Festool KF 5 EBQ User manual

468069_003
Originalbetriebsanleitung/Ersatzteilliste 6
Original operating manual/Spare parts list 12
Notice d’utilisation d’origine/Liste de pièces de rechange 18
Manual de instrucciones original/Lista de piezas de repuesto 24
Istruzioni per l'uso originali/Elenco parti di ricambio 30
Originele gebruiksaanwijzing/Lijst met reserveonderdelen 36
Originalbruksanvisning/Reservdelslista 42
Alkuperäiset käyttöohjeet/Varaosaluettelo 47
Original brugsanvisning/Reservedelsliste 52
Originalbruksanvisning/Reservedelsliste 57
Manual de instruções original/Lista de peças sobresselentes 62
   /   68
Originál návodu k obsluze/Seznam náhradních díl 75
Oryginalna instrukcja eksploatacji/Lista czci zamiennych 80
KF 5 EBQ

0
1-12
1-14
1-11
1-10
1-4
1-5
1-6
1-7
1-9
1-8
1
2
1-13
1-1 1-2 1-3

3-1
3-2
3-3
3-4
3-5
+- +-
4-3
4-2
4-1
4-4
3
4

12
KF 5 EBQ
GB
Original operating manual
The specified illustrations appear at the be-
ginning of the Operating Instructions.
1Symbols
2 Technical data
3 Intended use
The KF 5 EBQ putty cutter is designed for
puttying windows and routing wood, plastics
and similar materials. Aluminium and plas-
terboard can also be processed if used with
the corresponding cutters as specified in the
Festool catalogues.
The user bears the responsibility for
damage and accidents caused by im-
proper use.
4 Safety instructions
4.1 General safety instructions
WARNING! Read all safety warn-
ings and all instructions.
Failure to
follow the warnings and instructions may re-
sult in electric shock, fire and/or serious in-
jury.
Save all warnings and instructions for
future reference.
The term "power tool" in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
4.2 Machine-related safety instruc-
tions
– Hold power tool by insulated gripping
surfaces, because the cutter may con-
tact its own cord.
Cutting a "live" wire
may make exposed metal parts of the pow-
er tool "live" and could give the operator an
electric shock.
–
The tools must be rated for at least the
speed marked on the power tool.
Tools
running over rated speed can fly apart and
cause injury.
– The clamping collet should only be used to
clamp tools with a shank diameter appro-
priate for the collet.
– Check that the cutter is firmly fitted and
runs freely.
– The clamping collet and union nut must
show no signs of damage.
–
Never use dull or damaged mortising
bits.
Dull or damaged mortising bits can
cause the tool to lurch sideways unexpect-
1 Symbols .................................. 12
2 Technical data .......................... 12
3 Intended use............................ 12
4 Safety instructions .................... 12
5 Operation ................................ 13
6 Settings................................... 13
7 Electronics ............................... 15
8 Dust extraction......................... 15
9 Working with the machine .......... 15
10 Service and maintenance ........... 15
11 Accessories .............................. 16
12 Disposal .................................. 16
13 Warranty ................................. 16
14 EU Declaration of Conformity...... 17
Warning of general danger
Risk of electric shock
Read the Operating Instructions/
Notes!
Wear ear protection.
Wear protective goggles.
Wear a dust mask.
Wear protective gloves.
Do not throw in the household waste.
Putty Cutter KF 5 EBQ
Power 1010 W
Speed (no load) n
0
10000 -
24000 rpm
Quick height adjustment 55 mm
Fine height adjustment 8 mm
Connecting thread of the
drive shaft M16x1,5
Ø cutter, max. 30 mm
Weight (excluding cable) 3,1 kg
Safety class /II
Putty Cutter KF 5 EBQ

KF 5 EBQ
13
GB
edly and lead to a loss of control of the
power tool.
–
Wear suitable protection: such as ear
protection, safety goggles, a dust mask for
work which generates dust, and protective
gloves when working with raw materials
and when changing tools.
4.3 Emission levels
Levels determined in accordance with EN
60745 are typically:
Vibration emission value a
h
(vector sum for
three directions) and uncertainty K mea-
sured in accordance with EN 60745:
The emission values specified (vibration,
noise) were measured in accordance with the
test conditions stipulated in EN 60745 and
are intended for machine comparisons. They
are also used for making preliminary esti-
mates regarding vibration and noise loads
during operation.
The emission values specified refer to the
main applications for which the power tool is
used. If the electric power tool is used for
other applications, with other tools or is not
maintained sufficiently prior to operation,
however, the vibration and noise load may be
higher when the tool is used. Take into ac-
count any machine idling times and down-
times to estimate these values more accu-
rately for a specified time period. This may
significantly reduce the load during the ma-
chine operating period.
4.4 Metal processing
When processing metal, the following
measures must be taken for safety
reasons:
– Install an upstream residual-current cir-
cuit-breaker (FIG, PRCD).
– Connect the machine to a suitable dust ex-
tractor.
– Regularly remove dust deposits in the mo-
tor housing.
5 Operation
Always switch the machine off before
connecting or disconnecting the mains
lead!
Connecting and detaching the mains power
cable -> see Fig. [2].
The switch [1-4] is an on/off switch (press =
ON, release = OFF).
The locking button [1-3] can be engaged to
operate in continuous mode. Press the switch
again to release the knob.
6 Settings
Sound pressure level L
PA
= 78 dB(A)
Noise level L
WA
= 89 dB(A)
Measuring uncertainty
allowance K = 3 dB
CAUTION
Operating noise
Damage to hearing
X Use ear protection!
Vibration emission level
(3 directions) a
h
= 4,5 m/s
2
K = 2,0 m/s
2
Front handle a
h
= 6,5 m/s
2
K = 2,0 m/s
2
Wear protective goggles.
WARNING
Unauthorised voltage or frequency!
Risk of accident
X The mains voltage and the frequency of
the power source must correspond with
the specifications on the machine's name
plate.
X In North America, only Festool machines
with the voltage specifications 120 V/60
Hz may be used.
WARNING
Risk of injury, electric shock
X Always pull the plug out of the socket be-
fore performing any type of work on the
machine!

14
KF 5 EBQ
GB
6.1 Changing tools
You can turn the machine upside down when
changing the tool.
When loosening or tightening the locking nut
[1-10] with a 22 mm open-ended spanner,
press on the locking head [1-11] to arrest
the motor spindle.
Range of milling cutters for a wide vari-
ety of applications
Festool offers a range of practical milling cut-
ters for a wide variety of cutting work. For
further information, see the range of milling
cutters in the Festool brochure.
Clamp the end-milling cutter by means of
the clamping collet and locking nut:
X To fit the clamping collet, it is advisable to
adjust the putty cutter to maximum mill-
ing depth and arrest it by means of the
clamp knob [1-13].
X Insert the clamping collet [3-2] in the mo-
tor spindle [3-1], and tighten the locking
nut lightly by hand [3-3 --> + ].
X Insert the end-milling cutter into the
clamping collet, and tighten the locking
nut with a 22 mm open-end ed spanner.
Slot and rebating cutters have a tapered
shank [3-4], and are secured by means of a
locking nut [3-5]:
X Turn the locking nut on the cutter down to
the start of the shaft [3-5 --> - ].
X Insert the tapered shank into the motor
spindle, and tighten the locking nut with a
22 mm open-end ed spanner [3-5 --> +].
6.2 Setting the milling depth
The milling depth is adjusted in three stages:
Setting the zero point
X Open the clamping lever [1-6] so that the
stop cylinder [1-7] can move freely.
X Place the router with router table onto a
smooth surface. Open the rotary knob [1-
13] and press the machine down until the
milling cutter rests on the base.
X Clamp the machine in this position by
tightening the rotary knob [1-13].
X Press the stop cylinder against one of the
three sensing stops of the pivoted turret
stop [1-9].
The individual height of each sensing stop
can be adjusted with a screwdriver:
X Push the pointer [1-14] down so that it
shows 0 mm on the scale [1-12].
Setting the milling depth
The desired milling depth can be set either
with the quick depth adjustment or with the
fine depth adjustment.
Quick depth adjustment
X Pull the stop cylinder [1-7] up until the
pointer shows the desired milling depth.
X Clamp the stop cylinder in this posi tion
with the clamping lever [1-6].
Fine depth adjustment
X Clamp the stop cylinder with the clamping
lever [1-6].
X Set the desired milling depth by turning
the adjusting wheel [1-5] in.
Turn the adjusting wheel to the next mark on
the scale to adjust the milling depth by 0.1
mm. One full turn adjusts the milling depth
by 1 mm. The maximum adjustment range
with the adjust ing wheel is 8 mm.
Increasing the milling depth
X Open the rotary knob [1-13] and press
the tool down until the stop cylinder
touches the sensing stops.
X Clamp the machine in this position by
tightening the rotary knob [1-13].
6.3 Adjustable glass rest and splin-
ter guard
For the renovation of windows with the
glass in place
, a glass rest [4-1] is used to
support the machine on the glass.
In order to prevent scratches, this has a
coating on its bearing surface.
CAUTION
Hot and sharp tools
Risk of injury
X Wear protective gloves!
Sensing stop min. / max. height
A 38 mm / 44 mm
B 44 mm / 54 mm
C 54 mm / 67 mm

KF 5 EBQ
15
GB
To carry out height adjustment, loosen the
rotary knob [4-2]. The freely-movable splin-
ter guard [4-3] is in contact with the shank
of the glass rest [4-4], and is always set cor-
rectly for any position of the glass rest. For
milling work in the corners of windows, the
splinter guard can be lifted by hand.
L Note: From time to time, the splinter
guard should be clean ed to free it of putty
remains, etc.
7 Electronics
– Do not use the machine when the electron-
ics are faulty because the machine may
operate at excessive speeds. An absence of
the smooth start-up function or speed con-
trol indicates that the electronics are
faulty.
The machine features full-wave electronics
with the following features:
Smooth start-up
The electronically controlled smooth start-up
ensures that the machine starts up jolt-free.
Constant speed
The motor speed remains constant through
electronic control to ensure a uniform cutting
speed even when under load.
Speed adjustment
You can regulate the speed steplessly be-
tween 10000 and 24000 rpm using the ad-
justing wheel [1-3]. This enables you to op-
timise the cutting speed to suit the material.
Temperature control
To prevent overheating, the safety electron-
ics switches the machine off when it reaches
a critical motor temperature. Let the ma-
chine cool down for approx. 3–5 minutes be-
fore using it again. The machine requires less
time to cool down if it is running, i.e. in neu-
tral position.
Brake
The KF 5 EBQ has an electronic brake which
brings the spindle with tool to a standstill
within approx. 2 seconds of the tool being
switched off.
8 Dust extraction
At the extractor connector [1-8], a Festool
mobile dust extractor with an extraction hose
diameter of 27 mm can be connected.
9 Working with the machine
Please observe all mentioned safety in-
formations and the following rules
when working:
– Always secure the workpiece in such a
manner that it cannot move while being
processed.
– Always hold the machine with two hands
on the handles [1-2; 1-13] when perform-
ing work. This reduces the risk of injury
and is a prerequisite for precise work.
For work that generates dust, wear a
dust mask.
– Always switch on the router before bring-
ing the router bit into contact with the
workpiece!
– Always advance the router in the direction
opposite to the direction of rotation of the
cutter (counter-routing).
10 Service and maintenance
WARNING
Dust hazard
X Dust can be hazardous to health. Always
work with a dust extractor.
X Always read applicable national regula-
tions before extracting hazardous dust.
WARNING
Risk of injury, electric shock
X Always disconnect the mains plug from the
socket before performing maintenance
work on the machine!
X All maintenance and repair work which re-
quires the motor housing to be opened
must only be carried out by an authorised
service workshop.

16
KF 5 EBQ
GB
The machine is equipped with special carbon
brushes. If they are worn, the power is inter-
rupted automatically and the machine comes
to a standstill.
To ensure constant air circulation, always
keep the cooling air openings in the motor
housing clean and free of blockages.
11 Accessories
Use only original Festool accessories and
Festool consumable material intended for
this machine because these components are
designed specifically for the machine. Using
accessories and consumable material from
other suppliers will most likely affect the
quality of your working results and limit any
warranty claims. Machine wear or your own
personal workload may increase depending
on the application. Protect yourself and your
machine, and preserve your warranty claims
by always using original Festool accessories
and Festool consumable material!
The order numbers of the accessories and
tools can be found in the Festool catalogue or
on the Internet under "www.festool.com".
11.1 Routing with the parallel guide
The side stop is used to guide the KF 5 EBQ
precisely against the edge of the workpiece;
the stop is fitted and adjusted as follows:
X Secure both guide rods [5-6] with the two
rotary knobs [5-3] on the side stop.
X Insert the guide rods into the grooves on
the router base to the required distance
and secure them by turning the two rotary
knobs [5-1].
This distance can be adjusted faster and
more precisely with the fine precision adjust-
ment [5-7], available as an accessory:
X Turn the adjusting screw [5-4] in the plas-
tic part of the guide.
X Clamp the guide rods with the rotating
knobs [5-5] in the precision adjustment.
X Loosen the rotating knobs [5-3] of the
parallel guide.
X Set the desired distance with the adjust-
ing screw and retighten the rotating
knobs.
11.2 Routing with the FS guide sys-
tem
The guide system, available as an accessory,
facilitates routing straight grooves.
X Fasten the guide stop [6-1] to the platen
with the guide rails [5-6] of the parallel
guide.
X Fasten the guide rail [6-3] with FSZ screw
clamps [6-4] to the workpiece.
Make sure that the safety distance X - Fig.
[6] of 5 mm between the front edge of the
guide rail and cutter or groove is ob-
served.
X Place the guide stop onto the guide rail as
shown in Fig. [6] To ensure a backlashfree
guidance of the router stop you can adjust
two guide cheeks with a screwdriver
through the side openings [6-2].
X Screw the height-adjustable support [6-
5] of the router table’s threaded bore in
such a way that the underside of the rout-
er table is parallel to the surface of the
workpiece.
12 Disposal
Do not throw the power tool in your house-
hold waste! Dispose of machines, accesso-
ries and packaging at an environmentally re-
sponsible recycling centre. Observe the valid
national regulations.
EU only: European Directive 2002/96/EC
stipulates that used electric power tools must
be collected separately and disposed of at an
environmentally responsible recycling cen-
tre.
13 Warranty
We offer a warranty for material and produc-
tion defects for all our tools in accordance
with the locally applicable legal provisions,
but for a minimum of 12 months. Within the
EU member states, the warranty period is 24
months (verification through invoice or deliv-
ery note). Damage caused by the operator,
natural wear, overloading, incorrect handling
or through the use of the equipment not
specified in the operating manual, or damage
which was known at the time of purchase, is
not covered by the warranty. Furthermore,
damage caused by the use of non-original
accessories and consumable materials (e.g.
sanding pads) is also excluded.
Complaints can only be accepted if the tool is
returned while still assembled to the supplier
or an authorised Festool Customer Service
workshop. Keep the operating manual, safe-

KF 5 EBQ
17
GB
ty instructions, spare parts list and purchase
receipt in a safe place. Otherwise the current
warranty conditions of the manufacturer
shall apply.
Note
Due to continuous research and develop-
ment work, we reserve the right to make
changes to the technical content of this doc-
umentation.
14 EU Declaration of Conformi-
ty
We declare under sole responsibility that this
product complies with the following direc-
tives and standards:
2006/42/EG, 2004/108/EG, EN 60745-1, EN
60745-2-17, EN 55014-1, EN 55014-2, EN
61000-3-2, EN 61000-3-3.
Festool GmbH
Wertstr. 20, D-73240 Wendlingen, Germany
Dr. Johannes Steimel
Head of Research, Development and Techni-
cal Documentation
10.01.2008
REACh for Festool products, its accesso-
ries and consumable materials:
REACh is a European Chemical Directive that
came into effect in 2007. As "downstream
users" and product manufacturers, we are
aware of our duty to provide our customers
with information. We have set up the follow-
ing website to keep you updated with all the
latest news and provide you with information
on all the materials used in our existing prod-
ucts:
www.festool.com/reach
Putty Cutter Serial No.
KF 5 EBQ 494101
Year of CE mark: 2006
