A3-31 Adjustment Guide

There are four panels that can be removed from the top side: two
covering the hinges, and two covering the kip levers.

To access the adjustment bolts on the hinges, remove the back panel
comprising of nine screws. (Two screws are not shown as they are locat-
ed on the opposing side)

Loosen bolt (indicated above) to adjust the oueed table up
and down. Adjust table, using wrench, unl bolt is set within
the middle of its guide.

Loosen the four bolts and use the two worm screws to adjust the
height of tables.

Use the four set screws on the hinge-pin to make ne adjust-
ments and to make the infeed and oueed tables parallel to the
cuerblock.

Adjust the castle nuts in relaon to the hinge adjustments
so that the cast-iron tables are even across the cuer
block.

Place the straightedge on the cuer block assembly and con-
rm that the tables are coplanar with the cuer block assem-
bly.

Measure the cast-iron to the cuerblock on the hinge-side rst and
the front side second.
NOTE: Aer each adjustment, open and close the tables, and re-
check measurements.

Once the oueed table is level and parallel to the cuer block,
use a straightedge to level the infeed table.
