Flight Model M067 Slick 70" EP User manual

Wing Span:70"/1778mm; Flying Weight:3860-4210g
;
Wing Area:63.3sq.dm; Radio:4Channel 4Servos;
Length:66.3"/1684mm;
CAUTION : this plane is not a toy and should be kept away
children under 16 years of age! Before use , please carefully read
this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children’s reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model’s assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Remove the covering over the aileron servo openings and the aileron
control horn slots as shown
Cut servo hole and Use epoxy to install aileron horns as shown
Attached servo extensions to aileron servos,Use the string install in
the wing to pull the servo wire through the wing
Install the wheel onto the axles and secure with the wheel collars,as show
n
Slide on wheel/axle assembly into a wheel pant,and install
the wheel assembly on the landing geat leg,Tighten the locknut as shown
to secure the assembly onto the gear leg
Repeat for other side,Install the wheel cover,and fix it up to landing
gear with screw.
Fix up the landing gear on the fuselage bottom with 4 screws
.
Put the cover board in the right position,then fix up it.
Install the tail landing gear Use screws to fix up the fuselage bottom.
Apply epoxy into hinge hole of the rudder
Use glue to fix up rudder horns.
Finished photo
Cut the servo holes on the profile of the fuselage
Install the rudder horns and connect servo with wire as shown.
Install the rudder servo,servo,and hall links with locking nuts as shown
Crimp the servo end of the cables first,the cables cross once inside the
fuselage to form an "X"
Another way of Install rudder servo..
Using a tape measure or long ruler,measure from the stab to the wing tips.
in the diagram Equalize that measurement right and left to be sure your
stab is aligned
Drip thin glue onto the stab-to-fuselage joint top and bottom
Hinge the elevators onto the horizontal stabilizer
Install the elevator,Before installing the ekevator with the slot which
accepts the joiner,practice fitting it once,the joiner is very tight in the slot
Install elevator horn as shown,using the same technique as for the
rudder horns
Install the motor.as shown
Drill a small hole, Fix the cowl with screw as the show.
Apply one side of the self-adhesive velcro tape to the battery tray,
for another to your battery use the Install your receiver as shown on the
receiver tray
THE FINISHED PHOTO
Another scheme for choice
Dong Guang Flight Model CO.,Ltd
ADD:No.10,Fu Ning Street,Xian Xi Industrial,Chang An Town
DongGuan City,Guang Dong Province,China
Tel: +86-769-85070618 / +86-769-89790965
Fax: +86-769-85091868
E-mail:[email protected]
Web: http:www.flight-model.com
http://flight-model.preview.alibaba.com/
