ferm living Lager Trolley User manual

Assembly manual
Lager Trolley

2 3

General Instructions
PLEASE READ BEFORE INSTALLATION
WARNING:
The safety of this fitting can only be guaranteed if the following instructions are observed during both
installation and use. Please retain these instructions safely after installation.
PLEASE OBSERVE THE FOLLOWING GUIDELINES:
– Ensure that all screws are firmly tightened before using the couch.
MORE INFORMATION:
To access further information such as product overview and material descriptions, please visit our website
at www.fermliving.com. If you have any questions or comments, please do not hesitate to contact us at
[email protected].
2 3

1
Assembly Process
Place the top tray on its side on a soft surface on the floor.
Fit the side panel (A) with 3 screws, washers and bolts as shown.
Use the Allen key and tighten with a spanner
1 x Bottom tray
1 x Side panel (B) 1 x Side panel (C) 1 x Side panel (A)
1 x Top tray 18 x Screw 1 x Allen Key
18 x Washer 18 x Bolt
Box Content
4 5

1
Assembly Process
Place the top tray on its side on a soft surface on the floor.
Fit the side panel (A) with 3 screws, washers and bolts as shown.
Use the Allen key and tighten with a spanner
Assembly applies
to all screws!
4 5

2
Assembly Process
Mount the bottom tray with 3 screws, washers and bolts. (Follow step 1 for screw assembly)
3
Assembly Process
Mount the side panel (B) with 6 screws, washers and bolts.
(Follow step 1 for screw assembly)
6 7

Assembly Process
3
Assembly Process
Mount the side panel (B) with 6 screws, washers and bolts.
(Follow step 1 for screw assembly)
6 7

5
Assembly Process
Tilt the trolley up. Requires two people
4
Assembly Process
Mount the side panel (C) with 6 screws, washers and bolts.
(Follow step 1 for screw assembly)
8 9

5
Assembly Process
Tilt the trolley up. Requires two people
Assembly Process
TWO PERSON
LIFT REQUIRED
8 9
