ULTRA RESOLUTION VARIFOCAL
IR DOME CAMERA
MODEL: DBD24TL
QUICK START GUIDE
English Version 1.0
www.digimerge.com
IT’S ALL ON THE WEB!
www.digimerge.com
VISIT
Digimerge Technologies Inc.
Copyright © 2013
As our products are subject to continuous improvement, Digimerge
reserves the right to modify product design, specifications and prices,
without notice and without incurring any obligation. E&OE
1 x Indoor IR Dome
Camera with Varifocal Lens
Features
Safety Precautions
• This camera is for indoor use only.
• Use an appropriate low voltage power cable to prevent
fire or electrical shock.
• Make sure to install the camera in an area that can
support the camera weight.
• There are no user serviceable parts inside the camera.
Please do not disassemble the camera.
• Do not clean the lens cover with an abrasive cleaning
material. Please use a soft cloth to clean the lens cover.
• Ultra Resolution 1/3” Image Sensor / 600 TVL
• True Day / Night with Mechanical ICR
• 2.8-12mm Varifocal Lens
• 65ft (20m) IR Night Vision*
• 3 Axis Design for Wall / Ceiling Mount
• Secure Zoom / Focus Adjustment
• 12V DC Operation
* IR Illumination range under ideal conditions. Objects at or beyond
this range may be partially or completely obscured, depending on
the camera application
3 x Mounting Screws
1 x Dome Cover Key

Installing the Camera
ATTENTION - Test the camera prior to selecting a permanent
mounting location by temporarily connecting the camera(s) and
cables to the DVR.
Image Sensor 1/3” Color Image Sensor
Video Format NTSC
Effective Pixels H: 728 V: 488
Horizontal Resolution 600 TVL
Scan System 2:1 Interlace
Sync System Internal
S / N Ratio 52dB (AGC Off)
Iris AES
AES Shutter Speed 1/60 ~ 1/12,000 sec.
Min. Illumination 0.2 LUX (IR Off)
0 LUX (IR LEDs ON)
Video Output Composite 1.0Vpp @ 75ohm
Lens Focal Length / Type 2.8–12mm F1.4 / Varifocal
FOV (Diagonal) 27° ~ 92°
Termination Video: BNC Female
IR Range / Qty. 65ft / 20m; 17 IR LED’s
Power Requirement 12V DC ± 10%
Power Consumption 12V: 200mA MAX with IR LED
Operating Temp. Range 14° ~ 122°F / –10° ~ 50°C
Environmental Rating Indoor Only
Dimensions Diameter: 5.0” (128mm)
Height: 3.6” (91mm)
Weight (including stand) 0.6lbs / 0.3kg
Dimensions
Camera Specifications
Setting up the Camera
1. Connect the BNC connector of the camera to the
video cable.
2. DC Power—Power Adapter: Connect a 12V DC
Power Adapter (not included) to the camera. Plug
the Power Adapter into a local power outlet.
• DC Power—Power Pigtail (not included): Connect
a Power Pigtail to the camera. Connect the
terminating wires of the cable directly to the DC
power source.
NOTE: The Power Pigtail is a non-polarity input. You can
connect the wires to either the positive or negative ports of
the DC power source.
1. Use the included Dome Cover Key or your finger
to push in the button on the camera base while
pulling the dome cover up.
2. Locate the white latch on camera base (near
LOCK and UNLOCK labels). Push the latch
outward and hold in place.
128mm / 5.0”
91mm /
3.6”
Press to
open housing
3. Twist the black back plate
counterclockwise to
detach it from the camera.
Release the latch.
4. Optional - Punch out
the disc in the centre of
the black back plate to
run cables through the
mounting surface.
5. Use the included screws to attach the black
back plate to the mounting surface. Make sure
the CAMERA FRONT label points away from
the mounting surface.
6. Place the camera base over the black back plate
and turn counterclockwise to lock in place.
Push
outward
Punch out and
run cables
through here
ZOOM
FOCUS
7. Use a flat-head screwdriver to slightly loosen the
ZOOM and FOCUS knobs. Move knobs left and
right to adjust zoom and focus. Tighten knobs
when finished.
8. Adjust the position of the camera by rotating the
black camera module (rotates 360° before it is
stopped).
9. Use a philips screwdriver to loosen the screws on
either side of the camera module. Tilt the top of the
module to adjust the viewing angle. Tighten screws
when finished.
10. Replace the dome cover so the arrow on the dome
cover points toward the button on the camera
base.
Loosen screws
on both sides
to tilt
NOTE: Make sure IR
LED’s are clear from
camera housing when
installed. If IR LED’s are
blocked, nighttime image
may appear cloudy.
