Flexispot VB1B User manual

Installation Guide
Item No. : VB1B/VB1W/VB1U
Vibration Platform
Please use the product properly, and carefully, for your safety.

01 02
Specification
Net Weight:
Gross Weight:
Rated voltage:
Frequency:
Speed range:
Amplitude:
Max Loading: 
Product List
Please check whether the package is complete. If there is any problem please call 1-855-421-2808.
Vibration Platform
Product Overview & Usage
31 lbs
35 lbs
110 V
50 HZ
0-99 levels
0-12 mm
333 lbs
Remote Control
Power Cable
Instruction Manual
P
TIME
TIME/PRO SPEED
SPEED
START STOP
POWER PRG MODE
REMOTE
POWER
Power switch: Press the power switch to start or stop the product.
START
START: Press the start button to start the device.
Automatic program: Automatic programs can be selected (P0-3,P4-6,P7-9).
PPress button "P" once, the machine enter into auto-mode Program "P1".
How to use this program: press power switch button, machine shows“HA", which is
the manual mode.
PPress button "P" two times, the machine enters into auto-program "P2".
PPress button"P" three times, the machine enters into auto-program "P3".
Choose an auto-program and press the start button. The machine will start the chosen
program. You cannot adjust the time and speed when you start an auto-program.
Below is the automatic program guide:
START
Speed+ button: press this buttons to increase the speed as desired.
This button can be used when you use a manual program, before you
press the“start" button (not available with an automatic program).
Time adjust button: press the“time" button to adjust the time
This button can be used when you use a manual program (not available
for automatic programs).
Speed- button: press this buttons to decrease the speed. This button can
be used when you are using a manual program (not available for
automatic programs).
Note: The valid receiving range of the remote control is 2.5M;
The infrared light on the remote control must align with the infrared receiver
window on machine.

0304
Method of Moving
Grasp the product at the edge opposite to the wheel and hold it at a 45-degree angle.
It can then be rolled as needed.
Product Cleaning and Maintenance
Make sure the power is off. The machine can be cleaned with a warm, damp cloth
with detergent. Make sure the machine is completely dry before turning it on again.
Attention:
Be sure not to use benzene, thinner, ethyl alcohol, gasoline etc. which can result in
hazardous fumes, fading of the paint or corroding of the inner parts.
If the machine is not used for a long time, cover it to prevent dust from entering the
machine.
Problem Solving
Malfunction Possible Reason Solution
Lights are off
Noise
Remote control
does not work
Machine stops
while in use
Does not work
as intended
1
2
3
4
5
Is power supply ok?
Power switch of the
appliance off
Transient current too
strong, blown fuse
Plug in again
Turn off to on
Change a new fuse
Is the foot screw level
with the floor? Adjust foot screw
No battery / battery empty
Too far from the machine
Replace battery
Valid range is 2.5M
Machine is overheated
Received too many
commands
Start again after
10 minutes
Turn off power and
restart
Attention
●People who have hypertension, bronchitis, heart or skin disease, diabetes, or other
diseases, or pregnant women, should first consult a doctor before using this product.
●Keep children away from this machine
●Study the functions (for example, the switch button) and be sure you know how to
operate the machine to avoid malfunction or injury.
●To avoid injury and impairment, stamping on the pad is forbidden.
●Do not put your knees on the pad to prevent injury and impairment.
Do not put all your weight on one side; otherwise, the machine maybe overturned. Only
one person at a time may use the device.Do not touch the device with wet hands.
●This product is for exercising only. Other uses are prohibited.

05 06
FlexiSpot Limited Warranty
This limited warranty offered by FlexiSpot covers defects in material or workmanship in new FlexiSpot
products. This warranty extends to the original purchaser only and is non-transferable. Only consumers
purchasing FlexiSpot products from authorized FlexiSpot retailers or resellers may benefit from our
limited warranty.
What is Covered?
The FlexiSpot limited warranty covers our products against defects in material or workmanship as
follows:
·FlexiSpot Height Adjustable Desk Frames
All height-adjustable desks feature a 5-year warranty for the frame & motor and a 2-year warranty for the
controller, switch, electronics and other mechanisms from the year of 2019.
·FlexiSpot Sit-Stand Desktop Workstations
All sit-stand desktop workstations feature a 5-year warranty for the frame and MDF desktop and 3-year
warranty for the gas spring system and other mechanisms from the year of 2019.
·FlexiSpot Desk Bikes
All desk bikes and parts, including the frame, electronics, and other mechanisms, feature a 1-year
warranty from the year of 2019.
·Flexispot Treadmills
All treadmills feature a 1-year warranty from the year of 2020.
·FlexiSpot Monitor Mounts
All monitor mounts and parts, including arms, gas spring systems and other mechanisms, feature a 5-
year warranty from the year of 2019.
What are your Remedies?
FlexiSpot will replace at no charge to the consumer the defective parts only or, at FlexiSpot's option,
replace any product or part of the product that is defective because of improper workmanship and/or
material, under normal installation, use, service and maintenance. If FlexiSpot is unable to provide a
replacement and repair is not practical or cannot be completed in a timely fashion, FlexiSpot may elect to
refund the purchase price in exchange for the return of the product. In the rare event that your FlexiSpot
product is defective, we will provide you with a replacement item shipped at no cost to you within the
continental United States. The shipping method for replacement products is FedEx Ground, but
expedited shipping is available if you choose to pay the additional expense. In addition, you will need to
pay the shipping costs if any products need to be shipped to you at an address outside the continental
United States.
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE
PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
PURCHASER. FLEXISPOT NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR
ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
FlexiSpot Limited Warranty
What is Not Covered?
Our limited warranty does not cover any problem that is caused by:
1. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
2. Conditions, malfunctions or damage resulting from normal wear and tear, improper
installation, improper maintenance, misuse, abuse, negligence, accident or alteration.
3. Accessories, connected materials and products, or related products not manufactured by
FlexiSpot.
4. Conditions, malfunctions or damage resulting from failure to follow the instructions and
guidelines relating to the product's intended use.
Our limited warranty is void if a product is returned with removed, damaged or tampered labels
or any alterations (including removal of any component or external cover).
How to File a Claim?
In order to receive the benefit of our limited warranty, you need to process your claim in
compliance with the terms of this limited warranty and follow proper return procedure. To
request warranty service, please contact customer service via email at [e-mail]
or toll free at 855-421-2808. You will need to provide the sales receipt or other evidence of the
date and place of purchase for your FlexiSpot product.
Implied Warranties and Limitation of Damages
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES
(INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE) SHALL BE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY,
AND FLEXISPOT SHALL NOT BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF PROFITS OR
REVENUE, RESULTING FROM ANY BREACH OF EXPRESS OR IMPLIED WARRANTY OR
CONDITION, OR UNDER ANY OTHER LEGAL THEORY, EVEN IF FLEXISPOT HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some jurisdictions do not allow
limitations on the duration of an implied warranty or the exclusion or limitation of special,
indirect, incidental or consequential damages, so the above limitations or exclusions may not
apply to you.
Governing Law
This Warranty shall be governed by the laws of the State of California, USA, without giving
effect to any conflict of laws principles that may provide the application of the law of another
jurisdiction.
How State Law Applies
This Warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
