FLO-DYNAMICS TSD440 Programming manual

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941772
Quick Start Instructions
R
TSD440
TRANSMISSION
FLUID DIPSTICK
X-CHANGER
ADDITIONAL FEATURES
OPERATION
CONNECTION
Check the uid level. Press or to add or remove
uid in 2/10 of a quart increments. Use option 3 in the main
menu to add a full quart and option 4 to remove a full quart.
Press to return to the main menu.
With the engine o, use the arrow keys to select
the desired amount to be exchanged.
Press to proceed. Press again to begin exchange.
Press for Dipstick Exchange
Start the vehicle’s engine when display prompts you to do so.
Press . Once exchange is nished the screen will beep
and display “Complete”.
If needed, while running, pressing once will pause the
machine. Press to resume from pause, or press
a second time to cancel the exchange
Connect battery cables
to vehicle’s battery.
Connect red and gray service hoses to chrome manifold.
Insert nylon tube down dipstick tube the same length as the
dipstick, being cautious not to insert too far.
DIPSTICK Exchange

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941773
Quick Start Instructions: Additional Functions
R
TSD440
TRANSMISSION
FLUID DIPSTICK
X-CHANGER
From the Main Menu, press to proceed to the next menu.
Press to drain the New Fluid Tank. Press to drain
the Used Fluid Tank. Press to begin the process.
The unit will shut o when complete.
From the Main Menu, press to proceed to the next menu.
Press to display the voltage.
DRAINING THE TANKS
Connect any open end adapter to red hose and insert
into appropriate disposal container.
Make sure all other hoses are disconnected!
Press . Press to begin the process.
The unit will shut o when complete.
PRIMING THE MACHINE
Make sure there is uid in the New Fluid Tank. Connect the red
service hose to the tting on the left side of the machine.
MAIN MENU
Press for Main Menu
Connect battery cables
to vehicle’s battery.
VOLTAGE MONITOR

Flo-Dynamics, Inc. • 2600 Jeanwood Drive • Elkhart, IN 46514 • 800-303-5874 • www.odynamics.com 941773
Quick Start Instructions: Additional Functions
R
TSD440
TRANSMISSION
FLUID DIPSTICK
X-CHANGER
If there is a power failure during a transmission uid exchange,
the procedure can be continuted seamlessly.
Simply reconnect the battery cables, and press .
The exchange will resume where it left o.
POWER FAILURE MEMORY
From the Main Menu, press twice.
Press to display the total lter use. Press to reset.
TOTAL FILTER USE
The machine will indicate when the canister lters need to be
replaced. Remove service panel. Use a standard lter band clamp
tool to unscrew old lters, and replace them with new lters.
Make sure new lters are on tight.
IMPORTANT: Machine must be primed after lter change.
FILTER CHANGE DUE
CYCLE VALVES
From the Main Menu, press to proceed to the next menu.
Press to cycle the valves.
