Fisher-Price L4511 User manual

L4511
•Please keep this instruction sheet for future reference, as it
contains important information.
•Adult supervision is required.
•Never use near steps.
•Choose areas for riding that are free of obstacles.
•Learn to stop safely.
•Use with caution as this product requires skill to operate
safely to avoid falls, collisions, and injuries to yourself
(the rider) and others.
•Requires three “AA” (LR6) alkaline batteries (not included).
•Adult assembly is required.
•Tool required: Phillips screwdriver (not included).
fisher-price.com

Frame
Lion
Seat
Parts
2 Front Wheels
(Small)
4 Hubs
2 Rear Wheels
(Large)
#8 x 3/4˝(1,9 cm) Screws – 9
Shown Actual Size
Note: Tighten and loosen all
screws with a Phillips screwdriver.
Do not over-tighten screws.
2

Frame
This package contains small parts.
For adult assembly only.
CAUTION
Assembly
Seat
• Fit the seat onto the frame, as shown.
• Fit the lion onto the frame.
• While holding the lion in place, turn the assembly over.
• Insert five screws into the holes in the frame and tighten.
• Fit a rear wheel (large) onto the rear axle.
• Fit a hub into the center of the rear wheel.
• Insert a screw into the center of the hub and tighten.
• Repeat this procedure to attach the other rear wheel.
Rear Wheel
(Large)
Hub
3
1
3
2
4

• Fit a front wheel (small) onto the front axle.
• Fit a hub into the center of the front wheel.
• Insert a screw into the center of the hub and tighten.
• Repeat this procedure to attach the other front wheel.
Hub
Front Wheel
(Small)
Assembly
Note: A plastic tab was attached to the toy for in-store
demonstration purposes. While the tab may have already
been removed, check back of the lion to be sure. If the
plastic tab is still attached, pull and remove the tab from the
toy. Throw the plastic tab away.
Battery Safety Information
In exceptional circumstances, batteries may leak fluids that
can cause a chemical burn injury or ruin your toy. To avoid
battery leakage:
• Do not mix old and new batteries or batteries of different
types: alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium).
• Insert batteries as indicated inside the
battery compartment.
• Remove batteries during long periods of non-use. Always
remove exhausted batteries from the toy. Dispose of
batteries safely. Do not dispose of the product in a fire.
The batteries inside may explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent type,
as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the toy before charging.
• If removable, rechargeable batteries are used, they are
only to be charged under adult supervision.
1,5V x 3
“AA” (LR6)
4
• Locate the battery compartment on the back of the lion.
• Loosen the screws in the battery compartment door with
a Phillips screwdriver and remove the door.
• Insert three “AA” (LR6) alkaline batteries.
• Replace the battery compartment door and tighten
the screws. Do not over-tighten.
• If this product begins to operate erratically, you may need
to reset the electronics. Slide the power/volume switch off
and then back on.
• When sounds or lights become faint or stop, it’s time for an
adult to change the batteries!
Battery Installation
Before Use
• Protect the environment by not disposing of this
product with household waste (2002/96/EC). Check
your local authority for recycling advice and facilities.
5
Care
• Wipe with a clean cloth dampened with a mild soap and
water solution. Do not immerse.
• Periodically inspect this product for wear or damage.
Check all nuts and bolts, and tighten as needed. Replace
worn or broken parts immediately.

Rider to Walker
• Pull out the latch on the back of the seat and lift the seat.
• Lift the support and “snap” it into the opening under
the seat.
• Push down on the handle to be sure it's secure.
Walker to Rider
• Pull out the latch on the back of the seat and lift the seat.
• Lower the support and lower the seat.
5
11
22

©2012 Mattel. All Rights Reserved.
PRINTED IN CHINA L4511a-0922
• Slide the power/volume switch on the toy to:
ON with low volume
ON with high volume
OFF
Press the lion's
nose for fun lights
and sounds!
Flashing Lights and Lively Music! Consumer Information
FCC Statement (United States Only)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Consult the dealer or an experienced radio/TV
technician for help.
Note: Changes or modifications not expressly approved by
the manufacturer responsible for compliance could void
the user’s authority to operate the equipment. This device
complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
ICES-003
• This Class B digital apparatus complies with Canadian
ICES-003.
• Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause
undesired operation.
NMB-003
• Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
• L’utilisation de ce dispositif est autorisée seulement
aux conditions suivantes : (1) il ne doit pas produire de
brouillage et (2) l’utilisateur du dispositif doit être prêt
à accepter tout brouillage radioélectrique reçu, même
si ce brouillage est susceptible de compromettre le
fonctionnement du dispositif.
CO
N
SU
MER
ASS
I
S
T
A
N
C
E
1-800-432-5437 (US & Canada)
1300 135 312 (Australia)
Fisher-Price, Inc., 636 Girard Avenue, East Aurora, NY 14052.
Hearing-impaired consumers: 1-800-382-7470.
Outside the United States:
Canada: Mattel Canada Inc., 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2; www.service.mattel.com.
Great Britain: Mattel UK Ltd, Vanwall Business Park,
Maidenhead SL6 4UB. Helpline: 01628 500303.
www.service.mattel.com/uk
Mattel Europa B.V., Gondel 1, 1186MJ Amstelveen, Nederland.
Australia: Mattel Australia Pty. Ltd., 658 Church Street,
Locked Bag #870, Richmond, Victoria 3121 Australia.
New Zealand: 16-18 William Pickering Drive,
Albany 1331, Auckland.
