FitDesk FitStudent 4100 User manual

VISIT OUR WEBSITE: WWW.FITSTUDENT.COM
OR CALL US AT 1-855-713-8887 MONDAY - FRIDAY 9 A.M. - 5 P.M. EST
DISTRIBUTED BY FD PRODUCTS LLC
1161 SOUTH PARK DRIVE, KERNERSVILLE NC 27284
IMPORTANT: READ THE OWNER’S MANUAL BEFORE ASSEMBLING
MODEL: 4100
Junior Bike Desk

1
TABLE OF CONTENTS
INTRODUCTION
Thank you for choosing FitStudent™ We
hope your new FitStudent™ Junior Bike Desk
becomes a regular part of your daily routine. We
wish you good health and increased wellness as
you use the FitStudent™ to infuse activity into
parts of your day.
Before you start assembling your new Junior Bike
Desk please take a moment to read this manual
carefully before using your FitStudent™.
Specications:
Weight of Bike: 65 lbs
Recommended User Range:
Grades 2nd - 5th
Recommended Max User Weight:
150 lbs (68 kgs)
Introduction..............................................................1
Safety Warnings ......................................................2
Customer Service Questions...................................3
Tools ........................................................................4
Hardware.................................................................4
Parts ........................................................................5
Assembly.................................................................6
Warning and Labels.................................................10
Maintenance and Troubleshooting ..........................10
Warranty ..................................................................11
Complete Parts List .................................................13
Replacement Parts..................................................13
Exploded View.........................................................14
Other Great Products From FitDesk
®....................15
Desktop
Pedals
Front Stabilizer
Rear Stabilizer
Adjustment Knob
Storage Basket
Cup Holder Pencil Tray
Seat
Desk Storage

2
1. Read the entire manual before assembling and using the equipment. Safe use can only
be achieved if the equipment is assembled, maintained and used properly. All users of the
equipment must be informed of all warnings and precautions.
2. Before starting or using this equipment, you should consult your doctor to determine if you have
any health conditions that could create a risk to your health and safety or prevent you from using
the equipment properly.
3. Be aware of your body's signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in you chest, irregular
heartbeat, extreme shortness of breath or feeling light headed, dizzy or nauseous. If you do
experience any of these conditions consult your physician.
4. Read and follow all warning stickers on the FitStudent™.
5. Mount and dismount carefully. Extreme movements can tip machine resulting in injury and/
or equipment damage.
6. Usetheequipmentonasolid,levelsurfacewithaprotectivecoverforyouroororcarpet.
7. Inspect and tighten all parts often. Replace any worn parts immediately.
8. Ifyoundanydefectivecomponentswhileassemblingorcheckingtheequipmentorifyouhear
any unusual noises coming from the equipment during use, stop immediately. Do not use the
equipment until the problem has been resolved.
9. Recommended maximum user weight of 150lbs, 68 kg. Recommended for grades 2nd - 5th.
10. Do not stand while pedaling. For light exercise use only. The equipment is suitable for home
and school use only. Do not use in commercial or rental settings.
11. Do not sit on desktop this may cause tipping of the bike desk and injury.
12. Consult a physician if you feel pain or excessive discomfort while on the seat.
SAFETY WARNINGS - URGENT PLEASE READ THIS SECTION
WE WANT YOU TO SAFELY USE THIS PRODUCT

3
CUSTOMER SERVICE QUESTIONS
NEED HELP?
CONTACT US FIRST
1-855-713-8887
MONDAY - FRIDAY 9 A.M. - 5 P.M. EST
EASY TO USE CUSTOMER TICKETING
Step 1: www.thetdesk.com
Step 2: “Support”
Step 3: “Submit a Support Ticket”
customerservice@tstudent.com
FOR FASTEST POSSIBLE SERVICE PLEASE HAVE AVAILABLE
Model # 4100 - Serial # (Located on tubular base safety sticker)
WWW.FITSTUDENT.COM

4
TOOLS
HARDWARE
Estimated Assembly Time: 30 minutes
Note: Hardware and Tools not shown to actual size.
Note: If parts or hardware are missing contact customer service immediately. Please do not discard
your packaging until your entire FitStudent™ is fully assembled. Some parts are purposely packaged
in cardboard or Styrofoam and can mistakenly be thrown away with the packaging.
Each FitStudent™ comes equipped with one 4mm Allen Wrench (AA), one 5mm Allen Wrench (BB),
one Multi-functional Wrench (CC), and one 19mm Wrench (DD). It is recommended if you have your
own tools, that you use a 1/2” socket with drive and a 15mm Wrench to tighten the pedals from time to
time.
AA. 4mm Allen Wrench
(Supplied)
CC. Multi-functional
Wrench
DD. 19mm Wrench
BB. 5mm Allen Wrench
(Supplied)
EE. (6) M6*12 Bolt
I I. (4) M8*Nuts
HH. (4) M8*Curved Washers
GG.(2) 9/16” Nut (Left-Hand/Right-Hand
FF. (5) M8*16 Bolt

5
PARTS
A. Desktop
E . Seat
C. Seat Post
F. Main Frame
H. Basket
G. Front Stabilizer
I. Rear Stabilizer
B. Desktop Post
D. Left and Right Pedals

6
ASSEMBLY
We take great care to deliver quality products that will last for years. However, even with years of
manufacturing experience and high levels of quality control, problems still occur from time to time. If
you experience a problem with any part of your new FitStudent™, please contact us before returning
your product. In most cases, we can quickly resolve the issue with technical advice or easily send a
replacement part if needed.
The included Allen Wrench (AA), (BB) and
Wrench (CC) and Multi-functional Wrench (DD)
are required to complete this assembly. To make
the assembly easier, we recommend using a 1/2
inch Socket Wrench, and a 15mm Wrench.
NOTE: Before assembly please check all parts carefully.
Step 1: Remove the two nuts and washers
from the Front Stabilizer (G) and set aside for
reinstallation. Install the Front Stabilizer to the
Main Frame (F). Using the Multi-functional
Wrench (CC) (supplied), reinstall the two nuts and
washers and hand tighten. Repeat the process for
Rear Stabilizer (I). Figure 1
Note: Periodically check Front and Rear
Stabilizers for tightness.
1/2” Socket Wrench
15mm Wrench
Figure 1 F
G
F
DETAIL

7
ASSEMBLY
Step 2: Remove the nut from the Left “L” Pedal
(D) and set aside for reinstallation. Using the
Multi-functional Wrench (CC) (supplied), install
the “L” Pedal (reverse threading required) onto
the crank arm. Using the 19mm wrench (DD)
(supplied), reinstall the nut and tighten (Left pedal
is reverse thread). Figure 2
Note: The Pedals must be made extra tight.
WARNING: Care should be taken not to damage
the threads due to over tightening.
Figure 3
Figure 4
Step 3: Remove the nut from the Right “R” Pedal
(D) and set aside for reinstallation. Using the
Multi-functional Wrench (CC) (supplied), install the
“R” Pedal onto the crank arm. Using the 19mm
wrench (DD) (supplied), reinstall the nut and
tighten (Right pedal not reverse thread). Figure 3
Figure 2
Step 4: Using the 4mm Allen Wrench (AA)
(supplied), Install the Seat (E) to the Seat Post (C),
with four M6*12 Bolts (EE).
Figure 4

8
ASSEMBLY
Step 5: Disengage the height adjuster knob by
pulling outward and install the seat assembly
onto the Main Frame (F) Re-engage the height
adjuster knob. Using the 5mm Allen Wrench (BB)
(supplied), install the M8*16 Bolt (FF) and lightly
hand tighten. Final adjustments to the desired
seatheightwillbecompletedafternalassembly
in Step 8. Figure 5
Step 6: Disengage the height adjuster knob by
pulling outward from the Main Frame (F). Using
the 5mm Allen wrench (BB) (supplied), remove the
M8*16 Bolt (BB) and set aside for reinstallation.
Remove Desktop Post (B). On a clean surface,
free of debris that could possible scratch the
surface, turn the Desktop (A) over to install the
Desktop Post (B). Using a 5mm Allen Wrench
(BB), install the four M8*16 Bolt (FF) (supplied)
and tighten. Upright the Desktop and install the
assembly into the Main Frame (D). Reinstall
the M8*16 Bolt (FF) and lightly tighten Final
adjustments to the desired desktop height will be
completedafternalassemblyinStep8. Figure 6
Desktop
Desktop Post
Seat Assembly
Height Adjuster
Knob
Figure 5
Figure 6

9
ASSEMBLY
Step 7: Using the 4mm Allen Wrench (AA)
(supplied), install two M6*12 Bolt (EE) to attach
the Storage Basket (H) to the Main Frame (F).
Figure 7
Step 8: Assembly of your new FitStudent™
Main Frame
Storage Basket
Figure 8
Figure 7
Desktop
Height Adjuster Knob
Seat Height
Adjuster Knob
Junior Bike Desk is complete. If necessary,
adjust the Seat to the desired height by following
the series of steps in Figure 5. If necessary, adjust
the Desktop to the desired height by following the
series of steps in Figure 6. Figure 8

10
WARNING and LABELS
MAINTENANCE AND TROUBLESHOOTING
The integrity of the FitStudent™ bike can only be achieved when it is regularly maintained for
damage and wear. Special attention should be given to the following:
HARDWARE
Verify that all bolts are present and properly tightened.
TIP: Inspect nuts, screws and knobs on a weekly basis.
MAIN FRAME, SEAT, SEAT POST
Properly adjust seat for comfort and stability.
NOTE: Check Main Frame, Seat, Seat Post, Desktop mounting areas for wear.
WARNING: Do not use if any sign of frame cracking. Worn or damaged parts and components must
be replaced immediately.
PEDALS
Check pedals tightness with 15mm wrench.
NOTE: Make Pedals EXTRA Tight during Assembly.
FRONT and REAR STABILIZERS
Periodically check the Front and Rear Stabilizer bolts for tightness.
NOTE: Read all warning stickers before operating this product.
15OLBS / 68 KG
4100
1-855-713-8887
Read and follow the instruction manual before
assembling or using this product. This product
is intended for grades 2-5. Check that all hard-
ware is tight and secure before use. This label
should not be removed.
Contact FD Products, LLC for any questions.

11
WARRANTY
This limited warranty is applicable to each original end-customer (hereinafter “Customer”) purchasing the FitStudent™
Model: 4100 Student Bike Desk consisting of the structural metal frame (hereinafter the “Structural Frame”) and various
other non-frame components (hereinafter the “Non-Frame Parts”) sold by FD Products, LLC (hereinafter “Company”) for
Customer’s own use and not for resale. The Structural Frame and Non-Frame Parts are collectively referred to herein as
the “Products”.
1. LIMITED WARRANTY; EXCLUSIVE REMEDIES:
1.1. LIMITED WARRANTY ON PRODUCTS: Company warrants solely to the original Customer that (a) the Structural Frame
will be free from defects in materials and workmanship under normal use for a period of ONE (1) YEAR from the date
of original retail purchase, and (b) the Non-Frame Parts, will be free from defects in materials and workmanship under
normal use for a period of NINETY (90) DAYS from the date of original retail purchase. Notwithstanding the foregoing,
thecolorsand nishesoftheProducts mayvarywithinareasonablescopeduetounavoidable colorvariations in
different production batches, and such variations shall not constitute a material defect. This limited warranty is limited
solely to the original Customer with proof of purchase and is not transferable.
1.2. THE WARRANTY: During a covered Product’s limited warranty period, Company will, at Company’s sole option and
discretion, (1) repair the defective component or product without charge or (2) replace the defective component or
product without charge.
1.3. The foregoing limited warranty is subject to the Customer’s proper storage, transportation, handling and use of the
ProductsasthesamearedenedwithinCompany’sthen-currentpublishedguidesandinstructionsforuseandcare.
The limited warranty does not include defects due to normal wear and tear, abuse or misuse, mishandling, neglect,
accident,re,lightning,sunlightorothernaturalhazard,deliveryortransportationdamage,failuretofollowapplicable
directionsorinstructions,orimproperorinadequatecleaning,maintenance,care,repairs,modications,orusebeyond
a Product’s intended use.
1.4. LIMITED WARRANTY CLAIMS PROCEDURE: To obtain performance under this limited warranty, Customer shall
notify Company in writing (to FD Products, LLC, 1161 South Park Drive, Kernersville, NC 27284, Attn: Customer
Service/WarrantyDepartment),byemail(tocustomerservice@thetdesk.com),orbytelephone(to(336)423-5029)
with a full description of the defect that is covered by warranty and a copy of the dated proof of purchase of the
applicable product.
• Company shall review each such claim and issue Customer a return merchandise authorization (“RMA”) in the event
that the described defect or condition merits warranty review as determined by Company. Customers who have been
issued a RMA shall, at Company’s election, return the covered item to the same physical address listed above for
reporting initial claims. Company shall not accept any returned product without a RMA.
• Upon receipt, Company will evaluate the returned product(s) to determine if there is a warranty claim and, if so, how
Company wishes to remedy the same. During a covered product’s respective limited warranty period, Company will,
at Company’s sole and absolute option and discretion, (1) repair the defective component or product without charge
or (2) replace the defective component or product without charge. Refunds are not available pursuant to this limited
warranty.
• Customer is solely responsible for transportation of the covered product(s) to the Company for evaluation (if applicable
andrequestedbyCompany).IntheeventthatCompanydeterminesthataclaimunderthislimitedwarrantyisjustied,
Company shall be responsible for transportation of the repaired, corrected, replaced or exchanged product back to
Customer. Customer shall be solely responsible for the transportation of any product back to Customer if Company
determinesthataclaimunderthiswarrantyisnotjustied.
• Any repaired, corrected, replaced or exchanged Products shall be subject to the Limited Warranty set forth to the
duration of the original limited warranty period as set forth in Section 1.1. and not for any extended duration, following
their repair, correction, replacement or exchange.

12
WARRANTY
1.1. IF A COMPANY PRODUCT DOES NOT CONFORM TO THESE LIMITED WARRANTIES, THE PURCHASER’S
SOLE AND EXCLUSIVE REMEDY IS, AT COMPANY’S SOLE AND EXCLUSIVE OPTION, THE (1) REPAIR OF
ANY DEFECTIVE PRODUCT OR COMPONENT PART OR (2) REPLACEMENT OF ANY DEFECTIVE PRODUCT
OR COMPONENT PART. THE LIMITED WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE
AND MADE IN LIEU OF ALL OTHER WARRANTIES, REMEDIES, RIGHTS OR CONDITIONS, WHETHER
ORAL OR WRITTEN, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY
OR OTHERWISE, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. COMPANY SPECIFICALLY DISCLAIMS, WITHOUT LIMITATION, ANY AND ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, OF ANY KIND. IF COMPANY CANNOT LAWFULLY DISCLAIM
IMPLIED WARRANTIES UNDER THIS LIMITED WARRANTY, ALL SUCH WARRANTIES, INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE DURATION OF THIS LIMITED WARRANTY. The Company does not assume or authorize any
person to assume for them any other liability in connection with the Products.
2. EXCLUSION AND LIMITATION OF LIABILITY:
IN NO EVENT, WHETHER BASED ON CONTRACT OR TORT OR OTHER LEGAL THEORY, SHALL COMPANY BE
LIABLE FOR ANY INDIRECT, INCIDENTAL, PUNITIVE, SPECIAL OR CONSEQUENTIAL DAMAGES, INCLUDING
BUT: NOT LIMITED TO, DAMAGES TO OTHER PROPERTY, INCONVENIENCE, DAMAGES FOR LOSS OF
PROFITS, REVENUE, GOODWILL OR USE, INCURRED BY CUSTOMER OR ANY THIRD PARTY, WHETHER
IN AN ACTION IN CONTRACT, TORT, STRICT LIABILITY, OR IMPOSED BY STATUTE, OR OTHERWISE, EVEN
IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow the exclusion or limitation of
incidental or consequential damages or exclusions or limitations on the duration of implied warranties or conditions,
so the above limitations or exclusions may not apply to Customer. In jurisdictions that limit the scope of or preclude
limitations or exclusion of remedies or damages, or of liability, such as liability for gross negligence or willful misconduct
or do not allow implied warranties to be excluded, the limitation or exclusion of warranties, remedies, damages or
liability set forth above are intended to apply to the maximum extent permitted by applicable law. This limited warranty
givestheCustomerspeciclegalrights,andtheCustomermayalsohaveotherrightsthatvarybystate,countryor
other jurisdiction.
3. SEVERABILITY:
If any provision of this limited warranty is held to be illegal, invalid or otherwise unenforceable, such provision will be
enforced to the extent possible consistent with its stated intention, or, if incapable of such enforcement, will be deemed
to be severed and deleted from this limited warranty, while the remainder of the terms of this limited warranty will
continue in full force and effect.
4. DISPUTE RESOLUTION:
This FitDesk Limited Warranty shall be governed by and construed in accordance with the laws of the State of North
Carolina,withoutregardtoitsprinciplesofconictsoflaw.Thepartiesacknowledgetheexclusivejurisdictionofthe
federal and state courts of the State of North Carolina. Any claims or disputes under this FitDesk Limited Warranty
shall be heard exclusively in any state or federal courts sitting in Guilford County, North Carolina, and both parties
expressly consent to the personal jurisdiction and venue of the North Carolina state and federal courts for such actions.

13
COMPLETE PARTS LIST
REPLACEMENT PARTS
DESCRIPTION:
DESCRIPTION:
QTY.
QTY.
1. Main Frame 1
2. Front Stabilizer 1
3. Rear Stabilizer 1
4. Desktop 1
5. Seat Support Frame 1
6. Seat 1
7. Left Pedal 1
8. Right Pedal 1
9. Basket 1
10. M6*12 Hex Screws 6
11. M8*16 Hex Screws 5
12. M8 Curved Washer 4
13. M8 Nut 4
14. 9/16” Nut (Left-Hand Thread) 1
15. 9/16” Nut (Right-Hand Thread) 1
106L Pedal Left 9/16 1
106R Pedal Right 9/16” 1
103A Allen Wrench 1
103B Wrenches (supplied) 1

14
EXPLODED VIEW
For Questions or Replacement Parts Contact:
1-855-713-8887
MONDAY - FRIDAY 9 A.M. - 5 P.M. EST
3
11
13
12
8
15
1
9
13
12
2
6
10
11 14
5
7
10
4

15
OTHER GREAT PRODUCTS FROM FitDesk
®
®
Under Desk Elliptical
FitDesk® Model: 3040
FitDesk® Model: 3030
Model: 4150
Under Desk Cycle
To purchase additional items, please
Products > Accessories & Parts
This Desk Bike provides a proven, alternative
method of learning for middle, high school, and
college age students.
FitStudent
Varsity Bike Desk
TM
Dimensions
• 31“ x 23” desk surface
• 30” x 26” footprint
• Product weight: 93 lbs.
• Grades 6 - 12th, College
• Weight limit 250 lbs.

Updated 10/23/17
FitDesk®is a registered trademark of FD Products LLC. - All Rights Reserved 2017
facebook.com / Fitdesk
