ProBuilder 36CF
See-Through
(GSR2)
Installation Manual
WARNING: FIRE OR EXPLOSION HAZARD
Failure to follow safet
y
warnin
g
s exactl
y
could result in serious in
j
ur
y
, death, or propert
y
dama
g
e.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
! DANGER
HOT GLASS WILL CAUSE
BURNS
DO NOT TOUCH GLASS
UNTIL COOLED
NEVER ALLOW CHILDREN
TO TOUCH GLASS
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
Listed by
Omni-Test Laboratories, Inc.
Report # 0028GF115S
ANSI Z21.88:19
CSA 2.33:19
CSA 2.17-2017
Built-In Direct Vent
Fireplace
Natural Gas or Propane
Residential or Mobile
Home
This appliance may be installed in an aftermarket, permanently located, manufactured home
(USA only), or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. A conversion
kit is supplied with the appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
French language manuals at fireplacex.com.
Manuels de langue Française à fireplacex.com.
Travis Industries, Inc. 12521 Harbour Reach Dr., Mukilteo, WA 98275 www.travisproducts.com
Copyright 2023, T.I. $10.00 1/12/2023 100-01556
DRAFT
DRAFT
DRAFT

2 Introduction
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Overview
This manual details the installation
requirements for the PB36 See
Through (ST) GSR2 fireplace. For
operating and maintenance
instructions, refer to the PB36 ST
GSR2 Owner's Manual.
Listing Details
This appliance was listed to ANSI
Z21.88. The listing label is
attached to the appliance near the
gas control valve. A copy is shown
to the right.
Massachusetts Approval
This manual has been submitted to
the Massachusetts Board of State
Examiners of Plumbers and Gas
Fitters.
National Fireplace Institute
DRAFT
DRAFT
DRAFT

Table of Contents 3
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Table of Contents
Overview................................................................2
Listing Details .......................................................2
Table of Contents..................................................3
Installation Options ..............................................6
Heating Specifications .........................................6
Dimensions............................................................6
Packing List...........................................................7
Additional Items Required....................................7
Recommended Installation Procedure................7
Massachusetts Requirements .............................8
Requirements for the Commonwealth of
Massachusetts ....................................................8
MANUFACTURER REQUIREMENTS ................8
Fireplace Placement Requirements ....................9
Clearances ..........................................................9
Raised Fireplaces................................................9
Televisions Placed Above the Fireplace...........10
Minimum Framing Dimensions – Top or Side
Vent Configuration..............................................11
Min. Framing - Without CoolSmart TV kit ..........11
Min Framing – With CoolSmart TV Kit...............11
Header Standoff & Shield Installation ...............12
Removing the Shipping Brackets......................14
Centering the Fireplace ......................................14
Installing the Optional Centering Brackets.......15
Nailing Brackets..................................................16
Standard vs Extended Position– Left Side ........17
Standard vs Extended Position– Right Side......18
Standoff/Heatshield - Standard vs. Extended
Position................................................................19
Outdoor Fireplace Installations .........................20
Gas Line Requirements......................................21
Fuel ...................................................................21
Gas Line Connection.........................................21
Gas Inlet Pressure.............................................21
Gas Connection ..................................................22
Electrical Connection (required)........................23
Vent Requirements .............................................24
Vent Clearances................................................24
Vent Firestop or Thimble ...................................24
Altitude Considerations .....................................24
Approved Termination.......................................24
Approved Vent ..................................................24
Approved Vent ..................................................25
Vent Installation.................................................25
Approved Vent Configurations ..........................26
Restrictor Position .............................................26
Exhaust Restrictor Adjustment ..........................26
Diffuser Plate Adjustment ..................................27
Side Vent Configuration with Horizontal
Termination (no vertical rise).............................28
Vent Configuration: Horizontal Termination.....29
Vent Configuration: Vertical Termination .........30
Masonry Chimney Conversions ........................31
Class A Chimney Conversion ............................32
Termination Requirements.................................33
Hearth Requirements..........................................34
Facing Requirements .........................................35
Standard vs. Extended Position ........................36
Thick Facing Guide.............................................37
Thick Facing (Facing Thicker than 1-1/2”).........38
THICK FACING GUIDE SIZE............................39
Thin Facing (1/2” to 1-1/2”)................................40
Screen Assembly Mounts..................................40
Mantel Requirements..........................................41
Mantel Column Clearances ...............................41
Use of a Non-Combustible Mantel Below Listed
Mantel Clearances ..............................................42
Finalizing the Installation ...................................43
Pilot Flame Inspection.......................................43
Air Shutter Adjustment ......................................44
Location of Controls ..........................................45
Pilot Fuel Conservation Timer (GSB & GSR
units) ....................................................................46
Glass Frame Removal and Installation..............47
Barrier Screen Visual Deflector Adjustment ......49
Log Set Installation.............................................50
Part Numbers / Compatibility.............................50
Installation Warnings.........................................50
Installation – Oak vs. Birch................................50
Log Set Overview – Classic Oak 94500642 ......51
Log Set Overview – Birch 94500641.................52
Installation .........................................................53
Log #1 ...............................................................53
Ember bed Glass and Ember Material
Installation...........................................................60
Ember bed Glass Installation ............................60
Ember Material Installation (GSR2 ONLY) ........61
LP Conversion Instructions ...............................62
Fireback Installation ...........................................65
SKU #'s ................................................................65
Compatibility .......................................................65
Packing List.........................................................65
Preparing the Firebacks (BLACK GLASS ONLY)65
Installation...........................................................66
CoolSmart TV – Installation Overview (Optional)68
PB 36CF ST - Installation Requirements...........69
PB 36CF ST - Framing the Chase.....................70
PB 36CF ST - Fireplace Preparation.................71
PB 36CF ST- Reduced Mantel Height...............73
Wiring Diagram ...................................................74
Index .................................................................76
DRAFT
DRAFT
DRAFT

4 Safety Precautions
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Safety Warnings
Failure to follow all of the requirements may result in property damage, bodily injury, or even death.
Young children should be carefully supervised when they are in the same room
as the appliance. Toddlers, young children, and others may be susceptible to
accidental contact burns. A physical barrier is recommended if there are at-risk
individuals in the house. To restrict access to a fireplace or stove, install an
adjustable safety gate to keep toddlers, young children, and other at-risk
individuals out of the room and away from hot surfaces.
Children and adults should be alerted to the hazards of high surface temperature
and should stay away to avoid burns or clothing ignition. Do not touch the hot
surfaces of the heater. Educate all children of the danger of a high-temperature
heater.
Due to the high temperature, the heater should be located out of traffic and away
from furniture and draperies.
This unit must be installed by a qualified
installer to prevent the possibility of an
explosion.
This appliance must be installed in
accordance with all local codes if any; if not,
in U.S.A. follow ANSI Z223.1 and NFPA
54(88), in Canada follow CSA B149.1. In
Australia follow AS/NZS 5601.1.
A manufactured home (USA only) or mobile
home OEM installation must conform with
the Manufactured Home Construction and
Safety Standard, Title 24 CFR, Part 3280,
or, when such a standard is not applicable,
the Standard for Manufactured Home
Installations, ANSI/NCSBCS A225.1, or
Standard for Gas Equipped Recreational
Vehicles and Mobile Housing, CSA Z240.4.
This appliance may be installed in
Manufactured Housing only after the home
is site located.
All exhaust gases must be vented outside
the structure of the living area. Combustion
air is drawn from outside the living-area
structure. The venting must not be
connected to a chimney flue serving a
separate solid fuel burning appliance.
Notify your insurance company before
hooking up this fireplace.
The instructions in this manual must be
strictly adhered to. Do not use makeshift
methods or compromise in the installation.
Improper installation will void the warranty
and safety listing.
This heater is approved for use with natural
gas (NG) or propane (LP). Burning the
incorrect fuel will void the warranty and
safety listing and may cause an extreme
safety hazard. Direct questions about the
type of fuel used to your dealer.
Contact your local building officials to obtain
a permit and information on any installation
restrictions or inspection requirements in
your area.
If the flame becomes sooty, dark orange in
color, or extremely tall, do not operate the
heater. Call your dealer and arrange for
proper servicing.
It is imperative that control compartments,
screens, or circulating air passageways of
the heater be kept clean and free of
obstructions. These areas provide the air
necessary for safe operation.
Do not operate the heater if it is not
operating properly in any fashion or if you
are uncertain. Call your dealer for a full
explanation of your heater and what to
expect.
Do not store or use gasoline or other
flammable liquids in the vicinity of this
heater.
Do not operate if any portion of the heater
was submerged in water or if any corrosion
occurs. Immediately call a qualified service
technician to inspect the appliance and
replace any part of the control system and
any gas control which has been underwater.
DRAFT
DRAFT
DRAFT

Safety Precautions 5
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Safety Warnings (continued)
Because this heater can be controlled by a
thermostat there is a possibility of the heater
turning on and igniting any items placed on
or near the appliance.
Light the heater using the built-in igniter. Do
not use matches or any other external
device to light your heater.
Never remove, replace, modify, or substitute
any part of the heater unless instructions are
given in this manual. All other work must be
done by a trained technician. Don't modify
or replace orifices.
The viewing glass should be opened only for
conducting service.
Allow the heater to cool before carrying out
any maintenance or cleaning.
Operate the heater according to the
instructions included in this manual.
If the main burners do not start correctly turn
the gas off and call your dealer for service.
This unit is not for use with solid fuel.
Do not place anything inside the firebox
(except the optional artwork).
WARNING: Do not operate the appliance
with the glass front removed, cracked, or
broken. Replacement of the glass should be
done by a licensed or qualified service
person.
Do not throw this manual away. This
manual has important operating and
maintenance instructions that you will need
at a later time. Always follow the
instructions in this manual.
Instruct everyone in the house on how to
shut gas off to the appliance and at the gas
main shutoff valve. The gas main shutoff
valve is usually next to the gas meter or
propane tank and requires a wrench to shut
off.
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
If the barrier becomes damaged, the barrier
shall be replaced with the manufacturer’s
barrier for this appliance.
Clothing or other flammable material should
not be placed on or near the appliance.
Any safety screen, guard, or barrier
removed for servicing an appliance must be
replaced prior to operating the appliance.
Installation and repair should be done by a
qualified service person. The appliance
should be inspected before use and at least
annually by a professional service person.
More frequent cleaning might be required
due to excessive lint from carpeting, bedding
material, et cetera. It is imperative that
control compartments, burners, and
circulating air passageways of the appliance
be kept clean.
Travis Industries, Inc. grants no
warranty, implied or stated, for the
installation or maintenance of your
heater, and assumes no responsibility for
any consequential damage(s).
Proposition 65 Warning: Fuels used in gas, woodburning or oil-fired appliances, and the products of combustion
of such fuels, contain chemicals known to the State of California to cause cancer, birth defects, and other
reproductive harm. California Health & Safety Code Sec. 25249.6
DRAFT
DRAFT
DRAFT

6 Features and Specifications
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Installation Options
Residential or Mobile Home
Raised or Floor Placement
Internal or External Chase
Horizontal or Vertical Vent
Bedroom Approved
Heating Specifications
Natural Gas Propane
Approximate Heating Capacity (in square feet) * Up to 1,800 Up to 1,800
Maximum BTU Input Per Hour (BTU/hr.) 37,500 37,500
* Heating capacity will vary with floor plan, insulation, and outside temperature.
Dimensions
DRAFT
DRAFT
DRAFT

Installation ( for qualified installers only) 7
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Packing List
LP (Propane) Conversion Kit:
Outer Burner Orifice (1.25mm), Center Burner Orifice (1.25mm), Pilot Orifice (0.14 LP),
Thimble (2-Piece Assembly)
(2) Header Shields
Optional Centering Brackets
(see section “Centering the
Fireplace” for details)
Remote
Additional Items Required
If using LP (propane) a conversion kit is required (4-pack = 94400999, single = 250-01463).
Direct Vent Pipe
Gas Line Equipment (shutoff valve, pipe, etc.)
Electrical Equipment (min. 14-gauge, grounded line)
Log Set (Oak – sku# 94500642 or Birch – sku# 94500641)
Recommended Installation Procedure
Prepare the framing, making sure to leave the area around the fireplace open (see page 11). Make sure to allow for
vent installation and facing depth.
Place the fireplace into position.
Install the vent, gas line, and electrical hook-up.
Finalize the framing around the fireplace.
Secure the fireplace to the framing.
Install the drywall.
Install the hearth (if applicable).
Install the facing (if applicable).
Install the mantel (if applicable).
Install the media and embers.
Finalize the installation (see page 43) and install the face.
DRAFT
DRAFT
DRAFT

8 Installation (for qualified installers only)
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Massachusetts Requirements
NOTE: The following requirements reference various Massachusetts and national codes not contained in this document.
Requirements for the Commonwealth of Massachusetts
For all side wall horizontally vented gas fueled equipment installed in every dwelling, building, or structure used in whole or
in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust
vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks
and porches, the following requirements shall be satisfied:
Installation of Carbon Monoxide Detectors
At the time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gasfitter shall
observe that a hard-wired carbon monoxide detector with an alarm and battery backup is installed on the floor level where
the gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery operated or
hard-wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building, or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure
the services of qualified licensed professionals for the installation of hard-wired carbon monoxide detectors.
In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard-
wired carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
In the event that the requirements of this subdivision cannot be met at the time of completion of installation, the owner shall
have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day
period, a battery-operated carbon monoxide detector with an alarm shall be installed.
Approved Carbon Monoxide Detectors
Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be
ANSI/UL 2034 listed and IAS certified.
Signage
A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of
eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating
appliance or equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY
BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS.”
Inspection
The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the
provisions of 248 CMR 5.08(2)(a)1 through 4.
Exemptions
The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
• The equipment listed in Chapter 10 entitled “Equipment Not Required to Be Vented” in the most current edition of NFPA 54
as adopted by the Board; and
• Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the
dwelling, building, or structure used in whole or in part for residential purposes.
MANUFACTURER REQUIREMENTS
Gas Equipment Venting System Provided
When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design
or venting system components with the equipment, the instructions provided by the manufacturer for installation of the
equipment and the venting system shall include:
• Detailed instructions for the installation of the venting system design or the venting system components; and
• A complete parts list for the venting system design or venting system.
Gas Equipment Venting System NOT Provided
When the manufacturer of a Product Approved side wall horizontally vented gas fueled equipment does not provide the
parts for venting the flue gases but identifies “special venting systems,” the following requirements shall be satisfied by the
manufacturer:
• The referenced “special venting system” instructions shall be included with the appliance or equipment installation
instructions; and
• The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a
parts list and detailed installation instructions.
A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting
instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or
equipment at the completion of the installation.
See the Gas Connection section for additional Commonwealth of Massachusetts requirements.
DRAFT
DRAFT
DRAFT

Installation ( for qualified installers only) 9
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Fireplace Placement Requirements
The fireplace must be installed on a level surface capable of supporting the fireplace and vent.
The fireplace must be placed directly on wood or a non-combustible surface (not on linoleum or carpet).
This heater may be placed in a bedroom. Please be aware of the large amount of heat this appliance
produces when determining a location.
The fireplace must be installed in a room with a minimum ceiling height of 84” (2134mm).
Clearances
The fireplace requires a ½”
(13mm) clearance from both
ends of the fireplace (including
the air intake bump out). No
material (insulation, framing,
etc.) may be placed in this
area.
Due to the high temperature, the heater should be located out of traffic and away from furniture and
draperies.
The fireplace must be placed so the vents below and above the glass do not become blocked.
Raised Fireplaces
The fireplace (and hearth, if desired)
may be placed on a platform designed
to support the fireplace (300 Lbs. 137
kg) and vent.
The base of the fireplace must be a
minimum of 60” (1524mm) below the
room ceiling.
DRAFT
DRAFT
DRAFT

10 Installation (for qualified installers only)
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Televisions Placed Above the Fireplace
The following section gives guidelines to place a television above the fireplace.
IMPORTANT NOTE REGARDING TELEVISIONS AND THIS FIREPLACE
Most television manufacturers instruct the homeowner not to place the television above a heat source like this fireplace.
Doing so may decrease the longevity of the television and negate the warranty. If you do place a television above the
fireplace, you should place a mantel (or build-out) between the fireplace and television (or use a CoolSmart TV Wall™ kit).
Follow the guidelines below to reduce the amount of heat reaching the television. Travis Industries does not take
responsibility for any negative impact on televisions placed near this fireplace.
Minimum Dimensions:
(a) Minimum Mantel Height above Base of Fireplace* 43-1/2” (1106mm) with 8” (203mm) mantel depth*
(b) Mantel Depth* Minimum 8” (203mm) *
(c) Optional Columns (or Build-Out) Must Meet Side Wall Clearances
(Measured to the side of fireplace ZC-can)
* Minimum mantel depth must be 8” to allow heat to dissipate. If using a mantel larger than 8”, make sure to adjust
the mantel height (a) to meet the mantel clearance (see mantel requirements and/or chart above).
The mantel must extend 2” in front of the television and 1” to both sides.
If you have a television that is greater than 6” deep (including the 1” gap behind), you will need to alter the mantel
depth and height (see the example below).
The television must have a 1” gap to the wall to allow for proper cooling. Any build-out near the television must
maintain a 3” gap to the top and sides to prevent heat from being trapped near the television.
EXAMPLE: If you have a television that is 9” deep (including the 1” gap behind), the mantel must be 11”. The mantel height
would need to be 44-1/2” (1156mm) above the base of the fireplace.
WIRING NOTE: If running wiring into the enclosure, you may wish to use thermal insulating wrap around the wiring. Secure
the wiring to protect it from contact with hot surfaces.
Fireplace
Min. 1" (26mm)
Min. 1" (152mm) Min. 2" (51mm)
a
b
c
Optional Column
or Build-Out

















Min. 1" (26mm) Air Gap Behind TV
Min. 3"
(77mm)
Television (TV)



















(b) Depth
(a)
Height
Above
Base of
Fireplace
46" (1169mm)
0" (0mm)
1" (25mm)
2" (51mm)
8" (203mm)
7" (178mm)
6" (152mm)
5" (127mm)
4" (102mm)
3" (76mm)
9" (229mm)
10" (254mm)
11" (279mm)
12" (305mm)
45" (1143mm)
44" (1118mm)
43" (1093mm)
47" (1194mm)
DRAFT
DRAFT
DRAFT

Installation ( for qualified installers only) 11
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Minimum Framing Dimensions – Top or Side Vent Configuration
Min. Framing - Without CoolSmart TV kit
WARNING
When using a CoolSmart TV kit, see section: “CoolSmart TV - Framing the Chase”
on page 70.
Min Framing – With CoolSmart TV Kit
When using a CoolSmart TV kit, see section: “CoolSmart TV - Framing the Chase” on page 70 of this manual
or the installation instructions included with the kit for minimum framing dimensions.
DRAFT
DRAFT
DRAFT

12 Installation ( for qualified installers only)
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Header Standoff & Shield Installation
1. The (4) header
standoffs (2 on
each side) are
screwed down flat
to the front edge
of the top of the
fireplace.
Remove the
screw that is
closest to the
center of the
fireplace on each
standoff. Bend
the legs at the
perforations as
shown below and
attach the foot of
the standoff to the
top of the
fireplace using the
screw removed
earlier in this step.
2. On the header
shield, bend the two
tabs downward.
DRAFT
DRAFT
DRAFT

Installation ( for qualified installers only) 13
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
3. Set the header shield
onto the standoffs with
the 90° bend facing the
middle of the fireplace.
The tips of the standoffs
will protrude through the
heat shield.
4. Attach the heat shield to the standoffs by aligning the
holes on the heat shield tabs with the holes in the
header standoffs and secure using the included
screws.
5. When finished the fireplace should look like the
illustration to the right.
DRAFT
DRAFT
DRAFT

14 Installation ( for qualified installers only)
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Removing the Shipping Brackets
Remove the shipping brackets from the lower middle
of both ends of the fireplace. Use an 1/4” nut driver to
remove the (2) bolts that secure the bracket to the
side of the fireplace. Set the bolts aside for
reinstallation. Discard the shipping bracket.
Centering the Fireplace
The fireplace opening is not centered on the fireplace. The left half of the fireplace (when looking at the control
side) is wider than the right half. Depending on the desired finished appearance of the fireplace different
framing dimensions will be required to center the visible portion of the fireplace in the wall. See the illustration
below for the minimum framing width needed for installations with and without the optional centering brackets.
Without Optional Centering Brackets With Optional Centering Brackets
DRAFT
DRAFT
DRAFT

Installation ( for qualified installers only) 15
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Installing the Optional Centering Brackets
To install the optional centering brackets, follow the steps below.
1. If not already removed, remove the shipping
bracket from the lower middle of the right side of
the fireplace. Use an 1/4” nut driver to remove
the two bolts that secure the bracket to the side
of the fireplace. Set the bolts aside for
reinstallation. Discard the shipping bracket.
2. Loosen (but do not remove) the (6) bolts along the
outer edge of the end of the fireplace marked with
black circles. Remove the (2) bolts marked with
red circles to the right. Set the bolts aside for
reinstallation.
3. Place the keyhole slots on the centering bracket
over the three bolts along one of the edges of the
fireplace. With the keyholes over the loosened
bolts, slide the bracket toward the center. The
position of the standoff is dictated by the desired
way to apply the finish material (see “Standard vs
Extended Position” on page 36.
4. When the bracket is in the desired position, install
the bolts that were removed in steps 1 & 2 and
tighten the (3) bolts that the keyhole slots engaged
5. Repeat the above steps with the second centering bracket.
Remove these
bolts and discard
the shipping
bracket.
Loosen
Remove
Loosen
DRAFT
DRAFT
DRAFT

16 Installation ( for qualified installers only)
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Nailing Brackets
The fireplace has nailing brackets on both sides (the right side of the fireplace has them if the centering
brackets are not used). Secure the fireplace to the framing with the nailing brackets. The nailing brackets
should be oriented as shown below for all installs regardless of whether it is a flush installation or an extended
installation.
NOTE: Make sure the fireplace is square and plumb when placed in the framing. Measured corner-to-corner
the fireplace should be square. Use shims to ensure the fireplace is square.
NOTE: To prepare the nailing brackets, follow the steps below.
Without Optional Centering Brackets With Optional Centering Brackets
DRAFT
DRAFT
DRAFT

Installation ( for qualified installers only) 17
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Standard vs Extended Position– Left Side
The left side of the fireplace has two movable panels with attached nailing brackets that act as support for the
finish material. The nailing brackets have two positions: standard or extended. See the section “Facing
Requirements” for details on which position is best for your installation. The panels come in the "standard
position" from the factory. To reposition the panels and nailing brackets to the "extended" position, loosen the
(10) 1/4" screws (5 on each panel) and slide the panels inward ( & ). Tighten down the screws to secure
the panels. Secure the fireplace to the framing with the nailing brackets ( ).
DRAFT
DRAFT
DRAFT

18 Installation ( for qualified installers only)
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Standard vs Extended Position– Right Side
There are nailing brackets attached to the body of the fireplace on the right side. If the optional centering
brackets are not used position the nailing flanges as shown below, left.
There are also nailing flanges on the optional centering brackets. If the centering brackets are used, position
the centering brackets as shown below right to accommodate the style of facing that you will be using (If using
the centering brackets on the right side of the fireplace, they can be moved backward to accommodate the
extended finish material style of install (see “Standard vs. Extended Position” on page 36 for details). The
centering brackets have attached nailing brackets that act as support for the finish material. When using the
centering brackets the nailing brackets MUST BE IN THE POSITION SHOWN BOTTOM RIGHT. See the
section “Facing Requirements” for details on which position is best for your installation. To reposition the
centering brackets, loosen the (10) 1/4" screws (5 on each panel) and slide the panels to the desired position
( & ). Tighten down the screws to secure the panels. Secure the fireplace to the framing with the nailing
brackets ( ).
Nailing Brackets without
Centering Brackets
Nailing Brackets with
Centering Brackets
DRAFT
DRAFT
DRAFT

Installation ( for qualified installers only) 19
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Standoff/Heatshield - Standard vs. Extended Position
There are two positions where the standoff/heat shield assembly can be installed. The standoffs are
shipped in the standard (forward) position.
If the unit is installed in the standard position no modification is needed.
If the unit is being installed in the extended position, the standoff/heat shield assembly must
be repositioned back 1/2” (see illustration below).
NOTE: see pages 11 & 36 for additional details about standard vs. extended installations.
DRAFT
DRAFT
DRAFT

20 Installation ( for qualified installers only)
© Travis Industries 1/12/2023 - 1556 PB 36CF ST Install
Outdoor Fireplace Installations
Travis Industries Inc. gas-fired fireplaces are suitable for installation in outdoor areas protected from
direct water impingement. In addition to maintaining listed mantel and combustibles clearances, a rain
protection overhang factor of 1/2 shall be constructed to the front and to each side of installed
appliances (see the illustration to the right). All wiring connections to line power shall be in accordance
with the outdoor requirements of NECA NFPA 70.
Warnings Regarding Tempered Glass
This fireplace uses tempered glass which is susceptible to thermal shock. Take care to prevent water from
contacting the fireplace, especially if it is hot.
The fireplace may not be used as an indoor-outdoor partition (i.e., The fireplace may not be
placed on an exterior wall)
The fireplace may be installed in an outdoor location. However, it may not be used as an indoor/outdoor
partition (i.e., one side inside, one side outside). This fireplace conveys air through the side openings, making
this type of installation prohibited.
Travis Industries is not responsible for any damage caused by
water, corrosion, oxidation, or rust to the fireplace, its components,
or any optional accessories (e.g., faces, trim, firebacks, etc.)
DRAFT
DRAFT
DRAFT
