Fitbit Zip Surge User manual

Product Manual
Version 1.0

Table of Contents
Getting Started ....................................................................................................1
What you’ll find in the box..................................................................................................................1
What you’ll find in this document ....................................................................................................1
Setting up your Surge........................................................................................ 3
Setting up your tracker using a mobile device..........................................................................3
Setting up your tracker using a Mac or PC..................................................................................3
Mac & PC requirements...................................................................................................................3
Downloading Fitbit Connect .........................................................................................................3
Installing Fitbit Connect and pairing your tracker................................................................3
Syncing with a computer............................................................................................................... 4
Getting to know your Surge.............................................................................. 5
Wearing your Surge..............................................................................................................................5
Specifying dominant or non-dominant hand......................................................................... 6
Using your Surge in wet conditions .......................................................................................... 6
Getting around your Surge................................................................................................................7
Changing the clock display............................................................................................................... 8
Measuring heart rate ........................................................................................................................... 8
Default heart rate zones ................................................................................................................ 9
Custom heart rate zones ............................................................................................................... 9
Missing signal ....................................................................................................................................10
Using GPS ...............................................................................................................................................10
Battery life and charging ................................................................................................................... 11
Caring for your Surge ........................................................................................................................ 13
Automatic Tracking with Surge ...................................................................... 14
Tracking all-day stats.........................................................................................................................14

Tracking sleep.......................................................................................................................................14!
Tracking a daily goal .......................................................................................................................... 15!
Choosing a goal to celebrate...................................................................................................... 15!
Setting a value for your daily goal............................................................................................16!
Tracking Runs with Surge.................................................................................17!
Tracking a run ....................................................................................................................................... 17!
Using other Surge functions during a run.................................................................................. 18!
Tracking Exercise with Surge ......................................................................... 19!
Tracking exercise.................................................................................................................................19!
Choosing exercises to track ...........................................................................................................20!
Viewing stats tracked when exercising ...................................................................................... 21!
Using other Surge functions when exercising.......................................................................... 21!
Using Silent Alarms .......................................................................................... 22!
Setting silent alarms .......................................................................................................................... 22!
Dismissing or snoozing silent alarms .......................................................................................... 22!
Enabling or disabling silent alarms .............................................................................................. 23!
Receiving Call and Text Notifications ...........................................................24!
Enabling call and text notifications .............................................................................................24!
Viewing call and text notifications...............................................................................................24!
Disabling call and text notifications ............................................................................................ 25!
Controlling Music ..............................................................................................26!
Enabling music control.....................................................................................................................26!
Controlling music with your Surge .............................................................................................. 27!
Managing Settings on your Surge ..................................................................28!
Heart Rate Tracking........................................................................................................................... 28!
Backlight ................................................................................................................................................29!
Notifications..........................................................................................................................................29!
Bluetooth Classic ................................................................................................................................29!

Shutdown...............................................................................................................................................29!
Regulatory Info....................................................................................................................................29!
Using your Fitbit.com Dashboard.................................................................. 30!
Browser requirements ......................................................................................................................30!
Adding and removing tiles..............................................................................................................30!
Device info.......................................................................................................................................... 31!
Managing your tracker from Fitbit.com.................................................................................. 31!
Updating your Fitbit Surge .............................................................................32!
Restarting your Fitbit Surge ...........................................................................33!
Fitbit Surge General Info & Specifications....................................................34!
Sensors and motors...........................................................................................................................34!
Battery ....................................................................................................................................................34!
Memory...................................................................................................................................................34!
Display..................................................................................................................................................... 35!
Environmental conditions................................................................................................................ 35!
Help .......................................................................................................................................................... 35!
Return policy and warranty ............................................................................................................ 35!
Regulatory & Safety Notices ...........................................................................36!
USA: Federal Communications Commission (FCC) statement ........................................36!
Canada: Industry Canada (IC) statement..................................................................................36!
European Union (EU) ........................................................................................................................ 37!
Australia and New Zealand............................................................................................................. 37!
Mexico .....................................................................................................................................................38!
Israel.........................................................................................................................................................38!
South Africa ..........................................................................................................................................38!
South Korea ..........................................................................................................................................38!
Singapore...............................................................................................................................................39!
Taiwan.....................................................................................................................................................39!

Wireless sync dongle ....................................................................................................................39!
Surge ...................................................................................................................................................39!
Russia ..................................................................................................................................................... 40!
United Arab Emirates....................................................................................................................... 40!
Safety statement..................................................................................................................................41!
Important safety instructions..........................................................................................................41!
Cautions...............................................................................................................................................41!
Care and wearing tips....................................................................................................................41!
Built-in battery precautions........................................................................................................42!
Disposal and recycling information .............................................................................................42!

1
Getting Started
Welcome to Fitbit Surge, the high-performance Fitness Super Watch that helps you
meet your fitness goals.
What you’ll find in the box
Your Fitbit Surge box includes:
Surge
Fitness Super Watch
USB charging cable
Wireless sync
dongle
What you’ll find in this document
This manual gets you started quickly setting up your tracker. Setup ensures that your
tracker can synchronize its data with Fitbit.com or the Fitbit mobile app, where you
can get detailed information on your stats, view historical trends, log food, and more.
As soon as setup is complete you’re ready to start moving.
Next the manual introduces you to your Surge, specifically how to use the buttons
and touchscreen to find your stats and track a run or other exercise.
The remainder of the manual walks you through every function on your Surge and
also explains how to update your tracker when free firmware updates are available.
Throughout the manual you’ll notice that for tasks that can be done on the Fitbit.com
dashboard or the Fitbit mobile app, only the Fitbit.com instructions appear—if you
have the Fitbit app for iOS, Android, or Windows Phone, you can easily find the
comparable task in the app without needing tap-by-tap instructions here. That said,
all the details of our mobile apps are described in our articles at
https://help.fitbit.com. Just select Surge and then browse the iOS, Android, or
Windows Phone categories.
The manual concludes by explaining how to restart your Surge in the event you
encounter difficulty with your tracker. All other troubleshooting suggestions, as well

2
as detailed information about how Fitbit trackers and services work, can be found in
the articles on our help site, https://help.fitbit.com. Just select Surge and then pick
from a category to browse, or enter a search term to find something specific. Do us a
favor and rate the articles you read—it’s how we know we’re getting you the right
information at the right time!

3
Setting up your Surge
You can set up your Surge using your computer or the Fitbit apps for iOS, Android,
or Windows Phone.
Setting up your tracker using a mobile device
Over 120 mobile devices that support Bluetooth 4.0 technology allow you to set up
and wirelessly sync your Surge. To see if your mobile device is compatible with your
Surge, visit www.fitbit.com/devices. If your device is listed, you can then download
our free mobile app and follow the setup process in the app. If your device is not
listed, check back frequently because we’re continually adding new devices.
Even if your mobile device cannot sync via Bluetooth 4.0, you can still use the Fitbit
app to view your data and track your progress—you’ll just need to set up and sync
your Surge using a Mac or PC.
Setting up your tracker using a Mac or PC
To set up your Surge using your computer, you’ll first install Fitbit Connect. Fitbit
Connect is the software application that connects (“pairs”) your Surge to your
Fitbit.com dashboard, where you can view your data, log food, and more.
Mac & PC requirements
Software
Mac OS 10.6 or later
Internet Connection
Hardware
USB port
Software
Windows Vista or later
Internet Connection
Hardware
USB port
Downloading Fitbit Connect
1. Go to http://www.fitbit.com/setup.
2. Scroll down and click the pink Download button. If the button does not
correctly show your type of computer (for example, if it says “Download for
Mac” when you’re on a PC), choose the correct type before clicking the
button.
3. When prompted, save the file.

4
Installing Fitbit Connect and pairing your tracker
1. Plug in the wireless sync dongle and have your tracker nearby, turned on, and
charged.
2. Go to the folder containing the file you just downloaded and look for the
installation program:
-For Mac: Install Fitbit Connect.pkg
-For Windows: FitbitConnect_Win.exe
3. Double-click the file name to start the installation process.
4. Follow the brief onscreen instructions to finish setting up. You’re ready to get
moving.
Syncing with a computer
Now that Fitbit Connect is installed, your Surge will automatically and wirelessly
synchronize its data to your dashboard every 15-20 minutes under these conditions:
•Your Surge is within 15-20 feet of your computer and has new data to upload
(meaning if you haven’t moved, an automatic sync won’t occur).
•Your computer is powered on, awake, and connected to the Internet.
•The wireless sync dongle is inserted into a USB port and is recognized by the
computer.
To manually synchronize your Surge with your dashboard, click the Fitbit Connect
icon on your computer (located near the date and time) and click Sync Now.

5
Getting to know your Surge
Wearing your Surge
Your Surge should be worn on your wrist. While it may track stats such as steps and
floors when placed in a pocket or backpack, it is most accurate on the wrist. For all-
day wear, your Surge should usually rest a finger’s width below your wrist bone and
lay flat (as you would normally wear a watch).
As with all heart-rate monitoring technology, whether a chest strap or a wrist-based
sensor, accuracy is affected by personal physiology, location of wear, and type of
movement. In other words, not every person will get a perfectly accurate reading
with every type of exercise. For best heart rate accuracy keep these tips in mind:
1. Experiment with wearing the tracker higher on your wrist during exercise.
Because blood flow in your arm increases the farther up you go, moving the
tracker up a couple inches can improve the heart rate signal. Also, many
exercises such as spinning cause you to bend your wrist frequently, which is
more likely to interfere with the heart rate signal if the tracker is lower on your
wrist.

6
2. Do not wear your tracker too tight; a tight band restricts blood flow,
potentially affecting the heart rate signal. That being said, the tracker should
also be slightly tighter (snug but not constricting) during exercise than during
all-day wear.
3. With high-intensity interval training or other activities where your wrist is
moving vigorously and non-rhythmically, the movement may prevent the
sensor from finding an accurate heart rate. Similarly, with exercises such as
weight lifting or rowing, your wrist muscles may flex in such a way that the
band tightens and loosens during exercise. Try relaxing your wrist and staying
still briefly (about 10 seconds), after which you should see an accurate heart
rate reading.
Specifying dominant or non-dominant hand
To improve the accuracy of your Surge, we ask you to specify whether you’re
wearing it on your dominant or non-dominant hand. Your dominant hand is the one
you use for most day-to-day activities such as writing or brushing your teeth. You
can specify this setting in the Fitbit app or in the Fitbit.com dashboard.
To make this choice using the Fitbit.com dashboard:
1. Log in to Fitbit.com.
2. Click the gear icon in the top-right corner of the dashboard and select
Settings.
3. Using the navigation tabs on the left, find and specify the correct setting for
Dominant Hand.
4. Sync your Surge to update your tracker with the new setting:
a. Click the Fitbit Connect icon near the date and time on your computer.
b. Make sure your Surge is nearby and click Sync Now.
Using your Surge in wet conditions
Your Surge is splash-proof, rain-proof, and can withstand even the sweatiest
workout. Your Surge is not designed to be worn swimming. We also recommend
removing your tracker before showering. Though the device can withstand the water
exposure, wearing your tracker 24/7 does not allow your skin to breathe. After
getting your tracker wet, dry it thoroughly before putting it back on. For more
details, see https://www.fitbit.com/productcare.

7
Getting around your Surge
The Fitbit Surge has a touch screen with a backlight and three buttons: Home, Select,
and Action. Take a moment to memorize these button names and their location or
refer back to this image when reading the tasks in this manual:
Your Surge has two sets of screens: the Clock, where you can see your all-day stats,
and the Menu. To switch between the two sets, press the Home button.
•When viewing the Clock, swipe left and right to see:
oCurrent heart rate
oSteps taken
oDistance covered
oCalories burned
oFloors climbed
•When viewing the Menu, swipe left and right to see the different menu items.
To choose a menu option, either press the Select button or just tap the screen.
To exit the Run, Exercise, Alarms, or Settings screens, press the Home button.

8
The functions of the Select and Action buttons vary depending on what you’re doing.
An icon next to the button tells you what it does, such as pausing and resuming or
selecting an option.
Double-pressing the Home button displays the music playback control. For more
information, see “Controlling Music” on page 26.
Changing the clock display
You can choose a different clock face on the Fitbit app or the Fitbit.com dashboard.
Changing the clock face also changes the appearance of the all-day stats to resemble
the style of the clock.
To choose a different clock face using the Fitbit.com dashboard:
1. Log in to Fitbit.com.
2. Click the gear icon in the top-right corner of the dashboard and select
Settings.
3. Using the navigation tabs on the left, find Clock Display and choose a clock
face. The default, called Flare, provides a visual representation of your activity
level during the current hour.
Orbit Analog Digital Flare
4. Sync your Surge to update your tracker with the new clock face:
a. Click the Fitbit Connect icon located near the date and time on your
computer.
b. Make sure your Surge is nearby and click Sync Now.
Measuring heart rate
When your heart beats, your capillaries expand and contract based on blood volume
changes. PurePulse™ LED lights on the back of your Surge reflect onto the skin to
detect blood volume changes, and finely tuned algorithms are applied to measure
heart rate automatically and continuously.
When viewing the Clock, swipe to display your current beats per minute and heart
rate zone.

9
Default heart rate zones
Heart rate zones let you target different training intensities to help you optimize your
workout. Your zones are calculated based on your estimated maximum heart rate,
which is 220 minus your age.
To quickly determine what zone you’re in, take a look at the heart icon:
Out of zone Fat burn Cardio Peak
•When you’re out of zone, which means you’re below 50% of your maximum
heart rate, your heart rate may be elevated but not enough to be considered
exercise.
•Fat Burn zone, which means your heart rate is between 50% and 69% of your
maximum, is the low-to-medium intensity exercise zone and may be a good
place to start for those new to exercise. It’s called the Fat Burn zone because a
higher percentage of calories are burned from fat, but the total calorie burn
rate is lower.
•Cardio zone, which means your heart rate is between 70% and 84% of your
maximum, is the medium-to-high intensity exercise zone. In this zone you’re
pushing yourself but not straining. For most people this is the exercise zone to
target.
•Peak zone, which means your heart rate is 85% of your maximum or higher, is
the high-intensity exercise zone. Peak zone is for short intense sessions that
improve performance and speed.
At any time you can check your dashboard to see the amount of time you’ve
spent in each zone.
Custom heart rate zones
Instead of using the default heart rate zones you can configure a custom zone.
When your heart rate is above or below your custom zone you’ll see an outline of a
heart, and when your heart rate is in your custom zone you’ll see a solid heart.
To set a custom heart rate zone using the Fitbit.com dashboard:
1. Log in to Fitbit.com.
2. Click the gear icon in the top-right corner of the dashboard and select
Settings.
3. Using the navigation tabs on the left, find Heart Rate Zones and specify the
minimum and maximum heart rate for your custom zone.
4. Sync your Surge to update your tracker with the new setting:

10
a. Click the Fitbit Connect icon located near the date and time on your
computer.
b. With your Surge nearby click Sync Now.
At any time you can check your dashboard to see the amount of time you’ve spent in
your custom zone.
For more details about heart rate monitoring, including links to relevant American
Heart Association information, see our “Heart rate FAQs” article on
https://help.fitbit.com.
Missing signal
Surge continuously monitors your heart rate while you’re exercising and throughout
the day. However, occasionally the heart rate monitor may have difficulty finding a
good enough signal to show a hear rate. In those cases, you’ll see this screen:
If you’re not getting a heart rate signal, first make sure you’re wearing your Surge
correctly, either moving it higher or lower on your wrist or tightening or loosening
the band. After a short wait, you should see your heart rate again. If a heart rate
signal is still not found, check your Heart Rate Tracking setting; see “Managing
Settings on your Fitbit Surge” on page 28 for more information.
Using GPS
The Fitbit Surge includes a GPS receiver to track your route during several activities,
including Free Run, Lap Run, Walk, Bike, and Hike. On your dashboard, GPS data is
shown in a map view along with the stats tracked during the activity.
When you select a run or exercise that uses GPS, Surge begins searching for a GPS
signal. As with any GPS device, a signal is likely to be discovered more quickly if you
are outside in an open area and standing still.

11
For best results, wait for the signal to be discovered before you start your activity.
If a GPS signal isn’t discovered within a few seconds, a Quick Start option appears for
all GPS exercises except Bike.
If you don’t want to wait for the GPS signal to be discovered, you can press the
Select (Quick Start) button to move to the activity screen and get started. Surge will
continue to search for a GPS signal, but it will take longer to find than if you were
standing still.
If you start moving before the GPS signal is discovered, Surge uses your step count
to estimate how far you went before GPS tracking began. Therefore, the total
distance calculated for the activity may be slightly less accurate than it would be if
you got a GPS fix and then started moving. The Quick Start option does not appear if
you’re tracking a bike ride because GPS is required for calculating your distance.
Wait for a GPS fix before starting your ride.
NOTE: A maximum of 35 hours of GPS data can be stored on your Surge. If you try to
track more than 35 hours’ worth of GPS data without syncing, older data will
be deleted to make room for new data. To ensure that all your GPS data is
saved on Fitbit.com, sync your Surge regularly.
Battery life and charging
Depending on your usage, your battery life may vary:
•If you aren’t tracking runs or exercises that use GPS, your fully charged Surge
should last 7 days or more as a fitness watch with continuous heart rate
monitoring and activity tracking.
•Your fully charged Surge can track a maximum of about 5 hours of activities
that use GPS before needing a charge. To ensure that you’re always tracking
your data, we recommend charging your Surge after any activity that uses
GPS.

12
To charge your Surge, plug the charging cable into the USB port on your computer
and plug the other end into the port on the back of the Surge. You can also plug your
charging cable into any standard USB wall charger. Charging completely takes 1 to 2
hours.
When looking at the Menu, your tracker’s battery level appears in the top left.
Full Partially Full Very Low Critically Low Charging
If your battery is critically low, charge your Surge as soon as possible.
You can also check your battery level from the Fitbit app, or by logging into
Fitbit.com and clicking the gear icon on the top-right corner of the page. In these
cases, the battery level shown reflects the last time you synced your Surge. To make
sure you are seeing the current battery level, sync your Surge.
If you want to receive a mobile notification or email when your battery is low:
1. Log in to your Fitbit.com dashboard.
2. Click the gear icon in the top-right corner of the page and select Settings.
3. Using the navigation tabs on the left, find Notifications and choose which ones
you would like to receive.
4. Click Save.
If you won’t be using your Surge for a while, you can conserve battery life by
shutting it down; see “Managing Settings on your Surge” on page 28.

13
Caring for your Surge
Clean and dry your Surge regularly, particularly under the band. Use skin care
products sparingly on the areas of the skin covered by your Fitbit product. For more
information, see https://www.fitbit.com/productcare.

14
Automatic Tracking with Surge
Your Surge tracks a variety of stats automatically whenever you are wearing it. When
you sync your Surge, this data is uploaded to Fitbit.com where you can view it on the
Fitbit.com dashboard or in the Fitbit app.
Tracking all-day stats
Your Surge automatically tracks and displays the following all-day stats:
•Steps taken
•Current heart rate
•Distance covered
•Calories burned
•Floors climbed
To view these stats, display the Clock and swipe left or right.
In addition to the stats displayed on your Surge, the following all-day stats are also
tracked but shown only on your Fitbit.com dashboard or in the mobile app:
•Detailed heart rate history, including time spent in heart rate zones
•Active minutes
•Hours slept and quality of sleep
Your Surge starts tracking your stats for the next day at midnight based on your time
zone. Though your stats reset to zero at midnight, this does not delete the previous
day’s data; that data will be uploaded to Fitbit.com the next time you sync your
Surge.
You can adjust your time zone at www.fitbit.com/user/profile/edit, or use the Fitbit
app to detect your time zone automatically.
Tracking sleep
Your Surge automatically tracks the hours you sleep and your movement during the
night to help you understand your sleep quality. You don’t need to press any buttons
or otherwise enter a “sleep mode” to begin tracking sleep. Simply wear your Surge to
bed. Wearing your Surge while you sleep has the added benefit of making the
Resting Heart Rate measurements on your dashboard more accurate.
To see your sleep data, sync your tracker and then view the Fitbit.com dashboard or
mobile app. On the dashboard you can look at the sleep tiles or go to Log > Sleep. In
the mobile app tap your sleep tile.

15
Tracking a daily goal
Your Surge is designed to track your progress towards a goal that you define on
your Fitbit.com dashboard or in the Fitbit app. By default, your daily goal is set to
10,000 steps per day.
A progress bar keeps you motivated. For example, the solid portion of the line below
shows that you’re more than halfway to a goal of 10,000 steps.
When you reach your goal your Surge will vibrate and flash to celebrate.
Choosing a goal to celebrate
Using the Fitbit.com dashboard or the Fitbit app you can set your Surge to celebrate
a daily goal for steps taken (the default), distance traveled, calories burned, or floors
climbed.
To choose the goal you want to celebrate:
1. Log in to your Fitbit.com dashboard.
2. Click the gear icon in the top-right corner of the page and select Settings.
3. Using the navigation tabs on the left, find Daily Goal Progress and choose your
goal.
4. Sync your Surge to update your tracker with the new goal:
a. Click the Fitbit Connect icon located near the date and time on your
computer.
b. With your Surge nearby, click Sync Now.
