1. INTRODUCTION
NNoottee::tthheessee iinnssttrruuccttiioonnss sshhoouulldd bbee rreeaadd ccaarreeffuullllyy aanndd rreettaaiinneedd ffoorr
ffuuttuurree rreeffeerreennccee..
PPlleeaassee lleeaavvee tthheessee iinnssttrruuccttiioonnss wwiitthh tthhee uusseerr..
This guide is concerning the following types of appliances:
Silva
Cadra
Prisma
Spectra
Spectra Panorama
Special features:
- Realistic flame and glow effect because of the "flat fibre burner"
technology.
- Room sealed room appliance, inlet and outlet are led to the outside
using a natural draught concentric pipe system (100 mm/150 mm
(no power fan required . No additional ventilation required.
- Air supply and flue-gases go to outside atmosphere through wall or
roof. A maximum horizontal extension of 6 meters is possible.
- Remote Control option on all appliances.
- Meets the essential requirements of the European Gas Appliance
Directive (GAD and carries the CE mark.
2. SAFETY AND GENERAL
INFORMATION
Before installation, ensure that the local distribution conditions
(identification of the type of gas and pressure and the adjustment of
the appliance are compatible.
This gas appliance is factory set and shall not be adjusted by the
installer.
This appliance does not contain any component manufactured from
asbestos or any asbestos related products.
The pilot and flame sensing device fitted to this fire is also a safety
device. If for any reason any part of the pilot assembly is to be
replaced the entire assembly including the pilot burner, thermocouple,
electrode and injector must be exchanged complete for a pilot assembly
from the original manufacturer only.
Ventilation
This appliance is room-sealed and doesn't require purpose provided
ventilation.
2.1 General safety
It is the law in the UK that aallllgas appliances, are installed by a
competent person in accordance with the Gas Safety (Installation and
Use Regulations (as amended , the relevant British Standards for
Installation work, Building Regulations, Codes of Practice and the
manufacturers instructions.
The installation should also be carried out in accordance with the
following where relevant:
BS5871 Part1 BS5440 Parts 1 & 2 BS1251.
Building Regulations Document J (as applicable .

UK/IRL
5
UK/IRL
4
Building Regulations and Standards issued as relevant by the
Department of the Environment or the Scottish Development
Department.
In the Republic of Ireland installation should be carried out in
accordance with IS813, ICP3, IS327, Building Regulations, Codes of
Practice, the manufacturers instructions and any other rules in force.
Failure to comply with the above could leave the installer liable to
prosecution and invalidate the appliance warranty.
Safety instructions for the user: see chapter 9.
3. INSTALLATION REQUIREMENTS
N te:
Since the appliance is a source of heat, circulation of air occurs.
Therefore it is of importance that you do not use the appliance
shortly after a renovation of the home. Because of the natural
circulation of air, moist and volatile components from paint, building
materials, carpet etc. will be attracted. These components can settle
themselves down onto cold surfaces in the form of soot.
As on all heat producing appliances, soft furnishings such as blown
vinyl wallpaper placed too near to the appliance may become
scorched or discoloured. This should be born in mind when installing
the appliance.
3.1 Builders pening and surr und
The appliance can be installed in the following situations:
In a non-combustible fireplace or builders opening. This could be either
an existing builders opening or a new made prefab builders opening.
For the measurements, see figure 1 and index.
Although the appliance is tested for installation without a hearth, the
appliance must not stand on combustible materials or carpets. If the
appliance is placed on a combustible floor then a fibrelux or similar
heatproof board of 12 mm thickness should be placed under it. Any
under floor vents or openings within the builders opening should be
sealed off.
Do not place the lintel, surround or marble stone directly onto the
appliance. If possible, apply a lintel made of cement or something
similar.
Isolate the appliance with a ceramic blanket (25 mm . See also
chapter 4: Installation instructions.
Preferred choice for insulation is unbound insulation wool (at
1000 °C gives no smell .

UK/IRL
7
UK/IRL
6
3.1 Builders pening and surr und (c ntinuing)
If the builders' opening is constructed out of non-combustible
composition board (Fibrelux and you install the appliance without a
mantel then:
- Ventilate the space above the appliance (min. 1000 mm2 .
- Always fit the DC convection set.
- The plaster of the outside has to be resistant to a high
temperature. Use therefore the plaster materials especially made for
this, to prevent discoloring (min. 100 °C temperature resistant .
If the appliance is to be fitted against a wall with combustible
cladding, the cladding must be removed from the area covered by the
surround.
The minimum height from the top surface of the fire to the underside
of any shelf made from wood or other combustible materials is as
follows:
- For a shelf up to 150 mm deep – Minimum height = 350 mm
(fig. 1 .
- If the shelf depth is greater than 150 mm add 50 mm to the upper-
clearance height for every 25 mm increase in shelf depth.
- Side clearance = Minimum distance from the side of the fire frame
to combustible material = 150 mm.
fig. 1
table 1
BBuuiillddeerrss ooppeenniinngg ((mmmmSSppeeccttrraaCCaaddrraaPPaannoorraammaaPPrriissmmaaSSiillvvaa
A Opening width 780 680 810 710 600
B Opening height 705 805 710 710 715
C Opening depth (min. 430 430 430 430 350
SShheellff ddiimmeennssiioonnss ((ccoommbbuussttiibbllee
D Min. height shelf from top frame 350 350 350 350 350
E Depth shelf max. 150 150 150 150 150
DDiimmeennssiioonnss ((mmmm
F Box width 752 652 752 652 575
G Box depth 395 395 395 395 309
H Box height 714 814 714 714 693
I Frame width 790 690 875 775 629
J Frame height 720 820 732 732 727
K Frame thickness 22.5 22.5 122 124 15
L Position flue (behind frame 256.5 256.5 255 255 190
M Position flue (from the back side box 140 140 140 140 119
LM
F
I
CB
AJ
E
D
G
K
H

UK/IRL
9
UK/IRL
8
3.2 Flue requirements
The appliance is of the type C11/C31. The appliance will need to be
supplied with the approved flue pipes and terminal, it is not possible to
supply your own.
The minimum effective height of the flue system must be 1 m.
Terminal locations, through the wall as well as through the roof. See
figure 3.
Flue routing;
- a horizontal extension with elbows is allowed for a maximum of 6
meter (depending on the type and situation .
- vertical max. 12 meter.
Determine on the base of the table 2 and 3, depending on the type
and terminal position, if the desired situation is possible.
To establish this you will need to calculate:
-The effective height (this is the real difference in height between the
upper side of the appliance and the terminal .
- The total horizontal extension. This is the total horizontal flue length
where:
• each elbow, which is in the horizontal area, counts for 2 meters.
• each 45-degree bend, which is in the horizontal area, counts for 1
meter.
• elbows and bends at the transition of horizontal to vertically are
not to be counted.
• the wall mounted terminal counts for 1 meter.
FFlluuee rreessttrriiccttoorr
If applicable, in the table is also stated the size of a flue restrictor.
This restrictor needs to be fitted in the combustion chamber when
placing the appliance ( see chapter 4.2 . Normally the smallest flue
restrictor is fitted.

UK/IRL
11
01 2 3 4 56
0XX X X X XX
XXXXXX
XXXXX
XXXX
XXX
XX
X
000XX
00X
1 0 0
1,5 0 0 0 0
2 52.5 45/52.5 0 0 0 0 0
3 52.5 45/52.5 45/52.5 0 0 0 0
4 52.5 45/52.5 45/52.5 45/52.5 0 0 0
5 52.5 45/52.5 45/52.5 45/52.5 45/52.5 0 0
6 52.5 45/52.5 45/52.5 45/52.5 45/52.5 0 0
7 52.5 45/52.5 45/52.5 45/52.5 45/52.5 45/52.5
8 52.5 45/52.5 45/52.5 45/52.5 45/52.5
9 52.5 45/52.5 45/52.5 45/52.5
10 52.5 45/52.5 45/52.5
11 52.5 45/52.5
12 52.5
Horizontal extension
Effective height
Table Spectra, Spectra Pan rama, Prisma and Cadra
Determine according to the table 2 the right total horizontal- and vertical length.
When meeting an X, and when the values are outside the table, the combination
is not allowed.
Table Silva
Determine according to the table 3 the right total horizontal- and vertical length.
When meeting an X, and when the values are outside the table, the combination
is not allowed. The value 45/52.5 means place a flue restrictor of 52.5mm when
using a roof mount terminal or 45 mm when you installing a wall mount terminal.
NNoorrmmaallllyy tthhee 4455 mmmm fflluuee rreessttrriiccttoorr iiss pprreeiinnssttaalllleedd..
0123456
0XXX XXXX
XXX XXX
XXXXX
XXXX
XXX
XX
X
1 0 0 0 0 00
0
2 0 0 0 0 0 0 0
3 0 0 0 0 0 0 0
4 0 0 0 0 0 0 0
5 0 0 0 0 0 0 0
6 0 0 0 0 0 0 0
7 0 0 0 0 0 0
8 0 0 0 0 0
9 0 0 0 0
10 0 0 0
11 0 0
12 0
Horizontal extension
Effective height
table 2
table 3
UK/IRL
10
fig. 2a
Hvert.
N
M
L
K
J
I
H
fig. 2b
Hvert.
A
F
G
E
D
C
B
Example calculati n 1
Calculati0n h riz ntal extensi n fig. 2a:
Flue lenght C + E = 1m + 1m 2 m
Elbows D = 2m 2 m
Total horizontal extension 4 m
Measure r calculate effective height
(Hvert)
Flue lenght A 1 m
Roof mounted terminal 1 m
Total effective height 2 m
When calculating on basis of the
Spectra table Nr. 2:
It is allowed.
When calculating on basis of the Silva
table Nr. 3:
Allowed but without flue restrictor.
Remove the flue restrictor!
Example calculati n 2
Calculati0n h riz ntal extensi n fig. 2b:
Flue lenght J + L = 0,5 + 0,5 1 m
Elbows K + M = 2m + 2m 4 m
Terminal 1 m
Total horizontal extension 6 m
Vertical
Flue lenght H 1 m
When calculating on basis of the
Spectra table Nr. 2:
It is allowed.
When calculating on basis of the Silva
table Nr. 3:
Combination not allowed.

UK/IRL
13
UK/IRL
12
3.2 Flue requirements (c ntinuing)
3.2.1 Terminal p siti n
Verify if the required terminal position meets the local installation
regulations regarding disturbance, good functioning and ventilation.
(Also see: safety requirements .
NNoottee::
The terminal must be located so that the outlet is not obstructed. If
the flue terminal is located within 2 meters of a footway, path or
where people could come into contact with it then a suitable
terminal guard must be fitted.
Terminals located close to shared walkways, footpaths etc. could be
subject to legal constraints and this should be pointed out to the
customer before installation. If in any doubt about flue location
advice should be sought from local building control, or if appliance-
related, from the manufacturer including wherever possible a
dimensioned sketch.
Avoid locating the terminal in close proximity to plastic materials
such as gutters or other combustibles. If this is unavoidable then a
suitable deflector should be made.
Some important requirements for a good functioning are:
The wall-mounted terminal has to be at a distance of at least 0,5
meters off:
- Corners of the building.
- Below eaves.
- Balcony's etc. unless the duct is dragged to the front side of the
overhanging part.
The roof mounted terminal has to be at a distance of at least 0,5
meters of the sides of the roof, excluded the ridge.
Flue terminal p siti ns
fig. 3

Example f h w terminal p siti n is measured
33..22..22 UUssiinngg aann eexxiissttiinngg cchhiimmnneeyy aass aaiirr iinnlleett
You can connect the appliance onto an existing chimney. The existing
chimney then functions as air supply, where a flexible stainless steel
liner (to BS715 of 100 mm performs the flue function.
Requirements:
- Any existing chimney used as an air supply must only service this
appliance.
- A chimney that has previously been used for solid fuel must be swept
before use.
- The existing chimney needs to be airtight.
- The existing chimney needs to have an opening of min. 150 x 150
mm.
- The chimney needs to be intact and well looked after.
- Use the adjustable roof-mounted-terminal especially made for this,
and the chimney connection set.
- The minimum distance between two terminals should be at least 450
mm.
Dimension TTeerrmmiinnaall ppoossiittiioonnBalanced flue room sealed
(kW input 0-7 kW expressed in net Natural draught
A Direct below an opening, airbrick, 300 mm
opening windows, etc.
B Above an opening, airbrick, 300 mm
opening window ect.
C Horizontally to an opening, airbrick, 300 mm
opening window etc.
D Below gutters, soil pipes or drain pipes 500 mm
E Below eaves 500 mm
F Below balconies or car port roof 600 mm
G From a vertical drain pipe or soil pipe 300 mm
H From an internal or external corner 600 mm
I Above ground roof or balcony level 300 mm
J From a surface facing the terminal 600 mm
K From a terminal facing the terminal 600 mm
L From an opening in the carport (e.g. 1200 mm
window into the dwelling
M Vertically from a terminal on the same wall 1500 mm
N Horizontally from a terminal on the same wall 300 mm
P From a vertical structure on the roof 600 mm
Q Above intersection with roof 500 mm
UK/IRL
15
UK/IRL
14
Table 4
fig. 4

UK/IRLUK/IRL
16
4.2 Preparing the appliance (c ntinuing)
1. Remove the front by loosening the screws A (see fig. 5 .
2. Remove the glass by removing the glass clamps (B for instance with
a screwdriver. Careful when removing the glass! (see fig. 5 . Wear
gloves! Before placing the glass back, be sure that there are no
fingerprints on the glass, it is not possible to remove those prints
after you burn the appliance or a while (they will be burnt in .
3. Take the box with the log set out of the combustion chamber.
4.2.2 M del Spectra Pan rama and Prisma
1. Remove the front by loosening the screws A (see fig 6 .
2. Remove the glass by removing the glass clamps B for instance
with a screwdriver. Remove the nuts C and the strip on top of the
glass. Careful when removing the glass! (fig 6. Use gloves! Be sure
that there are no fingerprints on the glass, it is not possible to
remove those prints after you burn the appliance for a while (they
will be burnt in .
3. Take the box with the log set out of the combustion chamber.
fig. 6
4. INSTRUCTIONS FOR INSTALLATION
4.1 Gas c nnecti n
1. Installation pipes should be in accordance with BS 6891. Pipe work
from the meter to the appliance must be of adequate size.
2. The complete installation including the meter must be tested for
soundness and purged as described in the above code.
3. An isolator must be provided in the line to the fire.
4. The connection should be made in 8 mm copper or similar semi
flexible tube (max. 1 meter .
5. The gas connection is nut and olive suitable for 8 mm pipe.
4.2 Preparing the appliance
4.2.1 M del Spectra and Cadra
fig. 5
A
A
A
A
B
17
A
C
B
gas supply routes when fire is fitted in a deep surround
C = Through wall - Pipe must be sleeved and sealed to fire
A & B = Behind surround - Sleeve pipe through surround
inner wall
outer wall
cavity
surround
marble

UK/IRL
19
UK/IRL
18
4.3 Fitting the fireb x
Points of attention for placement:
- If possible, first locate the appliance before assembling the flue.
- If this is not possible then always use an extendible pipe before
connection onto the appliance.
1. Position the firebox in the fireplace opening. You can adjust the
height with the 4 adjustable feet.
2 Make the gas connection according to the instructions (also see gas
connection, chapter 4.1 .
3. Assemble the flue system onto the firebox (see chapter 5 .
4. If necessary, place the DC convection system (also consult the
instruction belonging to the DC construction set .
5. Isolate the firebox with a ceramic blanket (25 mm . Preferred choice
for insulation is unbound insulation wool (at 1000 °C gives no
smell .
6. Spread, the bag of embers (imitation ashes provided with the
appliance over the burner. Do not use more than the quantity
supplied. The embers glow on low setting.
ceramic blanket
ceramic
blanket ceramic
blanket
ceramic
blanket
ceramic
blanket
fig. 9
4.2 Preparing the appliance (c ntinuing)
4.2.3 M del Silva
1. Open the door by pressing against the door at the bottom right
and remove the door.
2. Remove the front, by unscrewing the four screws (see fig. 7 .
3. Remove the glass by disassembling the securing frame (unfasten
the two screws on the bottom of the frame and remove the 2
screws on top of the frame (see fig. 7 .
4. Take the box with the log set out of the combustion chamber.
5. Place the right flue restrictor in the combustion chamber. To
determine the right flue restrictor, see chapter 3. (Standard
preinstalled 45 mm .
fig. 8 placing flue restrictor
fig. 7

UK/IRL
21
UK/IRL
20
4.4 Placing the l g set (c ntinuing)
4.4.1 M del Spectra, Spectra Pan rama, Prisma, Cadra and Silva
The logs set consist of a rear log, which is permanently attached
(except for Silva to the combustion chamber, and four logs. For Silva
place the rear log into the U section in the back of the combustion
chamber.
The logs must rest on the log holder and the rear log.
Ensure that the pilot burner remains visible after installation of the log
set.
When not placing the log set correctly, the flames tend to burn to the
front against the window.
4.3 Fitting the fireb x (c ntinuing)
7. Place the log set (see placing log set, chapter 4.4 .
8. Before placing the glass; check the glass sealing rope is in good
condition and makes an effective seal. Be sure that there are no
fingerprints on the glass. It is not possible to remove those prints
after you burn the appliance for a while (they are burnt in .
Place the glass in front of the appliance and fix the glass frame or
use the glass clamps.
9. Replace the front and fix it.
4.4 Placing the l g set
The logs contain Refractory Ceramic Fibre which when cut or broken
open can be an irritant to skin and the respiratory tract. Always wear
gloves, do not blow dust into air and clean up using a vacuum
cleaner equipped with a HEPA filter.
Never place extra elements of any kind into the combustion chamber.
To guarantee good combustion, the log set may only be installed in
the way specified by Faber International. Any other arrangement can
lead to soot on logs or window. Do not use the fire with broken or
missing logs.
4.4.1 M del Spectra, Spectra Pan rama, Prisma, Cadra and Silva
Cadra log-set lay
A = large log
28 x 10 cm
B = medium log
24 x 9 cm
C = small log (wedge
26 x 8 cm
Spectra, Prisma, Panorama log-set lay
Silva log-set lay

UK/IRL
23
UK/IRL
22
5.2 C nnecti n nt an existing chimney
You can connect the appliance onto an existing chimney. The existing chimney then
functions as air supply, where a flexible stainless steel liner (to BS715 of 100 mm
performs the flue function. Any existing chimney used as an air supply must only
service this appliance.
Requirements:
- 300 mm of free space above the appliance;
- The chimney only supply’s air to this appliance;
- The existing chimney needs to be clean and very well swept;
- The existing chimney needs to be airtight;
- The existing chimney needs to have an opening of
min. 150 x 150 mm.
1. Place the aluminium closure plate (A onto the
chimney. Permanently attach and make airtight.
2. Cut down the roof mounted terminal (B to the
required length. At least cut off 500 mm. Leave
the inner pipe at least 100 mm longer than the
outside pipe. You need the cut off pieces for
connection of the appliance.
3. Pull the liner (C through the chimney.
4. Connect the liner onto the roof terminal and fix
this with the clamp provided with the chimney
connection set.
5. Place the roof terminal onto the closure plate.
6. Fixing the chimney sealing plate (D and place
the 150 mm grommet into the hole of the
sealing plate.
F
E
D
C
B
A
fig. 10
5. INSTALLATION OF THE FLUE
5.1 C nnecti ns with use f c ncentric duct material
- Build the system starting from the appliance on.
- Make a hole of ø 153 mm for the wall or roof mounted terminal.
- Make sure you place the pipes in the right direction, the narrow
end towards the appliance.
- Make sure the pipes are fixed sufficiently, a wall clamp every 2m, so
the weight of the pipes is not resting onto the appliance.
- The outside of the pipe can become hot (140 degrees . Stay 50 mm
away from wall surface or sealing. Make sure to provide sufficiently
heat resistant isolation when going through the wall or roof.
- Because of expansion or cooling down the concentric pipes can turn
loose. It is recommended to fix the spring clip with a self tapping
screw at inaccessible places.
- To get the exact measure flue length you can use cut down-
concentric pipe, wall mounted terminal or roof mounted terminal. To
obtain a smoke sealed connection, the inner pipe must be 20 mm
longer then the outside pipe.
- The horizontal pipes need to rise away from the appliance at a rate
of 3 degrees per metre.

UK/IRL
25
UK/IRL
24
5.3 Rem te c ntr l (if applicable)
The remote control is only meant to regulate the flames, it functions
only when the pilot burner is ignited. It is therefore not possible to
ignited the appliance with the remote control or to shut-off the pilot-
flame.
The radio-frequency remote control is intended for fireplaces installed
in a domestic setting in all EU countries except Austria, Denmark,
Finland, Greece, Portugal and Spain.
Features:
- Manual control will always remain possible.
- The remote control is a radio frequency type and has been approved
internationally.
- The remote control generates a unique safety code every time you
activate the transmitter, its similar to those used in a car.
- The remote control is easy to install retrospectively.
5.3.1 Installati n rem te c ntr l
1. Connect the mains adapter to the receiver box. The adapter is set
to the correct voltage in the factory 4.5V.
2. Slide the receiver box into the holder.
fig. 11
5.2 C nnecti n nt an existing chimney (c ntinuing)
7. Fix the sealing plate air tight into the builders opening (use the
isolation rope from the chimney connection set to make the plate
air tight .
8. Slide the cut off outside pipe (E into the sealing plate. Slide this
pipe so far that you will have enough space later on for
assembling the liner.
9. Install the appliance.
10. Connect the flexible stainless steel liner onto the appliance using
the cut off 100 mm inner pipe (F as adapter.
11. If the distance from the flue outlet to the sealing plate is bigger
then 300 mm, you have to use a concentric pipe first.
12. Slide the outside pipe onto the appliance or concentric extension
so that you have a air tight connection.

27
UK/IRL
26
UK/IRL
6. COMMISSIONING (functi nal checks)
6.1. Check pil t igniti n
1. Push in and turn the control knob (A from {anticlockwise to
the setting (small flame . You will hear a tick meaning there is
ignition. Hold the knob in and wait for a few seconds while the air
is purged.
2. Bring the knob back in the start position and turn the knob several
times to the position. Check that the pilot has lit.
3. Continue to hold in the control knob for a further ten seconds to
ensure that the pilot flame is stable.
4. Release the knob. The pilot should remain alight.
6.2 Functi nal burner check
1. Turn knob (B to max. clockwise.
2. Turn the knob (A more anticlockwise to the position (large
flame . Now it is possible to light the main burner.
3. Turn knob B anticlockwise to max. The main burner should light.
Check for gas soundness at all joints with leak detection floud!
4. Check the ignition of the main burner on low and high setting.
5. Turn knob B clockwise till {. The main burner is off.
6. Turn the knob A to {. The pilot should go out.
3. Connect the wires to the gas valve (see fig. 12 .
4. Check that there are batteries in the transmitter.
See "Replacing batteries", see chapter 10.4.4.
5. Set the on/off switch on the receiver to "on".
Setting the right transmissi n c de
The receiver has to learn the code from the transmitter, which is already done at the
factory. However the code disappears if the receiver is disconnected from the mains for a
longer period, or when you use the transmitter out of the range of the receiver for more
then 15 times. The code then doesn’t match the code in the receiver.
1. Push the "mod" button on the receiver and hold it for 3 seconds.
2. The green control lamp will light up and stay on. Repeat this step
if it doesn't.
3. Push a button on the remote control. The control lamp on the
receiver should now go out.
4. Again push a button on the remote control. The lamp starts
flashing and will switch off eventually.
5. The receiver now recognizes the remote control. The remote
control now functions.
6. Check if you can hear a sound and the motor runs when you
push a button on the remote control.
fig. 12
AB
fig. 13

29
UK/IRL
28
UK/IRL
7. HANDING OVER
(final check and cust mer briefing)
77..11Instruct the customer on the full operation of the appliance.
77..22..11Advise the customer how to clean the appliance including the
glass.
77..22..22Instruct the customer on the operation of the remote control,
including replacement of batteries and how to set the right
transmissions code.
77..22..33Hand over these instructions including the user guide to the
consumer.
77..22..44Recommend that the appliance should be serviced by a
competent person at least once a year.
6.3 Functi nal balanced flue check
1. Set the appliance on max. input.
2. Verify the flame picture, this means no flames against the
window, the flame have to come besides the logs, if not check
the log layout.
3. Check if the flames are yellow after 10 minutes of operation. If
you still have a blue flame or the appliance goes out check:
- If the flue pipes are fitted correctly (no leakage .
- If the wall mounted terminal is placed with the correct side up.
- If the correct flue restrictor is installed.
6.4 Check reference pressure
The appliance is preset to give the correct heat input.
No further adjustment is necessary. Fit a pressure gauge at the test
point D to check the burner pressure.
The pressure should be checked with the appliance alight and at max
input.
The ccoollddsetting pressure should be as shown at the technical data
page 36.
After checking the pressure, turn off the appliance. Remove the
pressure gauge and close the sealing screw. Re-light the appliance.
Turn to max. input and test around the test point D for gas
soundness using a suitable leak detection fluid.
C D
DC
AB
BA
fig. 14

UK/IRL
31
UK/IRL
30
8. SERVICING
To ensure safe, efficient operation of the appliance, it is necessary to
carry out routine servicing at regular intervals.
It is recommended, that the fire is inspected/serviced by a competent
person at least once a year.
IImmppoorrttaanntt
TTuurrnn ooffff tthhee ggaass ssuuppppllyy bbeeffoorree ccoommmmeenncciinngg aannyy sseerrvviicciinngg.. AAllwwaayyss tteesstt
ffoorr ggaass ssoouunnddnneessss aafftteerr rreeffiittttiinngg tthhee aapppplliiaannccee.
The pilot and flame sensing device fitted to this fire is also a safety
device. If for any reason any part of the pilot assembly is to be
replaced the entire assembly including the pilot burner,
thermocouple, electrode and injector must be exchanged complete for
a pilot assembly from the original manufacturer only.
8.1 R utine annual servicing
1. Clean (if necessary :
- the pilot system;
- the burner;
- the combustion chamber;
- the glass.
2. Check the log lay and replace the embers (if applicable .
3. Do the functional test as described at page 27.
4. Check the flue system and terminal on damage and soundness
(visual inspection .
NNoottee
The logs contain Refractory Ceramic Fibre which when cut or broken
open can be an irritant to skin and the respiratory tract. Always wear
gloves, do not blow dust into air and clean up using a vacuum
cleaner equipped with a HEPA filter. Never place extra elements of
any kind into the combustion chamber. To guarantee good
combustion, the log set may only be installed in the way specified by
Faber International. Any other arrangement can lead to soot on logs
or window. Do not use the fire with broken or missing logs.
8.1.1 Cleaning the glass
Depending on the intensity of use, you can get a deposit on the
glass. This can be removed with a special ceramic glass cleaner
(ceramic cook-top cleaner as follows:
1. Remove the door or front as described at 4.2.
2. Clean the glass. Handle the glass with clean hands, wear gloves if
possible.
3. To fit the glass, proceed in reverse order. Make sure that the log
set has been installed correctly before fixing the glass.
AAtttteennttiioonn::
Before placing the glass: check the glass sealing rope is in good
condition and makes an effective seal. Be sure that there are no
fingerprints on the glass. It is not possible to remove those prints
after you burn the appliance for a while (they are burnt in . Place
the glass in front of the appliance and fix the glass frame or use the
glass clamps.
8.1.2 Cleaning the c mbusti n chamber and burner
You can clean the combustion chamber with a vacuum cleaner
eexxcclluuddiinngg tthhee bbuurrnneerr ssuurrffaaccee..
If the burner is visibly damaged, this can affect the distribution of
the flame, if so then replace the burner.

UK/IRL
33
UK/IRL
32
8.1.3 Burner tray assembly
1. Remove the front, glass and log holder (if applicable .
2. Break the gas supply at the control valve.
3. Unscrew the burner assembly (8 screws and take them out of
the combustion chamber.
AAtttteennttiioonn!!A sharp or heavy object can damage the burner.
A The pilot and flame sensing device
B Injector (Spectra at burner inlet
C Burner tray
D Burner fixing bracket
E Receiver remote control
F Gas control
8.1.4 PPiilloott//tthheerrmmooccoouuppllee aasssseemmbbllyy
This is not a serviceable item, both thermocouple and pilot should
be replaced together.
AB
C
D
E
F
fig 15 burner Silva
C
A
E
FD
fig. 16 burner Spectra
- Remove the burner tray (see 8.1.3 .
- Remove the lead from the pilot spark igniter.
- Break the gas pipe connection to the pilot.
- Unscrew thermocouple nut from the rear of the gas control.
- Unscrew pilot assembly from the burner tray (2 screws .
- Replace and re-assemble in reverse order.
8.1.5 BBuurrnneerr aanndd iinnjjeeccttoorr SSiillvvaa
- Remove the burner tray (see 8.1.3 .
- Unscrew the burner from the burner tray (4 screws .
- Remove the burner.
- Unscrew the injector.
- Replace and re-assemble in reverse order.
8.1.6 BBuurrnneerr aanndd iinnjjeeccttoorr CCaaddrraa,, SSppeeccttrraa,, PPrriissmmaa,, PPaannoorraammaa
- Remove the burner tray (see 8.1.3 .
- Unscrew the burner from the burner tray (4 screws .
- Break the gas connection at the burner inlet.
- Unscrew heat-shield from the burner tray.
- Unscrew elbow connection from the burner inlet.
- Unscrew the burner from the burner tray and remove the burner.
- Unscrew the injector from the burner inlet.
- Replace and re-assemble in reverse order.
A Governor
B Adjusting screw pilot flame
C Inlet pressure test point
D Burner pressure test point
C D
DC
AB
BA
fig. 17 fig. 18

UK/IRL
35
UK/IRL
34
SSppeeccttrraaCCaaddrraaPPaannoorraammaaPPrriissmmaaSSiillvvaa
Description Company Company Company Company Company
part part part part part
Surround antracite A9264849 O9045049 O9052049 O9025052
Glas 04504600 04506900 04506000 04505900 O4508000
Injector assembly 20900020 20900020 20900020 20900027 13382180
Burner 20817300 20825500 20825500 20825500 20817200
Log set 20773200 20774500 20752500 20752500 20771100
Rear log 20759500 20759500 20759500 20759500
Rear log holder 11566301 11566301 11560400 11560400
Receiver 20604000 20604000 20604000 20604000 20604000
Remote control 20603900 20603900 20603900 20603900 20603900
Adapter 20900142 20900142 20900142 20900142 20900142
Gas control 37003089 37003089 37003089 37003089 37003089
Motor (remote control 37003086 37003086 37003086 37003086 37003086
Pilot assembly 37001042 37001042 37001039 37001039 37001042
Embers 20900019 20900019 20900019 20900019 20900019
Heat resisting paint spray
for combustion chamber 09000008 09000008 09000008 09000008 09000008
Set of glass clips 20900008 20900008 20900008 20900008 20900008
Touch Latch assembly 28103900
8.1.7 CCoommbbuussttiioonn tteesstt
A BS7967 combustion analysis check should be carried out using an
analyser to BS7927 positioned in the flue outlet.
A Ratio of CO/CO2 should be less than 0.01 within 30 minutes.
(100ppm CO per 1% CO2 .
A reading of CO in the room centre should give a rise of less than
9ppm over ambient, peak reading.
INDEX 1 LIST OF SPARE PARTS

UK/IRL
37
UK/IRL
36
CCoouunnttrryyUUKK//IIRRLLUUKK//IIRRLLUUKK//IIRRLLUUKK//IIRRLL
CCaatteeggoorryyI22HHII22HHII22HHII22HH
AApppplliiaanncceeSSppeeccttrraa //SSppeeccttrraa PPaannoorraammaaPPrriissmmaaSSiillvvaaCCaaddrraa
MMooddeell ttyyppeeCC1111 // CC3311CC1111 // CC3311CC1111 // CC3311CC1111 // CC3311
Type of gas G20 G20 G20 G20
Heat input Hi kW 6.1 5.6 5.5 6.1
Efficiency class 2 2 2 2
NOX class 4 4 4 4
Inlet pressure mbar 20 20 20 20
Gas rate (15° C / 1013 mbar m3/h 0.64 0.57 0.57 0.63
Reference burner pressure mbar 10 18.5 19 10.5
Injector size mm 2.2 1.85 1.8 2.2
Reduced input restrictor mm 1.6 1.6 1.6 1.6
Pilot assembly
Type Oxy-pilot Oxy-pilot Oxy-pilot Oxy-pilot
Code 9709M NG 9709M NG 9709M NG 9709M NG
Flue system
MV size 100-150 100-150 100-150 100-150
Preinstalled flue restrictor mm N.A. N.A. 45 N.A.
Cas control GV36-C5AODHC68M GV36-C5AODHC68M GV36-C5AODHC68M GV36-C5AODHC68M
Remote control
Adapter 230 VAC/50Hz/5VA 230 VAC/50Hz/5VA 230 VAC/50Hz/5VA 230 VAC/50Hz/5VA
Voltage adapter 4.5V 4.5V 4.5V 4.5V
Batteries remote control 2 x LR03 1.5V Alkaline long life 2x LR03 1.5V Alkaline long life 2 x LR03 1.5V Alkaline long life 2 x LR03 1.5V Alkaline long life
Gas connection 8 mm nut and olive 8 mm nut and olive 8 mm nut and olive 8 mm nut and olive
Dimensions: see table 1
