Finelite HP-6 Recessed Flush Diffuser Tech Zone 6"... User manual

Protected by one or more US Patents: 8915613; D702,391; D702,390; D700,732; D727,554 S; D727,550 S, D727,551 S
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. Form 98364 V2. 04/17
HP-6 Recessed Flush Diffuser 9/16" T-Bar
Starter/Independent Installation Instructions
Note: All power connections to be installed to local/national codes
by a Certified Electrician. Finelite, Inc. • 30500 Whipple Road • Union City, CA 94587-1530 • [phone] • Fax: [phone] • www.finelite.com 1
Step 1 Step 2
Remove diffuser and set aside to prevent it from getting dirty or
damaged. NOTE: If part of a longer run, diffuser will be reinstalled
back into original luminaire section as lengths vary.
Configure T-Bar to luminaire size and leave an opening for luminaire as noted above.
Make sure T-Bars are aligned at 90 degrees. Place luminaire on T-Bar.
0 - 10V
Dimming
Scan QR code for
helpful video(s)
Step 4 Step 5
Remove conduit plate from luminaire. NOTE: Purple and gray wires
are for Low Voltage Control.
Run power cables through conduit plate and jam nut. Make electrical
connections. Secure conduit onto conduit plate with jam nut, and
reinstall conduit plate carefully not to damage any wiring.
Attach optional splice box to conduit plate by hooking onto splice box
bracket. Insert wires through feed hole.
OPTIONAL SPLICE BOX
Splice Box
Conduit Plate
Splice Box
Bracket
Conduit
Conduit Plate
Jam Nut
Wires
Wires
Conduit Plate
Jam Nut
Conduit plate
OPTIONAL SPLICE BOX
Run power cable through knock-out. Make electrical connection.
Secure conduit on to splice box with jam nut and close conduit plate.
Screws
Diffuser
Starter
Starter
Install T-Bar bracket onto luminaire. Secure with #8-18 x 1/4" screws (provided).
Secure luminaire to structure using tie-wire (by others), as per code.
Step 3
T-Bar Bracket
Secure to
Structure
(by others)
#8-18 x 1/4" Self Drilling
Screws (Provided)
4"
6"
Center-to-Center
T-Bar Spacing
9/16" T-Bar

Protected by one or more US Patents: 8915613; D702,391; D702,390; D700,732; D727,554 S; D727,550 S, D727,551 S
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. Form 98364 V2. 04/17
HP-6 Recessed Flush Diffuser 9/16" T-Bar
Starter/Independent Installation Instructions
Note: All power connections to be installed to local/national codes
by a Certified Electrician. Finelite, Inc. • 30500 Whipple Road • Union City, CA 94587-1530 • [phone] • Fax: [phone] • www.finelite.com 2
Step 6 Step 7
Secure luminaire to T-Bar with #6-20 x 1/2" self drilling sheet metal
screw (provided).
Reinstall diffuser and turn power on. NOTE: If part of a longer run, diffuser
will be reinstalled back into original luminaire section as lengths vary.
Diffuser
Conduit
Secure to Structure
(by others)
#6-20 x 1/2"
Self Drilling Screws
(provided)

Protected by one or more US Patents: 8915613; D702,391; D702,390; D700,732; D727,554 S; D727,550 S, D727,551 S
HP-6 Recessed Flush Diffuser 9/16" T-Bar
Joiner/Ender Installation Instructions
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. Form 98365 V2. 04/17
Note: All power connections to be installed to local/national codes
by a Certified Electrician. 1
Finelite, Inc. • 30500 Whipple Road • Union City, CA 94587-1530 • [phone] • Fax: [phone] • www.finelite.com
Step 3
Install T-Bar bracket onto luminaire. Secure with #8-18 x 1/4" screws (provided).
Secure luminaire to structure using tie-wire (by others), as per code.
Joiner/Ender
#8-18 x 1/4" Self Drilling
Screws (Provided)
Step 4 Step 5
Remove backplate clips to release the backplates. We recommend using a flat head screwdriver to remove them.
CAUTION: Do not lose these pieces.
Slowly swing down backplates. CAUTION: Do not twist the backplate when swinging down – it will come out of the support extrusion. Note
that the screws shown are the pivot points, and the backplate can be slid a few inches either way for ease of access to the driver space.
Backplate Clips
Joiner/Ender
Starter
Starter
Joiner/Ender Pivot Point
Step 1
Remove diffuser and set aside to prevent it from getting dirty
or damaged. NOTE: If part of a longer run, diffuser will be
reinstalled back into original luminaire section as lengths vary.
0 - 10V
Dimming
Scan QR code for
helpful video(s)
Diffuser
Backplate
Secure to
Structure
(by others)
T-Bar Bracket
Step 2
Install joiner/ender onto ceiling next to starter. Align thd starter and joiner/ender
luminaires and slide them together.
Starter
Joiner/Ender
Secure to Structure
(by others)
4"
6"
Center-to-Center
T-Bar Spacing
9/16" T-Bar

Protected by one or more US Patents: 8915613; D702,391; D702,390; D700,732; D727,554 S; D727,550 S, D727,551 S
HP-6 Recessed Flush Diffuser 9/16" T-Bar
Joiner/Ender Installation Instructions
© 2017 FINELITE, INC. ALL RIGHTS RESERVED. Form 98365 V2. 04/17
Note: All power connections to be installed to local/national codes
by a Certified Electrician. 2
Finelite, Inc. • 30500 Whipple Road • Union City, CA 94587-1530 • [phone] • Fax: [phone] • www.finelite.com
Step 6
Step 9
Step 7 Step 8
IMPORTANT STEP: Secure joint with two yoke brackets (provided) using two #10-32 x 5/8" screws
(provided). When installed correctly these brackets will pull luminaires together to make a tight joint.
CAUTION: Do not over-tighten.
Connect plug-together wiring. Secure all luminaires to the T-Bar by driving #6-20 x 1/2” self-drilling screws (provided) through the T-Bar
brackets (provided).
Replace backplates by holding them in their original position and pushing the clips back in. Make sure wire connections are
not pinched. (If a 1 ft. backplate assembly is near joint, reconnect feed harness to LED board.) Replace diffuser and turn power
on to luminaire. NOTE: If part of a longer run, diffuser will be reinstalled back into original luminaire section as lengths vary.
T-Bar Bracket
#6-20 x 1/2" Self Drilling
Screws (4) (provided)
Joint Sleeves
Starter
Joiner/Ender
#10-32 x 5/8" Screws (2)
(provided) Yoke Brackets
(provided)
Plug-Together Wiring
Joiner/Ender
Diffusers
Secure to Structure
(by others)
IMPORTANT STEP
Backplate Clips
