FCC BBQ DRIFTER 2.0 Guide

!
INSTRUCTION MANUAL & MAINTENANCE
Sare  u  cookin!
OUTDOORUSEONLY
READTHEOPERATINGINSTRUCTIONS
BEFOREUSINGTHEAPPLIANCE.
FCC-G-19733-20 / EX211A

Contents
Warnings .........................................................................................................3
Technical data Drifter 2.0 ..................................................................4
Gas category..................................................................................................4
Exploded drawing .....................................................................................5
Parts list ............................................................................................................6
Assembly instructions ...............................................................................7
Gas leak test ................................................................................................18
Regulator and hose ...................................................................................19
Last Check.................................................................................................20
Lighting instructions................................................................................. 21
Warnings ......................................................................................................22
Maintenance .............................................................................................23
Grease fire ..................................................................................................24
Recipe..............................................................................25
Troubleshooting..........................................................................................27
Consumer Contact.................................................................................28
2

WARNINGS
• FAILURE TO FOLLOW THE INSTRUCTIONS PROVIDED CAN
IMPLY A RISK OF SERIOUS INJURY TO PERSONNEL AND FIXED
INSTALLATIONS.
• THE BBQ IS INTENDED FOR OUTDOOR USE ONLY IN WELL-
VENTILATED AREAS. NEVER BBQ IN ENCLOSED SPACES OR
UNDER A ROOF, DUE TO THE DANGER OF THE LACK OF
OXYGEN.
• ACCESSIBLE PARTS OF THE BBQ BECOME VERY HOT DURING
USE. KEEP CHILDREN AND OTHERS WHO NEED SUPERVISION AT
A SAFE DISTANCE.
• NEVER MOVE THE BBQ WHILE IN USE OR CONNECTED TO THE
GAS BOTTLE.
• SHUT OFF THE GAS ON THE REGULATOR AFTER USE AND
DISCONNECT FROM THE GAS BOTTLE.
• MODIFICATION OF THE BBQ CAN CAUSE DANGER AND WILL
INVALIDATE THE WARRANTY.
• DO NOT PLACE THE BBQ COVER OR OTHER FLAMMABLE
MATERIAL IN THE COMPARTMENT UNDER THE BBQ WHEN IT IS
IN USE OR HOT.
• CLEAN THE BBQ REGULARLY AND THOROUGHLY.
3
Read carefully

Width: 118,5 cm
Height: 103 cm Depth: 57,5 cm
DESTINATIONOF
COUNTRIESTOUSE VALVESIZE GASTYPE GASCATEGORY
AL, BG, CY, CZ, DK, EE,
FI, FR, HR, HU, IS, IT, LT,
LU, MK,
MT, NL, NO, RO, SE, SI,
SK, TR
Dia 0.89 mm G (butane), G(propane) and
their mixtures I3B/P(30)
Technical information
Total Heat input: 6,6 kW
Gas consumption: 472 gram/hour
Gasbottle (not included): Use standard bottle approved for use in the Nordic Region.
Even though butane and propane gas can be used, we recommend propane for use in the
Nordic Region. Approved hoses and regulators are available om most outlets selling gas
equipment.
NB! Gas hoses used for this product must not exceed 120 cm in length.
• ONLY THE GAS TYPE AND GAS CATEGORY LISTED IN THE RATING LABLE
COUILD BE USED ON YOUR APPLIANCE.
0359-18
This product is produced according to
EUROPEANGASAPPLIANCE
STANDARDEN-2012 and is CE certified.
I3B/P(30): G30(Butane), G31(propane)
and mixtures of these.
THE APPLIANCE IS SET TO OPERATE
4

Exploded drawing
A2
B1
A1
B11
A5
B2
B12
B13
B10
B7
B6
B15
B14
C2
C3
C4
C6
C16
C9
C12 C14
C10
C7
C8
C15
C11
B8
B4 B3
B9
A4
C13
C17
A3
C1
C5
B5
5

CODE DESCRIPTION QTY
A HOOD (PREASSEMBLEDTOBODY) 
A HOODHANDLE 
A HOODHANDLEHEATSHIELD 
A HEATINDICATOR 
A WARMINGRACK 
B BARBECUEBODY 
B BURNER 
B CONTROLPANEL 
B KNOB (PREASSEMBLED) 
B FMETAMERBRACKET 
B FMETAMER 
B COOKINGGRILL 
B INGNITIONBUTTON (PREASSEMBLED) 
B CONTROLPANELHEATSHIELD 
B ELECTRODE 
B HINGEBRACKET 
B BODYHEATSHIELD 
B BODYSUPPORT 
B GREASECUPHOLDER 
B GREASECUP 
C SIDESHELF (WITHBRACKET) 
C SIDESHELF (WITHOUTBRACKET) 
C SIDESHELFBRACKETA 
C SIDESHELFBRACKETB 
C LEFTFRONTLEG 
C LEFTREARLEG 
C RIGHTFRONTLEG 
C RIGHTREARLEG 
C GASBOTTLEHOLDER 
C LEGENDLOOP 
C WHEELSPACER 
C WHEEL 
C WHEELHUBCAP 
C AXLE 
C BOTTOMSHELF 
C GASBOTTLESTRAP 
C BOTTLEOPENER 
6
Parts List

WARNING! EXERCISECAUTIONWHENUSINGELECTRICTOOLS
 THEIRSTRENGTHCANDAMAGETHESCREWS.
CODE hard ware QTY
D MX BOLT 
D MX BOLT 
D MX BOLT 
D MX BOLT 
D ST.0X SCREW 
D ST.0X SCREW 
D ST.8X SCREW 
D LOCKNUT 
D M NUT 
D M NUT 
D SPACER 
D HOSECLIP 
1
1. Attach the Right Front Leg (C7) and Right Rear Leg (C8) to the Leg End Loop
(C10). The legs are a push fit onto the leg end loop. In case of difficulty, they may
need tapping with a so faced mallet. Take care not to damage the parts.
Please follow these instructions step by step.
A screwdriver and an adjustable wrench is necessary when assembling the BBQ.
7
Assembly

3
3. Attach right leg assembly to the bottom shelf assembly using M6x15 Bolts (D1x4pcs).
2
2. Attach the Gas Bottle Holder (C9) to the Bottom Shelf (C15) using ST4.8x15 Screws
(D7x2pcs). Take care not to over tighten these screws which will damage the plastic
gas bottle holder.
8
Assembly

4
5
4. Attach the Le Front Leg (C5) and Le Rear Leg (C6) to the Gas Bottle Holder (C9)
using ST4.8x15 Screws (D7x4pcs).
5. Insert the Axle (C14) through the clamping brackets underneath the Gas Bottle
Holder (C9) and tighten the clamping screws. Take care not to over tighten these screws
which will damage the plastic gas bottle holder.
Slide a Wheel Spacer (C11) over each end of the Axle (C14). Note: the spacers are packed
in a plastic bag with the electrode, grease cup holder and grease cup.
Slide the Wheels (C12) over each end of the axle. Secure the wheels into place with the
Locknuts (D8x2pcs). Place the Wheel Hubcaps (C13) onto the outside of the wheels.
9
Assembly

D1
B13
√
×
7
7. Unscrew the locknut om the Heat Indicator (A4). Insert heat indicator through the
Hood (A1) and fix it by tightening its locknut.
Attach the Hood Handle (A2) and Hood Handle Heat Shield (A3) onto the hood using
the M5x15 Bolts (D2x2pcs).
6
6. Carefully turn the completed trolley over, right side up.
Attach the Body Supports (B13) to the legs using M6x15 Bolts (D1x4pcs).
10
Assembly

8
9
8. Carefully place the Barbecue Body (B1) onto the tops of the legs.
Attach the barbecue body to the trolley assembly using the M6x15 Bolts (D1x8pcs).
Ensure the tabs on the body fit over the legs as shown in the diagram and do not go down
inside of the legs.
WARNING: DO NOT RELEASE THE BARBECUE BODY WHILE THE
BARBECUE HAS NOT BEEN PROPERLY SEATED. THIS MAY RESULT IN
INJURY OR DAMAGE TO YOUR BARBECUE.
9. Install a M6x15 Bolt (D1) and a Spacer (D11) into the upper fixing hole on each ont
leg. Place the Control Panel (B3) assembly in position by aligning the spacers with the
slot on each side of control panel and fix it onto the trolley assembly using M6x15 Bolts
(D1x2pcs).
11
Assembly

B14
B15
11
11. Feed the Burner (B2) into barbecue body. Ensure that the burner venturi tubes are
over the ends of the gas valves. They are a loose fit and not a gas tight seal. Secure the
burner with the ST4.0x10 Screws (D5x2pcs).
10
10. Feed the Grease Cup Holder (B14) through the hole in barbecue body.
Insert the Grease Cup (B15) into the grease cup holder.
12
Assembly

12
13
13. Attach the Body Heat Shield (B12) to barbecue body using the M5x10 Bolts
(D3x2pcs) and M5 Nuts (D10x2pcs).
12. Insert the Electrode (B10) into the hole at the bottom of the barbecue body and
secure with a ST4.0x10 Screw (D5).
13
Assembly

15
15. Carefully lay the Flame tamer (B6) onto its brackets in the barbecue body, ensuring
it lies level within the body. Lay the Cooking Grill (B7) into place.
14
14. Attach the Flame Tamer Brackets (B5) to barbecue body using the M4x10 Bolts
(D4x4pcs) and M4 Nuts (D9x4pcs).
14
Assembly

16
17
16. Attach the Warming Rack (A5) to the hood and barbecue body as shown. Make
sure that the shorter, fixed legs go through the holes in the hood, then the swing legs
fix to the body of the barbecue.
1 7. Attach the Side Shelf Bracket A (C3) and Side Shelf Bracket B (C4) to the
Side Shelf (C2) using ST4.0x15 Screws (D6x4pcs).
15
Assembly

19
1 9. Slide a Shelf Spacer (D11) onto a M6x15 Bolt (D1) and screw it into the upper fixing
point on the le rear leg as shown. Repeat for the le ont leg. Attach the previously
assembled Side Shelf (C1) to the le hand side of the barbecue by sliding a Shelf Spacer
(D11) onto a M6x15 Bolt (D1) and fitting the shelf to the lower fixing point on the rear
leg as shown. Repeat for the ont leg.
Hook the shelf onto the upper pins to extend it to its normal horizontal position.
18
18. Slide a Shelf Spacer (D11) onto a M6x15 Bolt (D1) and screw it into the upper fixing
point on the right rear leg as shown. Repeat for the right ont leg. Attach the assembled
Side Shelf (C2) to the right hand side of the barbecue by sliding a Shelf Spacer (D11)
onto a M6x15 Bolt (D) and fitting the shelf to the lower fixing point on the rear leg as
shown. Repeat for the ont leg.
Hook the shelf onto the upper pins to extend it to its normal horizontal position.
16
Assembly

NB!
ASSEMBLY IS NOW COMPLETE. ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK
TESTED BEFORE USING THE BBQ. LEAK TEST ANNUALLY, AND WHENEVER THE GAS BOTTLE
IS REMOVED OR REPLACED.
20
20. Fix the Hose Clip (D12) into the upper hole of the ont short leg using a ST4.0x10
Screw (D5), then feed the hose (not provided) through the clip as shown.
Important: Regularly check the hose positioning to ensure that it is not in contact with
any hot surfaces, such as the bottom of the body or the heat shield.
Attach the Bottle Opener (C17) to the Right Rear Leg using M6x15 Bolts (D1x2pcs).
1. Maximum diameter or breadth is 315mm.
2. Maximum height (regulator included) is 580mm.
17
Assembly

18
Gas Leak Testing
WARNING
ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BBQ.
LEAK TEST ANNUALLY, AND WHENEVER THE GAS BOTTLE IS REMOVED OR REPLACED.
ALWAYS PERFORM A LEAK TEST IN A WELL-VENTILATED AREA.
 IFTHEREARESTILLGASLEAKSAFTERREPEATEDATTEMPTS CONTACTYOURDEALER.
 IFBUBBLESAPPEAR SWITCHOFFTHEGASSUPPLYANDREPAIRTHE PROBLEM. PERFORMANEWLEAKTEST. DONOTUSETHEBBQBEFOREYOU
ARESURETHATTHEREARENOLEAKS.
OPENTHEGASTAPONTHEREGUTORANDCAREFULLYCHECKFORBUBBLES
APPEARINGANYWHERETHELIQUIDHASBEENAPPLIED.
MAKEAMIXEDSOLUTION  WATERANDLIQUID
DETERGENT / SOAP.
 ENSURETHATTHEREARENONAKEDFMES HEAT
SOURCESANDCIGARETTESINTHEVICINITY WHEN
PERFORMINGALEAKTEST.
 CHECKTHATTHECONTROLKNOBONTHEBBQARE
INTHE ”OFF” POSITION.

SETTHEREGUTORTOTHE ”OFF” POSITIONANDCONNECTITTOTHEGASBOTTLE.
APPLYTHELIQUIDTOALLJOINTSANDCONNECTIONSONTHEGASBOTTLE REGUTOR
THEENTIREHOSEANDALLVALVESONTHEBBQ.
!WARNING!
NEVER USE AN OPEN
FLAME TO PERFORM
A GAS LEAK TEST
Connect the gas hose to the gas rail inlet on the le
hand side of the barbecue. Do not overtighten.
Do not use any sealing tape, paste
or liquid on the connection.
Connect the regulator to the gas bottle according to
your regulator and bottle dealer’s instructions.
Gas hoses used for this product must not exceed 120
cm in length
Confirm all barbecue control knobs are in the OFF
position.
We recommend propane gas for use in the Nordic
Region, but butane can also be used.Butane is not very
suitable for low temperatures.
Fit the regulator and the hose.
Follow the assembly instructions supplied with the
regulator set
Check the gas hose regularly for cracks, damage and
decay. Never use a damaged gas hose.
Check that the movable plastic collar on the regulator
is intact and that it has not been damaged by hot BBQ
parts.
Check that the gas bottle stands on a firm, flat surface
and is lower than the connector.
Use an approved gas bottle that fits the regulator
supplied.
CONNECTING GAS

HOSE
Connect the gas hose to the gas rail inlet on the le hand side of the
barbecue. Do not overtighten.
Do not use any sealing tape, paste or liquid on the connection.
Connect the regulator to the gas bottle according to your regulator
and bottle dealer’s instructions.
Gas hoses used for this product must not exceed 120 cm in length
Check the gas hose regularly for cracks, damage and decay. Never use
a damaged gas hose.
Check that the movable plastic collar on the regulator is intact and
that it has not been damaged by hot BBQ parts.
Check that the gas bottle stands on a firm, flat surface and is lower
than the connector.
Use an approved gas bottle that fits the regulator supplied. Bottles of
10 kg or above are recommended.
REGULATOR
Confirm all barbecue control knobs are in the OFF position.
We recommend propane gas for use in the Nordic Region,
but butane can also be used.Butane is not very suitable for low
temperatures.
Fit the regulator and the hose.
Follow the assembly instructions supplied with the regulator set.
19
Regulator and gas hose
WARNING
NEVER STORE THE GAS BOTTLE UNDER THE BBQ WHEN IN USE. IF THE GAS BOTTLE IS
BEING STORED UNDER THE BBQ WHEN NOT IN USE, DISCONNECT THE REGULATOR.
NEVER MOVE THE BBQ WHILE IT IS IN USE, OR CONNECTED TO THE GAS BOTTLE.

LOCATION
Ensure that the BBQ is placed at least 150cm in all directions om house walls, trees,
plants and other flammable materials or liquids when in use.
Do not place the BBQ under a roof or overhang
Ensure the BBQ is placed where there is plenty of ventilation.
Do not BBQ below normal ground level.
FINAL CHECK
 Check that the control knobs
work normally.
Check that the gas hose is ee of
cracks and damage (it should always
be done before using the BBQ)
Check that the gas bottle and
hose do not come into contact with
hot objects.
GOOD ADVICE
A CLEAN BBQ WORKS BETTER, causes
less smoke and will last longer.
PREHEAT THE BBQ for 10 minutes at full
power prior to placing food on the BBQ. This
gives a better result, and cuts BBQing time.
20
Final Check
