Flight Model M089 F3A 68.5IN User manual

Wing Span:68.5 in /1740mm; Flying Weight: 3700-3800g;
Wing Area:60.43 sq.dm; Radio:6Channel 5Servos;
Length:70.8 in / 1800mm; Motor:FMA-5060 KV300
CAUTION : this plane is not a toy and should be kept away
children under 16 years of age! Before use , please carefully read
this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children’s reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model’s assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.

MAIN WING
All the parts together
Connect the aileron and the main wing
by hinges.Be sure to apply instant
type glue to both sides of each hinges.
Gather wing parts as shown.

Put the servo into the
hole and fix it with screws.
Link the servo arms and
tri-horns with pushrod
Main Landing Gear and Tail Wheel Unit
Gather the parts for the landing gear.
Fix up the landing gear on the fuselage
with screws.

Apply epoxy into
hinge hole of the rudder
Gather the parts for the rudder
Use glue to fix up rudder
horns

Install steel wire of rudder
as shown
Install the rudder servo
Attach the servo arm to the
rudder servo
Install the tail landing gear use
screws to fix up the fuselage bottom.

Apply epoxy into hinge hole of
the elevator
Gather the parts for the stabilizer
servo
Finished photo

Connect the stabilizer and the
fuselage with joiner
Drill holes used for fixed stabilizer
Fixed the stabilizer with screw
screw

Fixed the wing with nylon thumb
screw
Finished photo
Install the motor.as shown

Finished photo
Install the battery.as shown
Mounting screws （Don't lock）

Install the cowl and fix it with screws
Fixed it with mounting screws
Install the canopy and fix it with
canopy lock catch

You can adjust the degree of the
stabilizer,about 3-4 degree
CG
POSITION & CONTROL
THROWS

THE FINISHED PHOTO
Another scheme for choice.Flight Model CO.,LTD
