 060717
0800 603 2330 or (62) 3241-4600
[email protected]
www.faaftech.com.br
Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time
TECHNICAL SUPPORT Follow us on social media!
Installation Manual
FT-VF-HND3
For your safety and comfort, read this manual carefully.
Scan this QR code to see which
vehicles are compatible.
ACC
GND
ORIGINAL
MULTIMEDIA
Plug in to the original whip
ACC and GND outputs to power the mirroring module.
Note: ACC output has a low current. Use it only to power the
mirroring or the Digital TV module, we do not recommend its
usage to power any other accessories.
Plug in to the IR input on Faaftech’s TV-1SEGII
or TV-HD2. This will enable the channel switch
through the steering wheel commands.
Plug in to the multimedia
FT-VF-HND3
IR-TV

AV Input
Steering Wheel Commands
If you have installed a Faaftech Digital TV on the radio’s AV input, you can switch channels by using the steering wheel com-
mands, as shown on the picture below:
AV input: use it to connect a TV
or screen mirroring module
ORIGINAL
MULTIMEDIA
Entrada AV
Press for 1 second: Channel +
Press for 3 seconds: SCAN
Press for 1 second: Channel -
