Flash Furniture GO-2286M-GG User manual

ASSEMBLY INSTRUCTIONS
Before You Begin:
Please identify all component parts and hardware pieces required before you begin. Carefully remove all
of the components from the packaging and set aside for assembly. Assemble on a soft surface to prevent
scratching during assembly.
Caution:
Tighten all components securely before use. Failure to do so may result in personal injury.
DO NOT use any sharp objects to open plastic wrapped components as damage to product or
components may result.
Warning:
CHOKING HAZARD - Small Parts. Adult Assembly Required.
DO NOT ALLOW CHILDREN TO CLIMB ON FURNITURE
Serious or fatal injuries can occur from furniture tipping over. You must install Tipping Restraint Hardware
(where included) to help prevent the unit from tipping and causing accidental injury, instability, death or
damage. The tipping restraint is intended only as a safety measure, it is not a substitute for proper adult
supervision.
To help prevent furniture from tipping over it must be permanently attached to the wall. Anti-Tip Safety
Wall Straps suitable for the unit weight and wall materials (if not included) should be purchased and
installed.
Customer Service Email: [email protected] | Phone: [phone]
GO-2286M-BK-GG / GO-2286M-WH-GG
Leather Executive
Swivel Chair
Thank you for your purchase!
Online Assembly Instructions: http://ftp.flashfurniture.com/AssemblyInstructions/GO-2286M-BK-GG.pdf

Have a Question/ Concern?
Quality products and first-class customer service are the cornerstone of long-lasting consumer relationships.
We strive toward excellence in all we do and want you to be completely satisfied with your purchase.
Please contact our exceptional Customer Experience Agents at the email address or phone number
shown below to assist you with any product questions or issues before requesting a return.
We look forward to serving you in a friendly, efficient manner to resolve any issues you may have.
Customer Service Email: [email protected]
Customer Service Phone: [phone]
Our Warranty Statement
This warranty covers manufacturing defects associated with your new product. The product is warranted from
the original purchase date and to the original purchaser for normal usage, according to the below-referenced
specifications and limitations.
Normal usage means use in compliance with the restrictions and weight limits specified for the product. In the
absence of product-specific restrictions and weight limits, normal usage means use for no more than forty
hours per week by persons weighing 250 lbs. or less. Coverage terminates if the product is sold or otherwise
transferred. Repairs made by parties other than Belnick also void this warranty.
This warranty will not cover: (1) labor, freight, or damage from misuse, abuse, negligence, alteration,
assembly, installation, attachments, accident, vandalism, acts of nature or any other event beyond the control
of Belnick; (2) tearing, scratching, scuffing, or blemishing of leather or fabric; (3) cosmetic damage that may
result from normal usage; (4) damage attributable to use by persons exceeding specified weight limits or
commercial use exceeding forty hours per week; or (5) rust or other damage caused by exposure to moisture.
The user assumes all risk of injury resulting from use of this product. Liability for incidental or consequential
damage is excluded. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
Non-moving metal parts are warranted for 5 years.
Component parts including pneumatic cylinder, control mechanism, base and casters are
warranted for 2 years.
All other items are warranted for 1 year.
•
•
•

STEP 1 STEP 2 STEP 3
STEP 4
STEP 5 STEP 6
FRONT
(3)
(2)
(1)
(8)
(4)
(5)
(6)
(5)
(9)
(5)
(6)
Gas Lift Cylinder
Base
Casters
M8 x 20 Bolt
Lift Mechanism
Seat
STEP 4: Open the Velcro on both sides of seat first, then
place the Back Cushion (Part 6) on the Seat Cushion
(Part 5), and use 2 M6 x 20 Bolt (Part 9) to attach to the
lower bolt holes on Seat Cushion (Part 5)
(see diagram).
*Note:DO NOT FULLY TIGHTEN BOLTS.
M6 x 20 Bolt
STEP 5: Push the Back Cushion (Part 6) up to a vertical
position and attached the Seat Cushion (Part 5) to by
using 2 M6 x 20 Bolt (Part 9), then to cover the Velcro
back.
*Note: TIGHTEN THE BOLTS COMPLETELY.
Seat
Chair
Back
Chair
Back
Seat
(7)
(10)
Left Arm
Right Arm
(7)
M8 x 50 Bolt
STEP 1A: Insert Gas Lift Cylinder (Part 3)
into the Base (Part 2).
Step 1B:
Attach Gas Lift Cylinder (Part 3)
and casters (Part 1) into the Base (Part 2)
STEP 2: Attach Lift Mechanism (Part 4) to the underside
of the Seat (Part 5) using 4 M8 x 20 Bolt (Part 8).
STEP 3: Place seat (Part 5) onto the Gas Lift Cylinder
(Part 3).
STEP 6A: Attach Left and Right Arms (Part 7) to
assembled seat (Part 5 & 6) using 4 M8 x 50 Bolt
(Part 10).
(4)
(3)
Lift Mechanism
Gas Lift Cylinder
(5)
Seat
STEP 6B: Place the
Arm Cap (Part 11)
into the arm bolt hole
at left and right arm.
(11)
Arm Cap
(10)
M8 x 50 Bolt
(9)
M6 x 20 Bolt
(9)
M6 x 20 Bolt
(9)
M6 x 20 Bolt
Thank you for your purchase!
PARTS
(1)x5 (2)x1 (3)x1 (4)x1
(5)x1 (6)x1 (7)x1 (L&R) (8)x4
(9)x4 (10)x4 (11)x4 (12)x1
Chair Back
Casters Base Gas Lift Cylinder Lift Mechanism
Seat Left Arm Right Arm M8 x 20 Bolt
M6 x 20 Bolt M8 x 50 Bolt Arm Cap Allen Wrench
