FLORABEST FGW 84 A1 User manual

IAN 86282
TROLLEY BARBECUE FGW 84 A1
TROLLEY BARBECUE
Operating instructions
ΤΡΟΧΗΛΑΤΗ ΨΗΣΤΑΡΙΑ
Οδηүίες χρήσης
ROŠTILJ S KOTAČIMA
Upute za upotrebu
GRILLWAGEN
Bedienungsanleitung

GB / CY Operating instructions Page 1
HR Upute za upotrebu Stranica 13
GR / CY Οδηүίες χρήσης Σελίδα 25
DE / AT / CH Bedienungsanleitung Seite 37
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na osnovu toga sa svim funkcijama
uređaja.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

1
u
z
t
e
r
w
q
0
9
6
5
4
8
7
3
2

1
FGW 84 A1
GB
CY
Index
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Information for these operating instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basic Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Items supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connection elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Preparing for assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Required assembly material. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Assembly procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
IB_86282_FGW84A1_LB7.indb 1IB_86282_FGW84A1_LB7.indb 1 28.01.13 09:2128.01.13 09:21

2FGW 84 A1
GB
CY
Introduction
Information for these operating instructions
Congratulations!
With your purchase you have decided in favour of a quality product. Familiarise
yourself with the product before installation and before taking it into use for the
first time. In this regard, please read the following assembly instructions and safety
notices attentively. Use the product only as described and only for the specified
areas of application. Retain these instructions for future reference. In addition, pass
these documents on, together with the product, to any future owner.
Copyright
This documentation is copyright protected.
All reproductions or duplications, also as extracts, as well as representations of
the illustrations, even in an altered state, are only permitted with the written
approval of the manufacturer.
Intended use
This trolley barbecue is intended exclusively for the preparation of grilled foods.
It is suitable only for use outdoors. This trolley barbecue is intended for use only
in domestic environments, not for commercial applications.
No liability will be accepted for damage resulting from incorrect or improper
usage, the application of force or unauthorised modifications.
WARNING
Risks from unintended use!
Risks can arise if the appliance is used for unintended purposes and/or other
types of use.
► Use the appliance exclusively for its intended purposes.
► Observe the procedures described in these operating instructions.
The manufacturer assumes no responsibility for damage caused by improper use,
inappropriate repairs, making unauthorised changes or for using unapproved
replacement parts.
The operator alone bears liability.
IB_86282_FGW84A1_LB7.indb 2IB_86282_FGW84A1_LB7.indb 2 28.01.13 09:2128.01.13 09:21

3
FGW 84 A1
GB
CY
Safety
In this chapter you will receive important safety information regarding handling
of the appliance.
This appliance complies with the statutory safety regulations.
Incorrect usage can lead to personal injury and property damage.
Basic Safety Instructions
WARNING
Warnings about burns!
1. During use, place the grill on a secure, level and firm surface, otherwise it
could tip over.
2. CAUTION! For igniting and reigniting, do not use spiritus or benzine! Use
only ignition aids complying with EN 1860-3. Otherwise, the deflagration
could cause an uncontrollable development of heat.
3. ATTENTION! During use the grill will become very hot and therefore may
not be moved, otherwise it could tip over.
4. ATTENTION! Keep children and pets well away from it!
5. When grilling, wear appropriate grilling gloves and use grilling tongs.
6. NEVER leave a heated up grill unsupervised.
7. Allow the grill to cool down completely before cleaning it.
8. NEVER use water to extinguish the glowing charcoal.
WARNING
Warning in regard to suffocation!
► Use the grill ONLY outdoors!
► Do NOT operate the grill in enclosed spaces or roofed-over areas.
IB_86282_FGW84A1_LB7.indb 3IB_86282_FGW84A1_LB7.indb 3 28.01.13 09:2128.01.13 09:21

4FGW 84 A1
GB
CY
Items supplied
1 x Barbecue skewer (incl. 2 x barbecue racks and 1 x wooden handle)
21 x Wind protector, left
31 x Wind protector, middle
41 x Wind protector, right
51 x Grill grate (including 2 handles)
61 x Firebowl
71 x Handle
82 x Handle holder, short
92 x Stand braces
10 2 x Cross braces
11 5 x Storage slats, long
12 2 x Wheels
13 1 x Axle
14 2 x Wheel brace
15 2 x Storage holder, long
16 2 x Reinforcing braces
17 3 x Storage slats, short
Connection elements
M6x12
24x
M5x10
7x
M5x16
16x
M4x15
2x
M5
23x
M6
24x
M8
2x
M4x10
2x
Ø6x16
8x
Ø6x12
7x
IB_86282_FGW84A1_LB7.indb 4IB_86282_FGW84A1_LB7.indb 4 28.01.13 09:2128.01.13 09:21

5
FGW 84 A1
GB
CY
Assembly
Preparing for assembly
Allow yourself plenty of time for the assembly of the trolley barbecue. Secure a
level workplace of about two to three square meters. Remove all individual items
from the packaging and place them where they are conveniently handy. Check
the items to ensure that that they are all present and without any damage.
Required assembly material
Hammer
Philips-type screwdriver
Open-ended spanners SW 8 mm, SW 10 mm, SW 13 mm
WARNING
Warning about physical injuries!
► To avoid possible injury, the screw heads should always face outwards.
IMPORTANT
► First tighten all screw connections down when the assembly is complete,
this will help avoid undesirable material tensions.
IB_86282_FGW84A1_LB7.indb 5IB_86282_FGW84A1_LB7.indb 5 28.01.13 09:2128.01.13 09:21

6FGW 84 A1
GB
CY
Assembly procedure
Step 1
♦ Connect the shelf brackets 15 to the wheel braces 14 using M6x12 bolts
and M6 nuts.
Please take note that only the lower hole of the shelf bracket 15 is used for
making the bolted connection.
♦ Fix the reinforcing braces 16 to the wheel braces 14 using M6x12 bolts
and M6 nuts. Fix the reinforcing braces 16 to the shelf brackets 15 using
M6x12 bolts and M6 nuts.
♦ Fit the left wheel braces 14 with attached shelf brackets 15 to the fire bowl 6
using the M6x12 bolts, Ø6x16 washers and M6 nuts. The upper hole in
the wheel braces 14 is needed to do this.
Step 2
♦ Assemble the handle holder 8and stand braces 9as described in step 1.
Fix the handle 7between the short handle holders 8and then secure
them by means of the wood screws Ø 4x15.
♦ Fit the right stand braces 9with the fitted handle to the fire bowl 6using
the M6x12 bolts, Ø6x16 washers and M6 nuts. The upper hole in the
stand braces 9in needed to do this.
15
15
14
14
16
6
8
7
9
6
IB_86282_FGW84A1_LB7.indb 6IB_86282_FGW84A1_LB7.indb 6 28.01.13 09:2128.01.13 09:21

7
FGW 84 A1
GB
CY
Step 3
♦ Place the cross braces 10 between the wheel braces 14 and the stand
braces 9with the 5 holes facing upwards. Bolt these together using
M6x12 bolts and M6 nuts.
♦ Attach the five shelf slats 11 to the cross braces 10 . Bolt these together
using M5x16 bolts and M5 nuts.
Step 4
♦ Fit the three shelf slats 17 to the shelf brackets 15 using M5x16 bolts and
M5 nuts.
10
14
11
9
17
15
IB_86282_FGW84A1_LB7.indb 7IB_86282_FGW84A1_LB7.indb 7 28.01.13 09:2128.01.13 09:21

8FGW 84 A1
GB
CY
Step 5
♦ Guide the axle 13 through the lower boreholes on the wheel braces 14
and secure the placed-on wheels 12 with the self-securing nuts M8.
Step 6
♦ Attach the wind shield elements 234using M5x10 bolts, Ø6x12
washers and M5 nuts (only at the top). Next, bolt the wind shield elements
234to the fire bowl 6from the inside using M5x10 bolts, Ø6x12
washers and M5 nuts.
12
13
14
2
3
4
6
IB_86282_FGW84A1_LB7.indb 8IB_86282_FGW84A1_LB7.indb 8 28.01.13 09:2128.01.13 09:21

9
FGW 84 A1
GB
CY
Step 7
♦ Secure the wooden grip onto the rear part of the skewer (straight edge)
with light hammer blows. Slide the barbecue racks onto the skewer.
Secure the barbecue racks with the eye screws M4x10.
♦ Hook the two handles onto the cooking grill 5.
Step 8
♦ Place the cooking grill 5and the skewer inside the wind shields 234.
You can now remove the handles from the cooking grille 5so that they do
not interfere when you are barbecuing.
♦ To finish the assembly, tighten all screw connections firmly.
5
5
2
34
IB_86282_FGW84A1_LB7.indb 9IB_86282_FGW84A1_LB7.indb 9 28.01.13 09:2128.01.13 09:21

10 FGW 84 A1
GB
CY
Initial use
NOTICE
► Before the first use, the grill must be warmed up for at least 30 minutes.
WARNING
Warnings about burns!
► During use, place the grill on a secure, level and firm surface, otherwise it
could tip over.
► Warning! For igniting and reigniting, do NOT use spiritus or benzine!
Use only ignition aids complying with EN 1860-3. The deflagration could
cause an uncontrollable development of heat.
■ Build up a small pile of charcoal in the firebowl.
■ Place one or two solid firelighters on the existing layer of charcoal and ignite
the solid firelighters with a match or lighter.
■ Allow the firelighters to burn for 2 to 4 minutes. Then slowly start filling the
firebowl with charcoal.
■ After about 20 minutes the charcoal will display a white coating of ash.
The optimal burning temperature has now been reached.
■ Distribute the charcoal, using a suitable metallic implement, evenly in the
firebowl.
■ Insert the grill grate and start the barbecue.
IB_86282_FGW84A1_LB7.indb 10IB_86282_FGW84A1_LB7.indb 10 28.01.13 09:2128.01.13 09:21

11
FGW 84 A1
GB
CY
Cleaning and Care
WARNING
Warnings about burns!
► Before cleaning it or putting it into storage, allow the trolley barbecue to cool
down completely. NEVER use water to extinguish the glowing charcoal.
IMPORTANT
► Do not use abrasive or aggressive cleaning agents, they can damage the
enamelled pieces..
For normal cleaning, use a cloth and water with standard detergent.
For heavy soiling on the enamelled parts, use a standard commercial enamel
cleaner. Pay heed to the instructions supplied by the manufacturer of the cleaning
agent being employed. Clean the grill grate with detergent and a household sponge.
Disposal
Dispose of flammable materials carefully and with regard to the
environment. Fundamentally dispose of remaining waste ONLY into
containers made of metal and intended for this purpose or made of
non-flammable materials.
Dispose of the Trolley Barbecue through an approved waste disposal centre or
at your community waste facility. Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal centre.
Dispose of all packaging materials in an environmentally friendly manner.
Appendix
Technical data
Dimensions (assembled) approx. 84 x 86 x 45 cm
Grill grate approx. 48.3 x 28.3 cm
Weight approx. 6.6 kg
Fuel Charcoal
Firebowl capacity max. 1 kg
IB_86282_FGW84A1_LB7.indb 11IB_86282_FGW84A1_LB7.indb 11 28.01.13 09:2128.01.13 09:21

12 FGW 84 A1
GB
CY
Warranty
The warranty for this appliance is for 3 years from the date of purchase. The
appliance has been manufactured with care and meticulously examined before
delivery.
Please retain your receipt as proof of purchase. In the case of a warranty claim,
please make contact by telephone with our Customer Service Department. Only
in this way can a post-free despatch for your goods be assured.
NOTICE
► The warranty covers only claims for material and manufacturing defects,
not for transport damages, wearing parts or for damage to fragile compo-
nents, e.g. switches.
This product is for domestic use only and is not intended for commercial use. The
warranty is void in the case of abusive and improper handling, use of force and
internal tampering not carried out by our authorised service branch.
Your statutory rights are not restricted in any way by this warranty. The warranty
period is not extended by repairs made under the warranty. This applies also to
replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported immedi-
ately after unpacking, resp. no later than two days after the date of purchase.
Repairs made after the lapse of the warranty period are subject to charge.
Service
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: [email protected]
IAN 86282
CY Service Cyprus
Tel.: [phone]
E-Mail: [email protected]
IAN 86282
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
IB_86282_FGW84A1_LB7.indb 12IB_86282_FGW84A1_LB7.indb 12 28.01.13 09:2128.01.13 09:21

13
FGW 84 A1
HR
Sadržaj
Uvod. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Informacije u vezi sa ovim uputama za rukovanje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Autorsko pravo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Uporaba u skladu sa namjenom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sigurnost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Opće sigurnosne napomene . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Obim isporuke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Spojni elementi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Montaža . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Priprema montaže . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Potreban materijal za montažu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Koraci za montažu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Puštanje u rad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Čišćenje i održavanje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Odstranitev . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Prilog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Tehnički podaci . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Jamstvo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Servis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Uvoznik . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
IB_86282_FGW84A1_LB7.indb 13IB_86282_FGW84A1_LB7.indb 13 28.01.13 09:2128.01.13 09:21

14 FGW 84 A1
HR
Uvod
Informacije u vezi sa ovim uputama za rukovanje
Srdačno čestitamo!
Vašom kupnjom ste se odlučili za visokovrijedan proizvod. Prije montaže i prve
uporabe se upoznajte sa proizvodom. U tu svrhu pažljivo pročitajte slijedeće upute
za montažu i sigurnosne napomene. Proizvod koristite isključivo na opisani način i
u navedenim područjima primjene. Ove upute dobro sačuvajte. Svu dokumentaciju
u slučaju predaje proizvoda trećim osobama priložite i takođe predajte.
Autorsko pravo
Ova dokumentacija je zaštićena autorskim pravima.
Svako umnožavanje, odnosno svako tiskanje, čak i djelomičnog, kao i repro-
dukcija slika - i u promijenjenom obliku - dopušteno je isključivo uz pismeno
dopuštenje proizvođača.
Uporaba u skladu sa namjenom
Pokretni roštilj je namijenjen isključivo za pripravljanje namirnica prikladnih za
roštiljanje. Prikladan je isključivo za uporabu vani. Ovaj pokretni roštilj je namije-
njen isključivo za privatnu uporabu, a ne za komercijalne svrhe.
Za štete, koje proizlaze iz zloupotrebnog ili nenamjenskog korištenja, primjene
sile ili neovlaštene modifikacije uređaja proizvođač ne preuzima nikakvu odgo-
vornost.
UPOZORENJE
Opasnost uslijed nenamjenske uporabe!
Od ovog uređaja u slučaju nenamjenske uporabe i/ili drugih vrsti korištenja
mogu polaziti opasnosti.
► Uređaj koristite isključivo u skladu sa njegovom uporabnom namjenom.
► Poštujte postupke opisane u ovim uputama za rukovanje.
Potraživanja svake vrste koja proizlaze iz oštećenja uslijed nenamjenske uporabe,
nestručno izvedenih popravaka, neovlašteno izvršenih preinaka i korištenja nedo-
puštenih zamjenskih dijelova su isključena.
Rizik nosi isključivo korisnik.
IB_86282_FGW84A1_LB7.indb 14IB_86282_FGW84A1_LB7.indb 14 28.01.13 09:2128.01.13 09:21

15
FGW 84 A1
HR
Sigurnost
U ovom poglavlju možete pronaći važne sigurnosne napomene u vezi sa poslu-
živanjem uređaja.
Ovaj uređaj odgovara propisanim sigurnosnim odredbama.
Nestručna uporaba može dovesti do ozljeda osoba i do nastanka predmetne štete.
Opće sigurnosne napomene
UPOZORENJE
Upozorenje od opeklina!
1. Roštilj za vrijeme rada postavite na sigurnu, ravnu i čvrstu podlogu, jer u
protivnom može doći do prevrtanja.
2. PAŽNJA! Za potpaljivanje ili ponovno paljenje ne koristite špirit ili benzin!
Koristite isključivo pomoćna sredstva za potpaljivanje shodno normi EN 1860-3.
U protivnom može doći do naglog isparavanja i do nekontroliranog razvoja
topline.
3. PAŽNJA! Roštilj se jako zagrijava i za vrijeme rada ne smije biti pomaknut,
jer se u protivnom može prevrnuti.
4. PAŽNJA! Djecu i domaće životinje držite podalje!
5. Prilikom roštiljanja nosite odgovarajuće rukavice i koristite kliješta za grill.
6. Zagrijan uređaj ne smije ostati bez nadzora.
7. Roštilj prije čišćenja ostavite da se sasvim ohladi.
8. Nikada ne koristite vodu za gašenje drvenog uglja.
UPOZORENJE
Upozorenje na opasnost od gušenja!
► Roštilj koristite isključivo vani!
► Sa roštiljem ne rukujte u zatvorenim prostorijama ili na natkrovljenim
površinama.
IB_86282_FGW84A1_LB7.indb 15IB_86282_FGW84A1_LB7.indb 15 28.01.13 09:2128.01.13 09:21

16 FGW 84 A1
HR
Obim isporuke
1 x Garnitura bodeža (uklj. 2 x stezaljke za meso i 1 x drveni rukohvat)
21 x Vjetrobran lijevi
31 x Vjetrobran srednji
41 x Vjetrobran desni
51 x Rešetka za roštiljanje (uklj. 2x rukohvata)
61 x Zdjela za ugalj
71 x Rukohvat
82 x Držač rukohvata, kratki
92 x Stajaći potpornjak
10 2 x Poprečni potpornjak
11 5 x Daska za odlaganje, duga
12 2 x Kotača
13 1 x Osovina
14 2 x Potpornjak kotača
15 2 x Držač daske za odlaganje, dugi
16 2 x Potpornjak za stabilnije učvršćenje
17 3 x Daska za odlaganje, kratka
Spojni elementi
M6x12
24x
M5x10
7x
M5x16
16x
M4x15
2x
M5
23x
M6
24x
M8
2x
M4x10
2x
Ø6x16
8x
Ø6x12
7x
IB_86282_FGW84A1_LB7.indb 16IB_86282_FGW84A1_LB7.indb 16 28.01.13 09:2128.01.13 09:21

17
FGW 84 A1
HR
Montaža
Priprema montaže
Uzmite si dovoljno vremena za sastavljanje pokretnog roštilja. Stvorite si ravnu
radnu površinu od približno dva do tri četvorna metra. Izvadite pojedine dijelove
pakiranja i postavite ih na dohvatu ruke u pripravnosti. Provjerite kompletnost
obima isporuke i da li postoje oštećenja.
Potreban materijal za montažu
Čekić
Križni odvijač
Vilasti ključ veličine 8 mm, veličine 10 mm i veličine 13 mm
UPOZORENJE
Upozorenje na moguće ozljede!
► Glave vijaka radi Vaše sigurnosti uvijek trebaju biti usmjerene prema vani,
kako bi bile izbjegnute ozljede.
PAŽNJA
► Nakon završetka montaže čvrsto zategnite sve vijčane spojeve, kako ne bi
došlo do neželjenih zategnosti materijala.
IB_86282_FGW84A1_LB7.indb 17IB_86282_FGW84A1_LB7.indb 17 28.01.13 09:2128.01.13 09:21
