Fit4Home POWER TOWER TF-1007 User manual

1
BF-X5TK-7S4ZPlease Keep For Future Reference
IMPORTANT - Please Read Instructions Fully Before Assembly Or Use
These instructions contain important information which will help you get the best
from your equipment and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts,
call the Customer Helpline: 0330 124 0718 (Opening hours: Mon-Fri 9:00am-3:00pm)
or Email: [e-mail]
POWER TOWER TF-1007
USER MANUAL

2
CONTENTS
Safety Information
Parts List
Exploded Diagram
Assembly Instructions
Step 1
Step 2
Step 3
Step 4
Fit4Home Ltd
Declaration
03
04
05
06
06
07
08
09
10
11

3
IMPORTANT SAFETY INFORMATION
Home Gym 1007
Please note the following information given:
Whilst checking the parts list pay attention to the frame, due
to some parts having already been added to the frame.
The following parts have already been added to the frame:
• 18, 19, 21, 22, 23, 24, 25, 26 and 39
(Some screw bolts, washers and nuts may have already been
added to the frame)
• Parts 20 and parts 44 are pulleys, added together makes 14
pulleys. In reality there should be 10 pulleys in total, 6
pulley (20) and 4 convex pulleys (44).
If you need help or have damaged or missing parts, call the
Customer Helpline: 03301240718
Telephone Line Opening Hours: Mon – Fri: 9:00 am – 3:00 pm
Fit4home Ltd
Unit A, Perseverance Business park,
Olive Lane
Darwen, BB3 3DQ

4
PARTS LIST
No. Description Quantity No. Description Quantity
1 Bottom Tube 4 2 Lower Cross Beam 2
3 Main Support Tube 1 2 4 Main Support Tube 2 2
5 Weight Tube 4 6 Selector Bar 2
7 The Pulley Frame 2 8 Upper Beam 2
9 Top Beam 1 10 Handrail 2
11 Bottom Pull Bar 2 12 Bolt M10x60l 16
13 Bolt M10x65l 12 14 Bolt M10x40l 6
15 Bolt M10*75l 4 16 Washer ¢10 64
17 Nut M10 42 18 Bolt M8x20l 8
19 Washer ¢8 8 20 Pulley 10
21 Square Cap 8 22 Square End Inside Cap 4
23 Square End Inside Cap 8 24 Handle Sleeve 6
25 Sponge 2 26 Round End Inside Cap 2
27 Tube Housing 2 28 Pin 2
29 Weight Stack Top Plate 2 30 Weight Plate 28
31 Pin 2 32 Top Pull Bar 2
33 Hook 6 34 Chain 2
35 Rubber Ring 4 36 Pulley Bracket 2
37 Washer 012 2 38 Weight Cable 2
39 Bearing 4 40 Movable Pulley Frame 2
41 Pull Rope 1 42 Bolt M10x45l 4
43 Wire Rope Guide
Button
6 44 With Convex Pulley 4

5
EXPLODED DRAWING
NEEDS DIAGRAM IMAGE

6
ASSEMBLY INSTRUCTIONS
STEP 1
Assemble main support tube (3,4) onto the bottom tube (1) and lower cross beam (2).
NEEDS DIAGRAM IMAGE

7
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 2
1. Fix the weight slider tube (5) into weight plate (30).
2. Equip selector bar (6) with tube housing (27). Then put the pin (28) into the holes and insert
selector bar into weight plate (30), slide down the top plate (29) nally.
3. To connect the upper beam (8) onto the main support tube (3 ,4).

8
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 3
1. Connect top beam (9) with the pulley frame (7) and upper beam (8).
2. Please connect the handrail (10) onto the main support tube (3 ,4).

9
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 4
To cross the weight cables (38) over the pulleys (20) and xed by bolts (14) and nuts (17).

10
FIT4HOME LTD
Fit4Home is essentially an online business which aims to provide high
quality Exercise and Fitness products to ensure all customers maintain a
healthy lifestyle.
At Fit4Home we stock various dierent types of tness and exercise
equipment such as Treadmills, Cross Trainers, Weights, Exercise Bikes
etc and aim to provide an excellent service to each and every one of our
valued customers. We try to cater for every type of individual, so if you
are someone who is very serious about health and tness we can provide
you with professional heavy duty products, but if you are someone who
is busy and short on space we can provide you with equipment that is
compact and aesthetically pleasing.
Fit4Home employs a dedicated customer service team to ensure the
consumer is provided with the best service and experience. For any
queries or issues feel free to contact us via e-mail or phone.
As an online business we sell our products independently via our website,
and we also trade from established markets such as Amazon and EBay.
As an established business we endeavour to earn the condence of the
customer, it is for this reason that we try our utmost best to dispatch
products the same day using a next working day delivery service to all UK
mainland areas.
Along with the customer service department, Fit4Home consists of hard-
working and reliable technicians and designers who aim to meet the
needs of our customers.
We oer a market leading 12 month warranty, which is simple and hassle
free.
Fit4Home© Ltd
Hours of Business: 9am - 5pm
Website: www.t4home.co.uk
E-mail: customerservices@t4home.co.uk

11
Declaration of Conformity
We, Importer
Fit4home Ltd
Unit A, Perseverance Mills, Olive Lane, Darwen BB3 3DQ United Kingdom
Declare that the product
TF-1007 Cable Crossover
Complies with the essential health and safety requirements of the
following directive:
Direction for 2014/357/EU for Stationery training equipment
EN ISO 20957-1
EN ISO 20957-2
Authorised Signatory and technical le holder
Signed for and behalf of:
Fit4home Ltd
Unit A
Perseverance Mills
Olive Lane
Darwen
BB3 3DQ
United Kingdom
