Filtration Group Pi 211 User manual

Translation of original instructions with installation instructions
Duplex Filter
Pi 211/Pi 2110
Mat. No. of Instruction Manual
72464548

Page 2
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
1 Table of contents
1Table of contents ....................................................... 2
2General safety instructions....................................... 2
2.1 Safety instructions for installation and
operating personnel .......................................... 2
2.2 Warning structure.............................................. 2
2.3 Warning symbols used...................................... 2
2.4 Other symbols used.......................................... 3
3Glossary...................................................................... 3
4General information ................................................... 3
4.1 Manufacturer..................................................... 3
4.2 Information about the Instruction Manual.......... 3
4.3 Negative declaration ......................................... 3
5Intended application .................................................. 4
6Functional description............................................... 4
6.1 Principle ............................................................ 4
6.2 Main components of the duplex filter ................ 5
6.3 Operating principle of a duplex filter.................. 5
7Technical data ............................................................ 6
7.1 Order-specific data............................................ 6
7.2 Technical data of the duplex filter ..................... 6
7.3 Technical data of the PiS 3111 ......................... 6
8Transport and storage ............................................... 6
9Installation .................................................................. 6
9.1 Installation......................................................... 6
9.2 Pressure relief................................................... 7
10 Start-up ....................................................................... 7
11 Normal operation ....................................................... 7
12 Troubleshooting......................................................... 7
13 Maintenance ............................................................... 7
13.1 Maintenance work on the filters ........................ 7
13.2 Inspection and maintenance schedule.............. 8
13.3 Replacing the inner assembly........................... 8
13.4 Cleaning the filter housing ................................ 9
14 Assembly drawing ................................................... 10
15 Dimensions............................................................... 12
16 Spare parts ............................................................... 12
17 Explosion drawing ................................................... 13
18 Negative declarartion............................................... 14
19 Index.......................................................................... 15
2 General safety instructions
2.1 Safety instructions for installation and
operating personnel
This Instruction Manual contains important safety
instructions which must be heeded at all times during
installation, normal operation and maintenance.
Non-observance can result in the following risks to persons
and the environment as well as in damage to the machine
or system:
Failure of critical functions of the machine or system or
of its component parts.
Danger to persons from electrical or mechanical effects
as well as from chemical reactions.
Danger to the environment owing to the leakage of
hazardous substances.
Before installation/start-up:
•Read the Instruction Manual carefully.
•Make sure that installation and operating personnel are
adequately trained.
•Make sure the contents of the Instruction Manual are
fully understood by the responsible persons.
•Define areas of responsibility and competence.
•Prepare a maintenance schedule.
During operation of the system:
•Keep the Instruction Manual handy at the place where
the system is used.
•Heed the safety instructions. Always operate the
machine/system in accordance with its ratings.
If in doubt:
•Consult the manufacturer.
2.2 Warning structure
Where possible, warnings are structured according to the
following system:
Signal word
Possibly
with
symbol
Nature and source of the danger
Potential consequences of non-
observance
•Action to avert the danger.
2.3 Warning symbols used
DANGER!
Immediate danger!
Non-observance will result in serious or fatal injury.
WARNING!
Potentially dangerous situation!
Non-observance can result in serious or fatal injury.
CAUTION!
Potentially dangerous situation!
Non-observance can result in minor or moderate
injuries.
CAUTION! (without a symbol)
Potentially dangerous situation!
Non-observance can result in property damage.

Page 3
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
2.4 Other symbols used
Danger from high voltage
Danger information about explosion
protection
Information about environmental protection
Wear protective clothing!
Wear goggles!
Wear a respirator!
Hand symbol:
Indicates general information and
recommendations

Bullet:
Indicates the order in which actions are to be
carried out

Arrow:
Indicates responses to actions
3 Glossary
Initial differential pressure
Differential pressure at the start of the filtration process
(when the filter cartridge is "clean").
Differential pressure (delta p)
Pressure difference between the dirty side and the clean
side.
Filter cartridge
Cylindrical support structure with star-pleated filter medium.
The medium to be filtered flows inward from the outside.
Solids are retained on the outer surface of the cartridge.
Filtered fluid
Substance that is filtered.
4 General information
4.1 Manufacturer
Filtration Group GmbH
Schleifbachweg 45
D-74613 Öhringen
Phone [phone]
Fax [phone]
[e-mail]
industrial.filtrationgroup.com
4.2 Information about the Instruction Manual
FG Mat. No.:........................................................72464548
Date: .....................................................................22.07.20
Version: ..........................................................................01
4.3 Negative declaration
Our fluid filtration and automatic filter products are
designed for Group 2 fluids (not dangerous) as standard as
defined by the EC Pressure Equipment Directive
2014/68/EU Article 13 and Article 4 (3), in other words a
name-plate without a CE marking is affixed to these
products. No declaration of conformity may be issued for
this reason.
According to the criteria laid down in Article 2 of the
Machinery Directive 2006/42/EC, our standard hydraulic
filters are outside the scope of this directive. Under legal
provisions, therefore, we are not allowed to affix a CE
marking, nor are we permitted to issue a declaration of
incorporation or conformity.
According to the type approval, these filters may be used in
marine applications for filtering fuels, lubricants and
hydraulic oil.
Acceptance under SOLAS is possible at any time following
the notification of the specific regulation.

Page 4
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
5 Intended application
DANGER!
Operation contrary to the intended purpose can be
dangerous!
The manufacturer is discharged from all liability and all
warranty claims are rendered invalid.
This duplex filter is only allowed to be used in
accordance with the operating conditions specified in
the contract documentation and in the Instruction
Manual.
All forms of use which deviate from or exceed the
limits of use described above are considered to be
contrary to the intended purpose.
DANGER!
Operation contrary to the intended
purpose can be dangerous!
The manufacturer is discharged from all
liability and all warranty claims are
rendered invalid.
Prohibited:
Use for other purposes without prior
consultation with the manufacturer.
Use in hazardous areas, unless
explicitly mentioned in the contract
documentation.
Use with smouldering, burning or
adhesive particles.
Use with highly explosive liquids or
pastes.
Standard design for liquid group 2 according to pressure
equipment-directive 2014/68/EU article 4 (3) and article 13.
6 Functional description
6.1 Principle
Filtration
A star-pleated cartridge is mounted on a cylindrical support
structure, whereby the filter rating is determined by the type
of cartridge. The medium flows inward through the
cartridge from the outside. Solid particles are retained. The
star pleat results in a larger effective filter surface.
Fig. 1: Separating principle on the filter cartridge
Support structure
Filter medium

Page 5
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
6.2 Main components of the duplex filter
Fig. 2: Diagram of the main components (front)
1
Vent screw (filter 1)
2
Filter cover (filter 1)
3
Filter housing (filter 1)
4
Element (filter 1)
5
Switch-over handle
6
Drain plug on dirty side of filter 1 with sealing ring
7
Drain plug on clean side of filter 1 (optional)
8
Vent screw (filter 2)
9
Filter cover (filter 2)
10
Filter housing (filter 2)
11
Element (filter 2)
12
Pressure balance valve
13
Differential pressure display unit
14
Inlet
15
Drain plug on dirty side of filter 2 with sealing ring
16
Outlet
17
Drain plug on clean side of filter 2 (optional)
6.3 Operating principle of a duplex filter
Fig. 3: Operating principle
1
Dirty liquid flows in through the inlet.
2
The medium enters on the left or right filter side, depending
on the position of the switching lever. The handle position
indicates the non-operational filter side.
3
The liquid flows through the filter cartridge to the clean
side.
4
The filtered fluid exits the duplex filter via the outlet.
5
The maintenance indicator shows when the maximum
differential pressure is reached. In addition, a visual
indication is activated and the output of the maintenance
indicator is switched. The other filter side must then be
selected by reversing the switching lever. The spent
cartridge must be exchanged and disposed of correctly.
The filtration process is not interrupted.
6
The red pin (check function) on the differential pressure
display unit must be pressed in again by hand after
switching over the filter.

Page 6
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
7 Technical data
7.1 Order-specific data
This data is order-specific and can be taken from the
name-plate.
7.2 Technical data of the duplex filter
Nominal pressure:................................................... 40 bar
Pi 211080/Pi 211110/Pi 211063/211100:
107load changes: ................................................... 40 bar
Test pressure:
Pi 211080/Pi 211110/Pi 211063/211100:
................................................................................ 60 bar
Temperature range:................................ -10°C to +120°C
Bypass setting*/**:.................................. Δp 3.5 bar ± 10%
Maintenance indicator setting*:.......... Δp 2.2 bar ± 0.3 bar
Filter head material:................................Nodular cast iron
Filter housing material: ............................................. Steel
Filter cover material: ...............................Nodular cast iron
Seal material:............................................................. NBR
7.3 Technical data of the PiS 3111
Switch: .............................. normally open/normally closed
................................................................with reed contact
Protection class: ........................................................ IP65
NO contact load:...............................................max. 70 W
.................................................. max. 250 V AC/200 V DC
............................................................................ max. 1 A
Fig. 4: Circuit diagram
*Other pressures possible if conditions deviate from
standard.
** No bypass is used when filtering fuels.
8 Transport and storage
Transport
•Always transport horizontally in the original packaging
•Avoid vibrations
Storage
•Always store horizontally in the original packaging
•Always store in a dry, frost-free room
The packaging is seaworthy and has a
non-food declaration.
9 Installation
DANGER!
Danger if work is carried out on the system
by unauthorised persons!
Risk of injury to persons or damage to
property.
The system is only allowed to be installed,
accepted and tested by a suitably qualified
person (99/98/EC).
WARNING!
Danger if work is carried out on the system by
unauthorised persons!
Risk of injury to persons or damage to property.
All installation work must be carried out by suitably
qualified personnel.
9.1 Installation
It must be possible to remove the inner
assembly in order to carry out maintenance
work.
Prepare a suitable location for installing the filter (e.g. a
trough).
Be sure to allow the required clearances for dismantling
and discharging (see drawing).
Unpack the duplex filter.
Mount the duplex filter on bottom plates (feet) on the
floor (see data sheet for dimensions).
Remove the protection caps on the connections.
Stress relief must be provided for all pipe connections to
the duplex filter.
“In” is the dirty filter side.
“Out” is the clean filter side.
Use only suitable, chemically resistant seals
for the piping.

Page 7
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
9.2 Pressure relief
Design measures must be incorporated on the clean side
to prevent inadmissible excess pressure on the dirty side or
reverse flows.
Install pressure relief and/or check valves if necessary.
Fig. 5: Mechanical installation
10 Start-up
DANGER!
The duplex filter must not be put into service until the
relevant machinery / system / motor into which it is to be
incorporated has been declared in conformity with the
applicable EC directives, harmonised standards,
European standards or equivalent national standards
Check that the protection caps have been removed from
the connections.
Carefully open the vent screw on the filter side that is to
be started up until liquid exits from it.
Recover any exiting liquids in a suitable receiver flask.
Check that the pipe connections are tight.
Tighten all screws.
Rinse the pipes.
11 Normal operation
Please always ensure that you have original
FG replacement cartridges in stock.
Disposable cartridges (Mic) cannot be
cleaned.
The following parameter must be monitored daily
during normal operation:
Differential pressure
12 Troubleshooting
Fault
Possible cause
Remedy
Warning signal
from
maintenance
indicator
Cold start
Reset the signal
after reaching
operating
temperature
Filter dirty
Replace the filter
13 Maintenance
CAUTION!
Danger if work is carried out on the system by
unauthorised persons!
Risk of injury.
All maintenance work must be carried out by a suitably
trained person.
13.1 Maintenance work on the filters
Open the pressure equalising lever.
Shift the switch-over handle (the handle position always
indicates the non-operational side).
The filter side on which the cartridge must be replaced is
sealed off.
Close the pressure equalising lever.
Provide a suitable receiver flask.
Open the drain plug and the vent screw.
Discharge the filter.
Check the seals of the drain plug and the vent screw
and if necessary replace.
Close the drain plug.
Take steps to prevent the parallel unit from being
operated by unauthorised persons.
Take any necessary safety precautions (protective
clothing, goggles, etc.).
Carry out the maintenance work.
Open the pressure equalising lever again.
Reverse the switching lever.
The maintained filter side is now active.
Close the pressure equalising lever.
Observe the duplex filter.
Does it operate normally?
Drain
Drain
Dismantling
clearance
530 mm
Drain plug on clean side of
filter 1 (optional)
Drain plug on clean side of
filter 2 (optional)
Vent screw
Vent screw

Page 8
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
13.2 Inspection and maintenance schedule
•Refer also to the contract documentation.
To be fixed individually by the owner of the plant.
Visual inspection whenever the filter element
is replaced or every six months at the latest.
Carry out maintenance once a year.
13.3 Replacing the inner assembly
DANGER!
The filter is pressurised!
First relieve the pressure!
Then open the filter!
DANGER!
Risk of injury!
The cartridge is only allowed to be replaced on the
non-operational filter side.
CAUTION!

Keep all impurities away from the clean side of the
cartridge.
Be careful not to damage the wire cloth of the
cartridge or the inside with sharp or pointed objects.
Wear protective clothing and equipment appropriate to
the hazard potential of the medium (e.g. goggles,
respirator, protective clothing, etc.).
Fig. 6: Switching lever positions
1
Open the pressure equalising lever (12).
2
Select the other filter by reversing the switching lever
(5):
- Switching lever in position A: Filter 2 (F2) is deactivated
while filter 1 (F1) is activated.
- Switching lever in position B: Filter 1 (F1) is deactivated
while filter 2 (F2) is activated.
Fig. 7: Discharging the filter
Place a trough or drip pan underneath.
Close the pressure equalising lever (12).

Page 9
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
3
Loosen the vent screw (1) two or three turns.
4
Open the drain plug (6).
The filter is discharged.
Fig. 8: Removing the filter cover
5
Unscrew the filter cover (2).
Remove the filter cover (2).
2
Fig. 9: Removing the filter cartridge
6
Remove the filter cartridge (4).
4
Fig. 10: Removing the filter cartridge
Check all sealing points and seals.
Replace the seals if necessary.
Replace the dirty filter element (4) with a new FG
element.
To install
Install in reverse order.

After starting up one filter side, check that
all sealing points are tight.
The system cannot be cleaned one
hundred percent. The service life of the
cartridges is gradually shortened.
13.4 Cleaning the filter housing
Wear protective clothing and equipment appropriate to
the hazard potential of the medium (e.g. goggles,
respirator, protective clothing, etc.).
Open the filter housing and remove the cartridge.
Remove any coarse impurities by mechanical means.
Wash the filter housing in a suitable cleaning solution.

Page 10
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
14 Assembly drawing
Fig. 11: Assembly drawing

Page 11
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
Fig. 12: Assembly drawing

Page 12
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
15 Dimensions
All dimensions in mm.
Type
Port
A
B
Weight [kg]
Pi 211080 DN 64 1200 785 150
Pi 211110 DN 64 1465 1085 180
Pi 211063 DN 64 690 300 80
Pi 211100 DN 64 920 530 100
16 Spare parts
Qty.
Designation
Material
no.
Benennung
1
Seal kit for housing NBR
70318468
Dichtungssatz Gehäuse NBR
1
Seal kit for housing FPM
70318469
Dichtungssatz Gehäuse FPM
1
Seal kit for housing EPDM
70318471
Dichtungssatz Gehäuse EPDM
1
Service indicator optical PiS 3098/2.2
77669971
Wartungsanzeiger optisch PIS 3098/2.2
1
Service indicator electrical, optical
PiS 3097/2.2
77669948 Wartungsanzeiger optisch elektr. PIS 3097/2.2
1
Electrical top part
77536500
nur elektr. Oberteil
1
Seal kit for service indicator NBR
77760309
Dichtungssatz Wartungsanzeiger NBR
1
Seal kit for service indicator FPM
77760317
Dichtungssatz Wartungsanzeiger FPM
1
Seal kit for service indicator EPDM
77760325
Dichtungssatz Wartungsanzeiger EPDM
Please request a separate spare parts drawing and list of spare parts for special versions.

Page 13
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
17 Explosion drawing
Fig. 13: Explosionszeichnung

Page 14
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
18 Negative declarartion

Page 15
Translation of the original instructions with installation instructions Pi 211/Pi2110, Filtration Group GmbH, 22.07.20, Mat. No. 72464548, Version 01
19 Index
D
Discharge clearance.......................................................... 6
Dismantling clearance ....................................................... 6
Drain valve..................................................................... 7, 9
E
Environmental protection ................................................... 3
F
Filter cartridge.................................................................... 4
I
Inner assembly .......................................................... 6, 8, 9
L
Leakage............................................................................. 2
M
Manufacturer...................................................................... 2
P
Pressure relief ....................................................................7
Protective clothing and equipment .................................8, 9
R
Risks...................................................................................2
S
Safety instructions ..............................................................2
Seaworthy packaging .........................................................6
Spigot .................................................................................6
Supports.............................................................................6
Suspension.........................................................................4
W
Warnings ............................................................................2

Filtration Group GmbH
Schleifbachweg 45
D-74613 Öhringen
Phone [phone]
Fax [phone]
[e-mail]
industrial.filtrationgroup.com
72464548.I01.07/2020
