Fenix E05R User manual

FenixE05RFlashlight

TechnicalParameters 
ANSI/PLATOFL1 Burst High Med Low

Output
400lumens 150lumens 25lumens 3lumens

Runtime
/ 55minutes* 5hours 30hours

Distance
64meters 40meters 17meters 8meters

Intensity
1046candela 412candela 72candela 15candela

ImpactResistance
1meter

Submersible
IP68
Note:Accordingto the ANSI/PLATOFL1 standard,theabovespecificationsare fromtheresults
produced by Fenix through its laboratory testing using the built‐in 320mAh Li‐polymer battery
underthetemperatureof21±3°Candhumidityof50%‐80%.Thetrueperformanceofthisproduct
mayvaryaccordingtodifferentworkingenvironments.
*The High output is measured in a total of runtime including output at reduced levels due to
temperatureorprotectionmechanisminthedesign.

ProductFeatures 
 400lumensmaximumoutput,64metersmaximumbeamdistance.

 CreeXP‐G2S3whitelightLEDwithalifespanof50,000hours.
 Built‐in320mAhLi‐polymerbattery. 
 HiddenmicroUSBchargingport.
 Metalswitchforon/offandoutputselection.
 InstantBurst.
 High‐efficiencylenswithatotalreflectivecoating.
 MadeofdurableA6061‐T6aluminum.
 PremiumtypeHAIIIhard‐anodizedanti‐abrasivefinish.
 Size:2.68''x0.60''x0.59''/68x15.3x15mm.
 Weight:0.85oz/24g.

OperatingInstruction 
On/off
Pressandholdthesideswitchfor0.5secondstoturnon/offthelight.

OutputSelection
Withthelightswitchedon,singleclickthesideswitchtocyclethroughLow→Med→High.

InstantBurst 
Pressandholdthesideswitchfor1.2secondstoenterinstantBurst,releaseitthelightwillturn
backtoLowmode.

Lock/Unlock 
Lock:withthelightswitchedoff,doubleclicktheswitchwithin0.5secondstolockthelight,the
lightwillblinktwiceonLowtoindicatelockedstatus.
Unlock:withthelightlocked,doubleclicktheswitchwithin0.5seconds,thelightwillbeunlocked
andactivatedonLow.
*Inlockedstatus,clickingorpressingtheswitchwillactivate2one‐secondblinksonLowtoindicate
lockedstatus.


Charging 
1. FirstloosenthelightbodytorevealtheMicroUSBchargingportandplugtheUSBAsocketof
thechargingcableintoanelectricaloutlet,thenconnectthemicro USBsocketof the charging
cabletothelight. 
2. Theindicatorwilldisplayredwhilechargingandwillturngreenwhenfullycharged.
3. Oncechargingiscompleted,besuretotightenthelightheadtomaintainthedustproofand
waterproofability.

Note:
1.Chargethelighttimelywhenthebatterypowergetstoolowtoensurethenormallifeofthe
battery.
2.Thenormalchargingtimeisapproximately1hourfromdepletiontofullcharging.
3.Rechargeastoredlighteveryfourmonthstomaintaintheoptimumperformanceofthebattery.

IntelligentOverheatProtection 
ThelightwillaccumulatealotofheatwhenusedatHighmodeforextendedperiods.Whenthe
lightreachesatemperatureof60°Corabove,thelightwillautomaticallystepdownafewlumens
toreducethetemperature.Whenthetemperaturedropsbelow60°C,itwillthenallowtheuser
forthereselectionofthemode. 

UsageandMaintenance 
 Disassemblingthesealedheadcancausedamagetothelightandwillvoidthewarranty.
 Lockthelighttopreventaccidentalactivationduringstorageortransportation. 
 Long‐termusecanresultinO‐ringwear.Tomaintainaproperwaterseal,replacetheringwith
anapprovedspare.

Included 
FenixE05Rflashlight,MicroUSBchargingcable,Keychain,SpareO‐ring,Usermanual,Warranty

card

Warning
 Theflashlightisahigh‐intensitylightingdevicecapableofcausingeyedamagetotheuseror
others.Avoidshiningthelightdirectlyintoanyone’seyes.
 Thisflashlightwillaccumulatealotofheatwhenusedforextendedperiods,resultingina
hightemperatureoftheflashlightshell.Payattentiontosafeusetoavoidscalding.
 Donotshineanobjectatcloserange,toavoidburningtheobjectorcausingdangerdueto
hightemperature.
 TheLEDofthisflashlightisnotreplaceable;sotheentirelightshouldbereplacedwhenthe
LEDreachestheendofitslife.
 Ifanyoftheinformationprovidedinthismanualischanged,thenewversionofthemanual
shallprevail;ifyourincludedusermanualisanoldone,itacquiescesthatwewon'tsenda
newmanual.
