Fhiaba 1T User manual

53
1
1.1
1.2
2
2.1
2.2
3
3.1
3.2
3.3
3.4
3.5
3.6
4
4.1
4.2
4.3
5
5.1
5.2
5.3
6
6.1
7
7.1
8
8.1
8.2
9
9.1
9.2
9.3
9.4
9.5
10
10.1
10.2
11
12
12.1
12.2
12.3
13
13.1
13.2
14
14.1
15
15.1
15.2
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Index
Important instructions for safety and the environment
For your safety
Respect for the environment
Installation
Installation
Connection to the electrical mains
Before starting
Getting to know the appliance
Main components
Electronic Control
Main control panel
Electronic Control
Main control panel
Turning the appliance on and off
Turning on and off
How to adjust the temperature to suit various needs
Information and malfunction signals on the display
Settings and Special Functions
Customization and Language Settings
Special functions activated through the Menu
Basic settings of the Menu
Internal Layout
Internal Layout (positioning, adjustment, removal)
Lighting
Lighting
Use of the TriMode compartment
Use of the TriMode compartment
TriMode compartment
Conservation of wines
General directions
Wine conservation temperature
Time of conservation
Consumption temperature
Position of bottles
Food Conservation
Recommendations for conserving fresh food
Recommendations for conserving frozen food
Recommended times for food conservation
Care and Cleaning
Care and Cleaning
Condenser cleaning
Internal cleaning
Troubleshooting guide
Troubleshooting guide
Malfunction indications appearing on the display
Prior to calling Service
Prior to calling Service
Fhiaba Access Menu Map
Functions
Settings
USER MANUAL: Wines Cellars

54
1
1.1
B09001301
Product tested in accordante with EN62471
Risk Group 2
PRUDENZA:
NON FISSARE LA LAMPADA IN FUNZIONE.
PUÒ ESSERE DANNOSO PER GLI OCCHI.
CAUTION:
DO NOT STARE AT OPERATING LAMP.
MAY BE HARMFUL TO THE EYES.
1.2
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Make sure you dispose properly of all packing materials.
The appliance must not be disposed of with urban
waste.
Contact local waste disposal authorities for information on
the disposal of recyclable waste.
For disposal, cut the power supply cord and make it im-
possible to close the door.
During disposal, avoid damage to the refrigeration cir-
cuit.
Neither the refrigeration circuit nor the insulation contain
substances that are hazardous to the ozone layer
Notes
Suggestions for proper use
of the appliance
For your safety
Respect for the environment
Important
Instruction to prevent damage
to the appliance
Warning
Instructions for preventing
personal injury
Important instructions for safety and the environment
If this appliance is replacing an existing appliance which
must be removed or disposed of, make sure that it does not
become a dangerous trap for children by cutting its power
supply cable and rendering it impossible to close the door.
Use the same caution at the end of the lifespan of the new
appliance.
This appliance is designed to refrigerate beverages and
foods and is destined for domestic use.
The appliance must be installed by following the instruc-
tions in the Installation Guide, particular care should be
taken not to obstruct the vent openings of the appliance
and of the built-in units.
The appliance features a concentrated lighting system
with LED lamps. Do not stare into these lamps when they
are on to avoid possible eyesight damage.
This warning is also contained on the label attached to
the inside of the refrigerator door.
When the freezer is functioning do not touch the inner
surfaces in stainless steel with wet or damp hands, since
skin may stick to the very cold surfaces.
Do not use any type of electrical equipment inside of the
food conservation compartments.
When positioning the shelves, do not place fingers in the
shelf slide guides.
Do not position containers of ammable liquids near the
appliance.
Completely switch off the appliance and unplug the
power supply cable during cleaning operations. If the plug
is not easily reached, it is a good idea to disconnect the
omnipolar switch that controls the socket that the appli-
ance is connected to.
The packaging parts can be dangerous for children: do
not allow children to play with the plastic bags, plastic lm
or Styrofoam.
Any repairs must be performed by a qualified Fhiaba
Service technician.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or lack of experience
and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person re-
sponsible for their safety. Children should be supervised to en-
sure that they do not play with the appliance.
Do not damage the appliance refrigerant circuit pipes.
Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.

55
2-3
2.1 3.1
2.2
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Make sure that installation is performed correctly, adher-
ing to all of the instructions in the specic installation guide
provided with the appliance.
Installation
Connection to the electrical mains
The appliance is equipped with a Schuko type 16A plug.
It must be connected to the electrical mains by means of
a corresponding Schuko socket.
Do not use extension cords and/or multiple adapters for con-
nection.
Do not use extension cords and/or multiple adapters
for connection.
Installation
If energy is supplied through an alternative energy
power source (solar, geothermal, etc..) or if home
automation systems are installed, it is necessary
to install the Alternative Energy Kit to integrate the
unit into the power grid.
Getting to know the appliance
Congratulations for having purchased your new Fhiaba:
from now on you can use our innovative conservation sys-
tem, which will allow you to keep all of your food in the
best way possible.
This manual will answer most of your questions about the
product’s features. Should you require further information,
please check our website
www.fhiaba.com
or write us an e-mail at
[email protected].
Before calling, write down the model type and serial number
which are available on the warranty certicate and on the
rating plate located on the bottom left-hand corner of the
appliance, behind the bottom drawer and any messages
which may have appeared on the display.
[phone]

56
Cantina
TriMode
TriMode
1
1
7
8
8
9
9
10
10
11
11
12
12
2
2
3
3
5
4
5
6
6
7
Wine Cellar
Wine Cellar
3
3.2
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Before starting
Main components
1Structure in stainless steel
with aluminium trim
2Wine Cellar and TriMode
control panels with Menu
3Sliding bottle shelfs,
mounted on wheels for
easy extraction
4Cantina area control panel
5Wine Cellar
6 Frezer compartment that
can be transformed into a
refrigerator or Crisper-Fresco
compartment
(TriMode function)
7Double refrigeration system
8Temperature display
9Acoustic signals
10 Vacation function
(in Menu)
11 Innovative lighting
12 Automatic door and
drawer closure
1T Models
0T Models

57
3
TriMode
1
8
9
10
11
12
2
3
5
6
7
Wine Cellar
1
9
8
10
11
12
2
3
6
7
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
1Structure in stainless steel
with aluminium trim
2Wine Cellar and TriMode
control panels with Menu
3Sliding bottle shelfs,
mounted on wheels for
easy extraction
5Wine Cellar
6 Frezer compartment that
can be transformed into a
refrigerator or Crisper-Fresco
compartment
(TriMode function)
7Double refrigeration system
8Temperature display
9Acoustic signals
10 Vacation function
(in Menu)
11 Innovative lighting
12 Automatic door and
drawer closure
0H Models
Brilliance Models
Before starting
FridgeTriMode

58
3
3.3
3.3
Componenti principali
Componenti principali
3.4
3.3
12 34 56798
ALARM
ENTER
WINE CELLAR
UNIT LIGHT
1Unit
2Wine cellar
3Menu
4Up/down
Wine Cellar
5Display
6Up/Down
(TriMode)
7Enter
8Alarm
9Light
10 11 12 13
CANTINA HUMIDITY
10 Display
12
13
Cantina
Humidity
11 Up/Down
Cantina
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Before starting
Main control panel
Electronic Control
Allows complete shutdown and start-up of the appliance
(press for three seconds).
Allows access to the appliance functions menu.
Displays the temperature of the Wine Cellar and TriMode compart-
ments, the date and time, Menu functions and visual messages.
Allows illumination of the Wine Cellar and Cantina compartments also
when the door is closed. Once activated, the light of the top compart-
ment will automatically shut off after 6 hours.
Shows the temperature of the Cantina compartment.
Allows switching on and off only the Cantina compartment on or off
(press for three seconds).
Allows adjustment of humidity in the Wine Cellar and Cantina com-
partments to three levels: High, Medium, and Low.
Using the Up and Down keys, it is possible to change the set tempera-
ture for the Cantina compartment.
The innovative electronic control system designed by Fhiaba maintains constant temperature on the three compart-
ments and visualizes it on the control panel display. It also allows user interaction making it possible to personalize settings
of the various functions and to receive sound and/or visual messages should any malfunction occur in the appliance.
Allows switching on and off only the Wine Cellar compartment (press
for three seconds).
By selecting Up/Down the preset temperature can be changed ac-
cording to the selected function mode (freezer, refrigerator, Crisper-
Fresco) and scroll through the interactive menu.
Conrms activation or deactivation of the selections made in the
Menu.
Allows activating or deactivating the automatic ice production.
Using the Up and Down buttons, it is possible to change the set tem-
perature of the refrigerator and scroll through the interactive menu.

59
3.5
3
1
9
8
11
12
3
2
5
7
Cantina
Wine Cellar
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Before starting
Main components
0H Models
1Structure in stainless steel
with aluminium trim
2Wine Cellar control panels
with Menu
3Sliding bottle shelfs,
mounted on wheels for
easy extraction
5Wine Cellar
6 Frezer compartment that
can be transformed into a
refrigerator or Crisper-Fresco
compartment
(TriMode function)
7Double refrigeration system
8Temperature display
9Acoustic signals
11 Innovative lighting
12 Automatic door closure

60
3.6
12 34 56798
ENTER
UNIT HUMIDITY ALARM
LIGHT
1Unit
2
3Menu
4Up/down
Cantina
5Display
6
7Enter
8
Alarm
9
Light
3
Humidity
Up/Down
Wine Cellar
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Main control panel
Allows complete shutdown and start-up of the appliance
(press for three seconds).
Allows access to the appliance functions menu.
Displays the temperature of the Wine Cellar and TriMode compart-
ments, the date and time, Menu functions and visual messages.
Allows illumination of the Wine Cellar and Cantina compartments also
when the door is closed. Once activated, the light of the top compart-
ment will automatically shut off after 6 hours.
Conrms activation or deactivation of the selections made in the
Menu.
Allows activating or deactivating the automatic ice production.
Using the Up and Down buttons, it is possible to change the set tem-
perature of the refrigerator and scroll through the interactive menu.
Before starting
Allows adjustment of humidity in the Wine Cellar and Cantina com-
partments to three levels: High, Medium and Low.
Using the Up and Down keys, it is possible to change the set tempera-
ture for the Cantina compartment and scroll through the interactive
menu.

61
4
4.1 4.2
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Turning the appliance on and off
To prevent accidental modication of settings, the keypad
locks automatically after a certain period of time and the dis-
play shows the message “keypad locked”. To re-activate it,
simultaneously press the keys Menu and Up/Down (Down) for
three seconds or Menu.
At the rst start-up, if the message Standby does not appear,
it means that the appliance has already started the cooling
process. If this is the case, deactivate any possible acoustic sig-
nals by pressing the Alarm key , close the door and wait until
the set temperature is reached.
During the rst start-up, you will not be able to use the Menu to
modify factory settings until the default temperature has been
reached. It is however possible to set the time and date imme-
diately; these parameters are required to activate some of the
special functions.
If only the Cantina or Wine Cellar compartment is turned off,
the corresponding fan will continue to run independently to
prevent the formation of unpleasant odours and mould.
First start-up
Once you have turned on all of the compartments of the
appliance, you can turn off only the wine cellar compart-
ment by pressing the relevant key for three seconds.
The TriMode compartment is always on and cannot be
turned off except by completely turning off the appli-
ance.
To shut down the unit completely for cleaning or mainte-
nance, press the Unit key for three seconds.
Also take the plug out of the socket and turn off the om-
nipolar switch that powers it.
Turning off the Wine Cellar compartment
Turning the Wine Cellar compartment on again
Complete shutdown
Lengthy shutdown periods
Turning on and off
Press again for three seconds the relevant key.
When the appliance is connected to the electrical power
supply but has not yet been turned on, the display shows
the message
This is a safety message to warn that power is supplied to
the appliance, while all of the keys on the panel are off.
To switch on all the appliance compartments, press the
Unit button for three seconds.
After you have completely shut down the appliance and
unplugged it, empty it of all its contents, clean it and dry
it. Leave the doors and the drawers ajar to prevent the
formation of unpleasant odours.
To adjust the temperature in the various compartments,
use the up/down key for that compartment (see chapter
3.5).
If the “keypad locked” message appear, simultaneously
press the keys Menu and Up/Down (Down) for 3 sec-
onds or Menu .
How to adjust the temperatu-
re for suit various needs
Wines compartment
Each model has been carefully tested before leaving the
factory and is adjusted so as to ensure high performance
and low consumption.
The ideal temperature for wine conservation does howev-
er depend on the types of wine you want to conserve, the
method of conservation (Wine Cellar for conservation and
consumption, or Cantina for the conservation and aging
of prized bottles).
It also varies according to personal taste.
Please refer to the guide on wine conservation included
further ahead in this manual.
As needed, you can reset the temperatures as follows:
Cantina Compartment:
from +4° C to +18° C (from 39.2° F to 64.4° F).
The default temperature is +12° C (53.6° F).
Wine Cellar compartment:
from +4° C to +18° C (from 39.2° F to 64.4° F).
The default temperature is +10° C (50° F).
TriMode compartment
The TriMode compartment is default set to freezer mode
but it can also be set to run as a refrigerator or cooler com-
partment.
Instructions for conversion are provided in the paragraph
on special functions and settings.
As needed, you can reset the temperatures as follows:
Freezer compartment: from -15° C to -22° C (from 5° F to
-7.6° F).
The default temperature, which is recommended, is -18° (0° F)
Refrigerator compartment: from +2° C to +8° C (from 35.6°
F to 46.4° F).
Thedefaulttemperature, whichisrecommended,is +5°C(41° F).
Cooler compartment: from -2° C to +2° C (from 28.4° F to
35.6° F),
The default temperature, which is recommended, is 0° C (32° F).

62
4
4.4
5.1
5.2
ICE MAKER
ENTER
FRIDGE
UNIT
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
An integrated control system provides information through
luminous signals or text messages shown on the display.
The information signal is always displayed with a xed text
message, while a malfunction signal is shown with blinking
text.
The acoustic signal that accompanies some malfunction sig-
nals can be deactivated by pressing the Alarm key on the
main control panel.
The list of malfunction signals is located in the back of this
manual.
Turning on the appliance
The displayed temperature may vary slightly with respect to
the set temperature if the doors are continuously opened or
insertion of room temperature food or large quantities of food.
It takes 6 to 12 hours to reach the selected temperature.
Information and malfunction
signals on the display
If the “keypad locked” message appear, simultaneously press
the keys Menu and Up/Down (Down) for 3 seconds.
Customization and Language Settings
Special functions activa-
ted through the Menu
It is possible to customized the functions of your Fhiaba to
adapt it to diverse usage needs, resetting the main param-
eters (Settings) or activating special functions (Functions).
Functions are visualized on the main display by pressing the
Menu button .
The Up/Down buttons permit scrolling the available func-
tions, which can be selected by pressing the Enter button .
The display visualizes the current functioning status.
Using the Up/Down buttons , it is also possible to scroll through
the selected function, activating or deactivating by pressing
the Enter button .
This function can be activated only on models featuring a
wine cellar without internal separator. It allows to differentiate
the temperature in the upper part of the cellar (warmer and
therefore better suited to keep red wines) from the tempera-
ture in the lower part (colder and therefore better suited to
keep white wines).
This function must be activated at least 24 hours before
inserting room temperature items into the freezer, or sev-
eral hours before placing into the freezer previously frozen
items which have been subject to a slight temperature rise.
This function is automatically deactivated when the pro-
grammed time period expires.
It is possible o program timed activation of the function.
After a prolonged interruption of the electrical power, it is
necessary to reactivate the function.
To use special functions, select the Menu key and use
the Up/Down key to access the menu, conrming the se-
lection
.
How to activate
How to activate
How to deactivate
How to deactivate
How to program timed activation
Shopping TriMode
Dual Zone
To prevent an inadvertent change to the settings the keypad is
automatically locked after a certain period of time.
To re-activate the Menu function, press simultaneously the Menu
button and the Down button for at least three seconds or
just press the Menu button again for 3 seconds.
The key lock can be disabled through the specic function in
the Settings menu.
Once the function is conrmed, the display will automatically
visualize the main menu to select other functions.
At any time it is possible to return to the previous selection
through
the Menu button .
The language of the messages appearing on the display can
be changed by operating as follows:
Enter the Menu by pressing the Menu button select Set-
tings via the Up/Down buttons and conrm via Enter .
Then select the Language function and the desired lan-
guage.

63
5
5.3
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Settings and Special Functions
This function (recommended in case of prolonged absenc-
es since it allows considerable energy savings) brings the
Tri-Mode compartment temperature to - 18°C (46.4°F).
It is possible to program the duration, or it can be manually
deactivated upon re-entry after a period of absence.
This function remains active even if during the period of
absence there is a prolonged interruption of electrical
power.
It is possible to program a period from 1 to 90 days.
This function can be activated when it is necessary to cool
off beverages quickly, by placing them inside the freezer
compartment.
It is possible to select a duration of 1 to 45 minutes. A sound
signal will indicated when the optimal temperature has
been reached.
After removing the beverages, deactivate the sound sig-
nal by pressing the Alarm button .
Bottle Cooler
How to activate
How to deactivate upon re-entry
How to program the duration
How to activate
How to deactivate
How to program the duration
Vacation TriMode
The function makes it possible to comply to certain religious
observances requiring that the operation of the appliance
is not affected by the opening or closing of the doors (the
thermostatic control, the inner lighting and the ice maker
are deactivated).
Sabbath Mode (Optional)
How to activate
How to deactivate
Basic settings of the Menu
Select the Menu button and used the Up/Down button
to select .
The freezer compartment can, if required, be converted to
the refrigeration o Crisper-Fresco operating mode.
TriMode Options
How to set the Fridge function
How to set the Crisper-Fresco function
How to revert to the Freezer function
This offers the possibility to reset default factory settings
and cancels any previous changes.
Default Setting
How to reset default settings
ATTENTION: If the default settings are restored, it is necessary to
reactivate the choice of operation of the TriMode compartment in
case it was previously set as Fridge or Fresco.
Using this function it is possible to deactivate/activate the
date visualization on the display.
Show Date
How to activate the date
How to deactivate the date
The display will visualize the date in the format dd:mm:yy
(day:month:year), the day will blink. Use the Up/Down but-
tons to modify the setting, conrm with Enter to go on
to the next setting; once the year is conrmed the date will
be set.
Date
Set Date
How to set the date

64
5
6.1
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Settings and Special Functions
This function selects the display at 12 or 24 h.
Set 12/24
How to set the display to 12 h
How to set the display to 24 h
Through this function it is possible to activate/deactivate
the constant visualization of the time.
Show Time
How to activate the permanent time
How to deactivate
The display visualizes the hours and minutes in the format
hh:mm and with hh: blinking. Use the Up/Down buttons
to modify the setting and then conrm by pressing Enter
to go on to the next setting.
Once the minutes are conrmed, the time will be set.
Time
Set Time
How to set the time
The function allows selection of the language for the display
messages.
Language
Italian
English
French
German
Spanish
This function permits visualizing the temperature in Centi-
grade or Fahrenheit degrees. Normally, the appliance is
set for visualization in centigrade degrees.
Set °C/°F
How to set the temperature in Centigrade
How to set the temperature in Fahrenheit
The shelves can be easily removed for cleaning.
Remove the bottles, completely extract the shelf, tilt it up-
ward until the wheels are free of their seat and extract it.
Wine shelf
TriMode drawer
Internal Layout (positioning,
adjustment, removal)
Fixed to the slide guides with two locking nuts
to remove the drawer, unscrew the locking nuts and
remove the drawer.
to remove the inner TriMode drawer unscrew the lock-
ing nuts.
Through this function it is possible to activate/deactivate
the keypad lock.
keypad lock
keypad lock
Keypad lock
How to activate
How to deactivate

65
7-8
7.1
ICEMAKER
ENTER
FRIDGE
UNIT
ICEMAKER
ENTER
FRIDGE
UNIT
ICEMAKER
ENTER
FRIDGE
UNIT
CRISPER
8.1
8.2
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Lighting
Lighting
To provide optimum interior lighting, LED strips illuminate
the refrigerator compartment from the top and sets of LED
lights directly illuminate different areas of the refrigerator
compartment, of the Crisper-Fresco drawers and the freez-
er drawer.
In case of malfunction and/or failure of the lighting system,
you should contact an authorized Fhiaba Service Agent.
Once activated, the light of the top compartment
will automatically shut off after 6 hours.
Use of the TriMode compartment
The TriMode compartment, used in conjunction with the Wine
Cellar and Cantina compartment, allows great exibility in
the use of the appliance.
Some possible uses:
Freezer mode
Liquors, such as vodka, gin, tequila, schnapps, limoncel-
lo and the glasses to serve them
Rapid cooling of beverages, by activating the bottle cool-
er function
Storage of large amounts of ice.
Refrigerator mode
As expansion of the Wine Cellar or of the Cantina
For refrigeration of beer and soft drinks
For storage of cold dishes and snacks.
Cooler mode
For conservation of ham, salmon
gourmet preparations.
It comes without saying that, the compartment can be
used in a traditional manner. Suggestions and instructions
are provided to offer you best conservation of your food
over time in complete safety.
TriMode compartment
To fully use the capacity of the TriMode compartment:
remove the drawer
remove the top drawer
install the supports delivered with the units (on request)

66
9
Cantina
Cantina
Wine Cellar
Wine Cellar
Wine Cellar
TriMode
TriMode
9.1
9.2
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Conservation of wines
Models with Cantina and
Wine Cellar
Models with Cantina and
Wine Cellar
Models with Wine Cellar
As is known, wine can be stored for long periods of time if
this is done under the following conditions:
Suitable temperature without appreciable variations
over time
Controlled level of humidity
Protection from light
Absence of noise and vibrations
Absence of odours
Bottle kept horizontal.
All of these conditions are fully met in the Fhiaba Wine Cel-
lar.
General directions
Conservation temperature
The space offered by the Wine Cellar and Cantina com-
partments, which can be expanded as necessary by using
the TriMode compartment as a wine cellar, allows conser-
vation of your best wines at three different temperatures.
The three compartments are initially set to the following tem-
peratures:
Cantina compartment
+12° C (53.6° F) - adjustable from +4° C to +18° C (from 39,2°
F to 64,4° F)
Wine Cellar compartment
+10° C (50° F) - adjustable from +4° C to +18° C (from 39,2° F
to 64,4° F)
TriMode drawer
-18° (0° F) - adjustable from -15° C to -22° C (from 5° F to -7.6°
F)
(freezer mode)
To transform the TriMode compartment into a wine cellar
space, you must access the Menu, set it as a refrigerator
compartment, and adjust it to a temperature between +4°
C and +8° C (from 39.2° F to 46.4° F).
All the temperatures can be modied according to the
characteristics of the wines and personal preferences.
However, you should attempt to keep the temperature as
constant as possible over time.
Rapid and large-scale temperature variations can in fact
cause dilation of the liquid and early aging of the wine.
You should also avoid very low temperatures (below 4° C -
39.2° F ) which may lead to the formation of deposits and
damage the aesthetic qualities of the wine.
All the compartments offer optimal conditions and take
into account all these needs. It should however be noted
that the Cantina compartment, in particular, is thermostat-
ically controlled in a very precise manner and ensures the
utmost care and attention over time of your most prized
bottles. When the Cantina compartment is set below +10°
C (50° F) the Wine Cellar must not be set beyond +12° C
(53.6° F).

67
9
9.3
9.4
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Time of conservation
Consumption temperature
Improvement of wine over time and its duration usually de-
pends on the character of the variety and its type.
The following chart shows the best period of conservation
and aging for various types in ideal conservation condi-
tions offered by your appliance. However, you should al-
ways follow the instructions of the winemaker, especially
for ne wines.
TYPE OF WINE CONSERVATION TEMPERATURE TIME OF CONSERVATION
New wines (Vin Nouveau) from 12° to 14° C 6 months
Sweet sparkling wines from 8° to 10° C 1 year
Rosé from 10° to 14° C 1 year
Semi-sparkling wines from 10° to 12° C 1 - 2 years
Normal white wines from 10° to 14° C 1 - 2 years
Light red wines from 12° to 14° C 2 years
Dry sparkling wines from 8° to 10° C 2 years
Classic sparkling wines from 8° to 10° C 3 - 4 years
Barrique and Vigorous white wines from 8° to 12° C 3 - 5 years
Normal red wines from 14° to 16° C 3 - 5 years
Barrique and Vigorous red wines from 14° to 18° C 7 - 10 years
Straw wines or Liquorous wines from 16° to 18° C 10 - 15 years
As a general rule, white wines should be served at a tem-
perature between 10 and 12° C (50 and 53,6°F) and red
wines between 12 and 14° C (53,6 and 57,2°F).
Some wines may however be best enjoyed at higher or
lower temperatures.
You should also keep in mind that, during the summer, wine
is generally enjoyed at lower temperatures than during the
winter.
You should also consider the following:
White wines
White wines are normally not served at high temperatures,
since they are generally more acidic that red wines and not
very tannic. Therefore they are more enjoyable at low tem-
peratures.
It is preferable to serve these wines between 10° C and 14° C
(50°F and 57,2°F). Young, fresh and aromatic wines can also
be served at 10° C (50°F), while less aromatic ones are served
at 12° C (53,6°F).
Temperatures between 12° C and 14° C (53,6°F and 57,2°F)
are for soft, mature white wines that have been aged for
some years in the bottle.
Higher temperatures would favour the exaltation of the sweet
character of the wine, at the expense of the acidity and a-
vour, which are considered pleasant and desirable charac-
teristics of this type of wine.
Rosé
Rosé wine is served at the same temperature as white
wines. It should be noted that these wines may include
a certain amount of tannin and may therefore be pref-
Conservation of wines
erable at higher temperatures. Therefore, they are served
between 10° C and 12° C (50°F and 53,6°F), if young and
fresh, and between 12° C and 14° C (53,6°F and 57,2°F) if
robust and mature.
New wines (Vin Nouveau)
Due to the special processing they undergo, new vintage
wines contain a low tannin content and are therefore
more enjoyable if served between 12° C and 14° C (53,6
and 57,2°F).
Red wines
Since they contain more tannin and are less acidic, red
wines are normally served at higher temperatures.
Younger wines with less tannin are normally served be-
tween 14° C and 16° C (57,2 and 60,8°F), while more full-
bodied ones that are more tannic may be served at up to
18° C (64,4°F). Some wines that have aged for years in the
bottle, still full-bodies and tannic, may be served at 18°C
(64,4°F) or even 20° C (68°F).
Young red wines with little tannin and slightly structured
may be enjoyable at lower temperatures, between 12° C
and 14° C (53,6 and 57,2°F).
Sparkling wines
It is difcult to provide instructions to cover the wide variety
of sparkling wines in available.
As a general rule, sweeter and more aromatic sparkling
wines should be served at lower temperatures, down to 8°
C (46,4°F), whereas more tannic sparkling wines may be
served at higher temperatures, up to 14° C (57,2°F).
Dry sparkling wines are usually served between 8° C and

6868
9-10
9.5
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
The sliding shelves are made of fine wood and contoured
so as to hold bottles of the most classical traditional shape
or of the most modern design.
Whether your collection holds fine bouteilles or petit
bouteilles, they will be right at home in the Fhiaba Wine
Cellar. A special accessory, available on request, will let
you place them in an inclined position, in order to display
the labels of your most prized items.
Also Magnum bouteilles can be stored, provided you re-
move the shelf just above the one that will hold them.
If the TriMode compartment is also used as a wine cellar,
the bottles may be kept in a horizontal position, as long as
they do not move or touch one another. A special acces-
sory for this purpose may be provided on request.
Position of bottles
Conservation of wines
10° C (46,4 and 50°F).
“Classic” sparkling wines are normally served at these tem-
peratures, which may be as high as 12° C (53,6°F) for spar-
kling wines that have been aged for some time.
It is however advisable, especially for ner wines, to follow
the suggestions and recommendations of the winemaker
on the bottle.
Liqueur and straw wines
These types of wines can be served at temperatures be-
tween 16° C and 18° C (60,8 and 64,4°F), depending on
personal tastes, to attenuate the sweet taste of straw
wines, it can also be served at 10° C (50°F).
Recommendations for
preserving fresh food
Vegetables
Fruit
Packaged meat
Fresh meat, sh and poultry
Eggs
Milk, cream and fresh cheeses
Cheeses
Leftovers
Wash vegetables in cold water and dry well. Place vegetables
in vacuum packed containers, plastic containers or vegetable
bags in a Fresco Drawer.
Wash and dry fresh fruit. Pack very aromatic fruit in plastic
bags.
Fruit should be placed in the high humidity Fresco com-
partment.
Place in the refrigerator in its original packaging.
After opening, wrap the remaining food in plastic bags or
aluminum foil.
Remove the original packaging, then put in plastic bags or
containers and immediately place in the refrigerator.
Place the eggs in their package or container into the re-
frigerator without washing them. Check the “best before”
date and at any rate use the eggs within two weeks of
purchasing.
These should be kept in their original closed packaging.
Place these on refrigerator shelves and consume these
within ve days of purchase.
Place these in the Fresco drawer in their original packaging.
Once opened, close these hermetically in plastic bags or alu-
minum foil.
Let these cool off and cover hermetically with aluminum
foil or place
in sealed containers to prevent drying or the spread of
odors.

69
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Frozen food
Ice cream
Place food in plastic bags for the freezer. These bags must be
hermetically sealed against air and humidity. Do not refreeze
defrosted meat.
The rmness of ice cream depends on the quantity of
cream that it contains. In general, high-quality ice cream
has large amounts of cream, therefore a very low temper-
ature in the freezer will be necessary to maintain its rm-
ness.
Consequently, ice cream without much rmness is not nec-
essarily an indication of a temperature problem as raised
above normal levels.
Recommendations for pre-
serving frozen food
After a prolonged interruption of electrical power, once the
electrical power is reactivated, an audible signal will in-
dicate if the temperature has raised above normal levels.
In addition to this the display will show for one minute the
highest temperature detected inside the compartments, to
allow the user to decide how to better use the food items.
After one minute the display will resume normal operation,
while the Alarm button will continue to blink.
Press the Alarm button to display the highest recorded
temperatures.

70
11
70
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Fresh foods Conservation area Time
Raw meats
Large cuts Cooler Compartment 4 days
Steaks, poultry and wild game Cooler Compartment 3 days
Ground meat Cooler Compartment 1-2 days
Carpaccio Cooler Compartment Immediately
Cooked meat
Boiled meat and roasted meat Refrigerator Compartment 2 days
Meat sauce Refrigerator Compartment 6 days
Raw and cooked sh Cooler Compartment 2 days
Soups and broths Refrigerator Compartment 2 days
Pasta Refrigerator Compartment 2 days
Opened cold cuts Refrigerator Compartment 3 days
Fresh cheeses Refrigerator Compartment 2-3 days
Well protected aged cheeses Refrigerator Compartment Several months
Eggs (fresh and unwashed) Refrigerator Compartment 15 days
Opened containers Refrigerator Compartment 2-3 days
Raw vegetables (in perforated bags) Refrigerator Compartment 3-6 days
Frozen foods Conservation area Time
Beef, veal, lamb and goat Freezer Compartment (steaks) 6-12 months
Beef, veal, lamb and goat Freezer Compartment (Meat with bone) 4-6 months
Ground beef Freezer Compartment 1-2 months
Pork Freezer Compartment (Without bone) 4-6 months
Pork Freezer Compartment (With bone) 2-3 months
Ground pork Freezer Compartment 1-2 months
Meat leftovers Freezer Compartment 2-3 months
Whole chicken and turkey Freezer Compartment 8-12 months
Goose, duck and pheasant Freezer Compartment 4-8 months
Fish Freezer Compartment 1-2 months
Crustaceans Freezer Compartment 2-3 months
Cooked foods Freezer Compartment 1-2 months
Vegetables Freezer Compartment 8-12 months
Fruit Freezer Compartment 6-12 months
Desserts and cakes Freezer Compartment 2-3 months
Recommended times for food conservation

71
12
12.1
12.2
12.3
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
EN
Care and Cleaning
Care and Cleaning
Condenser cleaning
Internal cleaning
Scrupulously follow the detailed directions that can be found
in the provided kit and never use abrasive or metallic products
which could scratch and damage the satin nishing on the ap-
pliance permanently.
Before performing any sort of cleaning, disconnect the appliance
from the electrical power supply.
Make sure you do not damage the refrigerant circuit in any
way.
Do not bring cold glass parts into contact with boiling water.
Do not wash any parts of the refrigerator in a dishwashing
machine since this could damage or irreparably deform the
parts.
Clean the internal and removable parts by washing them
with a solution of lukewarm water, a small amount of dish-
washing detergent.
Rinse and dry right away.
Do not use mechanical devices or other methods to speed up
defrosting.
The edges of the condenser are sharp, therefore use adequate
protection for the hands and arms when cleaning the con-
denser.
Do not use water on the electrical parts, lights and control
panel.
To clean the parts made of steel use a microber cloth and
the sponge provided in the kit with the appliance. Always
use the cloth and sponge in the direction of the steel’s satin
nish.
Every now and then, to polish the steel, wipe with a slightly
damp microber cloth.
Do not use the sponge on aluminium parts, such as the han-
dles and the proles of the glass shelves.
You should use special care to keep the ventilation open-
ings in the appliance or in the cabinet that houses it free of
obstructions.
A ventilation grille is located either at the top of the appli-
ance or at the bottom according to the model type.
To clean it use a vacuum cleaner with a soft brush attach-
ment at maximum power, sweeping it along the vent slits. In
case of a signicant dust build up, the ventilation grille can
be removed to allow a more accurate cleaning of the lter.
Every 6 months the display shows the message “Check
Cond”, clean the condenser and press for 5 seconds the En-
ter button to reset.
Operate as follows:
Switch off the appliance by pressing the Unit button on
the main control panel for approx 3 seconds.
Wait approx 30 minutes, until the nned condenser cools
down to room temperature.
On models with ventilation at the base remove the grille
at the bottom (magnetically attached) and take it off. On
models with ventilation lift the grille as shown in the picture.
Thoroughly clean the grille and the foam lter, by means of
a vacuum cleaner and the soft brush attachment.
Clean it thoroughly from any dust build up as shown in the
picture, taking care not to damage it.
Start up the appliance again, by pressing the Unit button
on the main

72
13
72
13.1
www.fhiaba.com ∙ [email protected] ∙ Info Line 800-344222 ∙ Tel [phone] ∙ Fax [phone]
Did you leave the doors open for a long period of time?
Do the doors close perfectly?
If the doors do not close perfectly, contact your installer.
Clean the appliance completely as indicated in this man-
ual.
Hermetically cover all the food. Do not conserve food for
prolonged periods of time.
The appliance was designed to permit hermetic closure.
When the door is closed, a vacuum situation can occur: in
this case it is necessary to wait a few seconds until the pres-
sure balances before opening the door.
The Refrigerator or Freezer has frost or ice
Unpleasant odours inside the refrigerator
The doors are difcult to open
If you notice malfunctions in your appliance, use this guide
before calling Service. This guide may help you resolve the
problem yourself or could provide important information to
ensure rapid and effective service.
A malfunction is usually indicated on the display.
Problems that cannot be resolved by the user are signalled
through a malfunction code.
Is the appliance connected to the electrical power sup-
ply?
Does electrical power arrive at the electrical socket?
Is the Unit key activated?
Is the condenser clean?
Does the display show a malfunction code?
Is the temperature adjusted correctly?
Is the condenser clean?
Were the doors or drawers open for a long period of time?
Were large quantities of food recently inserted?
Bear in mind that during a very hot weather and with very
high temperatures in the room it is normal that the compres-
sor remains in operation for prolonged periods of time.
Were the doors or drawers open for a long period of time?
Were large quantities of food recently inserted?
Is the condenser clean?
Check that the doors are closed and that the food or con-
tainers do not obstruct the perfect closure of the door.
It is normal to hear noise from the fans or compressors dur-
ing the defrost phase.
Noise could be louder depending on the position of the
appliance and the surrounding environment.
If the climate is very humid, the formation of condensation
is normal. Opening the door or drawers for prolonged peri-
ods of time can contribute to the formation of condensa-
tion.
In any case, make sure that the doors are always perfectly
closed.
Malfunction message
The appliance does not work
The internal temperatures are
higher than normal
The appliance remains in function for a long
time period
If you hear strange noises
Condensation forms both inside and out
Troubleshooting guide
Troubleshooting guide
