FLO-DYNAMICS TS410 Programming manual

Quick Start Instructions
TS410
TRANSMISSION
FLUID X-CHANGER
Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941777
Check the uid level. Press or to add or remove
uid in 2/10 of a quart increments. Use option 3 in the main
menu to add a full quart and option 4 to remove a full quart.
Press to return to the main menu.
Once exchange is nished the screen will beep and display
“Complete”.
Use the arrow keys to select the desired amount to
be exchanged. Press to proceed. Turn vehicle’s engine on.
Press to begin the exchange.
Connect appropriate adapters to vehicle’s cooler line ttings.
Connect red and black service hoses to quick disconnect adapters
on the end of the cooler line adapters.
If needed, while running, pressing once will pause the
machine. Press to resume from pause, or press
a second time to cancel the exchange
CONNECTION
Press for Inline Exchange
Connect battery cables
to vehicle’s battery.
ADDITIONAL FEATURES
OPERATION
INLINE Exchange

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941776
Quick Start Instructions: Additional Functions
TS410
TRANSMISSION
FLUID X-CHANGER
From the Main Menu, press to proceed to the next menu.
Press to drain the New Fluid Tank. Press to drain
the Used Fluid Tank. Press to begin the process.
The unit will shut o when complete.
From the Main Menu, press to proceed to the next menu.
Press to display the voltage.
DRAINING THE TANKS
Connect any open end adapter to red hose and insert
into appropriate disposal container.
Make sure all other hoses are disconnected!
Press . Press to begin the process.
The unit will shut o when complete.
PRIMING THE MACHINE
Make sure there is uid in the New Fluid Tank. Connect the Red
and Black service hoses together using any two mating adapters.
MAIN MENU
Press for Main Menu
Connect battery cables
to vehicle’s battery.
VOLTAGE MONITOR

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941776
Quick Start Instructions: Additional Functions
TS410
TRANSMISSION
FLUID X-CHANGER
If the exchange stops and the display reads “Reverse Hoses”, turn
vehicle o, switch the red and black service hoses, restart vehicle,
and press .
If the exchange stops and the display reads “Shift to Neutral”,
set the vehicle’s parking brake, shift to Neutral, and press .
From the Main Menu, press twice.
Press to display the total lter use. Press to reset.
If there is a power failure during a transmission uid exchange,
the procedure can be continuted seamlessly.
Simply reconnect the battery cables, and press .
The exchange will resume where it left o.
The machine will indicate when the canister lters need to be
replaced. Remove service panel. Use a standard lter band clamp
tool to unscrew old lters, and replace them with new lters.
Make sure new lters are on tight.
IMPORTANT: Machine must be primed after lter change.
HALTED: REVERSE HOSES
HALTED: SHIFT TO NEUTRAL
TOTAL FILTER USE
POWER FAILURE MEMORY
CYCLE VALVES
FILTER CHANGE DUE
From the Main Menu, press to proceed to the next menu.
Press to cycle the valves.
