FEDERAL INDUSTRIES SSRC2452 Installation instructions

- 1 -
E3091-3
Revised 01/21/20
REV. D
INSTALLATION & OPERATIONS INSTRUCTIONS
REFRIGERATED SSRC & ESSRC MODELS
KEEP THIS MANUAL FOR FUTURE REFERENCE
Engineering and technical data are subject to change without notice.
FEDERAL INDUSTRIES 215 FEDERAL AVE Belleville, WI 53508
Toll Free 1(800) 356-4206 WI Phone [phone] Fax: [phone]
SSRC
ESSRC
All manuals and user guides at all-guides.com

- 2 -
CONTENTS
INTRODUCTION....................................................................................................................................................... 4
WARNING LABELS & SAFETY INSTRUCTIONS ............................................................................................. 5
PRE-INSTALLATION PROCEDURES .................................................................................................................. 6
Inspection For Shipping Damage.................................................................................................................... 6
GENERAL ELECTRICAL & GROUNDING......................................................................................................... 6
Permanent Connected .................................................................................................................................... 6
Cord Connected (Option)................................................................................................................................ 6
Electrical Information..................................................................................................................................... 7
INSTALLATION INSTRUCTIONS......................................................................................................................... 8
Locating The Display Case............................................................................................................................. 8
Removing Case From Shipping Skid.............................................................................................................. 8
Cleaning.......................................................................................................................................................... 8
REFRIGERATION ...............................................................................................................................................9-10
Self-Contained Models ................................................................................................................................... 9
Refrigeration Settings, SSRC.................................................................................................................... 9
Refrigeration Settings, ESSRC.................................................................................................................. 9
Remote Models............................................................................................................................................... 9
Refrigeration Settings, SSRC Remote....................................................................................................... 9
Remote Refrigeration Operation ............................................................................................................... 9
Remote Refrigeration Instruction............................................................................................................ 10
SHELVING INSTALLATION & REMOVAL.................................................................................................11-13
Shelf Brackets & Supports Installation....................................................................................................11-12
Wire Shelves Installation.............................................................................................................................. 12
Glass Shelves Installation (Option) .............................................................................................................. 13
REAR DOORS ....................................................................................................................................................14-16
Top Section Rear Sliding Doors Removal.................................................................................................... 14
Top Section Rear Swinging Doors Removal................................................................................................ 15
Bottom Section Rear Doors Removal (Option)............................................................................................ 16
NIGHT CURTAIN (SSRC OPTION) ..................................................................................................................... 17
Opening ........................................................................................................................................................ 17
Closing.......................................................................................................................................................... 17
SECURITY NIGHT COVER (SSRC OPTION).................................................................................................... 18
Installation .................................................................................................................................................... 18
Removal........................................................................................................................................................ 18
OPERATING INSTRUCTIONS........................................................................................................................19-23
Power Switch................................................................................................................................................ 19
Light Switch ................................................................................................................................................. 19
Temperature Control..................................................................................................................................... 19
Button and Display Overview ................................................................................................................. 20
Powering On Control............................................................................................................................... 20
Adjusting the Set Point............................................................................................................................ 21
Entering Manual Defrost Mode............................................................................................................... 21
Error Codes ............................................................................................................................................. 21
Electronic Control Operation .................................................................................................................. 22
Control Parameters ................................................................................................................................. 23
Initial Startup ................................................................................................................................................ 23
Top Section Refrigeration Louver Control................................................................................................... 24
Placing Product In Case................................................................................................................................ 24
MAINTENANCE...................................................................................................................................................... 25
Top Light Bulb Replacement, Fluorescent ................................................................................................... 25
Shelf Light Bulb Replacement, Fluorescent ................................................................................................. 25
Top Light Bulb Replacement, LED (Cases mfg’d After 08/01/18) .............................................................. 25
Shelf Light Bulb Replacement, LED (Cases mfg’d After 08/01/18) ............................................................ 25
PERIODIC MAINTENANCE................................................................................................................................. 26
Cleaning Condenser Coil.............................................................................................................................. 26
All manuals and user guides at all-guides.com

- 3 -
CLEANING INSTRUCTIONS...........................................................................................................................27-31
Daily Cleaning.............................................................................................................................................. 27
Weekly Cleaning .......................................................................................................................................... 28
Weekly Top Section Interior Cleaning ....................................................................................................28-29
Weekly Bottom Section Interior Cleaning.................................................................................................... 30
Weekly Exterior Cleaning ............................................................................................................................ 31
SERVICE INFORMATION ...............................................................................................................................32-33
Special Service Situations............................................................................................................................. 32
Pre-Service Checklist.................................................................................................................................... 33
SALE & DISPOSAL................................................................................................................................................. 34
Owner Responsibility ................................................................................................................................... 34
WIRING DIAGRAMS ........................................................................................................................................35-40
Self-Contained SSRC2452 w/ Fluorescent Lights........................................................................................ 35
Self-Contained SSRC3652 & ESSRC3652 w/ Fluorescent Lights............................................................... 36
Self-Contained SSRC5052/5952/7752, ESSRC5052/5952/7752 w/ Fluorescent Lights.............................. 36
Self-Contained SSRC2452 w/ LED Lights (Mfg’d After 12/1/19) .............................................................. 37
Self-Contained SSRC3652 & ESSRC3652 w/ LED Lights (Mfg’d After 12/1/19) ..................................... 38
Self-Contained SSRC5052/5952/7752, ESSRC5052/5952/7752 w/ LED Lights (Mfg’d After 12/1/19) .... 38
Remote SSRC2452, SSRC3652 w/ Fluorescent Lights................................................................................ 39
Remote SSRC5052/5952/7752 w/ Fluorescent Lights ................................................................................. 39
Remote SSRC5052/5952/7752 w/ LED Lights (Mfg’d After 12/1/19) ........................................................ 40
REPLACEMENT PARTS - SSRC.....................................................................................................................41-44
REPLACEMENT PARTS - ESSRC ..................................................................................................................44-46
All manuals and user guides at all-guides.com

- 4 -
INTRODUCTION
Thank you for purchasing a Federal Industries display case. This manual contains important instructions for
installing and servicing the Refrigerated Self-Service Merchandisers. A repair parts list and wiring diagram
are also included in the manual. Read all documents carefully before installing or servicing your case.
NOTICE
Read this manual before installing your case. Keep this manual and refer to it before doing any
service on the equipment. Failure to do so could result in personal injury or damage to the case.
NOTICE
Installation and service of the electrical components in the case must be performed by a licensed
electrician.
The portions of this manual covering components contain technical instructions intended only for persons
qualified to perform electrical work.
DANGER
Improper or faulty hookup of electrical components in the case can result in severe injury or death.
All electrical wiring hookups must be done in accordance with all applicable local, regional, or
national standards.
REGISTRATION & SERIAL NUMBER
It’s important to keep a record of the model and serial number of your merchandiser for warranty and part
identification. Please write them here for your quick reference.
Register your product online! Visit our website at www.federalindustries.com and register your product
today.
Case Model__________________________ Serial Number______________________
We’re here to provide you with the best possible experience with your new product, however, we cannot
cover everything about your merchandiser in this manual, so if you have any additional questions or issues,
please see the SERVICE INFORMATION PAGE to find who you should contact.
All manuals and user guides at all-guides.com

- 5 -
WARNING LABELS & SAFETY INSTRUCTIONS
This is the safety-alert symbol. When you see this symbol on your case or in the
manual, be alert to the potential for personal injury or damage to your equipment.
Be sure you understand all safety messages and always follow recommended precautions and safe
operating procedures.
NOTICE TO EMPLOYERS
You must make sure that everyone who installs, uses, or services your case is thoroughly
familiar with all safety information and procedures.
Important safety information is presented in this section and throughout the manual. The
Following signal words are used in the warning and safety messages:
DANGER: Severe injury or death will occur if you ignore the message.
WARNING: Severe injury or death can occur if you ignore the message.
CAUTION: Minor injury or damage to your case can occur if you ignore the message.
NOTICE: This is important installation, operation, or service information. If you ignore the
message, you may damage your case.
The warning and safety labels shown throughout this manual are placed on your Federal Industries case at
the factory. Follow all warning label instructions. If any warning or safety labels become lost or damaged,
call our customer service department at 1(800) 356-4206 for replacements.
This label is located on the back of the display case. This label is located below the display pan.
CAUTION
POWER BEFORE
RISK OF ELECTRIC
SHOCK DISCONNECT
91-12340
SERVICING UNIT.
CAUTION
HAZARDOUS MOVING PARTS
DO NOT OPERATE UNIT WITH
DISPLAY PANS REMOVED.
All manuals and user guides at all-guides.com

- 6 -
PRE-INSTALLATION PROCEDURES
Inspection for Shipping Damage
You are responsible for filing all freight claims with the delivering truck line. Inspect all cartons
and crates for damage as soon as they arrive. If damage is noted to shipping crates, cartons, or if a
shortage is found, note this on the bill of lading (all copies) prior to signing.
If damage is discovered when the case is uncrated, immediately call the delivering truck line and
follow up the call with a written report indicating concealed damage to your shipment. Ask for an
immediate inspection of your concealed damage item. Crating material must be retained to show
the inspector from the truck line.
GENERAL ELECTRICAL & GROUNDING
DANGER: Improper or faulty hookup of electrical components in the
display case can result in severe injury or death.
Permanent Connected (OPTION)
-Only a licensed electrician must perform all case electrical connections.
-All electrical wiring hookups must be done in accordance with all applicable local, regional, or national
electrical standards.
-A separate circuit for each display case is required to prevent other appliances on the same circuit from
overloading the circuit and causing malfunction.
-The electrical service must be grounded upon installation.
-See the electrical data plate located at the rear of the case for proper circuit size and wire ampacity.
-The electrical connection box is accessible from the rear of the case with rear grill removed.
REAR BASE PANEL
(6) REAR PANEL SCREWS
CONDUIT OR
POWER CORD
CONNECTION .875O
FIELD CONNECTION BOX
FLOOR CONDUIT
CONNECTION .875O
Cord Connected (OPTION)
-A factory installed optional power cord is properly sized to the amperage requirements of the case. See the
electrical data plate located on the rear exterior of the case for the proper circuit size for each case.
- The cord is factory installed protruding from the rear corner of the case.
-A separate circuit for each display case is required to prevent other appliances on the same circuit from
overloading the circuit and causing malfunction.
All manuals and user guides at all-guides.com

- 7 -
Electrical Information.
PERMANENTLY CONNECTED
MODEL VOLTAGE TOTAL AMPS MAX FUSE SIZE VOLTAGE MAX FUSE SIZE
SSRC2452 120/60/1 11.3 20 120/60/1 15
SSRC3652 120/60/1 14.3 20 120/60/1 15
SSRC5052/
ERSSC5052
230/60/1 9.5 15 120/60/1 15
SSRC5952/
ERSSC5952
230/60/1 14.5 20 120/60/1 15
SSRC7752/
ERSSC7752
230/60/1 14.5 20 120/60/1 15
MODEL VOLTAGE TOTAL AMPS CORD STYLE
SSRC2452 120/60/1 11.3
20AMP NEMA 5-20
SSRC3652 120/60/1 14.3
20AMP NEMA 5-20
SSRC5052/
ERSSC5052
230/60/1 9.5
15AMP NEMA 6-15
SSRC5952/
ERSSC5952
230/60/1 14.5
15AMP NEMA 6-20
SSRC7752/
ERSSC7752
230/60/1 14.5
15AMP NEMA 6-20
CORD CONNECTED OPTIONAL
SELF CONTAINED
SELF CONTAINED
REMOTE
(E3091-3 EXCEL)
All manuals and user guides at all-guides.com

- 8 -
INSTALLATION INSTRUCTIONS
Locating Display Case
The case should be located where it is not subjected to the direct rays of the sun, heating ducts, grills,
radiator, or ceiling fans, nor should it be located near open doors or main door entrances. Also, avoid
locations where there are excessive air movement or air disturbances.
The case requires a minimum of 12” clearance at the rear of the unit for air discharge. Do not locate case
with back tight against the wall.
No clearance is needed on sides of the unit.
Removing Case From Shipping Skid and General Installation
CAUTION: Do not push or pull against the top end glass, or
door frames and do not pull on end panels when removing the case
from the skid or moving the case. Case damage or glass breakage will result.
1. Remove crate top and sides and note missing or damaged items as explained in the pre-installation
procedures outlined above.
2. Move the case as near as possible to the final location and before removing it from the shipping skid.
3. Remove the (4) brackets that secure the case to the shipping skid.
4. Prepare cabinet according to instructions in this section that pertain to your model.
5. Lift the case off of skid and into required position. Only lift the case from under the rear lip and front
bottom trim channel above the base. Note: Do not push or pull on front bottom trim channel.
6. The case must be level for proper drainage of defrost condensate to the condensate evaporator. Using
the wrench provided level and square the case as needed by adjusting the leg leveler in each corner of
base. The 6’cases also have a set of leg levelers in the center. These must be adjusted so the base is flat.
7. The leveled case must be sealed to the floor using a NSF Listed Sealant.
Cleaning
For initial setup, clean the case as outlined in the “Weekly Cleaning” section of this manual.
All manuals and user guides at all-guides.com

- 9 -
REFRIGERATION
Self-Contained Models
SELF CONTAINED
RefrigerationR404 Charge 25 OZ 30 OZ 32 OZ 34 OZ 36 OZ
SSRC7752/
ERSSC7752
SSRC2452
WITH ELECTRONIC CONTROL
SSRC3652
SSRC5052/
ERSSC5052
SSRC5952/
ERSSC5952
(E3091-3 EXCEL)
The self-contained models are shipped from the factory with a completely operational 404A refrigeration
system and require no modifications or adjustments upon installation. Case must be installed as per the
installation section of this manual to provide proper condensing air cooling.
The dual pressure control is used as a safety device and is factory set. The pressure control works on a
differential. The low-pressure side is a safety to protect the compressor in the case of refrigerant loss. The
high-pressure side is a safety to protect from system failure causing too high of system pressure.
The high side of the pressure control is factory set to 400psi and is not adjustable. Low side setting
for the R404a cases are set at 40psi differential for the cutout and 60psi for the cut-in.
Note: The condenser fan runs continuously.
This unit also has a defrost timer that will shut the compressor off a set number of times per day to insure a
full defrost occurs. The compressor will remain off until the either the off time is reached or until the
temperature sensor on the coil reaches a set temperature, which ever happens first.
Remote Models
REMOTE
RefrigerationR449 Charge
Remote Low Press. SwitchCut In
Remote Low Press. SwitchCut Out
Remote High Press. SwitchCut Out
BTU Requirement @90F/20F 3600 4400 5400 6400 7400
450 psi
CHARGED INFIELD
50
15
SSRC5952R/
ERSSC5952R
SSRC7752R/
ERSSC7752R
SSRC2452R
SSRC3652R
SSRC5052R/
ERSSC5052R
(E3091-3 EXCEL)
All manuals and user guides at all-guides.com

- 10 -
Remote Refrigeration Operation
The remote models are designed to use R449 refrigerant and shipped from the factory with the evaporator
coil, expansion valve, drier filter, sight glass and refrigerant solenoid valve. A thermostat senses evaporator
temperature and opens and closes the refrigerant solenoid valve. The solenoid valve closes and shuts off the
refrigeration flow to the unit and initiates a pump down cycle. This will allow the remote low-pressure
switch to open and shut off remote compressor. The temperature control may require some adjustment by
installer for proper operation of unit. This unit also has a defrost timer that will shut the refrigeration
solenoid off a set number of times per day (set at factory for 3 times per day) to insure a full defrost occurs.
The solenoid will remain off until the either the off time is reached or until the temperature sensor on the
coil reaches a set temperature, whichever happens first.
The condensing unit is optionally supplied from the factory for remote location installation. The
condensing unit supplied from the factory will include a high/low pressure switch that must be mounted
and wired by the installer. The high/low pressure switch must be wired in series with the compressor power
supply as shown in diagram below. If the factory is not providing the condensing unit a high/low pressure
switch will need to be supplied by installer and installed by installer.
Remote Refrigeration Instructions
1. Mount condensing unit indoors as close to the remote display case as practical. The refrigeration line
should be as short as possible.
2. All refrigeration and/or electrical materials between the condensing unit and display case are to be
supplied by installing contractor.
3. Route properly sized and designed refrigeration lines from the condensing unit to the cabinet.
Horizontal suction lines should be pitched downward towards the condensing unit at least ½” per 10’
run to aid the oil drainage. A “P” trap must be installed in the suction line at the foot of every riser to
insure oil return. Dry nitrogen must be used to flow through tubing while brazing refrigeration lines.
4. Suction line must be insulated the entire length with Armaflex (or equivalent). Do not run liquid line
inside insulation with suction line.
5. The remote high/low-pressure control must be mounted, wired and set pressures by the installer.
6. Leak check condensing unit, cabinet, and all connecting tubing. Cabinet and condensing unit tubing
should be checked to insure no leaks occurred during shipping or from rough handling.
Make certain all refrigeration valves are opened and evacuate system to 500 microns. Charge the
system with refrigerant type specified on the data plates.
REMOTE
HIGH LOW
PRESSURE
CONTROL
LIQUID LINE
SUCTION LINE (INSULATED)
REMOTE
CONDENSING
UNIT
EVAPORATOR COIL
DISPLAY CASE
EXPANSION
VALVE
HIGH
LOW LIQUID LINE
SOLENOID VALVE
SIGHT GLASS
DRIER/FILTER
FIELD CONNECTION
HOT
FUSED
POWER
SUPPLY DEFROST
TIMER
HOT
DEFROST
TERMINATE
TEMPERATURE
CONTROL NEUT.
TEMP. CONTROL PROBE
All manuals and user guides at all-guides.com

- 11 -
SHELVING INSTALLATION & REMOVAL
Shelf Bracket & Supports Installation
SHELF STANDARD
REAR SHELF SUPPORT
SHELF LIGHT ASSEMBLY
SHELF BRACKET
SHELF LIGHT CORD
RETAINER CLIP
SHELF STANDARD
RETAINING SCREW
OPTIONAL BOTTOM
SECTION SHELF
TOP SECTION SHELF
REAR SHELF SUPPORT
REAR SHELF SUPPORT
1. Turn the light switch to the off position. Remove rear doors as described in the “Rear Sliding Door
Removal” section of this manual to allow access to interior of case. On 24” cases, open the rear
swinging door past 90º until it locks in the open position.
2. Follow the instruction in the illustration below and insert (1) of the (2) shelf brackets in the desired
shelf standard slot on one side of the case. Place the additional shelf bracket in the same shelf standard
slot on the opposite end of case. The bracket with a shelf light cord retainer clip must be on the side
with the shelf light receptacle. Shelf brackets on the 24” case may have bends, making them left-hand
or right-hand specific. Install the brackets so they are farthest spread apart at the front of the case.
0vNOTCH
6vNOTCH
4
1
2
3
4
INSTALLATION REMOVAL
23
1
TOP HOOK
BOTTOM TAB
SHELF BRACKET
SHELF STANDARD
1. Place shelf bracket top hook into desired shelf
standard slot.
2. Lift shelf bracket top hook to allow shelf bracket
bottom tab to clear shelf standard slot.
3. Swing shelf bracketbottom tab into shelf standard
slot.
4. Place the desired shelf bracket notch of 0, 6, or 12
degrees onto bottom of shelf standard slot.
1. Lift shelf bracket up to allow shelf bracket notch
to clear the bottom of shelf standard slot.
2. Swing shelf bracket bottom tab out of shelf
standard slot.
3. Drop shelf bracket down to allow shelf bracket top
hook to clear top of shelf standard slot.
4. remove shelf bracket top from shelf standard slot.
CLEAR BUMPER
TOWARDS END PANEL
3. Hang one end of shelf light housing or shelf support on the front notch of a shelf bracket. Hang the
other end of shelf light housing or shelf support on the notch of the shelf bracket on the opposite end.
4. Push shelf light cords into plastic shelf cord retainer clip located on inside of shelf bracket.
All manuals and user guides at all-guides.com

- 12 -
5. Remove the cap from the appropriate female light sockets.
IMPORTANT: Grip each side of cap firmly and wiggle and pull cap straight out of socket. Do not roll
cap during removal. Incorrect removal of cap may cause damage to electrical connection.
RIGHT WRONG
6. If the socket is not being used for a shelf light, the cap must be plugged into the socket. On models with
the 5 pin shelf plug, this is necessary for the entire light system to operate. On models with the 3 pin
shelf plug, this is necessary to prevent buildup and damage to receptacle.
7. Plug in each shelf light by aligning the male pins on the appropriate shelf light cord plugs with the
female light sockets and push together. IMPORTANT: Do not roll plug during insertion.
8. Hang one end of the shelf support on to the rear notch of one shelf bracket and then on the rear notch of
the shelf bracket on the opposite side. NOTE: If the bottom open section shelf is supplied instead of
step risers, the bottom rear support is not the same as the top rear support. See illustration above.
9. Place supplied shelving onto shelf supports as outlined in the appropriate “Shelf Installation” section of
this manual.
10. Removal of shelving is performed by following steps in reverse order.
11. The shelf standards are removable from case by removing the (2) shelf standard retaining screws
holding them to the inside wall of case.
Wire Shelves Installation
WIRE SHELF
WIRE SHELF
RETAINER CLIPS
SNAP THE REAR RAIL OF
THE WIRE SHELF INTO
RETAINER CLIPS ON
REAR SHELF SUPPORT
1. Install shelf brackets & shelf supports as described in Shelf Bracket & Supports Installation Section of
this manual.
2. Place the front of wire shelf onto front shelf light or front shelf support.
3. Snap the rear of shelf into the clear plastic clips on rear shelf support.
All manuals and user guides at all-guides.com

- 13 -
Glass Shelves Installation
GLASS SHELF
SHELF STANDARD REAR SHELF
SUPPORT
SHELF LIGHT ASSEMBLY
SHELF BRACKET
GLASS SHELF
RETAINER CLIP
CORD RETAINER CLIP
PRODUCT STOP
RETAINER CLIP
SLOT
PLACE BACK SIDE OF GLASS
SHELF RETAINER CLIP INTO SLOT
IN OF REAR SHELF SUPPORT
TOP SECTION GLASS SHELF
PLACE GLASS SHELF RETAINER
CLIP OVER REAR SHELF SUPPORT
SHELF STANDARD
RETAINING SCREW
OPTIONAL BOTTOM
SECTION GLASS SHELF
CLIP LOCATED IN FAR
CORNER OF GLASS SHELF.
CLIPS FIELD INSTALLED TO GLASS.
TOP VIEW
PRODUCT STOP
PRODUCT STOP
1. For first time installation attach (2) glass shelf retainer clips to each glass shelf in location shown in
illustration. Clean area of glass where glass shelf holder is to be located with rubbing alcohol and let
air dry before installing shelf glass holder. Remove backing from tape located on flat side of glass shelf
holder. Position the glass shelf holders in the (2) far corners of glass. Repeat for each glass shelf.
2. For first time installation attach (1) product stop to each glass shelf as shown in detail above. Align the
product stop edge with the edge of the glass and push the “U” portion of the product stop on to glass lip
across the entire front of glass.
3. Attach a clear bumper on both sides of the light housing top surface for the front of the glass to set on.
This step may have already been performed at the factory for you.
4. Place front of glass shelf onto clear bumpers on front shelf light. (On front shelf support for models
without shelf lights.)
5. If clear plastic clips were factory-installed on top of rear shelf support, remove and discard clear plastic
clips.
6. For SSRC top section glass shelf set the rear of the glass shelf onto the rear shelf support so that the
back side of the glass shelf retainer sets into the slot on the rear shelf support. For ESSRC top section
glass shelf and all optional bottom section glass shelves, set the rear of the glass shelf onto the rear shelf
support so that the back side of the glass shelf retainer straddles the rear shelf support.
All manuals and user guides at all-guides.com

- 14 -
REAR DOORS
TOP SECTION REAR SLIDING DOORS REMOVAL
UPPER TRACK
LOWER TRACK
1. LIFT UP DOOR
2 SWING BOTTOM OUT
1. Starting with the outer door, lift the door upward until the bottom edge of door clears the
lower track and then swing the bottom of the door outward and down out of upper track.
2. After the outer door is removed repeat the procedure for the inner door.
3. Reverse this procedure for door reinstallation. The doors are not interchangeable.
All manuals and user guides at all-guides.com

- 15 -
TOP SECTION REAR SWINGING DOOR REMOVAL
2. REMOVE SCREW
3. REMOVE SCREWS
1. ROTATE DOOR TO LOCKED OPEN POSITION
1. Open the door. Continue to rotate the door past the 90º position until you feel it lock in the open
position.
2. Remove the pivot screw located under the door, at the pivot point of the lower hinge. It is not
necessary to remove the (2) screws that secure the lower hinge bracket to the case.
3. With the door still in the open position, use a 5/16” wrench to remove the (2) screws that attach
the upper hinge bracket to the case.
4. Lift the door up, and out of the pocket in the lower hinge bracket.
5. Reverse this procedure for door reinstallation.
All manuals and user guides at all-guides.com

- 16 -
BOTTOM SECTION REAR DOORS REMOVAL (OPTIONAL)
1. LIFT UP DOOR
2 SWING BOTTOM OUT
1. LIFT UP DOOR
2 SWING BOTTOM OUT
INNER DOOR CATCH
INNER DOOR CATCH SLOT
INNER DOOR UPPER TRACK
OUTER DOOR UPPER TRACK
OUTER DOOR LOWER TRACK
INNER DOOR LOWER TRACK
OUTSIDE DOOR SET
1. Starting with the outer outside door, lift the door upward until the bottom edge of door clears the
lower track and then swing the bottom of the door outward and down out of upper track.
2. Remove the outer inside door using the same procedure.
3. The inner door set can then be removed using the same procedure starting with the inner outside
door followed by the inner inside door.
4. Reverse this procedure for door reinstallation starting with the inner inside door followed by the
inner outside door. Check that the doors slide freely.
5. Replace the outside inner door and the outside outer door. Be sure to slide the inner door catch
into the inner door catch slot for each door.
Note: None of the doors are not interchangeable and they must be replaced in the same
location that they were removed from.
All manuals and user guides at all-guides.com

- 17 -
NIGHT CURTAIN (SSRC OPTION)
NIGHT CURTAIN STRAP
NIGHT CURTAIN SNAP
SNAP
FRONT PANEL
NIGHT CURTAIN
HOLDER BRACKETS
Opening:
1. Grasp the night curtain strap and lift the rolled night curtain out of the night curtain holder
brackets. Pull the night curtain across the top of case and down the front.
2. Attach the snap located under the night curtain strap on to the snap located on the front
trim.
Closing:
1. Grasp the night curtain strap and detach the snap from the snap located in the front top trim.
2. While holding the night curtain strap allow the night curtain to roll up and place the rolled
night curtain carefully into the night curtain holder brackets.
Note: The 59”’ and 77” models have (2) night curtains.
All manuals and user guides at all-guides.com

- 18 -
SECURITY NIGHT COVER (SSRC OPTION)
Removal:
1. Unlock the lock handles and turn handles to the vertical position to disengage from lock
handle catches.
2. Grasp the front grab handles and lift the cover straight up and out of the case opening.
Installation:
1. Turn the lock handle so the latch handle is vertical to the top of the case.
2. Holding the grab handles place the bottom flange of the security night cover inside the “U”
retainer clips located on each side of case opening behind the front clear deflector. There
also may be a “U” retainer clip in the center of the case that must also engage the security
night cover flange.
3. Set the top flange of the security cover down against the top glass handle.
4. Turn the lock handles so they engage the lock handle catches and use the key to lock them
in place.
IMPORTANT: Cleaning the Acrylic plastic security night cover require special care to prevent hazing of
material. Lightly dust (not wipe) the surface with clean soft cloth. Then the surface can be wiped carefully
with a soft, wet cloth or chamois. The cloth or chamois must be kept free of grit by frequently rinsing in
clean water. Grease and oil can be removed with kerosene. Do not use window cleaners or kitchen scouring
compounds. DO NOT use solvents such as Acetone, Benzene, Carbon Tetrachloride, and Lacquer
Thinners. A spray wax such as Pledge or Maguire’s polish can be applied and wiped with a clean soft cloth.
The wax tends to fill in and hide small scratches.
All manuals and user guides at all-guides.com

- 19 -
OPERATING INSTRUCTIONS
NOTICE: This refrigerated display case is designed to operate
in a maximum environment of 80 DEG. F and 55% relative
humidity. Exceeding these limits will cause poor case
performance and sweating of glass panels.
Controls
TEMPERATURE CONTROL
POWER SWITCH
LIGHT SWITCH
Power Switch
The unit has a power switch that turns off power to the entire unit, including the condensate evaporator
and the lights.
Light Switch
The unit has a light switch that turns on and off the interior lights of unit.
Electronic Temperature Control
Located in the rear grille of the display case, the temperature control allows the user to adjust the
temperature of the display merchandiser to their needs.
All manuals and user guides at all-guides.com

- 20 -
Button and Display overview
DIGITAL DISPLAY
SET POINT ADJUST MODE
POWER TO CONTROL ON/OFF
AND SET POINT UP ADJUST
MANUAL DEFROST AND
SET POINT DOWN ADJUST
COMPRESSOR RUN
INDICATOR
DEFROST MODE INDICATOR
ALARM INDICATOR
Button Overview
Press and hold this button for three seconds to turn system on (if off) or off (if on).
Also used to adjust set point when in set point adjust mode
Press to enter set point adjust mode, confirm set point changes, and mute alarms.
Press and hold this button for three seconds to initiate a manual defrost (and cancel defrost if
initiated), also adjusts set point down when in set point adjust mode
Powering on control
To turn refrigeration control power on, press and hold for approx. three seconds. The display will read
“On” while the button is depressed. When the control powers on, the display will read the current set point
(a number “1” thru “9” ). The compressor run indicator will illuminate on the display, meaning that the
compressor is running. (Note: the control may already be in the on mode when shipped from factory).
To turn refrigeration control power to off, press and hold for approx. three seconds. The display will
read “Off” while the button is depressed. When the control powers off the display will flash back and forth
between the relative current case temperature and “Off”. The compressor run indicator will be off on the
display. When refrigeration control is in the off-mode cabinet lights and evaporator fans will still operate,
but the compressor will not turn on causing the case to gradually reach room temperature.
Adjusting the set point
The set point is what determines how cold the display case will hold food and beverage. To adjust the set point press
and hold the button approx. three seconds until the display begins to flash a number. Then press the use the
button to scroll number up (colder) or press the button to scroll number lower (warmer). There are nine (9)
available set points numbers, the higher the number of the set point, the colder the display case will run, with setting
“9” being the coldest and setting “1” being the warmest. Once you have chosen your desired setting press the
button again to confirm your choice.
All manuals and user guides at all-guides.com
