Fema S Series User manual

Series S . S40-T
Panel meter for temperature signals
Panel meter for process temperature, in compact size 72 x 36 mm, and standard 14 mm digit height.
Accepts signals from Pt100 / RTD (2 and 3 wires) and thermocouples J, K, T, E, S, R, N, C, L and X. Read-
ing congurable in ºC or ºF. Manual oset congurable. Congurable cold juncon compensaon.
Sensor break detecon. Reading with 4 digit display. Fast access to alarm setpoints, ‘on power up’
funcon, congurable reading brightness. Universal AC and DC power. Up to 2 oponal modules for
output and control (relays, transistor, control SSR, analog outputs, Modbus RTU communicaons, RS-
485 ASCII, RS-232, ...) www.fema.es
Tel. [phone] inf[email protected]
User’s Manual
ELECTRONICS FOR INDUSTRIAL AUTOMATION
PANEL METERS . SIGNAL CONVERTERS . LARGE DISPLAYS
PANEL METERS
2264r08

FEMA ELECTRÓNICA . Series S . S40-T
2
1. Panel meter S40-T
Panel meter in compact 72 x 36 mm size for temperature signals
Panel meter in compact 72 x 36 mm size, for temperature signals, with
14 mm digit height. Accepts signals from Pt100 / RTD (2 and 3 wires)
and thermocouples J, K, T, E, S, R, N, C, L and X. Congurable reading
in º Celsius or º Fahrenheit. Thermocouple cold juncon compensa-
on congurable (see secon 1.11.2). Congurable oset for display
reading (see secon 1.11.2). Selectable behavior in case of sensor
break (see secon 1.11.2). Reading with 4 digits and negave sign.
Opons for output and control with 1 and 2 relays, transistor out-
puts, controls for SSR relays, isolated analog outputs, communica-
ons in Modbus RTU, RS-485 ASCII and RS-232. Special opons with
4 relay outputs.
Independent alarms congurable as maximum or minimum, with 1
or 2 setpoints per alarm, hysteresis, independent acvaon and de-
acvaon delays and control for inverted relay.
Front protecon IP54. Connecons by plug-in screw terminals. For
industrial applicaons.
• ‘Fast access’ menu to selected funcons, accessible with key UP (5)
(see secon 1.11.5)
• ‘On power up’ for system protecon on rst ‘cold’ start-up (see
secon 1.11.7)
Display lters, memory for maximum and minimum reading, pass-
word protecon, 5 brightness levels.
1.1 How to order
Index
1. Panel meter S40-T . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 How to order . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Front view . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Power connecons . . . . . . . . . . . . . . . . . . . . . 3
1.5 Signal connecons - Pt100 / RTD . . . . . . . . . . . . . 3
1.6 Signal connecons - Thermocouple. . . . . . . . . . . . 3
1.7 Mechanical dimensions (mm) . . . . . . . . . . . . . . . 3
1.8 Technical specicaons . . . . . . . . . . . . . . . . . . 4
1.9 Messages and errors . . . . . . . . . . . . . . . . . . . . 5
1.10 How to operate the menus. . . . . . . . . . . . . . . . 6
1.11 Conguraon menu. . . . . . . . . . . . . . . . . . . . 7
1.11.1 Inial set-up . . . . . . . . . . . . . . . . . . . . . . 7
1.11.2 Temperature conguraon . . . . . . . . . . . . . . 7
1.11.3 Alarms . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.11.4 Display lters. . . . . . . . . . . . . . . . . . . . . . 9
1.11.5 Fast access . . . . . . . . . . . . . . . . . . . . . . . 9
1.11.6 Super fast access . . . . . . . . . . . . . . . . . . . 9
1.11.7 Menu ‘On Power Up’ . . . . . . . . . . . . . . . . . 10
1.11.8 Menu ‘Key LE’ . . . . . . . . . . . . . . . . . . . . .10
1.11.9 Funcon ‘Password’ . . . . . . . . . . . . . . . . . 10
1.11.10 Factory reset . . . . . . . . . . . . . . . . . . . . .10
1.11.11 Firmware version. . . . . . . . . . . . . . . . . . . 11
1.11.12 Brightness . . . . . . . . . . . . . . . . . . . . . . 11
1.11.13 Access to oponal modules . . . . . . . . . . . . . 11
1.12 Full conguraon menu . . . . . . . . . . . . . . . . . 12
1.13 To access the instrument . . . . . . . . . . . . . . . . .14
1.14 Modular system . . . . . . . . . . . . . . . . . . . . . .14
1.15 Precauons on installaon . . . . . . . . . . . . . . . .15
1.16 Factory conguraon . . . . . . . . . . . . . . . . . . .15
1.17 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.18 CE declaraon of conformity . . . . . . . . . . . . . . . 15
2. Output and control modules . . . . . . . . . . . . . . . . . 16
2.1 Module R1. . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2 Module T1. . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Module SSR . . . . . . . . . . . . . . . . . . . . . . . . .17
2.4 Module AO . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.5 Module RTU. . . . . . . . . . . . . . . . . . . . . . . . . 18
2.6 Module S4. . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.7 Module S2. . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.8 Modules R2, R4 . . . . . . . . . . . . . . . . . . . . . . .19
S40 T
Model Power
-
Opon 1 Others
H- - -
Opon 2
-
-R1 (1 relay)
-AO (analog output)
-RTU (Modbus RTU)
-S4 (RS-485)
-S2 (RS-232)
-T1 (1 transistor)
-SSR (1 control SSR)
- (empty)
-H (85-265 Vac/dc)
-L (11/60 Vdc,
24 Vac, 48 Vac)
-G (green led)

FEMA ELECTRÓNICA . Series S . S40-T
3
1.2 Front view
1.3 Rear view
Earth connecon - Although a
terminal is provided for earth
connecon, this connecon is
oponal. The instrument does
not need earth connecon for
correct operaon nor for com-
pliance with the security regu-
laons.
Fuse - To comply with security regulaon 61010-1, add to the power
line a protecon fuse acng as disconnecon element, easily acces-
sible to the operator and idened as a protecon device.
Power ‘H’ fuse 250 mA me lag
Power ‘L’ fuse 400 mA me lag
1.4 Power connecons
1.5 Signal connecons - Pt100 / RTD
Buon ‘UP’
Logo
Alarms
Units
Buon ‘SQ’
Buon ‘LE’
‘Conguraon menu’
(see secon 1.11)
‘Fast access‘
(see secon 1.11.5)
1.6 Signal connecons - Thermocouple
Signal
(see secon 1.5 and 1.6)
Opon 2Opon 1
Power
(see secon 1.4)
Detail of the plug-in screw terminals provided with
the instrument. The instrument is provided with all
terminals needed, both male and female.
~
~+
-
8 9 0
1.7 Mechanical dimensions (mm)
123
+
-
For Pt100 / RTD with 2 wires
For Pt100 / RTD with 3 wires
Pt100 2 wires
123
123
Pt100 3 wires
123 890
72
36
32,5
69
Panel
cut-out
18 8
80

FEMA ELECTRÓNICA . Series S . S40-T
4
Digits
number of digits 4
led 7 segments led
color red or green
digit height 14 mm
Reading
overrange 9999 with ash reading
underrange -1999 with ash reading
in case of sensor break reading ‘to_high’ or ‘to_low’ (see secon 1.11.2)
Signal ranges (see Table 1)
Accuracy at 25 ºC (see Table 1)
Thermal dri (see Table 1)
Signals accepted Pt100 / RTD (see Table 1)
thermocouples (see Table 1)
temperature scale ITS90
units ºC or ºF, congurable
Pt100 / RTD 2 or 3 wires, congurable
resoluon 1º or 0.1º, congurable
ranges (see Table 1)
max. error at 25ºC (see Table 1)
oset dri (see Table 1)
span dri* (see Table 1)
(*span dri includes oset dri)
cable compensaon automac up to 14 Ohms
readings 4 / second
Thermocouples J, K, T, E, S, R, N, C, L and X
(thermocouple X is 10 uV/ºC linear signal)
resoluon 1º
ranges (see Table 1)
max. error at 25 ºC (see Table 1)
oset dri (see Table 1)
span dri* (see Table 1)
(*span dri includes oset dri)
thermocouple CJC automac (see secon 1.11.2)
cold juncon accuracy <1.0 ºC
cold juncon dri <0.04 º/ºC
readings 3 / second
Power
power ‘H’ 85 a 265 Vac/dc
power ‘L’ 11 a 60 Vdc y 24/48 Vac
isolaon* 2500 Ve with power ‘H’
1500 Ve with power ‘L’
*all units tested during 60 seconds
consumpon <1.5 W only meter
<4.0 W meter with opons
Conguraon 3 buons front keypad
(and rear jumper)
Front protecon IP54
Output and control opons relays, analog outputs, serial communi-
caons, ... (see secon 2)
1.8 Technical specicaons
Sensor Range (en ºC) Error max.
at 25 ºC
Range (en ºF) Oset dri Span dri*
*includes oset dri
Pt100 / RTD 800 / -200 ºC <0.2 ºC 1562 / -328 ºF 0.05 º/ºC 0.10 º/ºC
Thermocouple J 1200 / -200 ºC <2 ºC 2192 / -328 ºF 0.05 º/ºC 0.20 º/ºC
Thermocouple K 1372 / -200 ºC <2 ºC 2372 / -328 ºF 0.05 º/ºC 0.20 º/ºC
Thermocouple T 400 / -200 ºC <2 ºC 752 / -328 ºF 0.02 º/ºC 0.02 º/ºC
Thermocouple E 1000 / -200 ºC <2 ºC 1832 / -328 ºF 0.05 º/ºC 0.20 º/ºC
Thermocouple S 1768 / -50 ºC <4 ºC 2282 / -58 ºF 0.20 º/ºC 0.20 º/ºC
Thermocouple R 1600 / -50 ºC <4 ºC 2912 / -58 ºF 0.20 º/ºC 0.20 º/ºC
Thermocouple N 1300 / -200 ºC <2 ºC 2372 / -328 ºF 0.05 º/ºC 0.20 º/ºC
Thermocouple C 2320 / 0 ºC <2 ºC 4192 / 32 ºF 0.02 º/ºC 0.02 º/ºC
Thermocouple L 900 / -200 ºC <2 ºC 1652 / -328 ºF 0.05 º/ºC 0.20 º/ºC
Thermocouple X 4000 / -200 ºC <2 ºC 7232 / -328 ºF 0.02 º/ºC 0.02 º/ºC
Table 1 - Technical specicaons for each sensor

FEMA ELECTRÓNICA . Series S . S40-T
5
Funcons included Secon
‘Fast access’ yes 1.11.5
Manual oset congurable 1.11.2
Thermocouple cold juncon congurable 1.11.2
Sensor break detecon congurable 1.11.2
Display lters steps 1.11.4
Memory max. and min. readings 1.11.4
Password conguraon block 1.11.9
Alarms double setpoints
acvaon delays
deacvaon delays
hysteresis
inverted relays
locked alarms
1.11.3
Display brightness 5 levels 1.11.12
‘On Power Up’ yes 1.11.7
Table 2 - Funcons included
Mechanical
mounng panel
connecons plug-in screw terminal
housing material ABS, polycarbonate (V0)
weight <150 grams
front size 72 x 36 mm
panel cut-out 69 x 32.5 mm
depth from panel 98 mm (including terminals)
Temperature
operaon from 0 to +50 ºC
storage from -20 to +70 ºC
warm-up me 15 minutes
Messages and errors
‘h.oVr’ Hardware overrange (‘h.ovr’). Input signal is higher than
the maximum signal the instrument can detect (80 mV)
‘h.udr’ Hardware underrange (‘h.udr’). Input signal is lower than
the minimum signal the instrument can detect (-30 mV).
‘d.udr’
‘d.oVr’
display underrange (‘d.udr’) / overrange (‘d.ovr’). The
instrument already displays the minimum / maximum
value possible (-1999 / 9999).
‘brk’ instrument will display ‘brk’ message in the following
cases
• when measuring Pt100 / RTD, the resistance measured
is higher than 390 Ohms (higher than 850 ºC)
• when measuring Pt100 / RTD, the third wire (sense
wire) presents an impedance higher than 15 Ohms
• when measuring thermocouples, the thermocouple cir-
cuit is open circuit
‘Err.1’ incorrect password.
‘Err.2’ at ‘oPt.X’ menu entry. Installed module is not recognized.
Table 3 - Messages and error codes
The error messages are shown on display in ash mode.
1.9 Messages and errors1.8 Technical specicaons (cont.)

FEMA ELECTRÓNICA . Series S . S40-T
6
The instrument has two menus accessible to the user :
‘Conguraon menu’ (key SQ) (<)
‘Fast access’ menu (key UP) (5)
Conguraon menu
The ‘conguraon menu’ modies the conguraon parameters to
adapt the instrument to the applicaon needs. To access the ‘con-
guraon menu’ press for 1 second the SQ (<) key. This access can
be blocked by acvang the ‘Password’ (‘PASS’) funcon. While
operang the ‘conguraon menu’, the alarm status is ‘hold’ to the
status they had before accessing the menu, and the output and con-
trol modules remain in ‘error’ state. When leaving the ‘conguraon
menu’, the instrument applies a system reset, followed by a brief
disconnecon of the alarms and the output and control modules.
Funconality is then recovered.
For a detailed explanaon on the ‘conguraon menu’ see secon
1.11, and for a full view of the ‘conguraon menu’ structure see
secon 1.12.
‘Fast access’ menu
The ‘fast access’ menu is an operator congurable menu, providing
fast and direct access to the most usual funcons of the instrument
with a single key pad stroke. Press key UP (5) to access this menu.
See secon 1.11.5 for a list of funcons eligible for ‘fast access’ in
this instrument. The ‘Password’ (‘PASS’) funcon does not block ac-
cess to this menu. Accessing and modifying parameters in the ‘fast
access’ menu does not interfere with the normal funconality of the
instrument, and it does not generate any system reset when validat-
ing the changes.
Front key pad descripon
Key SQ (<) - press the SQ (<) key for 1 second to access the ‘con-
guraon menu’. Inside the menu, the SQ (<) key funcons as a
‘ENTER’ key. It selects and accesses the menu opon currently dis-
played. At menus with numerical value entries, it validates the num-
ber displayed.
Key UP (5) - the UP (5) key gives access to the ‘fast access’ menu.
Inside the menus, it moves vercally through the dierent menu op-
ons. At menus with numerical value entries, it modies the digit
selected by increasing its value to 0, 1, 2, 3, 4, 5, 6, 7, 8, 9.
Key LE (3) - inside the menus, the LE (3) key funcons as the ‘ES-
CAPE’ key. It leaves the selected menu, and eventually, will leave the
whole menu. When leaving the ‘conguraon menu’ with the LE (3)
key, the changed parameters are acvated. At menus with numeri-
cal value entries, the LE (3) key allows to select the acve digit. To
modify the value of the selected digit use the UP (5) key.
Menu ‘rollback’
Aer 30 seconds without interacon from the operator, the instru-
ment will rollback and leave the ‘conguraon menu’ or the ‘fast ac-
cess’ menu. All changes will be discarded.
1.10 How to operate the menus
Input
Example of operaon inside the
‘conguraon menu’.
1. The SQ (<) key enters into the
‘conguraon menu’.
2. The SQ (<) key enters into the
‘InP’ opon menu.
3. The UP (5) key moves through
the menu opons.
4. The SQ (<) key selects the
desired range and returns to the
‘InP’ menu.
5. The LE (3) key leaves the ac-
tual menu level and moves to the
previous menu level.
6. The LE (3) key leaves the ‘con-
guraon menu’. Changes are ap-
plied and saved at this moment.
(2)
(3)
(3)
(3)
(3)
(3)
(4)
(4)
(4)
(4)
(5)
(5)
(5)
(5)
(3)
(3)
(6)
(6)
(1)

FEMA ELECTRÓNICA . Series S . S40-T
7
The ‘Temperature conguraon’ (‘cnF.t’) menu allows to congure
several funcons associated to the measure and working with tem-
perature signals.
• at the ‘Degree’ (‘dEG’) menu, select ‘ºc’ to measure in Celsius
degrees, or select ‘ºF’ to measure in Fahrenheit degrees.
• at the ‘Resoluon Pt100’ (‘P.rES’) menu, select the reading res-
oluon for the Pt100 / RTD. Select ‘1º’ for 1º resoluon or select
‘0.1º’ for 0.1º resoluon.
• at the ‘Reading oset’ (‘oFFS’) menu, congure a number of
counts to be added to the reading. Applies both to the measure in
Pt100 / RTD and thermocouples. This oset allows to correct read-
ing errors associated to dierent types of probes, which can not
be corrected by other means. Oset value allows for ‘±100’ display
counts.
• the ‘Thermocouple CJC’ (‘t.cJc’) menu allows to acve or deac-
vate the automac compensaon of the thermocouple cold junc-
on. When working with a real thermocouple, compensaon must
be on. In case of using an electronic thermocouple simulator, it may
be needed to deacvate the automac cold juncon compensaon.
• at the ‘on break’ (‘on.bk’) menu select the behavior of the instru-
ment in case of sensor break detecon. Select ‘to_h’ to set reading
to overrange, or select ‘to_L’ to set reading to underrange.
• at the ‘Alpha’ (‘ALPh’) menu congure the alpha for the
Pt100 / RTD. The standard values in industry are ‘385’ and ‘390’.
1.11 Conguraon menu
Press ‘SQ’ (<) for 1 second to access the ‘conguraon menu’.
For a descripon on how to operate inside the menus see secon
1.10. For a full vision of the ‘conguraon menu’ structure see
secon 1.12.
1.11.1 Inial set-up
1.11.2 Temperature conguraon
Input
Temperature
conguraon
Degrees
Degrees Celsius
Degrees Fahrenheit
Resoluon Pt100
1º resoluon
0.1º resoluon
Reading oset
Thermocouple
CJC
‘On break’
Reading to maximum
Reading to minimum
Alpha
Alpha 385
Alpha 390
Pt100 / RTD 2 wires
Pt100 / RTD 3 wires
Thermocouple J
Thermocouple K
Thermocouple T
Thermocouple E
Thermocouple S
Thermocouple R
Thermocouple N
Thermocouple C
Thermocouple L
Thermocouple X
To congure the inial set up of the instrument, select the type of
sensor to be connected to the instrument.
Access the ‘Input’ (‘InP’) menu to select the type of sensor. Opons
available are Pt100 / RTD with 2 and 3 wires, and thermocouples J, K,
T, E, S, R, N, C, L and X. Thermocouple X is a linear signal os 10 uV/ºC.

FEMA ELECTRÓNICA . Series S . S40-T
8
1.11 Conguraon menu (cont.)
Alarm 1
Setpoint
Hysteresis
Setpoint 2
Acve
Alarm type
Alarms
Acvaon delay
Deacvaon delay
The ‘Alarms’ (‘ALr’) menu congures the independent acvaon of
up to 2 relay outputs (or transistor or control SSR), installed with the
R1 (or T1 or SSR) oponal modules (see secon 2.1). For outputs up
to 4 relays, see special modules R2 and R4 at secon 2.8. The alarm
states are indicated in the front display with leds marked as ‘1’ and
‘2’.
To congure an alarm, enter into the alarm menu (‘ALr1’ or ‘ALr2’)
and congure the following parameters :
• select ‘Acve’ (‘Act’) to ‘on’
• at ‘Alarm type’ (‘TypE’) select the alarm acng as a maximum
type alarm (‘MAX’) or a minimum type alarm (‘MIn’). The maxi-
mum type alarm (or minimum type alarm) acvates when the dis-
play value is higher (or lower) than the setpoint value.
• at ‘Setpoint’ (‘SEt’) enter the value for the alarm acvaon point.
This parameter is eligible for conguraon through the ‘Fast access’
menu (see secon 1.11.5).
• congure the hysteresis value at ‘Hysteresis’ (‘hySt’). The hys-
teresis applies to the deacvaon process of the alarm. The alarm
deacvates when the reading has passed the setpoint value plus
the hysteresis value. Hysteresis helps to avoid repeve switching
of the alarm relays, due to uctuang input signals around the set-
point.
• at ‘Acvaon delay’ (‘dEL.0’) congure the delay to apply before
alarm acvaon. The acvaon delay starts counng when the set-
point value is passed. Value from 0.0 to 99.9 seconds.
• at ‘Deacvaon delay’ (‘dEL.1’) congure the delay to apply
before alarm deacvaon. The deacvaon delay starts counng
when the setpoint value plus the hysteresis value, is passed. Value
from 0.0 to 99.9 seconds.
• to work with ‘windowed alarms’ (see graphical example below)
acvate ‘Setpoint 2’ (‘SEt2’) to ‘on’ and then congure the desired
second setpoint value. Second setpoint must always be higher in
value than the rst setpoint.
• the ‘Relay inverted’ (‘r.Inv’) parameter inverts the normal relay
connecons. When set to ‘on’ the relay will be acve when alarm is
inacve. For security applicaons where an inacve relay controls
the shutdown of the system.
• the ‘Locked alarm’ (‘A.Lck’) parameter disables the automac
deacvaon of the alarm. Alarm deacvaon must be performed
manually, by pressing the ‘LE’ front buon (see secon 1.11.8)
1.11.3 Alarms
Reading
Time
setpoint
hysteresis
Alarm as maximum,
no hysteresis, no delays
on
o Time
acvaon
delay
on
o
deacvaon
delay
Time
Alarm as maximum,
with hysteresis and delays
on
o Time
Alarm as minimum,
no hysteresis, no delays
Reading
Time
Setpoint 2
Setpoint 1
Alarm as minimum,
with double setpoint,
no hysteresis, no delays
on
o Time
Relay inverted
Locked alarm

FEMA ELECTRÓNICA . Series S . S40-T
9
The instrument provides several funcons associated to the reading
of the display values
• the ‘Steps’ (‘StEP’) funcon allows to dene minimum reading
steps, which will be done in steps of 1, 2, 5, 10, 20 or 50 counts.
Example - selecng a step of 20 congures the reading to change in
steps of 20 counts (‘1420’, ‘1440’, ‘1460’, ...).
• the ‘Memory of maximum’ (‘MAX’) funcon displays the maximum
reading value stored in memory. It also provides a way to reset the
value. This parameter is eligible for conguraon through the ‘Fast
access’ menu (see secon 1.11.5).
• the ‘Memory of minimum’ (‘MAX’) funcon displays the minimum
reading value stored in memory. It also provides a way to reset the
value. This parameter is eligible for conguraon through the ‘Fast
access’ menu (see secon 1.11.5).
1.11.4 Display lters
1.11 Conguraon menu (cont.)
The ‘UP’ (5) key at the front of the instrument gives access to a list
of funcons congurable by the operator. See secon 1.10 for an ex-
planaon on how to operate the ‘fast access’ menu.
The ‘Key UP (Fast access)’ (‘K.uP’) menu allows to select which func-
ons will be accessible through the ‘fast access’ menu. Select ‘on’ to
acvate each funcon.
• the ‘Setpoint 1’ (‘ALr1’) funcon allows to visualize and modify the
alarm 1 setpoint through the ‘fast access’ menu.
• the ‘Setpoint 2’ (‘ALr2’) funcon allows to visualize and modify the
alarm 2 setpoint through the ‘fast access’ menu.
• the ‘Memory of maximum’ (‘MAX’) or ‘Memory of minimum’
(‘MIn’) funcons allow to visualize the maximum or minimum read-
ing value stored in memory. To reset this value, visualize the memory
value at the ‘fast access’ menu with key UP (5) and when message
‘rSt’ is displayed, press (<) to reset.
1.11.5 Fast access
If only a single funcon is selected for the ‘fast access’ menu, press-
ing the the ‘UP’ (5) key will shortly display the funcon name and
then automacally jump to the funcon value.
1.11.6 Super fast access
Steps
Display
Memory of
maximum
Memory of
minimum
Tools Key UP
(‘Fast access’)
Memory of
maximum
Memory of
minimum
Setpoint 1
Setpoint 2

FEMA ELECTRÓNICA . Series S . S40-T
10
1.11 Conguraon menu (cont.)
The ‘On Power Up’ (‘on.Pu’) menu congures funcons to apply at
start-up. It applies only to instrument restart aer power loss. It does
not apply to instrument restart due to change in conguraon.
• parameter ‘Delay’ (‘dLAy’) assigns a waing me in seconds. The
instrument waits the congured me before starng normal func-
on. During this waing me, the display shows all decimal points on
in ash mode, all alarms are in the state dened at the ‘Alarm 1’ and
‘Alarm 1’ entries, there is no signal acquision and there is no com-
municaons or control being performed. Aer the congured me is
over, the instrument starts in normal funcon. Delay value between
0 and 200 seconds.
Applicaon - the start-up process for an automaon system implies
that dierent parts of the system (engines, actuators, controllers, ...)
have dierent start-up mes. The ‘Delay’ funcon gives me to the
instrument to wait unl the slowest part of the system is fully func-
onal before execung acons on the system (signal reading, relay
acvaon, ...)
• the ‘Alarm 1’ (‘ALr1’) and ‘Alarm 2’ (‘ALr2’) parameters allow to de-
ne the status of the alarms while the instrument is starng from a
power loss. Select ‘on’ for acve alarm, select ‘oFF’ for deacvated
alarm.
1.11.7 Menu ‘On Power Up’
At the ‘Password’ (‘PASS’) menu select a 4 digit code to block access
to the ‘conguraon menu’. Instrument conguraon will not be ac-
cessible to non authorized personnel. To acvate the ‘Password’ se-
lect ‘on’ and introduce the code.
The code will be requested when trying to access the ‘conguraon
menu’ (key ‘SQ’ (<)). The ‘fast access’ menu is not password pro-
tected.
At the ‘Factory reset’ (‘FAct’) menu, select ‘yes’ to load the default
factory conguraon for the instrument (see secon 1.16).
1.11.8 Menu ‘Key LE’
The ‘LE’ (3) key at the front of the instrument can be congured to
acvate several funcons. Only one funcon can be assigned to the
‘LE’ (3) key
• the ‘No funcon’ (‘nonE’) value assigns no funcon.
• the ‘Alarm unlock’ (‘A.Lck’) value assigns the manual unlock of the
alarms funcon, for instruments with the ‘Locked alarms’ (‘A.Lck’)
funcon acvated (see secon 1.11.3)
Password
Factory reset
Key LE
Alarm unlock
No funcon
On Power-Up Delay Seconds
Alarm 1
Alarm 2
1.11.9 Funcon ‘Password’
1.11.10 Factory reset

FEMA ELECTRÓNICA . Series S . S40-T
11
1.11 Conguraon menu (cont.)
The ‘Version’ (‘VEr’) menu informs of the current rmware version
installed in the module.
At the ‘Brightness’ (‘LIGh’) menu select the light intensity for the
front leds. With this funcon it is possible to adapt the instrument to
the environment light intensity.
1.11.11 Firmware version
Menus ‘OPt.1’ and ‘OPt.2’ give access to the ‘conguraon menus’
of the output and control modules installed at slots Opt.1 and Opt.2.
See secon 2 for a list of output and control modules available for
each slot. The ‘conguraon menu’ of each module is described at
the User’s Manual of each module.
1.11.12 Brightness
1.11.13 Access to oponal modules
Opon 1
Conguraon menu for the module installed at Opt.1
Opon 2
Conguraon menu for the module installed at Opt.2
Version
Minimum
Brightness
Maximum
Standard

FEMA ELECTRÓNICA . Series S . S40-T
12
1.12 Full conguraon menu
Press ‘SQ’ (<) for 1 second to access the ‘Conguraon
menu’. See secon 1.11 for a descripon of each menu entry.
Steps
Display
Memory of
maximum
Memory of
minimum
Alarms
Alarm 1
Setpoint
Hysteresis
Setpoint 2
Acve
Type of alarm
Acvaon delay
Deacvaon
delay
Menu for Alarm 2
Inverted relay
Locked alarm
Pt100 / RTD 2 wires
Pt100 / RTD 3 wires
Thermocouple J
Thermocouple K
Input
Temperature
conguraon
Thermocouple T
Thermocouple E
Thermocouple S
Thermocouple R
Thermocouple N
Thermocouple C
Thermocouple L
Thermocouple X
Degrees
Degrees Celsius
Degrees Fahrenheit
Resoluon Pt100
1º resoluon
0.1º resoluon
Reading oset
Thermocouple
CJC
‘On break’
Reading to maximum
Reading to minimum
Alpha
Alpha 385
Alpha 390

FEMA ELECTRÓNICA . Series S . S40-T
13
1.11 Full conguraon menu (cont.)
Opon 1
Conguraon menu for the module installed at Opt.1
Opon 2
Conguraon menu for the module installed at Opt.2
Minimum
Brightness
Maximum
Standard
Tools Key UP
(fast access)
Memory of
maximum
Memory of
minimum
Setpoint 1
Setpoint 2
Password
Firmware version
Factory reset
Key LE
Alarm lock
no funcon
On Power-Up Delay Seconds
Alarm 1
Alarm 2

FEMA ELECTRÓNICA . Series S . S40-T
14
1.13 To access the instrument
1.14 Modular system
Series S panel meters are designed to create a modular system. This
modular system allows for addion, replacement or substuon of
any of the internal modules conforming the instrument. Below is a
graphic explanaon for the posion of each module.
Risk of electric shock. Removing the front cover will
grant access to the internal circuits. Disconnect the
input signal to prevent electric shock to the operator.
Operation must be performed by qualied personnel
only.
You may need to access the inside of the instrument to add or re-
place internal modules. Use a at screwdriver to unlock the upper
clips marked with ‘A’. Then unlock the lower clips marked with ‘B’ and
remove the front cover. Let the inside of the instrument slide out of
the housing.
To reinsert the instrument make sure that all modules are correctly
connected to the pins on the display module. Place all the set into
the housing, assuring that the modules correctly t into the internal
guiding slides of the housing. Once introduced, place again the front
cover by clipping rst the upper clips ‘A’ and then the lower clips ‘B’.
A
B
Front Filter Display Module Oponal Control Modules
Input Signal Module
Housing
Power Supply Module
Opt.2
Opt.1

FEMA ELECTRÓNICA . Series S . S40-T
15
1.15 Precauons on installaon
1.16 Factory conguraon
1.17 Warranty
1.18 CE declaraon of conformity
This instrument is warranted against all manufacturing defects for a
period of 24 MONTHS from the shipment date. This warranty does
not apply in case of misuse, accident or manipulaon by non-autho-
rized personnel. In case of malfuncon get in contact with your local
provider to arrange for repair. Within the warranty period and aer
examinaon by the manufacturer, the unit will be repaired or subs-
tuted when found to be defecve. The scope of this warranty is lim-
ited to the repair cost of the instrument, not being the manufacturer
eligible for responsibility on addional damages or costs.
Sensor Pt100 / RTD 2 wires
Temperature conguraon
Pt100 / RTD resoluon 0.1º
Reading oset 0 counts
Thermocouple CJC on
On break to_h
Alpha 385
Symbol ‘º’ oFF
Alarms 1 and 2
Acve o (disabled)
Type alarm as maximum
Setpoint 1000
Hysteresis 0 counts
Acvaon delay 0.0 seconds
Deacvaon delay 0.0 seconds
Setpoint 2 o
Inverted relay o
Locked alarms o
Display
Steps o
Maximum memory -1999
Minimum memory 9999
Tools
‘Fast access’ o
‘On power-up’
Delay 0 seconds
Alarm 1 o
Alarm 2 o
Key LE no funcon
Password o
Brightness 3
This instrument has been designed and veried conforming to the 61010-1 CE Security
Regulaon, for industrial applicaons.
Installaon of this instrument must be performed by qualied personnel only. This manual
contains the appropriate informaon for the installaon. Using the instrument in ways not
specied by the manufacturer may lead to a reducon of the specied protecon level.
Disconnect the instrument from power before starng any maintenance and / or instal-
laon acon.
The instrument does not have a general switch and will start operaon as soon as power is
connected. The instrument does not have protecon fuse, the fuse must be added during
installaon.
The instrument is designed to be panel mounted. An appropriate venlaon of the in-
Risk of electrical shock. Instrument terminals can be connected
to dangerous voltage.
Instrument protected with double isolaon. No earth connecon
required.
Instrument conforms to CE rules and regulaons.
strument must be assured. Do not expose the instrument to excess of humidity. Maintain
clean by using a humid rag and do NOT use abrasive products such as alcohols, solvents,
etc.
General recommendaons for electrical installaons apply, and for proper funconality
we recommend : if possible, install the instrument far from electrical noise or magnec
eld generators such as power relays, electrical motors, speed variators, ... If possible, do
not install along the same conduits power cables (power, motor controllers, electrovalves,
...) together with signal and/or control cables.
Before proceeding to the power connecon, verify that the voltage level available matches
the power levels indicated in the label on the instrument.
In case of re, disconnect the instrument from the power line, re alarm according to local
rules, disconnect the air condioning, aack re with carbonic snow, never with water.
Manufacturer FEMA ELECTRÓNICA, S.A.
Almira 14 - Pol. Ind. Sanga
E08210 - Barberà del Vallès
BARCELONA - SPAIN
www.fema.es - inf[email protected]
Products S40-T
The manufacturer declares that the instruments indicated comply with the
direcves and rules indicated below.
Electromagnec compability direcve 2014/30/EU
Low voltage direcve 2014/35/EU
Direcve ROHS 2011/65/EU
Security rules EN-61010-1
Instrument Fixed
Permanently connected
Polluon degree 1 and 2 (without condensaon)
Isolaon Double
Electromagnec compability rules EN-61326-1
EM environment Industrial
Immunity levels
EN-61000-4-2 By contact ±4 KV Criteria B
By air ±8 KV Criteria B
EN-61000-4-3 Criteria A
EN-61000-4-4 On AC power lines : ±2 KV Criteria B
On DC power lines : ±2 KV Criteria B
On signal lines : ±1 KV Criteria B
EN-61000-4-5 Between AC power lines ±1 KV Criteria B
Between AC power lines and earth ±2 KV Criteria B
Between DC power lines ±1 KV Criteria B
Between DC power lines and earth ±2 KV Criteria B
Between signal lines and earth ±1 KV Criteria B
EN-61000-4-6 Criteria A
EN-61000-4-8 30 A/m at 50/60 Hz Criteria A
EN-61000-4-11 0 % 1 cycle Criteria A
40 % 10 cycles Criteria A
70 % 25 cycles Criteria B
0 % 250 cycles Criteria B
Emission levels
CISPR 11 Instrument Class A, Group 1 Criteria A
Barberà del Vallès November 2017
Xavier Juncà - Product Manager
According to direcve 2012/19/EU, electronic equip-
ment must be recycled in a selecve and controlled
way at the end of its useful life.

FEMA ELECTRÓNICA . Series S . S40-T
16
2. Output and control modules
2.1 Module R1
The T1 module provides 1 transistor output to install at digital panel
meters from Series S, up to a maximum of 2 transistors in a single
meter.
Conguraon is performed from the frontal keypad of the meter, by
seng the parameters at the alarm menu. Check the parameters of
at the alarm menu for full informaon.
Transistor output is optoisolated, provides 2 terminals for connec-
on, and can switch up to 35 V and 50 mA.
Modules T1 can be ordered pre-installed into a Series S digital panel
meter, or standalone for delayed installaon, as they do not require
soldering or special conguraon.
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of output transistor
Max. voltage 35 Vdc
Max. current 50 mA
Isolaon 3500 Ve
Type of terminal plug-in screw terminal, pitch 5.08 mm
Slots allowed ‘Opt.1’, ‘Opt.2’
‘B’
‘A’
Schemac for T1 output
Opt.2Opt.1
PowerSignal
A B C A B C
The R1 module provides 1 relay output to to install at digital panel
meters from Series S, up to a maximum of 2 relays in a single meter.
Note : for more than 2 relays per instrument or larger relay density
per module, see special modules R2 and R4.
Conguraon is performed from the frontal keypad of the meter, by
seng the parameters at the alarm menu. Check the parameters of
at the alarm menu for full informaon.
Relay with 3 contacts (common, normally open, normally closed)
with up to 250 Vac switching voltage and 8 A.
Modules R1 can be ordered pre-installed into a Series S digital panel
meter, or standalone for delayed installaon, as they do not require
soldering or special conguraon.
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of relay 3 contact relay (NC, NO, common)
Current maximum 8 A per relay (resisve load)
Voltage maximum* 250 Vac connuous
Isolaon 3500 Ve
Type of terminal plug-in screw terminal, pitch 5.08 mm
Slots allowed ‘Opt.1’, ‘Opt.2’
Terminal A Common
Terminal B NO - Normally open
Terminal C NC - Normally closed
Opt.2Opt.1
PowerSignal
A B C A B C
2.2 Module T1

FEMA ELECTRÓNICA . Series S . S40-T
17
2.3 Module SSR
Opt.2Opt.1
PowerSignal
A B C
M V A B C
M V
Output ranges 4/20 mA acve, 4/20 mA passive 0/10 Vdc
Accuracy (at 25 ºC) <0.1% FS
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’
The AO module provides 1 analog output with 4/20 mA or 0/10 Vdc
congurable output range. Output current loop congurable as ac-
ve (the instrument provides the excitaon for the loop) or passive
(the loop is externally powered). Signal output proporonal to the
instruments reading. Fully congurable scaling, in direct (posive
slope) or inverse (negave slope) scaling.
Up to a maximum of 2 analog output modules can be installed in a
single instrument, all outputs isolated between them and isolated
from the power and input signal circuits.
Conguraon from instrument front keypad, through menu entries
‘Opt.1’ or ‘Opt.2’, depending on the posion the module is installed.
The AO module can be ordered pre-installed into a Series S panel
meter, or standalone for delayed installaon, as it does not require
soldering or special conguraon.
Terminal A Vexc
Terminal B Signal in mA or Vdc
Terminal C GND
Jumper M closed for mA
Jumper V closed for Vdc
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
The SSR module provides 1 output to control SSR relays, to install at
digital panel meters from Series S, up to a maximum of 2 SSR con-
trols in a single meter.
Conguraon is performed from the frontal keypad of the meter, by
seng the parameters at the alarm menu. Check the parameters of
at the alarm menu for full informaon.
The module provides +15 Vdc voltage and up to 45 mA.
Modules SSR can be ordered pre-installed into a Series S digital panel
meter, or standalone for delayed installaon, as they do not require
soldering or special conguraon.
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of output to control an SSR relay
Voltage output 15 Vdc
Max. current 45 mA
Isolaon 1000 Vdc
Type of terminal plug-in screw terminal, pitch 5.08 mm
Slots allowed ‘Opt.1’, ‘Opt.2’
Schemac for SSR control module
‘B’
‘A’
Relé SSR
+15 Vdc ‘C’
Opt.2Opt.1
PowerSignal
A B C A B C
2.4 Module AO

FEMA ELECTRÓNICA . Series S . S40-T
18
Protocol ASCII
Bus type RS-485, up to 57.6 Kbps
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’
2.5 Module RTU
The S4 module provides a RS-485 communicaons module for Series
S of panel meters. ASCII protocol with ‘Master’ / ‘Slave’ architecture.
Addressable with up to 31 modules. Frames codied in represent-
able ASCII characters (codes 32 to 255), directly visible using ‘hyper-
terminal’ or similar programs.
• Congurable for direct retransmission to remote meters M60-
485 (14 mm digit height) and BDF Series (60 mm and 100 mm digit
height).
• Access to display values, alarm status, memory of maximum and
minimum, alarm setpoints, ...
Conguraon from instrument front keypad, through menu entries
‘Opt.1’ or ‘Opt.2’, depending on the posion the module is installed.
The S4 module can be ordered pre-installed into a Series S panel me-
ter, or standalone for delayed installaon, as it does not require sol-
dering or special conguraon.
Terminal B B signal from RS-485 bus
Terminal A A signal from RS-485 bus
Terminal G GND
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Protocol Modbus RTU
Funcons implemented 4 (Read_Input_Registers)
Bus type RS-485, up to 57.6 Kbps
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’
The RTU module provides a Modbus RTU communicaons module
for Series S of panel meters. The RTU module implements funcon
‘4’ (‘Read Input Registers’) of the Modbus RTU protocol, to access the
instrument registers (reading value, alarm status, memory of maxi-
mum and minimum, ...)
Conguraon from instrument front keypad, through menu entries
‘Opt.1’ or ‘Opt.2’, depending on the posion the module is installed.
The RTU module can be ordered pre-installed into a Series S panel
meter, or standalone for delayed installaon, as it does not require
soldering or special conguraon.
Terminal B B signal from RS-485 bus
Terminal A A signal from RS-485 bus
Terminal G GND
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Opt.2Opt.1
PowerSignal
B A G B A G
Opt.2Opt.1
PowerSignal
B A G B A G
2.6 Module S4

FEMA ELECTRÓNICA . Series S . S40-T
19
Opt.2Opt.1
PowerSignal
A B C D E A B C D E
Opt.2Opt.1
PowerSignal
ABCDEF GHIJKL
2.7 Module S2
Protocol ASCII
Bus type RS-232, up to 57.6 Kbps
Isolaon 1000 Vdc
Slots allowed ‘Opt.1’, ‘Opt.2’
2.8 Modules R2, R4
The R2 and R4 modules provide 2 and 4 relay outputs for Series S
panel meters. Relays with 3 contacts each, with switching capability
up to 250 V @ 6 A.
Modules R2 and R4 are installed on slot ‘Opt.1’ and are congured
from instruments front keypad, and provide setpoint conguraon,
hysteresis, independent acvaon and deacvaon delays, and sec-
ond alarm setpoint for windowed alarms.
Only one module R2 or R4 can be installed per instrument. Modules
R2 and R4 are not compable with standard R1, T1 and SSR modules.
The R2 and R4 modules can be ordered pre-installed into a Series S
panel meter, or standalone for delayed installaon, as they do not
require soldering or special conguraon.
The S2 module provides a RS-232 communicaons module for Series
S of panel meters. ASCII protocol with ‘Master’ / ‘Slave’ architecture.
Addressable with up to 31 modules. Frames codied in represent-
able ASCII characters (codes 32 to 255), directly visible using ‘hyper-
terminal’ or similar programs.
• Access to display values, alarm status, memory of maximum and
minimum, alarm setpoints, ...
Conguraon from instrument front keypad, through menu entries
‘Opt.1’ or ‘Opt.2’, depending on the posion the module is installed.
The S2 module can be ordered pre-installed into a Series S panel me-
ter, or standalone for delayed installaon, as it does not require sol-
dering or special conguraon.
Relay Common Normally Open
(NO)
Normally Closed
(NC)
relay 1 A B C
relay 2 D E F
relay 3 G HI
relay 4 J K L
Table 4 - Connecons for modules R2 and R4
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
For more informaon : hp://fema.es/docs/4254_SERIES_M-K-S_
OPTIONS_manual_i.pdf
Type of relay 3 contact relay (NC, NO, common)
Current maximum 6 A per relay (resisve load)
Voltage maximum* 250 Vac connuous
Isolaon 2500 Ve
Type of terminal plug-in screw terminal, pitch 3.81 mm
* terminals approved for 300 V (according to UL1059, groups B and
D) and 160 V (according to VDE on CAT-III and polluon degree 3).
Module R2 occupies Opt.1
Module R4 occupies Opt.1 and Opt.2
Terminal E GND
Terminal D Rx1
Terminal C Tx1
Terminal B Rx2
Terminal A Tx2
