Getting started
FLIR A6xx series
#T810153; r. AA/34081/34081; mul

Table of contents
1 List of contents ...................... . .. . . . . . . . . . . . . ...................... .. . .. 1
2 Illustrations . . . . . ...................... ... . . . . . . . . . . . . . . . ..................... .. 2
3 EN-US English ................................... .. . .. . . . . . . . . . . . . ............. 4
#T810153; r. AA/34081/34081; mul vii

1 List of contents
• Infrared camera with lens
• Ethernet cable
• FLIR ResearchIR Max1
• Hard transport case or cardboard box
• Mains cable
• Power cable, pig-tailed
• Power supply
• Printed documentation
• ThermoVision System Tools & Utilities CD-ROM2
• USB cable1
Note FLIR Systems reserves the right to discontinue models, parts or accesso-
ries, and other items, or to change specifications at any time without prior notice.
#T810153; r. AA/34081/34081; mul 1
1. The inclusion of this item is dependent on model.
2. The inclusion of this item is dependent on model. FLIR IR Monitor on the CD-ROM only supports FLIR
A310 cameras.

2 Illustrations
Note Explanations of the illustrations are provided in each language section.
Figure 2.1 Connectors
Figure 2.2 Typical system overview, FLIR A6xx series
#T810153; r. AA/34081/34081; mul 2

2 Illustrations
Figure 2.3 Typical system overview, FLIR A6xx sc series
#T810153; r. AA/34081/34081; mul 3

3 EN-US English
3.1 Thank you!
Thank you for choosing a product from FLIR Systems. We hope that the product
will meet your expectations and that you will consider us again for your future
needs.
3.2 Read the manual before use
Go to the following website to read or download the
manual:
http://support.flir.com/resources/6kb4
3.3 Register your product now
Be the first to receive advance notice on new product updates, software up-
grades, and special offers.
Go to the following website to register your product:
http://www.flir.com/thg/register
3.4 Download FLIR Tools
FLIR Tools lets you quickly create professional inspection reports that clearly
show decision makers what you’ve found with your IR camera.
Import, analyze, and fine-tune images easily. Then incorporate them into concise
documents to share findings and justify repairs.
Go to the following website to download FLIR Tools:
http://support.flir.com/tools
#T810153; r. AA/34081/34081; mul 4

3 EN-US English
3.5 Quick start guide, FLIR A6xx series
Follow this procedure:
1. Connect the power and Ethernet cables to the camera.
2. Connect the power cable to a power supply.
3. Connect the camera to the network, using the Ethernet cable.
4. Use FLIR IP Config to identify the unit in the network and set the IP address
if necessary. Download FLIR IP Config from http://tinyurl.com/o5wudd7.
5. Use FLIR Tools to set up and control the camera. For more information, see
section 3.4 Download FLIR Tools, page 4.
3.6 Quick start guide, FLIR A6xx sc series
Follow this procedure:
1. Go to http://support.flir.com/rir4 and download FLIR ResearchIR Max.
2. Install FLIR ResearchIR Max.
3. Start FLIR ResearchIR Max.
When asked for the license key, enter the license key that is printed on the
FLIR ResearchIR Max download card. The card is included with your
camera.
4. Connect the camera to the computer using the provided Ethernet cable.
5. Start the camera. This displays a start-up dialog box in FLIR ResearchIR
Max. If the start-up dialog box is not displayed, go to View >Startup Dialog.
6. In the start-up dialog box, click the camera you want to connect to.
For more information about the installation and connection processes, see the
FLIR ResearchIR Max manual.
3.7 Connectors
See Figure 2.1 Connectors, page 2.
1. Network cable with an RJ45 connector for Ethernet connectivity and Power
over Ethernet (PoE) (dependent on the camera model).
Note Only CAT-6 Ethernet cables should be used with this camera.
2. Power cable for 12–24 V DC power in.
Note The power connector on the camera is polarity protected.
3. USB cable with a USB mini-B connector for control and image transfer.
4. Digital I/O ports, opto-isolated (six-pole screw terminal).
#T810153; r. AA/34081/34081; mul 5

3 EN-US English
A. Hardware reset button (for a factory default reset).
Use a straightened paper clip or a similar tool to press the reset button
through the small hole on the back of the camera for 5 seconds, then release
the button.
B. Power indicator.
3.8 Typical system overview, FLIR A6xx series
See Figure 2.2 Typical system overview, FLIR A6xx series, page 2.
1. Computer.
2. CAT-6 Ethernet cable with RJ45 connectors.
3. Industrial Ethernet switches with fiber-optic ports.
4. Fiber-optic cable.
5. FLIR A6xx cameras.
6. Industrial process to be monitored, e.g., items on a conveyor belt.
3.9 Typical system overview, FLIR A6xx sc series
See Figure 2.3 Typical system overview, FLIR A6xx sc series, page 3.
1. PC running FLIR ResearchIR Max (a download card with a printed license
key is included with the camera).
2. Gigabit Ethernet connection to a PC.
3. Alternative USB connection to a PC (lower frame rate).
4. Allowed range: 10–30 V DC, 24 W absolute max.
5. Digital I/O connector (screw terminals).
3.10 Training
Let the Infrared Training Center help you maximize your investment in thermal
imaging:
www.infraredtraining.com [email protected]
www.irtraining.eu [email protected]
www.irtraining.com [e-mail]
#T810153; r. AA/34081/34081; mul 6

3 EN-US English
3.11 Customer support
Do not hesitate to contact our Customer Support Center at http://support.flir.com
if you experience problems or have any questions about your product.
