Flexispot Sit2Go User manual

Item No. Sit2Go Fitness Chair

7. This machine is designed for adults but allows children to use it under the supervision of the
adults.
8. Children are not allowed to play on this product and should never put their fingers near any
moving parts of this machine.
-01- -02-
100kg/220lbs.

-03- -04-
Allen Key
5x5mm
(1 PC)
Screws
M8x20
(6 PCS)
Washer
Φ8.5xΦ16x1.2
(6 PCS)
C
No. Part Qty No. Part Qty
Installation Diagram
Rear Feet
1. Unfold the two rear feet of the bike base (A) follow the direction as shown. This step is not
completed until a "click' sound is heard.
Left Pedal
After the pedal is
unfolded, it should
be level normally.
2. Unfold the left and right pedals of the bike base(A) as shown until a 'click' sound is heard.
After the pedal is unfolded, it should be level normally.
Click
Click

-05- -06-
Plastic Handle Raise the seat
tube to the
highest position
3. Pull up the plastic handle to raise the seat tube to the highest position
Assembly step 4
Assembly step 3 Assembly step 5
4. Place cushion (B) on the seat tube. Use an Allen key ① to tighten the 4 screws ② and 4
washers ③ to fix the seat cushion on the seat tube.
Seat Tube
5. Insert the backrest (C) in to the bottom pipe groove, use the allen key(1) to tighten the
two screws(2) with two washers(3), so that the backrest can be fixed.
Bottom Pipe
Groove


①

-07- -08-
Display Operation Instruction&Button Function Description
1. Press the key button at the bottom of the LCD display to switch and show exercise time,
speed, distance, calories, total distance，rotating speed and other parameters.
2. If stop exercising for more than 4 minutes, the display will enter sleep mode and the LCD
display will automatically turn off.
3.Press the Key button or step on the pedal for one round to reactivate the LCD display.
LCD Display
Key Button
Scan
Time
Speed
Distance
Calories
Total Distance
Rotating Speed
Two Double A
Battery 1.5V
Instruction 1 Instruction 2
Governor Handwheel
Resistance Adjustment Method：
Rotate the governor handwheel towards
the "+" direction to increase resistance,
towards the "-" direction to decrease
the resistance force.
Cushion
Plastic
Handle
Plastic
Handle
How to adjust the height of the cushion: Slightly
raise the buttocks, pull up the plastic handle
(as shown in figure 1) to raise the cushion,
release the handle to lock the cushion at
current position; Pull up the plastic handle,
lower the height of the cushion by the weight
of the human body, release the handle to lock
the cushion at current position. According to
the above method, the cushion can be adjusted
to the most comfortable position.
Instruction 3
Instruction 4
Unfolding function of rear feet: Tilt the product appropriately, and use an Allen key ① to
push the limit pin into the hole (as shown in Figure ②), at the same time, fold the rear feet
completely in the direction of the arrow as shown.
Rear Feet
Figure 2
Limit Round Pin
Note:this method is only recommended for return or exchange before entering the box.
Adjust cushion position: To adjust the installation position of the seat cushion, use an
Allen key ① to loosen the 4 screws under the seat cushion (B) for a few turns. (Refer to
Figure ③) ; after the seat cushion is adjusted to the proper position, tighten the 4 screws
with an Allen key① to fix the cushion.
Figure 3
4 Screws Cushion
Figure 1
