Fisher & Paykel CE604DT Mounting instructions

NZ AU GB IE
Installation instructions
and User guide
Touch control
ceramic glass cooktops
CE604DT, CE704DT,
and CE754DT models

1
Contents
Safety and warnings 2
Installation instructions 6
Introduction 12
Using your cooktop 14
Using your cooktop’s special features 18
Cooking guidelines 23
Care and cleaning 26
Troubleshooting 28
Warranty and service 30
Important!
SAVE THESE INSTRUCTIONS
The models shown in this user guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Fisher & Paykel dealer.

2Safety and warnings
Your safety is important to us. Please read this information before using your cooktop.
Installation
WARNING!
Electrical Shock Hazard
Disconnect the appliance from the mains electricity supply before carrying
out any work or maintenance on it.
Connection to a good earth wiring system is essential and mandatory.
Alterations to the domestic wiring system must only be made by a qualified
electrician.
Failure to follow this advice may result in electrical shock or death.
WARNING!
Cut Hazard
Take care – panel edges are sharp.
Failure to use caution could result in injury or cuts.

3
Safety and warnings
Important safety precautions
Read these instructions carefully before installing or using this appliance.
No combustible material or products should be placed on this appliance at any time.
Please make this information available to the person responsible for installing the appliance as it
could reduce your installation costs.
In order to avoid a hazard, this appliance must be installed according to these instructions for
installation.
This appliance is to be properly installed and earthed only by a suitably qualified person.
This appliance should be connected to a circuit which incorporates an isolating switch providing
full disconnection from the power supply.
Failure to install the appliance correctly could invalidate any warranty or liability claims.

4Safety and warnings
Operation and maintenance
WARNING!
Hot Surface Hazard
During use, accessible parts of this appliance will become hot enough to
cause burns.
Do not let body, clothing or any item other than suitable cookware contact
with the ceramic glass until the surface is cool.
Never leave metal objects on the cooktop as they can become hot very
quickly.
Keep children away.
Handles of saucepans may be hot to touch. Check saucepan handles do not
overhang other cooking zones that are on. Keep handles out of reach of
children.
Failure to follow this advice could result in burns and scalds.
WARNING!
Electrical Shock Hazard
Do not cook on a broken or cracked cooktop. If the cooktop surface should
break or crack, switch the appliance off immediately at the mains power
supply (wall switch) and contact a qualified technician.
Switch the cooktop off at the wall before cleaning or maintenance.
Failure to follow this advice may result in electrical shock or death.
WARNING!
Cut Hazard
The razor-sharp blade of a cooktop scraper is exposed when the safety
cover is retracted. Use with extreme care and always store safely and out
of reach of children.
Failure to use caution could result in injury or cuts.

5
Important safety precautions
Never leave the appliance unattended when in use. Boilover causes smoking and greasy
spillovers that may ignite.
Never use your appliance as a work or storage surface.
Never leave any objects or utensils other than suitable cookware on the appliance.
Never use your appliance for warming or heating the room.
Do not allow children to play with the appliance or sit, stand or climb on it.
Do not store items of interest to children in cabinets above the appliance. Children climbing on
the cooktop could be seriously injured.
Do not leave children alone or unattended in the area where the appliance is in use.
Children or persons with a disability which limits their ability to use the appliance should have a
responsible and competent person to instruct them in its use. The instructor should be satisfied
that they can use the appliance without danger to themselves or their surroundings.
Do not repair or replace any part of the appliance unless specifically recommended in the
manual. All other servicing should be done by a qualified technician.
Do not use a steam cleaner to clean your cooktop.
Do not place or drop heavy objects on your cooktop.
Do not stand on your cooktop.
Do not use pans with jagged edges or drag pans across the ceramic glass surface as this can
scratch the glass.
Do not use scourers or any other harsh/abrasive cleaning agents to clean your cooktop, as these
can scratch the ceramic glass.
If the power supply cable is damaged, it must only be replaced by a qualified technician.
Safety and warnings

6
Installation instructions
Cooktop and cutout dimensions Electrical connection is
made at the middle rear
A
B
CCI
D
G
F
E
Cooktop and cutout dimensions (mm)
CE604DT CE704DT CE754DT
Aoverall width of cooktop 600 700 750
Boverall depth of cooktop 530 530 530
Cheight of chassis (below top of bench) 48 48 48
CIheight of terminal block (below top of bench) 58 58 58
Dwidth of chassis 552 552 715
Edepth of chassis 480 480 480
Foverall width of cutout 560 560 725
Goverall depth of cutout 490 490 490

7
Installation instructions
Clearances
A
B
C
C
E
D
Clearances (mm)
CE604DT CE704DT CE754DT
Aminimum clearance from rear edge of cutout to:
nearest combustible surface 55 55 55
Bminimum clearance from glass surface to:
rangehood 650 650 650
Cminimum clearance from side edges of cutout to:
nearest combustible surface 85 135 78
Dminimum clearance from benchtop to:
overhead cabinet not directly above the cooktop 450 450 450
Eminimum clearance below top of benchtop to:
thermal protection barrier 68 68 68

8
Installation instructions
Before you install the cooktop, make sure that
the benchtop is square and level, and no structural members interfere with space requirements
the benchtop is made of a heat-resistant material
the cooktop will not be installed directly above a dishwasher, as the humidity may damage the
cooktop electronics
the installation will comply with all clearance requirements and applicable standards and
regulations
a suitable isolating switch providing full disconnection from the mains power supply is
incorporated in the permanent wiring, mounted and positioned to comply with the local wiring
rules and regulations. The isolating switch must be of an approved type and provide a 3 mm air
gap contact separation in all poles (or in all active [phase] conductors if the local wiring rules
allow for this variation of the requirements)
the isolating switch will be easily accessible to the customer with the cooktop installed
you consult local building authorities and by-laws if in doubt regarding installation
you use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces
surrounding the cooktop.
When you have installed the cooktop, make sure that
the power supply cable is not accessible through cupboard doors or drawers
there is adequate flow of fresh air from outside the cabinetry to the base of the cooktop
if the cooktop is installed directly above an oven or its base is accessible through a cupboard
or drawer space after installation, a thermal protection barrier is installed below the base of the
cooktop (see Fig.1)
the isolating switch is easily accessible by the customer
you complete the ‘Final checklist’ at the end of these installation instructions.
The thermal protection barrier must be:
removable
heat-resistant
made from low thermal conductivity
material
at least 20 mm below the base of the
cooktop to ensure adequate ventilation
20 mm min.
Fig. 1 Thermal protection barrier
< Fresh air from
outside the
cabinetry

9
Installation instructions
Fastening the cooktop to the bench
1 Turn the cooktop upside down and place it on a soft surface.
2 Spread the seal around the edges of the ceramic glass with the adhesive side facing down,
making sure that the whole perimeter is sealed. Cut off any excess material.
3 Mount the supplied clamps (A) and screws (B) onto the cooktop, as shown (without tightening
the screws).
4 Place the cooktop into the cutout, then tighten the screws to clamp the cooktop securely to the
bench.
5 Using a sharp cutter or trimmer knife, trim the excess sealing material around the edge of the
cooktop. Take care not to damage the benchtop.
Note: if your bench is thicker than 40 mm, recess the underside to between 30 and 40 mm.
Fig. 2 Preparing the cooktop before installation
Fig. 3 Fastening the cooktop to the bench
A
A
A
AB
Seal
B
B
B
Adhesive side
30 mm min.
40 mm max.
A
B
Seal

10
Installation instructions
Connecting the cooktop to the mains power supply
Important!
This cooktop must be connected to the mains power supply only by a suitably qualified person.
This cooktop must be earthed.
Before connecting the cooktop to the mains power supply, check that:
1 the domestic wiring system is suitable for the power drawn by the cooktop
2 the voltage corresponds to the value given on the rating plate
3 the power supply cable sections can withstand the load specified on the rating plate.
To connect the cooktop to the mains power supply, do not use adapters, reducers, or branching
devices, as they can cause overheating and fire.
The power supply cable must not touch any hot parts and must be positioned so that its
temperature will not exceed 75
o
C at any point.
Power supply
CE604DT 6400W @ 220-240/380-415V 2N~ (28A)
CE704DT 6400W @ 220-240/380-415V 2N~ (28A)
CE754DT 7300W @ 220-240/380-415V 2N~ (32A)
Connection diagrams Fig. 4 Opening the terminal block cover
PE
1
2
3
4
5
N (L2)L1
220 - 240 V
220-240 V ~
1
2
3 5
4
N L2
PE
L1
1
2
3 5
4
PE
N
L1 L2
380-415 V 2N ~
Single-phase connection Two-phase connection
PE
1
2
3
4
5
380 - 415 V 2N
N
L2L1
Bridging links
removed

11
Final checklist
TO BE COMPLETED BY THE INSTALLER
Is the cooktop earthed?
Check that the power supply cable is NOT touching the base of the cooktop. This will ensure that
the cable is not damaged by heat from the cooktop.
Check that the power supply cable is not accessible via cupboard doors or drawers.
Is the cooktop clamped down securely?
Check that all the cooking zones function correctly. Turn on all of them to a high setting and
leave them on for at least one minute.
Are all elements glowing?
Are all touch controls and displays functioning?
To check that the ‘hot surface’ indicators function correctly, turn off all the cooking zones. Is H
displayed in all the cooking zone displays?
Have you shown the customer how to use the cooktop? Make sure you explain to the customer
about the ‘hot surface’ indicators. Encourage them to read the full user guide before using the
cooktop.
Installer’s name:
Installer’s signature:
Installation company:
Date of installation:
LEAVE THESE INSTRUCTIONS WITH THE CUSTOMER
Installation instructions

12
About your new cooktop
Thank you for buying a Fisher & Paykel ceramic glass cooktop. This guide introduces you to all its
special features. We recommend you read the whole guide before using your new cooktop, for
both safety and cooking success.
For more information, visit our local website listed on the back cover.
Before using your new cooktop
Read this user guide, taking special note of the ‘Safety and warnings’ section.
Remove any protective film that may still be on your cooktop.
Touch
controls/
displays
Setting
selector
Dual cooking zone
Fig.5 Cooktop layout
(for illustration only-layouts vary)
Introduction
Cooking
zone
Cooking
zone
Cooking
zone

13
Touch controls overview
ON/OFF control
Turns the cooktop
on and off
Keylock control:
Locks the controls
(except ON/
OFF) to prevent
unintended use
Turns the outer
section of the
dual cooking
zone off and on
Warning!
The cooking
zone is not
in use but its
surface is still
very hot!
if on:
outer section of the dual
cooking zone is on
if off:
outer section of the dual
cooking zone is off
if on:
controls (except
ON/OFF) are
locked and
unresponsive
if off:
controls are
responsive
Timer display:
- shows the
number of
minutes set/
remaining
- shows
CL
(cleared) if the
timer is not set
if on:
cooktop is on
if off:
cooktop is off
if on:
cooking zone is
selected and
ready to be set
These indicators show
which cooking zone(s) the
timer is set for:
if flashing:
timer is selected and ready
to be set
if steadily lit:
timer is set and counting
down
if flashing and beeping:
set time is up
Setting selector:
Touch this area or
slide your finger
along it to select
the heat or timer
setting. The lights
above the selector
correspond to
the setting levels
(0-
u -9)
Introduction

14
Using the touch controls
The cooking zone and timer displays also function as
touch controls. To select a cooking zone or the timer,
simply touch its display. Use the ball of your finger, not its
tip. The controls respond to touch, so you don’t need to
apply any pressure.
Once you have selected a cooking zone or the timer, you
have 10 seconds to set it (while the little red light at the
bottom right of the display is on). If the little red light
goes out before you have had a chance to select a setting,
simply re-select the cooking zone or timer by touching its
display again.
Make sure the controls are always clean, dry, and there
is no object (eg a utensil or a cloth) covering them.
Even a thin film of water may make the controls
difficult to operate.
To select a setting on the selector:
Using your cooktop
Touch at one point to “jump” to a
specific setting
OR slide your finger along the
selector.

15
To start cooking
Using your cooktop
1 Turn on the cooktop.
Notes:
CL (cleared) in the timer display means
that the timer is not set.
If you do not select a cooking zone within
20 seconds, the cooktop will automatically
turn off.
3 Select a heat setting (0-9).
Note: setting
u(between 0and 1))provides continuous gentle heat between 0and 1.
See ‘Using your cooktop’s special features’.
2 Select a cooking zone.

16
To modify the heat setting during cooking
When you have finished using a cooking zone, you can
turn it off, but continue to use other cooking zones:
turn the whole cooktop off:
Using your cooktop
1 Select a cooking zone.
1 Select the cooking zone you want to turn
off.
2 Hwill show which cooking zone surface is too
hot to touch. It will disappear when the surface
has cooled down to a safe temperature.
1 Turn the cooktop off.
2 Modify its heat setting.
2 Decrease its heat setting until the display
shows 0. If the cooking zone surface is
too hot to touch, Hwill replace 0in the
display.

17
Using the dual (right rear) cooking zone
When you turn the dual (right rear) cooking zone on, both the inner and outer sections
will heat. Use the control to toggle the outer section off or on again.
Locking the controls
You can lock the controls to prevent unintended use (for example children accidentally turning
cooking zones on).
When the controls are locked, all controls except the ON/OFF control are disabled.
To lock the controls
1 Make sure that the cooktop is turned on but no cooking zone is in use.
2 Touch and hold the keylock control for 2 seconds. The red light above the control comes on,
indicating that the controls are locked.
Note: the cooktop will automatically turn off after 10 seconds, but the controls will still be locked
when you turn the cooktop on again.
To unlock the controls
1 Make sure the cooktop is turned on.
2 Touch and hold the keylock control for 2 seconds. The red light above the control goes out.
3 You can now start using your cooktop.
Important!
Do not lock the controls while a cooking zone is in use. If you do, you can always turn the cooktop off with
the ON/OFF control in an emergency.
Using your cooktop
outer section
ON
outer section
OFF

18
Using the Auto Heat-reduce feature
Cooking zones set for this feature will:
first quickly heat up food or liquid at the highest setting
then automatically reduce the heat to a preset lower setting to cook the food through.
To set a cooking zone for Auto Heat-reduce
When Auto Heat-reduce is set
Initially, while the cooking zone is at the highest setting, Awill flash alternately with your
selected lower setting. Then, when the period of highest setting is over (eg after 5 minutes), A
will stop flashing and the cooking zone will automatically reduce the heat to your preset
lower setting.
Using your cooktop’s special features
1 Select a cooking zone.
3 Re-touch the right end of the setting
selector.
Awill start flashing alternately with 9in
the cooking zone’s display.
2 Select heat setting 9.
4 Choose the lower heat setting you want the
cooking zone to automatically reduce to
(1-8).
