Fieldmann Fdh 2001-e User manual

FDH 2001-E

L CTRIC HAND-H LD PLAN R OP RATING INSTRUCTIONS

Electric Hand-held Planer

INSTRUCTION MANUAL

Thank you for your purchase of the electric hand-held planer. For your personal safety,

read and understand the Instruction Manual before using. Keep the Instruction Manual in

a safe place for future reference.

CONTENTS

PICTORIAL APPENDIX ......................................................................................................................................... 3

1. GENERAL SAFETY INSTRUCTIONS ................................................................................................................ 8

2. SYMBOLS .............................................................................................................................................................. 13

3. LAYOUT .................................................................................................................................................................. 14

4. PROPER USE ........................................................................................................................................................ 14

5 BEFORE STARTING THE EQUIPMENT .......................................................................................................... 14

6. OPERATION ......................................................................................................................................................... 15

7. REPLACING THE POWER CABLE ................................................................................................................. 16

8. CLEANING, MAINTENANCE AND ORDERING OF SPARE PARTS .....................................................17

9. TECHNICAL SPECIFICATIONS .......................................................................................................................19

10. DISPOSAL .............................................................................................................................................................. 20

11. DECLARATION OF CONFORMIT .................................................................................................................21

ontents

N 8

DH 2001-E

eneral safety instructions

1. GENERAL SAFETY INSTRUCTIONS

WARNING! Carefully read the instruction manual before use.

Important safety warnings

Unpack the product carefully and be sure not to throw away any part of the package before having found all

components of the product.

Keep the product in a dry place out of reach of children.

Read all cautions and instructions. The failure to adhere to warning cautions and instructions may result in

an accident, fire and/or a serious injury.

Packaging

The product is placed in a package preventing damage during transport. This package is a raw material

therefore it can be handed-over for recycling.

Instructions for use

Before beginning to work with the machine, read the following safety rules and instructions for use. Familiarize

with operating elements and the proper use of the device. Keep the manual in a safe place for future reference.

We recommend keeping the original package including the inner packaging materials, cash voucher and

guarantee card for a period of warranty at minimum. For a case of transportation, pack the machine into the

original box from the manufacturer, thus ensuring a maximum protection of the product during a possible

transport (e.g. moving or sending into a service station)..

Note: If you hand the machine over to next persons, hand it over together with the manual. Adherence to

the attached instructions for use is a precondition for the proper use of the machine. The operation manual

includes also instructions for operation, maintenance andrepairs.

The manufacturer does not take any responsibility for accidents or damages resulting

from the failure to adhere to this manual.

L CTRIC HAND-H LD PLAN R OP RATING INSTRUCTIONS

eneral safety instructions

Carefully read, remember and keep these safety instructions

WARNING! In the use of electric machines and power tools, it is necessary to respect

and follow the following safety instructions for the reasons of protection against electric

shock, personal injury and danger of ﬁre. The term “power tool” in the instructions below

refers both to mains-operated (corded) power tool or battery-operated (cordless) power tool.

Save all warnings and instructions for future reference.

Workplace

Keep the work area clean and well lit. Cluttered or dark areas in the workplace invite

accidents. Store power tools that you don’t currently use.

Do not operate power tools in environments with danger of occurrence of a ﬁre or explosion,

such as in the presence of ﬂammable liquids, gases, or dust. Power tools create sparks

which may ignite the dust or fumes.

Keep unauthorised persons, especially children, away from the work area while operating

a power tool! Distractions can cause you to lose control over the performed activity. In no

event leave your power tool unattended. Keep the equipment away from animals.

Electrical Safety

Power tool plugs must match the mains socket outlet. Never modify the plug in any way.

Do not use any adapter plugs with earthed (grounded) power tools. Undamaged plugs and

matching outlets will reduce risk of electric shock. Damaged or fouled supply cables increase

the risk of electric shock. If the power cord is damaged, it must be replaced by a new power

cord which is available at the authorised service centre or the importer.

Avoid body contact with earthed or grounded surfaces such as pipes, radiators, cooking

ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or

grounded.

Do not expose power tools to rain or wet conditions. Never touch the power tool with wet

hands. Never wash the power tool under running water or immerse it in water.

Never use the supply cable for other than intended purposes. Never use the cord for carrying

or pulling the power tool. Never unplug the plug from the outlet by pulling the cable. Keep

electric cables away from sharp or hot objects to prevent mechanical damage.

The power tool was designed to be powered solely by alternating electric current. Always

check if the electric voltage matches the information speciﬁed in the type label of the power

tool.

Never use power tool with damaged electric cable or plug or which has been dropped or is in

any way damaged.

N 10

DH 2001-E

eneral safety instructions

If an extension cord is used, always check whether its technical parameters match the

information speciﬁed in the type label of the power tool. When operating a power tool

outdoors, use an extension cord suitable for outdoor use. If extension drums are used, these

must be rolled out to prevent overheating of the cord.

If a power tool is operated in a damp location or outdoors, its operation is only permitted if

connected to an electric circuit protected by a residual current device <30 mA. Use of residual

current device (RCD) reduces the risk of electric shock.

Hold the power tool by insulated gripping surfaces only as the cutting or drilling tool may

contact hidden wiring or its own power cord during operation.

Personal Safety

Be careful, stay alert and watch what you are doing when operating a power tool.

Concentrate on your work. Do not use a power tool while you are tired or under the inﬂuence

of drugs, alcohol or medication. A moment of inattention while operating power tools may

result in serious personal injury. Do not eat, drink and smoke while operating a power tool.

Use personal protective equipment. Always wear eye protection. Use protective equipment

corresponding to the type of work you are doing. Protective equipment such as dust mask,

non-skid safety shoes, hard hat, or hearing protection used in accordance with the working

conditions will reduce the risk of personal injury.

Prevent unintentional starting. Do not carry the power tool while it is energised or with

your ﬁnger on the switch or trigger. Ensure the switch or trigger is in the “off” position before

connecting to power source. Carrying power tools with your ﬁnger on the switch or energising

power tools that have the switch on may result in serious injuries.

Remove any adjusting key or wrench before turning the power tool on. An adjusting wrench or

a key left attached to a rotating part of the power tool may result in personal injury.

Keep proper footing and balance at all times. Do not overreach. Never overestimate your own

capabilities. Never use power tools while you are tired.

Dress properly. Wear work clothes. Do not wear loose clothing or jewellery. Keep your hair,

clothing, gloves and other part of your body away from moving or hot parts of the power tool.

Connect the equipment to dust exhaustion. If the tools are provided for the connection of dust

collection or exhaustion devices, ensure these are properly connected and used. Use of such

devices can reduce dust-related hazards.

Fix the work-piece tightly. Use a cabinet clamp or a cramp to ﬁx the work-piece you are about

to machine.

Never use power tools if you are under the inﬂuence of alcohol, drugs, medication or other

narcotic or addictive substances.

This equipment is not intended for use by persons (including children) with limited physical,

sensual or mental capacities or lack of experience or knowledge unless they are supervised

or instructed about the use of the equipment by a person responsible for their safety. Children

must be supervised to make sure they are not playing with the equipment.

L CTRIC HAND-H LD PLAN R OP RATING INSTRUCTIONS

eneral safety instructions

Power Tool Use and Maintenance

Always disconnect the power tool from the mains in case of any problem during the work,

before cleaning the power tool or its maintenance, during each transportation and after the

completion of the work! Never operate a power tool if it is damaged in any way.

Immediately stop working if the power tool generates abnormal noise or smell.

Do not overload the power tool. The power tool will operate better and safer if it is used at the

rate for which it was designed. Use correct power tool which is intended for the given activity.

The correct power tool will do the job it was designed for better and safer.

Do not use the power tool if it cannot be safely turned on and off using the control switch.

Use of such power tool is dangerous. Defective switches must be repaired by a certiﬁed

service provider.

Disconnect the tool from the power source before making any adjustments, changing

accessories or maintenance. Such preventive safety measure prevents the risk of starting the

power tool accidentally.

Store idle power tools out of the reach of children and unauthorised persons. Power tools can

be dangerous in the hands of untrained users. Store the power tools in a dry and safe place.

Keep the power tool in good condition. Check the adjustment of moving parts and their

mobility. Check for any damage to the protective guards or other parts which could affect

safe operation of the power tool. If damaged, have the power tool properly repaired before

further use. Many accidents are caused by poorly maintained power tools.

Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting

edges facilitate work, reduce the risk of injury and are easier to control. Use of accessories

other than those speciﬁed in the instructions for use could result in damage to the power tool

and cause injuries.

Use the power tool, accessories and tool bits etc. in accordance with these instructions and

in the manner intended for the particular type of power tool taking into account the working

conditions and the work to be performed. Use of the power tool for purposes other than those

the power tool was intended for could result in hazardous situations.

Use of Cordless Power Tools

Before inserting the battery, make sure the switch is in the “0-OFF” position. Inserting a battery

into a switched-on power tool could result in hazardous situations.

Charge batteries only using the chargers prescribed by the manufacturer. Using a charger

intended for other battery type could result in its damage and occurrence of ﬁre.

Use only batteries intended for particular power tool. Use of different batteries could cause

injury or occurrence of ﬁre.

If the battery is not used, keep it separately from metal objects such as clamps, keys, bolts

and other small metal items which could cause connection of one battery contact with the

other. Short-circuiting the battery could result in injury, burns or occurrence of ﬁre.

N 12

DH 2001-E

eneral safety instructions

Handle the batteries with care. Rough handling could result in leak of chemical substance

from the battery. Avoid contact with such substance and if, nonetheless, any contact occurs

wash the affected area under running water. If eyes get into contact with the chemical

substance seek immediately medical aid. Chemical substance from the battery can cause

serious injuries.

Service

Do not replace parts of the power tool, do not make any repairs or interfere in any way with

the construction of the power tool. Have your power tool repaired by qualiﬁed repair persons.

Any repair or modiﬁcation of the product without our company’s authorisation is

impermissible (it could cause injury or damage to the user).

Always have your power tool repaired in a certiﬁed service centre. Use only original or

recommended replacement parts. This will ensure that your safety and the safety of your

power tool is maintained.

L CTRIC HAND-H LD PLAN R OP RATING INSTRUCTIONS

ymbols

2. SYMBOLS

Double-insulated.

Read the Instruction Manual

attentively prior to use.

The product complies with the applicable

standards and regulations.

Use eyes protective equipment

Use ears protectiove equipment

Subjected to recycling

Wear a breathing mask.

N 14

DH 2001-E

ayout | Propeer Use | Before starting the equipment

3. LAYOUT (Figs. 1/2/3)

1. Setting knob for the chip depth

2. Dust bag

3. Safety lock-off

4. ON/OFF switch

5. Rear base plate

6. Belt cover

7. Chip ejector

8. Front base plate

10. Power cable

11. Thumb screw for step depth scale

12. Step depth scale

13. Parallel stop

4. PROPER USE

The hand-held electric planer is designed for planing, rabating and chamfering pieces of wood.

The machine is to be used only for its prescribedpurpose. Any other use is deemed to be a case of misuse.

The user / operator and not the manufacturer will be liable for any damage or injuries of any kind caused as a

result of this.

Please note that our equipment has not been designed for use in commercial, trade or industrial applications.

Our warranty will be voided if the machine is used in commercial, trade or industrialbusinesses or for equivalent

purposes.

5. BEFORE STARTING THE EQUIPMENT

Before you connect the equipment to the mains supply make sure that the data on the rating plateare identical

to the mains data.

Always pull the power plug before making adjustments to the equipment.

5.1 Adjusting the chip depth (Fig. 4/Item 1)

You can adjust the chip depth in steps of 0.1 mm from 0 to 2 mm by turning the setting knob for the chip depth (1).

Turn the setting knob for the chip depth (1) in a clockwise direction to set a greater chip depth:

Greater chip depth

L CTRIC HAND-H LD PLAN R OP RATING INSTRUCTIONS

efore starting the equipmen | Operation

Turn the setting knob for the chip depth (1) in a counter-clockwise direction to set a lower chip depth:

Lower chip depth

After ﬁnishing work, set the chip depth so that the knives are lowered and thus protected from damage. Turn the

setting knob for the chip depth to position “0” for this purpose.

5.2 Sawdust extraction (Fig. 5-6)

For an optimal sawdust extraction you can connect the supplied dust bag (2) to the hand-held electric planer.

To do so, slide the dust bag (2) into the the chip ejector (7) of the hand-held electric plane.

5.3 Parallel stop (Fig. 7/Item 13)

Use the parallel stop (13) when you want to planer parallel to the edge of the workpiece.

Fitting the parallel stop (Fig. 7)

Fasten the mount (d) of the parallel stop to the left side of the tool using the supplied thumb screw (a).

Now connect the mount (d) to the slide of the parallel stop (13).

The guide rail must always be aligned in downward direction.

Fix the distance required between the parallel stop and the edge of the workpiece.

Fasten the parts with the carriage bolt (b) and the wing nut (c).

6. OPERATION

6.1 ON/OFF switch (Fig. 8)

The hand-held electric planer comes with a safety switch which is designed to prevent accidents.

To switch on the tool press the side safety lockoff (3) and press the button switch.

Release the button switch (4) to switch off the electric plane. The button switch (4) jumps back into its

starting position.

6.2 Practical tips

Important: Only ever bring the hand-held electric planer towards the workpiece while switched on.

6.2.1 Planing surfaces

Now adjust the desired chip depth. Equip the front base plate and place the hand-held electric planer onto the

piece of wood you whish to plane. Then switch on the plane. Push to electric planer over the surface with both

hands and make sure that the both the front and the rear base plate lie ﬂat on the workpiece.

Used a low chip depth for ﬁnishing surfaces and complete several passes over the surface.

N 16

DH 2001-E

peration | Replacing the power cable

6.2.2 Chamfering edges (Fig. 9-10)

There is a V-shaped groove (a) in the front base plate that enables you to planer edges at an angle of 45° for

a smooth finish.

Switch on the tool and wait until it reaches full speed. Place the V-shaped groove (a) on the edge of the

workpiece at an angle of 45°.

Now move the electric planer along the edge of the workpiece.

To achieve a good quality result you should keep the feed speed and angle constant.

6.2.3 Planing steps (Fig. 7/11)

The planing of steps is possible with the help of the parallel stop (13).

Mount the parallel stop (13) on the left side of the tool (see section 5.3).

To mount the depth stop fasten the step depth scale (12) to the front right side of the planer housing with the

locking screw (11) (see Fig. 11).

Release the locking screw (11) and position the step depth scale (12) so that the required step depth is dis-

played. Tighten the locking screw (11) again.

Width of step:

You can set the width of the step with the parallel stop (13).

Depth of step:

We recommend you to set a cutting depth of 2 mm and to keep planing the workpiece until the required depth

of step is reached.

7. REPLACING THE POWER CABLE

If the power cable for this equipment is damaged, it must be replaced by the manufacturer or its aftersales

service or similarly trained personnel to avoid danger.

L CTRIC HAND-H LD PLAN R OP RATING INSTRUCTIONS

leaning, maintanance and ordering of spare parts

8. CLEANING, MAINTENANCE AND ORDERING

OF SPARE PARTS

Always pull out the mains power plug before starting any cleaning work.

8.1 Cleaning

Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. Wipe the

equipent with a clean cloth or blow it with compressed air at low pressure.

We recommend that you clean the device immediately each time you have ﬁnished using it.

Clean the equipment regularly with a moist cloth and some soft soap. Do not use cleaning agents or solvents;

these could attack the plastic parts of the equipment. Ensure that no water can seep into the device.

8.2 Carbon brushes

In case of excessive sparking, have the carbon brushes checked only by a qualiﬁed electrician.

Important! The carbon brushes should not be replaced by anyone but a qualiﬁed electrician.

8.3. Changing the planing knives (Fig. 12-13)

Important : Always pull the plug out of the power socket before doing any work on the equipment.

To change the planing knives, use the supplied wrench (a).

The hand-held electric planer comes with two carbide metal reversible knives. Reversible knives have two

cutting edges and can be reversed. The guide slot on the reversible knives ensures the same height setting after

a change. Replace a worn, blunt or damaged knife.

Carbide metal reversible knives cannot be resharpened.

Undo the three hexagonal screws (c) using the wrench (a) supplied and push the carbide metal reversible knife

out of the planing shaft using a piece of wood. (see Fig. 12).

Clean the knife seat before ﬁtting. Install the knives in reverse order. Check that the planing knife conforms with

both ends of the planing shaft. Always replace both knives to ensure a uniform chip depth.

Important : Before using the hand-held electric planer make sure the knives are installed securely and in

the right place.

Check the correct setting (Fig. 13)

(8) Front base plate (moving planer shoe)

(5) Rear base plate (ﬁxed planer shoe)

N 18

DH 2001-E

leaning, maintanance and ordering of spare parts

1. Correct adjustment

Result: Smooth planed surfaces

2. Notches in the surface

Problem: The cutting edge on the planing knife (or both planing knives) is not parallel to the height ofthe rear

base plate.

3. Furrows at the start of the planed surface

Problem: The cutting edge on the planing knife (or both planing knives) is below the height of the rear base plate.

4. Furrows at the end of the planed surface

Problem: The cutting edge on the planing knife (or both planing knives) is above the height of the rear base plate

8.4 Replacing the drive belt

The belt should be replaced by a trained expert.

The drive belt (b) must be replaced if it is worn.

Undo the screws (a) and remove belt cover at the sides (6).

Remove the worn belt drive (b) and clean the two belt pulleys (c/d).

Place the new drive belt on the small belt pulley (c) and pull the belt onto the large belt pulley (d) whilst turning

the planing shaft.

Ensure that the longitudinal grooves on the drive belt are in the guide grooves on the drive wheels.

Fit the belt cover (6) and secure it with the screws (a).

8.5 Maintenance

There are no parts inside the equipment which require additional maintenance..

8.6 Ordering replacement parts

Please quote the following data when ordering replacement parts:

Type of machine

Article number of the machine

Identiﬁcation number of the machine

Replacement part number of the part required

For our latest prices and information please go to www.isc-gmbh.info

L CTRIC HAND-H LD PLAN R OP RATING INSTRUCTIONS

echnical specifications

9. TECHNICAL SPECIFICATIONS

Electric hand-held planer:

Mains voltage: 230V/50Hz

Power input: 750W

Idling speed: 12 000rpm

Chip depth: 0-2mm

Rebate depth: 0-6mm

Planer width: 82mm

Protection class: II

Weight: 2.9kg

Sound and vibration

Sound and vibration values were measured in accordance with EN 60745.

LpA sound pressure level 87dB(A)

LWA sound power level 87dB(A)

Wear ear-muffs.

The impact of noise can cause damage to hearing.

Total vibration values determined in accordance with EN 60745.

Vibration emission value ah = 4.189 m/s2

Important !

The vibration value changes according to the area of application of the electric tool and may exceed the speci

ied value in exceptional circumstances.

N 20

DH 2001-E

isposal

10. DISPOSAL

INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED PACKAGING

Put any used package material to the place determined by the municipality for waste disposal.

DISPOSAL OF USED ELECTRIC AND ELECTRONIC EQUIPMEN

This symbol on products or accompanying documents means that used electric or

electronic products must not be put to ordinary municipal waste. Hand over such products

to determined collection points for proper disposal, restoration and recycling. Alternatively,

in some countries of the European Union or other European countries you can return your

products to your local dealer when you buy an equivalent new product. By dutiful disposal of

this product you can preserve precious natural resources and you help prevent any potential

adverse effects on the environment and human health which could be the results of wrong

waste disposal. Ask your local authority or the nearest collection point for additional details.

In case of improper disposal of this waste kind penalties can be imposed in accordance

with national regulations.

For companies in the European Union countries

Should you want to dispose of electric and electronic devices, ask your dealer or vendor

for necessary information.

Disposal in other countries outside the European Union

Should you want to dispose of this product, ask your local authorities or your dealer

for necessary information about disposal method

This product fulﬁls all basic requirements of the EU directives that apply to it.

Text, design and technical specifications can change without prior notice and we reserve the right for

their change.
