Fit4Home TF-7002 MULTIGYM User manual

1
F4H-HG-7002
Please Keep For Future Reference
IMPORTANT - Please Read Instructions Fully Before Assembly Or Use
These instructions contain important information which will help you get the best
from your equipment and ensure safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts,
call the Customer Helpline: 0330 124 0718 (Opening hours: Mon-Fri 9:00am-6:00pm)
or Email: [e-mail]
TF-7002 MULTIGYM
USER MANUAL

2
CONTENTS
Safety Information
Parts List
Exploded Diagram
Assembly Instructions
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Step 8
Step 9
Step 10
Step 11
Step 12
Step 13
Step 14
Step 15
Step 16
Declaration
03
04,05
06
07
07
08
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22

3
IMPORTANT SAFETY INFORMATION
This exercise equipment is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual before
you assemble or operate your equipment. In particular, note the following safety precautions:
1. Keep children and pets away from the equipment at all times. DO NOT leave children
unattended in the same room with the equipment.
2. Only one person at a time should use the equipment.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms,
STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the equipment on a clear, leveled surface. DO NOT use the equipment near water or
outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or other
clothing that could become caught in the equipment. Running or aerobic shoes are also
required when using the equipment.
7. Use the equipment only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
8. Do not place any sharp object around the equipment.
9. Disabled person should not use the equipment.
10. Before using the equipment to exercise, always do stretching exercises to properly warm up.
11. Never operate the equipment if the equipment is not functioning properly.
12. A spotter is recommended during exercise.
13. This equipment is designed and intended for home and consumer use only, not for
commercial use.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN.
THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS
WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING
ANY FITNESS EQUIPMENT. TUNTURI FITNESS BV. ASSUMES NO RESPONSIBILITY FOR
PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF
THIS PRODUCT.
SAVE THESE INSTRUCTIONS.

4
PARTS LIST
NO. DESCRIPTION QTY NO. DESCRIPTION
1 MAIN BASE TUBE 1 2 SHORT BASE TUBE 2
3 REAR BASE TUBE 1 4 WEIGHT SLIDER TUBE 2
5 WEIGHT PICK UP POLE 1 6 MAIN SUPPORT TUBE 1
7 TOP BRACE TUBE 1 8 SUPPORT TUBE FOR
BUTTERFLY ARM
1
9 BUTTERFLY ARM ( R ) 1 10 BUTTERFLY ARM (L) 1
11 HANDLE BAR 4 12 SEAT TUBE 1
13 14 LEG DEVELOPER 1
15 PAD SUPPORTING TUBE 1 16 ROLL PAD TUBE 2
17 SIDE VERTICAL TUBE(UP) 1 18 SIDE VERTICAL TUBE
(DOWN)
1
19 SIDE BASE TUBE 1 20 SIDE SUPPORT TUBE(L) 1
21 SIDE SUPPORT TUBE (R ) 1 22 PEDDAL TUBE (R) 1
23 PEDAL TUBE (LEFT) 1 24 T-BAR 1
25 LAT PULL BAR 1 26 BOLT M10X70L 21
27 BOLT M10X65L 8 28 BOLT M10X60L 4
30 BOLT M10X45L 1
31 BOLT M10X40L 8 32 01O WASHER 52
33 ANTI-SLIP BOLT M10 32 34 BOLT M12X130L 1
35 BOLT M12X80L 1 36 012 WASHER 6
37 ANTI-SLIP BOLT M12 4 38 012 WASHER 2
39 BOLT M8X40L 3 40 NUT M8X20L 8
41 BOLT M8X15L 6 42 M8X16L BOLT 2
43 BOLT M8X15L 2 44 08 WASHER 14
45 ANTI-SLIP NUT M8 5 46 M5X30L SCREWS 4
48 038X026.5X1 WASHER 4
49 BEARING 4 50 SMALL BEARING 4

5
PARTS LIST
51 08 WASHER 2 52 SHOCK ABSORBER 2
53 T TYPE SUPPORTING PLATE 2 54 PRESS PIN 1
55 PULLEY CONNECTING
PLATE
2 56 DOUBLE PULLEY BRACKET 1
57 SINGLE PULLEY GROUP 2 58 PIN 1
59 PIN 1 60 HOOK 5
61 CHAIN 2 62 TUBE HOUSING 1
63 BALL 025 TUBE CAP 1 64 RUBBER WASHER 2
65 T TYPE NYLON CAP 6 66 PULLEY A 11
67 PULLEY B 1 68 PULLEY HOUSING 2
69 50X50MM TUBE CAP 7 70 025 TUBE CAP 2
71 30X60 TUBE CAP 2 72 025 TUBE CAP 2
73 50X50 TYPE FOOT CAP 2 74 50X50 FOOT CAP 4
75 PVC HANDLE BAR HOUSING 8 76 025 TUBE CAP 4
77 HALF ROUND COVER 2 78 038X026.5 INSERT CAP 4
79 5OX5OX025 CAP 2 80 38X38X025 CAP 2
81 CONE TYPE WASHER 2 82 BIG SPONGE 2
83 SMALL SPONGE 4 84 M10X35 KNOB 1
85 M10 M10 KNOB 1 86 WEIGHT STACK TOP PLATE 1
87 WEIGHT PLATE 9 88 BACK CUSHION 1
89 SEAT CUSHION 1 90 PREACHER PAD 1
91 SMALL BACK CUSHION 1 92 ELBOW CUSHION 2
93 INSIDE CAP 1 94 CABLE A 1
95 CABLE B 1 96 CABLE C 1

6
EXPLODED DRAWING

7
ASSEMBLY INSTRUCTIONS
STEP 1
1. ASSEMBLE MAIN BASE TUBE (1) AND REAR BASE TUBE (2) WITH 2 X BOLT M10*70(26), 4 X
Ø10 WASHER(32) AND 2X M10 NUT (33)
NEEDS DIAGRAM IMAGE

8
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 2
1. INSERT THE WEIGHT SLIDER TUBE(4) THROUGH RUBBER RING(64) UNDER REAR BASE
TUBE(3) WITH 2X M8*20 BOLT(40) AND 2X *Ø8 WASHER（44（
2. PUT DOWN WEIGHT PLATE (87) THROUGH WEIGHT SLIDER TUBE (4)
3. ASSEMBLE TUBE HOUSING(62) AND WEIGHT PICK UP POLE (5) WITH PIN(58).INSERT
INSIDE OF WEIGHT PLATE AND PUT DOWN THE WEIGHT STACK TOP PLATE(86) ON TOP
4. INSERT THE PIN (59) INTO WEIGHT STACK

9
ASSEMBLY INSTRUCTIONS
STEP 3
1. ASSEMBLE WEIGHT SLIDER TUBE(4) AND TOP BRACE TUBE(7) WITH 2X M8*20 BOLT(40)
AND 2XØ8 WASHER(44),FIXED THEM
2. ASSEMBLE TOP BRACE TUBE(7) AND MAIN SUPPORT TUBE(6) WITH 2XM10*70
BOLT(26),2XØ10 WASHER(32)AND 2XM10 NUT(33)
STEP 4
1. ASSEMBLE SUPPORT TUBE FOR BETTERFLY ARM(8) AND TOP BRACE TUBE(7) WITH
M12*130 BOLT(34),4*BEARING(50) AND 2XØ12WASHER（36（TIGHTEN WITH M12 NUT(37)

10
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 5
1. ASSEMBLE BUTTERFLY ARM (9,10) AND SUPPORT TUBE(8) WITH 2 BEARING(49) AND Ø12
WASHER(36),TIGHTEN M12 NUT(37)
2. ASSEMBLE THE BIG SPONGE(82) TO THE BUTTERFLY ARM(9,10) AND THE SQUARE END
ISIDE CAP(80);HANDLE CAP(75)
3. INSERT THE HANDLE BAR(11) TO THE BUTTERFLY ARM(9,10) FIXED WITH M8*20 BOLT(40)
AND Ø8 WASHER(44)

11
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 6
1. ASSEMBLE THE PRESS PIN(54) AND MAIN SUPPORT TUBE(6) WITH M8*40BOLT(39);2 X Ø8
WASHER AND M8 NUT, FIXED

12
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 7
1. ASSEMBLE SEAT TUBE(12) AND MAIN SUPPORT TUBE(6) WITH 2XM10*70 BOLT(26) AND
4X Ø10 WASHER(32),2X M10 NUT(33),TIGHTEN
2. ASSEMBLE LEG DEVELOPER(14) AND SEAT TUBE(12) WITH M12*80 BOLT(35)2*Ø12
WASHER(36)AND M12 NUT, TIGHTEN
3. INSERT THE PREACHER PAD SUPPORT TUBE(15) INTO THE LEG DEVELOPER(14) FIXED
WITH KNOB (84)

13
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 8
1. FIXED THE SIDE BASE TUBE(19) AND MANI BASE TUBE (1) WITH 2*M10*70 BOLT(26),4*Ø10
WASHER(32)AND 2 X M10 NUT (33)
2. FIXED THE SIDE VERTICAL TUBE(18) AND SIDE BASE TUBE(19) WITH 2*M10*70 BOLT(26),
4*Ø10 WASHER(32)AND 2 X M10 NUT (33)

14
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 9
1. INSERT THE SIDE VERTICAL TUBE(UP) INTO THE SIDE VERTICAL TUBE(DOWN) FIXED
WITH 2X M10*60 BOLT(8),4*Ø10 WASHER(32)AND 2*M10NUT(33)FIXED TOP BRACE
TUBE(7) WITH 2PCSM10*70(26)4*Ø10 WASHER(32)AND 2*M10NUT（33（

15
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 10
1. ASSEMBLE THE SIDE SUPPORT TUBE L & R (21,22) AND SIDE VERTICAL TUBE(UP) (17)
WITH 2PCS M10*70 BOLT(26); 4PCS Ø10 WSHER(32)AN2PCS M10 NUT(33),TIGHTEN
2. INSERT THE VERTICAL HANDLE BAR(75) INTO SIDE SUPPORT TUBE L & R (21,22) FIXED
WITH M8*20 BOLT(40) AND Ø8 WASHER(44)

16
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 11
1. ASSEMBLE THE PEDAL SUPPORT TUBE L & R AND SIDE VERTICAL TUBE (18) WITH
WASHER(48), NYLON WASHER(78),CAP(77) AND M8*16 BOLT(42), TIGHTEN
2. FIXED THE SHOCK ABSORBER(52), SIDE VRTICAL TUBE(18) AND PEDAL SUPPORT
TUBE(22) WITH M8*40 BOLT(39),2*Ø8 WASHER(44)AND M8*10BOLT(43)Ø8 WASHER(51)

17
ASSEMBLY INSTRUCTIONS
STEP 12
1. ASSEMBLE THE BACK CUSHION (88) AND MAIN SUPPORT TUBE(6) WITH 2*M10*65 BOLT
(27) AND 2*Ø10 WASHER(32)
2. FIXED THE “T” TYPE SUPPORTING PLATE(53) AND SEAT CUSHION(89) WITH 4PCS M8*15
BOLT(41)AND 4PCS Ø8 WASHER(44) FIRST. ASSEMBLE THE SEAT CUSHION (89) AND SEAT
TUBE (12) WITH 2*M10BOLT(33) & 2*Ø10WASHER（32（
3. FIXED PREACHER PAD(90) AND SUPPORTING TUBE(15) WITH 2*M8*15BOLT (41) &
2*Ø8WASHER(44)
4. FIXED THE SAMLL BACK CUSHION(91) AND SIDE VERTICAL TUBE(UP)(17)WITH 2PCS
M10*65 BOLT(27)AND 2PCS Ø10 WASHER(32)
5. FIXED THE SAMLL ELBOW CUSHION (92) AND SIDE SUPPORTING TUBE L & R WITH 2PCS
M10*65 BOLT(27) AND 2PCS Ø10 WASHER(32)

18
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 13
1. FIXED THE SINGLE PULLEY BRACKET (57) AND MAIN SUPPORT TUBE(6) WITH M10*60
BOLT(28)
2. FIXED ONE END OF CABLE C AND BUTTERFLY ARM L (10) WITH M8*15 BOLT(41)M8
NUT（45（ LET CABLE C GOES THROUGH SINGLE PULLLEY BRACKET(57),THEN DOUBLE
PULLEY BRACKET(66),FIXED THEM WITH M10*40 BOLT; M10 NUT. FINALLY GO UP
THROUGH SINGLE PULLEY BRACKET(57) AND FIXED THE CABLE END AND BUTTERFLY
ARM R(9) WITH M8*15 BOLT(41)M8 NUT(45)

19
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 14
1. LET CABLE A GOES THROUGH PULLEY B (67) FIRST, THEN FIXED THE PULLEY
HOUSING(30) PULLEY B(67) AND TOP BRACE TUBE(7) WITH M10*45 BOLT AND M10 NUT.
LET CABLE A GOES THROUGH THE PULLEY OF MAIN SUPPORT TUBE(6),OVER PULLEY
CONNECTING PLATE(55),GOES UP THROUGH THE PULLEY(66)ON THE TOP BRACE TUBE(6)
FIXED WITH WEIGHT PICK UP POLE AFTER GOES THROUGH Ø12 BIG WASHER. TIGHTEN
ALL PULLEYS WITH M10*45 BOLT(31) AND M10 NUT(33)

20
ASSEMBLY INSTRUCTIONS
NEEDS DIAGRAM IMAGE
STEP 15
1. LET CABLE B GOES THROUGH PULLEY OF LEG DEVELOPER FIRST AND THE PULLEY OF
MAIN SUPPORT TUBE. THEN GOES THROUGH AS SHOWN AS THE DRAWING CONNECTED
WITH HOOK AND CHAIN
