Festool MXC User manual

사용 설명서 원본 - 충전기 3
Original operating manual - Charger 5
MXC
717973_001
Festool GmbH
Wertstraße 20
D-73240 Wendlingen
Tel.: +49 (0)7024/804-0
Telefax: +49 (0)7024/804-20608
www.festool.com
85 mm
3 mm
(3 '')
11
32
1-3
1-21-1
1
3
MXC
원본 사용 설명서
1 안전 수칙
1.1 일반 안전 수칙
경고! 본 도구와 함께 제공된 모든 안전 경고, 지침, 그림, 사양을 확인하십시오.
아래의 지침을 일부라도 준수하지 않으면 감전, 화재 및 심각한 부상을 입을 수
있습니다.
언제든지 참조할 수 있도록 모든 경고와 지침을 안전한 장소에 보관하십시오.
1.2 공구 관련 안전 수칙
–본 제품의 충전기는 안전 사용 및
위험에 대한 감독 또는 지시를 받는
경우 신체, 감각 또는 정신적 기능이
저하되거나 실제 경험 및 지식이
부족한 사람도 사용할 수 있습니다.
어린이가 전동 공구를 사용하거나
가지고 놀지 않도록 주의하십시오.
–배터리 팩이나 충전기를 열지 마십시오.
전원과 분리된 후에도 충전기 내부의
커패시터 전압은 여전히 높습니다.
–배터리 팩 고정 슬롯을 통해 금속 물체
(예: 금속 칩) 또는 액체가 기기 안으로
들어가지 않도록 주의하십시오.
–다른 제조업체의 배터리 팩으로
충전하지 마십시오. 충전기는 정품
배터리 팩을 충전하는 용도로
제작되었습니다. 다른 제조업체의
충전기로 배터리 팩을 충전하지
마십시오. 그렇지 않으면 화재 및
폭발의 위험이 있습니다.
–충전 중에는 충전기를 환기가 잘 되는
장소에 두십시오.
–배터리 팩이 습기에 노출되지 않게
하십시오.
–열기, 오일, 날카로운 물체가 케이블에
닿지 않도록 주의하십시오.
–플러그와 케이블을 정기적으로
점검하고, 손상된 경우 사고 예방을
위해 공식 AS 센터에서 교체를
요청하십시오.
2 기호
기호 의미
일반적인 위험에 대한 경고
감전 위험
사용 설명서 및 안전 표지를
확인하십시오.
가정용 쓰레기와 함께 버리지
마십시오.
3 전동 공구의 기능
[1-1] 배터리 팩
[1-2] 충전기
[1-3] LED 디스플레이
사용 설명서의 전반부에 이와 관련된 그림이 나와
있습니다.
4 기본 용도
충전기 MXC는 다음과 같은 작업에 적합합니다.
–제품 목록에 명시된 배터리 팩 충전
–BP-XS
–내부용
부적절한 사용 및 기본 용도에서 벗어난
사용에 대한 책임은 사용자에게 있습니다.
4
MXC
5 기술자료
충전기 MXC
전원 전압(입력) 220~240 V ~
주파수 50/60 Hz
충전 전압(출력) 10.8 V =
급속 충전 타입 2.8 A
충전 시간
리튬이온 1.5 Ah 약 23분
리튬이온 2.6 Ah 약 45분
허용 온도 범위 -10 °C~+40 °C
온도 모니터링 NTC 저항기
이용
안전 등급 / II
6 사용 방법
경고
미승인 전압 또는 주파수!
사고 위험
X전원 소스의 전압과 주파수가 공구의 이름판에
표시된 사양과 일치해야 합니다.
6.1 배터리 팩 충전 [1]
충전기에서 지정된 배터리 팩만 충전하십
시오(기본 사용 참조).
충전기의 LED [1-3]를 통해 작동 상태를 확인할
수 있습니다.
LED 노란색 - 연속 점등
충전기를 사용할 수 있습니다.
LED 초록색 - 빠른 점멸
배터리 팩을 최고 속도로 충전
하고 있습니다.
LED 초록색 - 느린 점멸
전류를 낮춰 배터리 팩을
80%까지 충전하고 있습니다.
LED 초록색 - 연속 점등
충전이 완료되었습니다.
LED 빨간색 - 점멸
접촉 불량, 단락, 배터리 팩
하자 등 일반적인 폴트가 발생
했습니다.
LED 빨간색 - 연속 점등
배터리 온도가 허용 범위
(0 °C~55 °C) 밖입니다.
6.2 충전기 벽 장착
충전기 MXC의 뒷면에 2개의 긴 구멍이 있습니다.
스크류 2개(예: 섕크 직경이 5 mm인 둥근 머리
또는 납작 머리 스크류)를 이용해 벽에 장착할 수
있습니다(그림 [1] 참조).
7 서비스 및 유지관리
다음 지침을 준수하십시오.
–냉각이 정상적으로 이루어질 수 있도록 공구의
환기구를 청결하고 열린 상태로 유지하십시오.
–공구, 충전기, 배터리 팩에서 접촉한 부분을
청결한 상태로 유지하십시오.
고객 서비스 및 수리
제조사 또는 서비스 센터에서만 정식 고객
서비스와 수리 서비스가 제공됩니다. 다음
주소에서 가까운 지점을 찾아보십시오.
www.festool.com/Service
EKAT
1
235
4
Festool의 정식 부품만 사용하십시오.
주문 번호 확인: www.festool.com/Service
8 액세서리
액세서리와 공구의 주문 번호는 Festool 카탈로그
또는 www.festool.com에서 확인할 수 있습니다.
9 환경
본 제품을 가정용 쓰레기와 함께 버리지
마십시오. 기기, 액세서리, 포장을 재활용
하십시오. 관련 국내 규정을 준수하십
시오.
5
MXC
Original operating instructions
1 Safety instructions
1.1 General safety instructions
WARNING! Read all safety warnings, instructions, illustrations and
specifications provided with this tool. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1.2 Machine-related safety instructions
– This charger can be operated by
persons with reduced physical, sensory
or mental capabilities or a lack of
practical experience and knowledge,
provided they are supervised or have
been instructed to use the machine
safely and understand the dangers of
machine operation. Children are not
allowed use or play with the machine.
– Do not open the battery pack or the
charger. Even after disconnection
from the mains, there is still a high
capacitor voltage inside the charger.
– Make sure that metal objects (such
as metal chips) or fluids do not enter
the machine through the battery
pack retaining slots (danger of short
circuit).
– Do not charge battery packs from
other manufacturers. The charger
is designed for charging original
battery packs only. Never charge the
battery packs in chargers from other
manufacturers. Otherwise there is a
danger of fire and explosion.
– During charging, place the charger on
a well-ventilated surface.
– Protect the machine from moisture.
– Protect the cable from heat, oil and
sharp edges.
– Check the plug and the cable regularly
and should either become damaged,
in order to avoid a hazard, have them
replaced by an authorised after-sales
service work-shop.
2 Symbols
Symbol Significance
Warning of general danger
Risk of electric shock
Read operating instructions and
safety notices!
Do not dispose of as domestic
waste.
3 Machine features
[1-1] Battery pack
[1-2] Charger
[1-3] LED display
The specified illustrations appear at the beginning
of the Operating Instructions.
4 Intended use
Charger MXC suitable
– for charging the listed battery packs:
– BP-XS
– only for internal use.
The user is liable for improper or non-
intended use.
6
MXC
5 Technical data
Charger MXC
Mains voltage (input) 220 - 240 V ~
Mains frequency 50/60 Hz
Charging voltage (output) 10.8 V =
Rapid charging typ. 2.8 A
Charging times for
LiIon 1.5 Ah approx. 23 min
LiIon 2.6 Ah approx. 45 min
Permitted operating
temperature range
-10 °C to +40 °C
Temperature monitoring via NTC-resistor
Safety class /II
6 Operation
WARNING
Unauthorised voltage or frequency!
Risk of accident
XThe mains voltage and the frequency of the
power source must correspond with the
specifications on the machine’s name plate.
6.1 Charging the battery pack [1]
Charge only battery packs that are des-
ignated for use with the charger (see
Indended use)!
The LED [1-3] on the charger indicates the re-
spective operating status of the charger.
LED yellow - lit continuously
Charger is ready to use.
LED green - flashing quickly
Charging battery pack at maxi-
mum rate.
LED green - flashing slowly
Charging battery pack to 80%
and with reduced current.
LED green - lit continuously
Charging process is charged.
LED red - flashing
General fault indicator, e.g.
incomplete contact, short cir-
cuit, defective battery pack,
etc.
LED red - lit continuously
Battery temperature is outside
permissible limit values (0 °C
to 55 °C).
6.2 Charger wall mount
The charger MXC has two elongated holes on
its back. It can be mounted on a wall using two
screws (e.g. round head or flat head screw with
shank diameter of 5 mm) (see Fig. [1]).
7 Service and maintenance
Observe the following instructions:
– Keep the air slits on the machine and the
charger free and clean to ensure adequate
cooling.
– Keep the contacts on the machine, charger and
battery pack clean.
Customer service and repair. Only
through manufacturer or service work-
shops: Please find the nearest address
at: www.festool.com/Service
EKAT
1
235
4
Use only original Festool spare parts!
Order No. at: www.festool.com/Service
8 Accessories
The order numbers of the accessories and tools
can be found in the Festool catalogue or on the
Internet under “www.festool.com”.
9 Environment
Do not dispose of electric power tools
in household waste! Recycle devices,
accessories and packaging! Observe
the valid national regulations.
경기도 의왕시 맑은내길 67, 501-2호
(오전동, 에이엘티지식산업센터)
(우) 16071
전화: 02-6022-6740
팩스: 02-6022-6799
http://www.festool.co.kr
Gyeonggi-do, Uiwang-si Clear No. 67, 501-2
(AM East, ADT Knowledge Industrial Center)
(R) 16071
phone: 02-6022-6740
fax: 02-6022-6799
http://www.festool.co.kr
