OPERATING MANUAL
KOMPAKTOMAT
K500PS / K600PS
K700PS / K800PS
K1000PS
Edition: 1 | effective from: 1. 7. 2018

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
2 │56
Dear customer,
Semi-carried machines KOMPAKTOMAT are quality products of Farmet a.s. Česká Skalice.
You can fully utilise the advantages of your machine after thoroughly studying the operating manual.
The serial number of the machine is punched on the production label and written in the operating manual
(see MACHINE SPECIFICATION). This machine serial number must be stated whenever ordering spare parts for
possible repairs. The production label is located on the middle frame near the tow bar.
Use only original spare parts for these machines according to the Spare parts catalogue officially issued by the
manufacturer, Farmet a.s. Ceska Skalice.
POSSIBILITIES OF USE OF YOUR MACHINE
KOMPAKTOMAT je is intended for presowing preparation of soil as a subsequent operation after
ploughing or stubble breaking with incorporated plant residues.
MACHINE SPECIFICATION:
TYPE OF MACHINE KOMPAKTOMAT
SERIAL NUMBER OF MACHINE
USED EQUIPMENT:
...................................................................................................................................................................................
...................................................................................................................................................................................
...................................................................................................................................................................................
...................................................................................................................................................................................
...................................................................................................................................................................................

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
3 │56
CONTENTS
BASIC DESCRIPTION OF THE KOMPAKTOMAT MACHINE........................................................................ 4
Machine limit parameters....................................................................................................................... 7
Safety statement..................................................................................................................................... 7
A. GENERAL INSTRUCTIONS FOR USE................................................................................................. 7
Protective tools ....................................................................................................................................... 8
B. MACHINE TRANSPORT USING TRANSPORT MEANS....................................................................... 8
C. MACHINE HANDLING USING LIFTING EQUIPMENT........................................................................ 9
D. WORK SAFETY LABELS..................................................................................................................... 9
1. DESCRIPTION ................................................................................................................................ 15
2. AGREGATION TO A TRACTOR ....................................................................................................... 16
3. WORKING PARTS .......................................................................................................................... 16
4. MACHINE ASSEMBLY AT THE CUSTOMER .................................................................................... 19
5. COMMISSIONING.......................................................................................................................... 19
5.1 Agregation to a tractor.......................................................................................................... 20
5.2 Hydraulic of the machine ...................................................................................................... 21
5.3 Folding and unfolding the machine....................................................................................... 26
5.3.1 Putting the machine into transport position................................................................. 26
5.3.2 Putting the machine into the working position ............................................................ 28
6. MACHINE TRANSPORT ON ROADS ............................................................................................... 31
7. ADJUSTING THE WORKING PARTS OF THE MACHINE .................................................................. 32
7.1 Adjusting the position and depth of the track cultivators .................................................... 32
7.2 Adjusting the spring-mounted front leveller......................................................................... 33
7.3 Adjusting the components of working rollers....................................................................... 35
7.3.1 RR- ring rollers............................................................................................................... 35
7.4 Adjusting the depth of the share section.............................................................................. 35
7.4.1 MCD- mechanical depth setting.................................................................................... 36
7.4.2 HD- hydraulic depth setting .......................................................................................... 36
7.5 Adjusting the leveller height behind shares.......................................................................... 37
7.6 Setting the finishing section features.................................................................................... 37
7.6.1 Setting the angle of the rear leveller............................................................................. 37
7.6.2 Setting the pressure of the finishing roller.................................................................... 38
8. Side frame folding drawbars......................................................................................................... 39
8.1 Adjusting the folding drawbar spring -Lp.............................................................................. 39
8.2 Adjusting the lenght of the drawbar -Lt................................................................................ 40
9. AGGREGATION WITH OTHER EQUIPMENT................................................................................... 42
9.1 Transport position of the Kompaktomat three-point hitch arms ......................................... 43
9.2 Working position of the Kompaktomat three-point hitch arms ........................................... 44
9.3 Aggregation with pneumatic drill machine........................................................................... 44
10. MAINTENANCE AND REPAIRS OF THE MACHINE ...................................................................... 46
10.1 Lubrication plan for the machine...................................................................................... 48
10.2 Replacement of worn shares............................................................................................. 49
10.2.1 Replacement of worn shares on the central frame ...................................................... 49
10.2.2 Replacement of worn shares of the side frame ............................................................ 49
10.3 Specification of spare parts for axles ................................................................................ 49
11. MACHINE STORAGE –LONG-TERM MACHINE SHUTDOWN: .................................................... 50
12. PROTECTION OF ENVIRONMENT............................................................................................... 50
13. MACHINE DISPOSAL AFTER SERVICE LIFE EXPIRY...................................................................... 50
14. SERVICING AND WARRANTY CONDITIONS................................................................................ 51
CE Certificate of Conformity .................................................................................................... 52

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
4 │56
BASIC DESCRIPTION OF THE KOMPAKTOMAT MACHINE
The modular concept of the Kompaktomat machine design allows for variable use of its various alternatives.
The machine can be attached to the tractor either via the rear arms of the three-point hitch or via the fixed
bottom hitch. Furthermore, to improve the function in particular conditions, it is possible to change the
working parts of the machine such as the type and number of track cultivators, type of front levellers, type of
front rollers, type of share sections and type of rear rollers. To increase productivity, Kompaktomat machines
can be additionally equipped with hydraulic control of the front leveller position and share depth setting.
The standard version of the semi-carried machine consists of the following parts:
-Carrier bar for connecting to the three-point hitch of the pulling vehicle
-Towing forks with adjustable tractor track cultivators
-Supporting frames of the machine
-The machine is standardly equipped with a mechanical drawbar that secures the side frames in the
transport position
-The machine is standardly equipped with front and rear safety plates with oblique red-and-white hatching
and with taillights and a reflective plate for vehicle marking according to EHK No. 69
Standard Version Working parts
1)
Three-point hitch carrier bar 3
2)
Automatically spring-loaded track cultivators with sweeps
3)
Automatically spring-loaded front levellers with mechanical height adjustment
4)
Front 12-piece slatted roller 400mm
5)
Sweep section on formed springs with a levelling bar and mechanically controlled depth
6)
Rear cross-kill roller with a cleaner
7)
Rear leveller with the option of mechanical adjustment of the leveller angle
1
2
3
4
5
6
7

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
5 │56
TECHNICAL PARAMETERS
K500PS
K600PS
K700PS
K800PS
Working width (mm)
5000
6000
7000
8000
Transport width (mm)
3000
Transport height (mm)
2400
2900
3400
3900
Total length of the machine (mm)
6105
Working depth (mm)
0-100
Number of shares AL/CF/AP
23/49/23
27/59/24
31/69/31
35/77/32
Working performance (ha/hour)
3-5
3,5-6
4,5-7
5,5-8
Working speed (km/hour)
8-12
Maximum transport speed (km/hour)
20
Maximum slope accessibility (°)
6
Tyre dimensions (type)
19.0/45-17 14PR
Tyre pressure (kPa)
400
Max. weight of the machine (standard
version)
4025
4360
4960
5345
Oil filling HLP 46 DIN51524-2 (l)
10
12
Requirement for the engine power of
the tractor (kW)*
120
130
150
160
Requirement for tractor aggregation
STANDARD EQUIPMENT
Spacing of the bottom hitch joints
(as measured on the joint axes)
1010 ± 1,5 mm
of the bottom hitch joint holes
for the hitch pins of the machine
37,5mm
ABOVE-STANDARD EQUIPMENT
Fixed bottom hitch height
600 ± 30 mm
ABOVE-STANDARD EQUIPMENT
Fixed bottom hitch aggregation
mechanism
Pin 50mm
Pin 70mm
Ball K80
Requirement for the hydraulic system
of the tractor
STANDARD EQUIPMENT
- Side frame folding circuit
Pressure in the circuit 200bar, 2
sockets for snap coupling
ISO 12.5
STANDARD EQUIPMENT
- Axle lifting circuit
Pressure in the circuit 200bar, 2
sockets for snap coupling
ISO 12.5
ABOVE-STANDARD EQUIPMENT
- Front leveller control circuit
Pressure in the circuit 200bar, 2
sockets for snap coupling
ISO 12.5
ABOVE-STANDARD EQUIPMENT
- Share depth control circuit
Pressure in the circuit 200bar, 2
sockets for snap coupling
ISO 12.5
ABOVE-STANDARD EQUIPMENT
- Drill machine drive fan circuit
PRESSURE BRANCH –circuit
with oil supply priority
Pressure in the circuit 130bar, 1
socket for snap coupling
ISO 12.5,
Maximum flow rate 40 l/min
WASTE BRANCH –free waste
into the oil tank
Pressure in the circuit 5bar, 1
socket for snap coupling ISO 20
Requirement for the air system of the
tractor
STANDARD EQUIPMENT
- Machine axle braking circuit
Pressure in the circuit at least
6bar –max. 15bar,
2 coupling heads of single-circuit
two-hose brakes
* These values are only as recommended tractive equipment. The actual tractive force may substantially differ according to the processing
depth, soil conditions, slope of the land, wear and tear of working parts and their adjustment.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
6 │56
TECHNICAL PARAMETERS
K1000PS
Working width (mm)
9850
Transport width (mm)
3000
Transport height (mm)
4000
Total length of the machine (mm)
6660
Working depth (mm)
0-100
Number of shares AL/CF/AP
43/91/38
Working performance (ha/hour)
8,5-10
Working speed (km/hour)
8-12
Maximum transport speed (km/hour)
20
Maximum slope accessibility (°)
6
Tyre dimensions (type)
19.0/45-17 14PR
Tyre pressure (kPa)
400
Max. weight of the machine (standard
version)
6920
Oil filling HLP 46 DIN51524-2 (l)
16
Requirement for the engine power of the
tractor (kW)*
180
Requirement for tractor aggregation
STANDARD EQUIPMENT
Spacing of the bottom hitch joints
(as measured on the joint axes)
1010 ± 1,5 mm
of the bottom hitch joint holes
for the hitch pins of the machine
37,5mm
ABOVE-STANDARD EQUIPMENT
Fixed bottom hitch height
600 ± 30 mm
ABOVE-STANDARD EQUIPMENT
Fixed bottom hitch aggregation
mechanism
Pin 50mm
Pin 70mm
Ball K80
Requirement for the hydraulic system of the
tractor
STANDARD EQUIPMENT
- Side frame folding circuit
Pressure in the circuit 200bar,
2 sockets for snap coupling
ISO 12.5
STANDARD EQUIPMENT
- Axle lifting circuit
Pressure in the circuit 200bar,
2 sockets for snap coupling
ISO 12.5
ABOVE-STANDARD EQUIPMENT
- Front leveller control circuit
Pressure in the circuit 200bar,
2 sockets for snap coupling
ISO 12.5
ABOVE-STANDARD EQUIPMENT
- Share depth control circuit
Pressure in the circuit 200bar,
2 sockets for snap coupling
ISO 12.5
Requirement for the air system of the
tractor
STANDARD EQUIPMENT
- Machine axle braking circuit
Pressure in the circuit at least
6bar –max. 15bar,
2 coupling heads of single-
circuit two-hose brakes
* These values are only as recommended tractive equipment. The actual tractive force may substantially differ according to the processing
depth, soil conditions, slope of the land, wear and tear of working parts and their adjustment.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
7 │56
MACHINE LIMIT PARAMETERS
(x) The machine is to be used for presowing preparation of soil after ploughing or stubble breaking with
working depth from 0 mm to 100 mm for soil cultivation in agriculture. Other uses exceeding the
determined purpose is forbidden.
(x) The machine is only operated by one person –the tractor driver.
(x) Machine operator must not use the machine in a different way, especially:
(x) Transport of persons and animals on the machine structure,
(x) Transport of burdens on the machine structure,
(x) Aggregation of the machine with another towing equipment than stated in Chapter „5.1./p.20“.
SAFETY STATEMENT
A. GENERAL INSTRUCTIONS FOR USE
A.1 (x) The machine is made in accordance with the latest equipment state and approved safety regulations.
However, dangers of user or third person injury or machine damage or creation of other material
damage may arise during use.
A.2 (xx) Use the machine only in a technically sound condition, in accordance with its purpose, aware of
possible dangers, and while adhering to the safety instructions of this operating manual!
The Manufacturer is not liable for damages caused by the use of the machine that is in contradiction
with the limit parameters of the machine (p. 4) and with the instructions for the use of the machine
(Chapter A and 3). The User bears the risk.
Immediately remove especially the failures that may negatively affect safety!
A.3 (7) Machine operation may be performed by a person authorised by the operator under these
conditions:
(8) It must own a valid driver's licence of the corresponding category,
(9) It must be demonstrably familiarised with the safety regulations for work with the machine and
must practically master the machine operation,
(10) The machine may not be operated by juveniles,
(11) It must know the meaning of the safety signs located on the machine. Their respecting is
important for safe and reliable machine operation.
A.4 (12) Maintenance and servicing repairs on the machine may only be performed by a person:
(13) Authorised by the operator,
(14) Educated in the machinery field with knowledge of repairs of similar machines,
(15) Demonstrably familiarised with safety regulations for work with the machine,
(16) During a repair of a machine connected to a tractor, it must own a driver's licence of the
corresponding category.
A.5 (17) Machine operator must secure the safety of other persons when working with the machine or
transporting the machine.
This warning sign warns about an immediate dangerous situation
ending with death or severe injury.
This warning sign warns about a dangerous situation ending with
death or severe injury.
This warning sign warns about a situation that may end with a smaller
or slight injury. It also warns about dangerous actions related to the
activity that could lead to an injury.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
8 │56
A.6 (18) During machine work in the field or during transport, the operator must control the machine from the
tractor's cabin.
A.7 (19) The operator may enter the machine structure only with the machine at rest and blocked against
movement, namely only for these reasons:
(20) Adjustment of the machine working parts,
(21) Repair and maintenance of the machine,
(29) Release and securing of spherical valves of the axle,
(27) Securing of spherical valves of the axle before folding the side frames,
(28) Adjustment of the working parts of the machine after unfolding the side frames.
A.8 (xxx) When stepping on the machine, do not step on tyres of the axles or other rotary parts. Those may
turn and you can cause very serious injuries by the subsequent fall.
A.9 (22) Any changes or modifications of machine may be performed only with written consent of the
manufacturer. For possible damage arisen due to ignoring this instruction, the producer bears no
responsibility. The machine must be maintained equipped with prescribed accessories and equipment
including safety marking. All warning and safety signs must be legible and in their places. In case of
damage or loss, these signs must be immediately renewed.
A.10 (23) The operator must have the Operating Manual with the work safety requirements available at any
time when working with the machine.
A.11 (24) The operator must not consume alcohol, medicines, narcotic and hallucinogenic substances that
decrease his attention and coordination capabilities while using the machine. If the operator must use
medicines prescribed by a physician or uses freely sold medicines, he must be informed by a physician,
whether he is capable of responsible and safe operation of the machine under these circumstances
PROTECTIVE TOOLS
For the operation and maintenance use:
Tight clothes
Protective gloves and goggles for protection against dust and sharp parts of the machine
B. MACHINE TRANSPORT USING TRANSPORT MEANS
B.1 (1) The transport means designed for machine transport must have the load capacity minimally identical
with the weight of the transported machine. The total weight of the machine is stated on the production
label.
B.2 (2) The dimensions of the transported machine including the transport means must comply with the valid
regulations for road traffic (decrees, laws).
B.3 (3) The transported machine must be always fastened to the transport means so that its spontaneous
loosening could not happen.
B.4 (4) The carrier is responsible for damage caused by the loosening of incorrectly or insufficiently fastened
machine to the transport means.
B.5 (xx) The carrier shall observe the instructions of the responsible employees of Farmet in charge of loading
concerning proper binding and securing of the machine on the transportation vehicle, particularly with
regard to the potential damage of the machine to be transported.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
9 │56
C. MACHINE HANDLING USING LIFTING EQUIPMENT
C.1 (1) The lifting equipment and tying means designed for handling of the machine must have their load
capacity at least identical with the weight of the handled machine.
C.2 (2) Machine fastening for handling may only be performed in places designed for that and marked with
self-adhesive labels showing the "chain" symbol.
C.3 (3) After fastening (suspending) at designated points, it is forbidden to move in the space of possible
reach of the handled machine.
C.4 Table with approximate weights of the parts according to the loading alternative
K500PS
K600PS
K700PS
K800PS
K1000PS
TOWING FORK
(kg)
220
220
220
220
220
CENTRAL FRAME
(kg)
2100
2100
2300
2300
2400
FORK+CENTRAL FRAME
(kg)
2320
2320
2520
2520
2620
RIGHT SIDE FRAME
(kg)
900
1100
1500
1700
1100
LEFT SIDE FRAME
(kg)
900
1100
1500
1700
1100
EXTERIOR RIGHT SIDE FRAME
(kg)
-
-
-
-
1000
EXTERIOR LEFT SIDE FRAME
(kg)
-
-
-
-
1000
AXLE
(kg)
350
350
500
500
500
MACHINE
(kg)
4150
4600
5100
5500
7000
D. WORK SAFETY LABELS
Warning safety labels serve for operator protection.
THE FOLLOWING APPLIES GENERALLY:
D.1 Strictly observe the warning safety labels.
D.2 All safety instructions also apply to other users.
D.3 The operator shall ensure completeness and readability of labels on the machine, i.e. the operator shall
replace any damaged labels with new ones.
D.4 The appearance and exact meaning of the warning safety labels on the machine are specified in the
following table.
WARNING SAFETY LABELS
TEXT TO THE LABELS
POSITION ON THE
MACHINE
Before handling the machine, carefully read the
operating manual.
Observe the instructions and safety regulations
for machine operation during use.
P 1 H
When connecting or disconnecting, do not step
between the tractor and the machine, also do
not enter this space, if the tractor and the
machine are not at rest and the engine is not
turned off.
P 2 H
Stay outside the reach of the tractor -
agricultural machine set, if the tractor engine is
in operation.
P 6 H

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
10 │56
Před začátkem transportu stroje zajisti boční
rámy proti rozklopení a nápravu proti
nečekanému poklesu.
P 13 H
Secure the side frames against unfolding and the
axle against sudden fall prior to the
transportation of the machine.
P 20 H
When unfolding the side frames into the
transport position, do not reach into the area of
contact with the central frame.
P 37 H
Driving the machine and transportation on its
construction is strictly forbidden.
P 39 H
When working and transporting the machine,
maintain safe distance from the electric
appliances.
P 50 H
Stay outside the reach of the unsecured side
frames of the machine.
P 53 H
Do not approach the rotary parts of the machine
unless they are standing still, i.e. they are not
rotating.
P 100 H
It is strictly folding and unfolding the side frames
on slopes or inclined surfaces.
P 101 H
The shown positions of the handle and the
function of the hydraulic ball valve located on
the piston-rod.
The mechanical stops of the axle must be used
for K800PS and K1000PS in the transport
position. They keep the transport height below
4m.
When working in the field, switch the stops to
the working position.
m17807
D.5 The positions of the warning safety labels on the machine are shown in the following pictures.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
11 │56
K500PS, K600PS, K700PS, K800PS - Rear view
P37H
P53H
P37H
P53H
P39H
P50H
P39H
P50H
P1H
P2H
P6H
P101H
P101H, P13H
P101H, P13H
P20H
P20H
P13H
P1H
P1H

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
12 │56
K500PS, K600PS, K700PS, K800PS - Front view
P37H
P53H
P37H
P53H
P39H
P50H
P39H
P50H
P1H
P20H
P20H
K800PS
m17807

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
13 │56
K1000PS - Rear view
P37H
P53H
P37H
P53H
P37H
P53H
P37H
P53H
P1H
P2H
P6H
P101H
P39H
P50H
P39H
P50H
P39H
P50H
P39H
P50H
P101H, P13H
P101H, P13H
P20H
P20H
P20H
P20H

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
14 │56
K1000PS - Front view
P37H
P53H
P37H
P53H
P37H
P53H
P37H
P53H
P39H
P50H
P39H
P50H
P39H
P50H
P39H
P50H
P101H, P13H
P101H, P13H
P1H
K1000PS
m17807

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
15 │56
1. DESCRIPTION
Kompaktomat is structurally designed as a semi-carried folding machine aggregated behind a tractor. The
machine consists of a towing fork and supporting frames where the individual working parts are installed. The
modular design of the machine allows selecting various types of working parts so that the machine meets the
high demands of any soil conditions.
The basic version of the machine (see p. 4) combines seven soil-processing operations in a single pass.
The control for folding the side frames into the transport or working position is designed as a single
independent hydraulic circuit controlled by the driver in the tractor cabin.
The control of the axle in the transport or working position is designed as a single independent hydraulic
circuit controlled by the driver in the tractor cabin.
The Kompaktomat machines meet the regulations for road traffic = width up to 3m + height up to 4m.
The design of the Kompaktomat machine allows using a whole range of additional equipment to increase
productivity and efficiency.
A. HYDRAULIC LEVELLERS…the automatic front leveller position control system using an independent
hydraulic circuit controlled by the driver in the tractor cabin.
B. HYDRAULIC DEPTH…the automatic share depth control using an independent hydraulic circuit
controlled by the driver in the tractor cabin.
C. REAR THREE-POINT HITCH …the design of the rear three-point hitch to which it is possible to attach
other equipment for soil cultivation, or a pneumatic seed drill to Kompaktomat.
Track cultivator
with sweeps
Front leveller
Front bar roller
Sweep section
Levelling bar
Rear crumbling
roller
Rear finishing
leveller
3-point hitch
towing work 3

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
16 │56
2. AGREGATION TO A TRACTOR
TRACTOR ARM VERSION –T3; T4
Aggregation of the machine to the rear arms of the tractor in the
category TBZ (three-point hitch). You can choose pins for categories
TBZ3=ø36mm, TBZ4=ø50mm.
The standard version of the drawbar can be applied to tractors with
width up to 3,800mm with tyres or belts. For tractors with a width
exceeding 3,800mm, an extended version of the drawbar has to be
used.
HITCH VERSION –K80; C40; C50; C70
Aggregation of the machine to the fixed bottom hitch with a K80
ball or with a pulling loop with the diameter of 40mm, 50mm or
70mm.
This is offered as the optional equipment of the machine.
The standard version of the drawbar can be applied to tractors with
width up to 3,800mm with tyres or belts. For tractors with a width
exceeding 3,800mm, an extended version of the drawbar has to be
used.
3. WORKING PARTS
TRACK CULTIVATOR
CA –Track Cultivator with Sweep
Automatically released tractor track cultivator with a sweep. Suitable for
loose types of soil where there is no risk of formation of wet clods. Possibility
of mechanical depth setting up to 80mm. Possibility of setting the position
directly behind the tractor wheels.
CC –Track Cultivator with Chisel Share
Automatically released tractor track cultivator with a chisel share. Suitable
for heavier types of soil where there is no risk of formation of wet clods.
Possibility of mechanical depth setting up to 80mm. Possibility of setting the
position directly behind the tractor.
FRONT LEVELLERS
FL –Front Fixed Serrated Levelling Bar
Automatically released levelling bar with a serrated section. Massive
construction for precise levelling of coarse furrows.
Possibility to adjust the height of the leveller; the leveller spring
preloading may be changed.
You can choose either manual adjustment of the leveller height or
hydraulically controlled leveller height.
L –Front Levelling Bar with Flexible Segments
Automatically released levelling bar with separate flexible segments.
Better clod crumbling, better permeability of larger quantity of
loosened soil.
Possibility to adjust the leveller height and to change the angle of the
blades.
You can choose either manual adjustment of the leveller height or
hydraulically controlled leveller height.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
17 │56
WORKING ROLLERS
SB –Spiral Bar Roller - 40 cm - 60 kg/m –9 bars
Quality clod crumbling.
Suitable for humid conditions.
This type of roller can be used as the FRONT or REAR roller.
BR - Bar Roller - 40 cm - 60 kg/m –12 bars
Very good quality clod crumbling.
Not suitable for humid conditions.
This type of roller can be used as the FRONT or REAR roller.
RR –Ring Roller 40 cm - 115 kg/m
Quality work in all types of soil.
Good depth guiding.
Suitable for more humid soils.
This type of roller can be used as the FRONT or REAR roller.
CR –Cross-kill Roller with Cleaner - 40 cm - 170 kg/m
Quality clod crumbling and backwards compaction.
Excellent work in light, medium and heavy soils.
Not suitable for more humid soils.
Not suitable for soils with a large quantity of rocks.
This type of roller can be used as the REAR roller only.
DCR –Double-row Cross-kill Roller - 40 cm / 40 cm - 175 kg/m
Quality clod crumbling and backwards compaction.
Mixes the processed soil more intensely.
Excellent work in light, medium and heavy soils.
Can work in slightly moist conditions.
Not suitable for rocky soils.
This type of roller can be used as the REAR roller only.
BR
SB
CR
DCR
RR
Crumbling
●●●○
●●●○
●●●●
●●●○
●●○○
Compacting
●●●○
●●●○
●●●●
●●●○
●●●●
Depth guiding
●●●●
●●●●
●○○○
●●○○
●●●●
Resistance to clogging
●●○○
●●●○
●●●○
●●●●
●●●●
Suitable for rocky soils
●●●○
●●●○
●●○○
●○○○
●●●○
Suitable for wet soils
●○○○
●●●○
●●○○
●●●○
●●●●
Heavy soils
●●○○
●●○○
●●●○
●●●○
●●●○
Medium soils
●●●○
●●●○
●●●●
●●●●
●●●○
Light soils
●●●●
●●●●
●●●●
●●●●
●●●○
● –MAX / ○ - MIN
SHARE SECTIONS
AL –Section of shares with sweeps in two rows
The share section is equipped with sweeps with the width of 25 cm
in two rows. Each sweep is protected by a leaf spring. This section is
suitable for lighter soil conditions without plant residues. There is a
leveller behind the sweeps.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
18 │56
CF –Section of chisel shares in four rows
The share section is equipped with slim chisels with the width of 7
cm in four rows. The section is suitable for processing soil in spring
when it is not suitable to pull wet soil out to the surface, or for
heavy soils. There is no leveller behind the chisels.
AP –Section of shares with sweeps in two rows
A universal share section is equipped with sweeps with the width of
25 cm in two rows. The sweeps are mounted to frames with
geometry improving the permeability of plant residues. Therefore,
this section is suitable for land with a higher occurrence of crushed
plant residues as well as for heavy soils. There is a leveller behind
the sweeps.
AL
CF
AP
Number of rows of shares (pieces) / Row
spacing (mm)
2 / 400
4 / 240
2 / 490
Leveller behind shares
●●●●
○○○○
●●●●
All-area processing
●●●●
●●●○
●●●●
Suitable for light soils
●●●●
●●●●
●●●●
Suitable for medium soils
●●●○
●●●○
●●●●
Suitable for heavy soils
●●●○
●●●○
●●●●
Suitable for rocky soils
●●●○
●●●○
●●●●
Suitable for wet soils
●●○○
●●●●
●●○○
Resistance to clogging
●●○○
●●●○
●●●○
● –MAX / ○ - MIN
LEVELLING BARS BEHIND SHARES
LEVELLING BAR BEHIND SHARES
The bar can be used behind all types of share sections. The bar is sued for
spreading the loosened soil before the rear roller. The height adjustment
is performed using a chain, which the bar is suspended from.
FINISHING OPERATIONS
LF - REAR FINISHING LEVELLING BAR
The levelling bar behind the rear roller levels and evenly spreads the
loosened soil. Possibility to change the angle of the leveller using backstop
plates  thus increasing the efficiency of the leveller.
RF - REAR FINISHING ROLLER
The finishing roller actively disintegrates any remaining clods behind the
rear roller. Be careful –the finishing roller cannot be used behind the two-
row cross-kill rollers. Possibility to change the preloading of the draw
spring tension  thus increasing the efficiency of the finishing roller.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
19 │56
4. MACHINE ASSEMBLY AT THE CUSTOMER
Always assemble the machine on a flat and reinforced surface.
Use the Spare Parts Catalogue with 3D views as reference for assembly.
The operator must perform the assembly according to the instructions of the producer, best in
cooperation with the expert servicing technician determined by the producer.
The operator must secure a functional test of all assembled parts after the completion of the machine
assembly.
The operator must secure that the handling of the machine using lifting equipment during its assembly is
in accordance with chapter „C“/p.9.
Example of a loaded machine, K800PS, on the truck platform
Unloading the K800PS machine from the truck platform using a forklift truck
5. COMMISSIONING
Before taking over the machine, test and check, whether damage occurred during transport and
whether all parts contained in the bill of delivery were supplied.
Before commissioning the machine, carefully read this operating manual, especially Chapters A-D page
7-14. Before the first use of the machine, familiarise yourselves with its controls and overall function.
During work with the machine, observe not only the instructions of this operating manual but also
generally valid regulations of work safety, health protection, fire and transport safety, and
environmental protection.

Manual
KOMPAKTOMAT K500PS | K600PS | K700PS | K800PS | K1000PS
20 │56
The operator must check the machine before every use (commissioning) from the standpoint of
completeness, work safety, work hygiene, fire safety, transport safety, and environmental protection.
A MACHINE SHOWING SIGNS OF DAMAGE MUST NOT BE COMMISSIONED!!
Aggregation of the machine with the tractor is to be performed on a flat and hardened surface.
When working on slopes, observe the lowest slope grade of the set TRACTOR - MACHINE.
Before starting the tractor motor, check whether no person or animal is in the working space of the set
and push the warning sound signal.
The operator is responsible for the safety and all damage caused by the operation of the tractor and the
connected machine.
The operator is obliged to adhere to the technical and safety regulations of the machine determined by
the producer when working.
The operator must raise the machine when turning at the plough turning end, i.e. the working parts
must not be in the ground.
The operator is obliged to observe the prescribed working depths and speeds stated in the manual in
table page 5-6 when working with the machine.
The operator is obliged to lower the machine to the ground and secure the set against movement
before leaving the tractor cabin.
When connecting, no persons may stay in the space between the tractor and the machine. Exercise
utmost caution!
5.1 AGREGATION TO A TRACTOR
The machine can be connected only to a tractor, whose curb weight is identical or higher than the
overall weight of the connected machine.
The machine operator must observe all generally valid regulations of work safety, health protection, fire
safety, and environmental protection.
The operator may connect the machine exclusively to a tractor that is equipped with a rear three-point
hitch or lower agro tow bar and a functional undamaged hydraulic system.
The controlling distributors in the tractor must be secured or blocked when the machine is in the
transport position or when the machine is not in use to prevent accidental or third-party (children,
passengers) caused movement of the hydraulics.
Aggregate the machine with the tractor using type and dimensionally consistent components
corresponding to the output requirements. For example, do not aggregate a machine with ø50mm
pulling loop to ø40mm pin!
The design allows selecting from several versions of aggregation to the tractor.
Aggregation to the rear TBZ hitch Aggregation to the agro tow bar = K80, C40, C50,
C70
