Falcon DOMINATORPLUS E3512 User guide

E3512 and E3532
DOMINATORPLUS Grills
INSTALLATION and
SERVICING INSTRUCTIONS
IMPORTANT
The installer must ensure that the installation of the appliance is in conformity with these instructions
and National Regulations in force at the time of installation. Particular attention MUST be paid to –
BS7671 IEE Wiring Regulations
Health and Safety At Work Act
Electricity at Work Regulations
Fire Precautions Act
WARNING
BEFORE ATTEMPTING ANY MAINTENANCE, ISOLATE THE APPLIANCE AT THE MAINS
ISOLATING SWITCH AND TAKE STEPS TO ENSURE THAT IT CANNOT BE INADVERTENTLY
SWITCHED ON.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED BEFORE INSTALLING
AND COMMISSIONING THIS APPLIANCE. FAILURE TO COMPLY WITH THE SPECIFIED
PROCEDURES MAY RESULT IN DAMAGE & NEED FOR A SERVICE CALL.
On completion of the installation these instructions should be left with the Engineer-in-Charge for
reference during servicing. In addition, the Users Instructions should be handed to the User, having
had a demonstration of the operation and cleaning of the appliance.
PREVENTATIVE MAINTENANCE CONTRACT
In order to obtain maximum performance from this unit we would recommend that a maintenance
contract be arranged with SERVICELINE. Visits may then be made at agreed intervals to carry out
adjustments and repairs. A quotation will be given upon request to the contact numbers below.
WEEE Directive Registration No. WEE/DC0059TT/PRO
At end of unit life, dispose of appliance and any replacement
parts in a safe manner, via a licenced waste handler.
Units are designed to be dismantled easily and recycling of all
material is encouraged whenever practicable.
Falcon Foodservice Equipment
HEAD OFFICE AND WORKS
Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
SERVICELINE CONTACT
Phone: [phone] Fax: [phone]
T100788 Ref.1

IMPORTANT INFORMATION
Warranty Policy Shortlist
Warranty does not cover :-
•Correcting faults caused by incorrect installation of a product.
•Where an engineer cannot gain access to a site or a product.
•Repeat commission visits.
•Replacement of any parts where damage has been caused by misuse.
•Engineer waiting time will be chargeable.
•Routine maintenance and cleaning.
•Gas conversions i.e. Natural to Propane gas.
•Descaling of water products and cleaning of water sensors where softeners/ conditioners are not fitted,
or are fitted and not maintained.
•Blocked drains
•Independent steam generation systems.
•Gas, water and electrical supply external to unit.
•Light bulbs
•Re-installing vacuum in kettle jackets.
•Replacement of grill burner ceramics when damage has been clearly caused by misuse.
•Where an engineer finds no fault with a product that has been reported faulty.
•Re-setting or adjustment of thermostats when unit is operating to specification.
•Cleaning and unblocking of fryer filter systems due to customer misuse.
•Lubrication and adjustment of door catches.
•Cleaning and Maintenance
• Cleaning of burner jets
• Poor combustion caused by lack of cleaning
• Lubrication of moving parts
• Lubrication of gas cocks
• Cleaning/adjustment of pilots
• Correction of gas pressure to appliance.
• Renewing of electric cable ends.
• Replacement of fuses
• Corrosion caused by use of chemical cleaners.

1.3 ELECTRICAL SUPPLY
Warning
THIS APPLIANCE MUST BE EARTHED
A cable entry suitable for 20mm conduit is situated in the
unit rear at the RH side. To gain access to the terminals,
the RH side panel must be removed.
Mains connection must be made via a suitably rated
isolating switch with a contact separation of at least 3mm
on all poles. The use of heat resistant cable is
recommended. Wiring should be in accordance with
current IEE Wiring Regulations.
Particular attention must be paid to providing adequate
and effective earthing using the earth terminal provided.
1.4 ELECTRICAL LOADINGS
The electrical loading is stated on unit data plate. This is
located on RH outer side panel.
SECTION 2 - ASSEMBLY
2.1 ASSEMBLY
Note
Mounting accessories are available. Contact Falcon
Sales, an equipment distributor or place of purchase.
a) Unpack unit and place it in position using separate
mounting accessories.
b) Mounting accessories should be assembled according
to separate instructions provided.
c) Check the following listed parts are included:-
Brander plate
Brander drip trough
Grid shelf
Grid shelf handles
Drip tray
d) The grid shelf handles are supplied separately and
must be screwed on to grid shelf arms.
1.1 MODEL NUMBERS, NETT WEIGHTS
and DIMENSIONS
1.2 SITING
Installation should be made in accordance with local
and/or national regulations applying at the time and a
competent installer must be employed. There should be
a clearance of 200mm from any wall or object liable to
damage from overheating and 75mm clearance should
be left from any wall to allow removal of the side panels
for maintenance.
In the event of a requirement to position this appliance in
close proximity to a wall, partion, kitchen furniture or
decorative finish, etc. it is recommended that these be
constructed of a non-combustible material. If this is not
possible then these surfaces require to be clad in a
non-combustible, heat insulating material. Close
attention must be paid to fire prevention regulations.
The grill should be installed level and in a well lit position
with adequate ventilation.
Mounting
The grill can be mounted upon:
Floorstand.
Legs: 300mm high.
Wall bracket.
Note
E3532 model is not compatible with old-style plate
shelves.
Model Width
(mm)
Depth
(mm)
Height
(mm)
Weight
(kg)
E3512 Grill 730 560 505 55
E3532 Grill 785 355 350 30
SECTION 1 - INSTALLATION
UNLESS OTHERWISE STATED, PARTS WHICH HAVE BEEN PROTECTED BY THE MANUFACTURER
ARE NOT TO BE ADJUSTED BY THE INSTALLER.

3.4 RELAY
3.4.1 E3512/E3522 Grills - To Replace
Undo RH side panel fixings and remove panel.
Undo fixings that secure relay to bracket. Remove relay.
Note wire connections/locations and transfer to
corresponding positions on replacement relay.
Secure mounting bracket and replace panels in reverse
order.
3.4.2 E3532 Grill - To Replace
Undo RH outer side panel fixings to remove panel.
Relay can be removed from bracket by undoing fixings.
Note wire connections/locations and transfer wires to
corresponding positions on replacement relay.
Secure to mounting bracket and replace panels in
reverse order.
SECTION 4 - SPARES
and ACCESSORIES
When ordering spare parts, always quote appliance type
and serial number.
This information will be found on data badge attached to
base plate.
SECTION 3 - SERVICING
Before attempting any maintenance, isolate unit at main
switch. Take steps to ensure that it cannot inadvertently
be switched on.
3.1 MAINS INDICATOR LAMP
An indicator neon is located on the control panel and
must be replaced if failure occurs. Undo bottom fixing and
remove panel.
Remove 2 lamp connections. Connect replacement neon
and replace control panel.
3.2 ELEMENTS
3.2.1 E3512 Model
This are fitted with a number of identical elements that
may be replaced individually. To replace a faulty element,
proceed as follows:
Undo back panel fixings and remove panel.
Remove fixings from both sides of element control
bracket, gaining access from front of unit.
Undo fixing that secures element to rear inner panel and
withdraw element.
Fit replacement element and replace additional parts in
reverse order.
3.2.2 E3532 Model
This model is fitted with a single element. To replace a
faulty element, proceed as follows:
Undo fixings on control panel underside and remove.
Remove fixings at top panel rear, front and sides to
remove top panel.
Undo fixings on top front facia and remove.
Remove heat shield above elements. Remove element
connections at terminal posts. Undo fixing that secures
element to RH side panel and withdraw element.
Fit replacement element and replace panels which have
been removed to gain access.
3.3 ENERGY REGULATOR
Remove knob and control panel. Undo screws that
secure regulator to control panel and remove regulator.
Note wire connections/locations and transfer to
corresponding position on control. Fit new control to panel
and replace panel.

E3532 CIRCUIT DIAGRAM
E3512 CIRCUIT DIAGRAM
