FLUENCE RAPTR Troubleshooting guide

TABLE OF CONTENTS:
LUMINAIRE SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
LUMINAIRE INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . 3
CAUTIONS AND WARNINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PRODUCT GUARANTEE & WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . 7
USER & INSTALLATION GUIDE
RAPTR
© Copyright 2023 Fluence Bioengineering 062023 | Subject to change without notice

3
LUMINAIRE SPECIFICATIONS
Spectra Power Length Width Height Weight
Broad R4 1020W 39.6”[1 m] 14.6” [37 cm] 4.1” [10,5 cm] 32 lbs [15 kg]
800W 31.5” [80 cm] 14.6” [37 cm] 4.1” [10,5 cm] 28 lbs [13 kg]
All Others 1020W 39.5” [1 m] 11.3” [28,7 cm] 4.2” [10,7 cm] 28 lbs [13 kg]
800W 31.5” [80 cm] 11.3” [28,7 cm] 4.2” [10,7 cm] 24 lbs [11 kg]
Max. Ambient Temperature 45°C [113°F]
Environmental Rating IP66* rated; RH <90% non-condensing
Input Voltage 277V-480V~, 50/60Hz for America
277V-400V~, 50/60Hz for Europe
Dimming Source Signal Driver, 0/1-10V, OFF/10-100%
INTENDED INSTALLATION ENVIRONMENT:
Length
Height
Width
FAMILY REGION SPECTRUM WATTAGE DISTRIBUTION INPUT VOLTAGE CONNECTOR
RP RAPTR C
A
GLOBAL
AMERICA
BW4
BP6
BP8
BP9
B8F
BROAD R4
BROAD R6
BROAD R8
BROAD R9
BROAD R8 +FR
800
1K
800 WATT
1020 WATT
STD
150
120° LAMBERTIAN
150° WIDE
JVG 277-480 VAC RST1 WIELAND
(RST20i3 Gr)
Dimming Cable Wire Color Americas Dimming Cable Wire Color International Power Supply Pin Connection
Red Black DIM (+)
Black White DIM (-)
Bare Wire Bare Wire Shield Drain (not connected to PS)
0-10 V DIMMING SIGNAL CABLE CONNECTIONS
NOTE: Connect the dim cable shield drain to only one PE ground connection point, i.e. at the dimming control panel.
AC POWER CABLE CONNECTIONS
Americas
AC Cable Wire Colors
International
AC Cable Wire Colors
Power Supply
Pin Connection 277 V 347 V 400 V 480 V
Black Brown L Phase Phase Phase Phase
White Blue N Neutral Neutral Phase Phase
Green Green-yellow G PE PE PE PE
NOTE: In 3-phase power applications, the light fixtures/loads should be properly distributed across all three phases, and not all on the same phase.
Dimming Input Off/on 0/1-10V sink dimming, source driver
Dimming Range 10-100 %, Linear
Typ / Max Source Current @ Vdim=0V 300 A/ 400 A
Voltage @ Full load 10 V
Voltage Dim to OFF 0.8 V
Voltage Dim to ON 1.0 V
Hysteresis ( V / %) 0.2 V / 2 %
DIMMING SPECIFICATIONS
SYSTEM SPECIFICATION SHEETS
For complete product information and system specifications please visit
www.fluence.science/support-center/
or email support@fluence-led.com

4
LUMINAIRE INSTALLATION PROCEDURE
1
4
2
Remove unit from carton and inspect to ensure no shipping
damage has occurred.
Place unit on the floor with the LED optic chamber facing up.
DO NOT place luminaire facing down to
prevent damaging optics.
Hook the mounting bracket to each end of the luminaire in the holes located at each end.
3Determine mounting bracket type needed (sold separately) and install on frame as outlined below. Note that the luminaire should be
positioned so that prolonged staring into the luminaire at a distance closer than 2.2 m is not expected.
The minimum distance from lighted object is 0.2 m.
IMPORTANT: For your protection, you must carefully read all warnings and instructions entirely PRIOR TO installation, operation, service or
maintenance. Failure to do so can result in personal injury and property damage.
3a 3b
3a
BRACKET TYPES
Square mounting type
for 70 mm truss
Unistrut mounting type
for 40 x 40 mm
Universal mounting type
3b
3c
3c Hook
Detail

5
CORD AND CABLE GUIDELINES:
1. Do not conceal or extend through a wall, floor, ceiling, or other parts of the building structure;
2. Do not locate above a suspended ceiling or dropped ceiling;
3. Do not permanently affix to the building structure;
4. Route so that cords are not subject to strain and are protected from physical damage;
5. Are visible over their entire length; and
6. Are used within their rated ampacity as determined for the maximum temperature of the installed environment specified in the
instructions.
SERVICIBILITY GUIDELINES:
The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire must be replaced.
LUMINAIRE INSTALLATION PROCEDURE
5
N
L
CAUTIONS AND WARNINGS
WARNING
Turn off and disconnect the power before installation. Installation should be performed by a qualified electrician in accordance with all national and
local electrical and construction codes and regulations.
• DO NOT attempt to install or use this product until you have fully read and understand the installation instructions contained in this user and
installation guide and on the product safety labels. Failure to follow the Fluence product instructions and safety label advice may result in
damage to the product, damage to property, or personal injury. Be sure to retain a copy of this user guide after installation for future reference.
• Risk of Electrical Shock. Turn off and disconnect the power before installing, moving, or cleaning to reduce the possibility of serious injury.
DO NOT disconnect cables from the power supply or LED light bar while energized.
• Only connect the system to an electrical outlet or circuit of appropriate type and rating for the cord and plug. Connect the system only to power
sources of the correct voltages and frequencies listed in the product specifications.
• Protect power cables from being pinched, walked on, or otherwise damaged.
• Use a strain-relief or power cord grip if needed. Maintain a minimum of 1” (2.5 cm) bend radius for all cables.
• Use IP wet-rated junction boxes and fittings for the power cords equal to the IP rating of the rating of the lighting system for the application.
• DO NOT connect to live power until installation is complete and all connections are made.
• DO NOT modify or alter the product; doing so will void the warranty. Please refer to the Fluence Terms and Conditions and Limited Warranty for
further details.
• LED and heatsink surfaces may be hot. DO NOT touch while in operation. Allow sufficient cooling time before handling.
• To reduce the risk of overheating or fire, never place operating fixtures face down on a flush surface. Always allow for adequate ventilation of
fixtures and power supplies.
Make electrical connection using AC power cable through the
Wieland connector on the luminare.
A. To attach the connector, match up the keyed pins (male to
female) and push it on until you hear a “click”.
B. Check that the connector is securely attached by lightly
tugging on the fixtures. The connector will not come off if
properly installed. Failure to test the cable connection may
result in electrical shock or damage to the product.
To disconnect the fixture and cable connectors:
A. Wieland RST: Use a flat head screwdriver to press on the
center release button to unlock.
B. M19: Twist the locking ring a quarter turn counter-clockwise
and pull straight out.
5a

6
ETL Rating: RAPTR fixtures are rated suitable for wet locations. A “wet location” is defined as an interior or exterior location in which water or other liquids
may drip, splash or flow on or against the electrical components of a lighting fixture. RAPTR Series luminaires are certified to meet UL standards (ETL) from the
Intertek safety consulting and certification company. Systems are cETL listed and are rated IP66 by IEC standard 60598-1.
CAUTIONS AND WARNINGS
PHOTOBIOLOGICAL HAZARD SAFETY
Photobiological safety of lamps and lamp systems (IEC/EN 62471 and TR 62778). This International Standard describes the photobiological safety of
lamps and lamp systems including luminaires. The rating of this product according to this standard can be found in the table below.
These photobiological safety markings are based on testing of the light output characteristic of a single horticultural luminaire. Increased exposure
risk to facility personnel may be present depending upon the number of horticultural luminaires and their placement and/or positioning within the
plant growth facility.
It is the responsibility of the plant growth facility to address these risks at the facility level and to ensure that people entering the plant growth areas
while the lights are on are aware of these risks and that appropriate safeguards are in place.
Ordering Code Radiation hazard -
Actinic UV 200-400 nm
Radiation hazard -
Retinal Blue Light (small source) 300-700 nm
Minimum viewing distance
(meter/inch) All Other Radiation Hazards
RP-x-BP6-800-STD-JVG-RST1-S
Exempt Group
(None)
Risk Group 2
(Moderate) 2.162 / 85.118 Exempt Group (None)
RP-x-BP6-800-150-JVG-RST1-S
RP-x-BP6-1K-STD-JVG-RST1-S
RP-x-BP6-1K-150-JVG-RST1-S
RP-x-BP9-800-STD-JVG-RST1-S
Risk Group 1
(Low)
Risk Group 2
(Moderate) 1.557 / 61.299 Exempt Group (None)
RP-x-BP9-800-150-JVG-RST1-S
RP-x-BP9-1K-STD-JVG-RST1-S
RP-x-BP9-1K-150-JVG-RST1-S
All Others Exempt Group
(None)
Risk Group 1
(Low) N/A Exempt Group (None)
Retinal Blue Light Radiation Hazard - RISK GROUP 2
CAUTION: POSSIBLY HAZARDOUS OPTICAL RADIATION EMITTED FROM
THIS PRODUCT. DO NOT STARE AT THE OPERATING LAMP. MAY BE
HARMFUL TO THE EYE.
Actinic UV Radiation Hazard - RISK GROUP 2
CAUTION: UV EMITTED FROM THIS PRODUCT. EYE OR SKIN IRRITATION
MAY RESULT FROM EXPOSUREMINIMIZE EXPOSURE TO EYES OR SKIN. USE
APPROPRIATE SHIELDING.
CHEMICAL EXPOSURE PRECAUTION
Fluence lighting systems are designed to be resilient against crop protection products. Many chemicals used in the Commercial Horticultural
Industry are corrosive to electronic equipment. If the luminaire is accidentally exposed to a corrosive liquid or vapor (e.g. VOC –Volatile Organic
Compound and H2S – Hydrogen Sulfide) the luminaire must be rinsed with clean water as soon as possible. The product warranty will no longer
apply if the product is exposed or remains in the corrosive environment. It is recommended the luminaires be removed and protected from the
corrosive environment during all periods of disinfection or sanitization of the facility.
CALIFORNIA PROPOSITION 65 WARNING
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more
information: www.P65Warnings.ca.gov.

7
Importer:
Signify Netherlands B.V.
Flight Forum 2000
5657 EX Eindhoven
The Netherlands
D Produkt zur Raumbeleuchtung im Haushalt nicht geeignet GB
Product not suitable for domestic household lighting F Produit inadapte
a l’eclairage interieur d’une habitation I Prodotto non idoneo a impianti
di illuminazione domestici E Producto no adecuado para iluminacion
residencial P Produto nao adequado para iluminacao domestica GR Το
προϊόν δεν είναι κατάλληλο για φωτισμό οικιακής χρήσης NL Product niet geschikt
voor huishoudelijke verlichtingsdoeleinden S Produkten ar ej lamplig for hushalls-
belysning FIN Tuotetta ei voida kayttaa kotitalouksien valaisuun N Produktet er ikke
egnet til a lyse opp rom med DK Produktet er ikke egnet husholdningsbelysning
CZ Vyrobek neni vhodny pro osvětleni domacnosti RUS Продукт не подходит для
бытового освещения помещений KZ Бұл өнім үйдегі тұрмыстық жарықтандыруға
жарамайды H A termek nem alkalmas haztartasi vilagitasnak PL Produkt nie jest
odpowiedni do oświetlenia domowego SK Produkt nie je vhodny na osvetlenie miest-
nosti v domacnosti SLO Izdelek ni primeren za osvetlitev bivalnih prostorov TR Urun,
ev aydınlatması icin uygun değildir HR Proizvod nije prikladan za rasvjetu prostorija
u kućanstvu RO Produsul nu este adecvat pentru iluminatul locuinţei BG Продуктът
не е подходящ за жилищно-битово осветление EST Toode ei sobi majapidamis-
valgustiks LT Prietaisas neskirtas namų apšvietimui LV Produkts nav piemērots
apgaismojumam mājās. SRB Proizvod nije pogodan za rasvetu u domaćinstvu UA
Продукт не підходить для побутового освітлення приміщень
D WEEE-Geratekennzeichen: Nicht in den Hausmull werfen! Sach-
gerechte Entsorgung der Produkte und Verpackung nach geltendem
Landesrecht vornehmen. GB WEEE device identication: Do not dis-
pose of in domestic waste! Proper disposal of the product and packaging
must be done in accordance with the applicable national law. F Identi-
cation WEEE du dispositif : ne pas jeter avec les dechets menagers ! Le
produit et son emballage doivent etre elimines conformement a la legis-
lation nationale en vigueur. I Identicazione RAEE del dispositivo: Non smaltire con i
riuti domestici! Lo smaltimento corretto del prodotto e dell’imballaggio deve essere
e󰀨ettuato secondo la legge nazionale applicabile. E Identicacion RAEE del dispositi-
vo: No desechar con los residuos domesticos. El desecho adecuado del producto y
el embalaje debera llevarse a cabo de conformidad con la ley nacional aplicable. P
Identicacao do dispositivo REEE: Nao deite fora no lixo domestico! A eliminacao
adequada do produto e da embalagem deve ser feita em conformidade com a leg-
islacao nacional aplicavel. GR Αναγνώριση συσκευής WEEE: Μην απορρίπτετε με
τα οικιακά απορρίμματα! Η απόρριψη του προϊόντος και της συσκευασίας πρέπει να
γίνεται σύμφωνα με την ισχύουσα εθνική νομοθεσία. NL WEE-apparaatidenticatie:
niet weggooien bij het huishoudelijke afval! Correcte verwijdering van het product en
verpakking dient te gebeuren overeenkomstig de toepasselijke nationale wetgeving.
S Enhetens identikation for WEEE: Slang inte bland hushallssopor! Produkten och
forpackningen maste slangas pa ett korrekt satt i enlighet med gallande nationell lag.
FIN WEEE-laitetunnus: Ala havita kotitalousjatteen seassa! Tuotteen ja pakkauksen
asianmukainen havittaminen on suoritettava soveltuvien paikallisten lakien mukai-
sesti. N WEEE Enhetsidentikasjon: Skal ikke kastes i husholdningsavfallet! Riktig
avhending av produktet og emballasjen ma gjores i henhold til gjeldende nasjonale
lover. DK WEEE enhedsidentikation: Ma ikke bortska󰀨es med husholdningsa󰀨ald!
Korrekt bortska󰀨else af produktet og emballagen skal ske i overensstemmelse med
g.ldende national lovgivning. CZ Označeni zařizeni podle systemu WEEE: Nevyhazo-
vat do domovniho odpadu! Spravna likvidace vyrobku a obalu musi byt provedena
v souladu s platnymi narodnimi legislativnimi předpisy. RUS Идентификация
устройства в соответствии с Директивой ЕС (WEEE) об отходах электрического
и электронного оборудования: Не выбрасывайте продукт вместе с бытовыми
отходами! Продукт и упаковку необходимо утилизировать надлежащим образом
в соответствии с действующим национальным законодательством. KZ WEEE
құрылғы идентификаторы: үй қоқысымен бірге тастамаңыз! Бұл өнім мен оның
қаптамасының тасталуы қолданыстағы ұлттық заңға сай дұрыс орындалуы тиіс.
H WEEE keszulek azonosito: Kommunalis hulladekba helyezni tilos! A termek es a
csomagolas megfelelő artalmatlanitasat a hatalyos nemzeti szabalyozas szerint kell
elvegezni. PL Identykacja urządzenia WEEE: Urządzenia nie wolno wyrzucać wraz
ze zwykłymi odpadami domowymi! Właściwe usuwanie produktu i opakowania musi
odbywać się zgodnie z obowiązującym prawem krajowym. SK Označenie zariadenia
WEEE: Nelikvidujte v ramci komunalneho odpadu! Riadna likvidacia tohto produktu a
obalov sa musi vykonať v sulade s narodnymi pravnymi predpismi. SLO Identikacija
izdelka v smislu OEEO: Ne zavrzite med gospodinjske odpadke! Izdelek in embalažo
je treba med odpadke zavreči ustrezno in v skladu z veljavno nacionalno zakonodajo.
TR WEEE cihaz kimliği: Evsel atıklara dahil etmeyin! Urun ve ambalajın doğru bicim-
de imhası ilgili ulusal yasaya uygun olarak gercekleştirilmelidir. HR Oznaka WEEE na
uređaju: ne odlažite u kućni otpad! Proizvod i pakiranje potrebno je ispravno odložiti
u skladu s primjenjivim zakonom države. RO Identicarea dispozitivelor WEEE: Nu
eliminaţi produsul in gunoiul menajer! Eliminarea corectă a produsului şi ambalarea
se vor face in conformitate cu legea naţională aplicabilă. BG Идентификация на
устройството по WEEE: Да не се изхвърля с битовите отпадъци! Правилното
третиране на продукта и опаковката му като отпадъци трябва да става в
съответствие с приложимото национално законодателство. EST WEEE-seadme
identitseerimine: Arge visake olmejaatmetesse! Toote ja pakendite nouetekohane
korvaldamine peab toimuma kooskolas kehtivate siseriiklike oigusaktidega. LT WEEE
įrenginio identikacija: nešalinti kartu su buitinėmis atliekomis! Gaminio ir pakuotės
šalinimas turi būti atliekamas pagal šalyje galiojančius įstatymus. LV WEEE ierīces
identikācija: neizmest sadzīves atkritumos! Produkts un iepakojums jāizmet atbil-
stoši piemērojamam valsts likumam. SRB Identikacija WEEE uređaja: Nemojte da
odlažete u otpad iz domaćinstva! Proizvod i pakovanje morate da odložite u otpad u
skladu sa važećim nacionalnim zakonom. UA Ідентифікація пристрою відповідно
до Директиви ЄС (WEEE) щодо відпрацьованого електричного й електронного
обладнання: Не викидайте продукт разом з іншим домашнім сміттям! Продукт та
упаковку слід утилізувати належним чином відповідно до діючого національного
законодавства.
D CE-Kennzeichen: Hiermit erklart OSRAM, dass dieses Produkt den
grundlegenden Anforderungen und den relevanten Vorschriften der
europaischen Richtlinien entspricht. GB CE marking: OSRAM declares
that this product conforms with the basic requirements and relevant
provisions of the European guidelines. F Marquage CE: OSRAM declare que ce
produit repond aux exigences de base et aux dispositions applicables des directives
europeennes. I Marchio CE: OSRAM dichiara che questo prodotto e conforme ai
requisiti di base e i provvedimenti pertinenti secondo le linee guida europee. E Marca
CE: OSRAM declara que este producto cumple con los requisitos basicos y las
disposiciones relevantes de las directrices europeas. P Marca CE: A OSRAM declara
que este produto esta em conformidade com os requisitos basicos e as disposicoes
relevantes das diretrizes europeias. GR Σήμανση CE: Η OSRAM δηλώνει ότι το
προϊόν αυτό συμμορφώνεται με τις βασικές απαιτήσεις και τις σχετικές διατάξεις των
ευρωπαϊκών οδηγιών. NL CE-markering: OSRAM verklaart dat dit product voldoet
aan de basisvereisten en relevante bepalingen van de Europese richtlijnen. S
CE-markning: OSRAM tillkannager att den har produkten uppfyller de grundlaggande
kraven och relevanta bestammelserna i de europeiska riktlinjerna. FIN CE-merkinta:
OSRAM takaa, etta tama tuote tayttaa Eurooppalaiset perusvaatimukset ja muut
tarkeat vaatimukset. N CE-merking: OSRAM erkl.rer at dette produktet oppfyller
krav og relevante bestemmelser i de europeiske retningslinjene. DK CE-m.rkning:
OSRAM erkl.rer, at dette produkt overholder de grundl.ggende krav og relevante
bestemmelser i de europ.iske vejledninger. CZ Značka CE: Společnost OSRAM
prohlašuje, že tento vyrobek splňuje zakladni požadavky a ustanoveni evropskych
směrnic. RUS Маркировка CE: компания OSRAM заявляет, что данный
продукт отвечает основным требованиям и соответствующим положениям
Европейских директив. KZ CE белгісі: OSRAM компаниясы бұл өнімнің
Еуропалық нұсқаулықтардың негізгі талаптары мен қатысты ережелеріне сай
екенін жариялайды. H CE jeloles: Az OSRAM kijelenti, hogy a termek teljesiti az
Europai iranyelvek alapvető kovetelmenyeit es vonatkozo előirasait. PL Oznakowan-
ie CE: rma OSRAM oświadcza, że niniejszy produkt jest zgodny z podstawowymi
wymogami i odpowiednimi postanowieniami wytycznych europejskich. SK Označenie
CE: Spoločnosť OSRAM tymto deklaruje, že tento produkt vyhovuje zakladnym
požiadavkam a relevantnym predpisom europskych smernic. SLO Oznaka CE: Druž-
ba OSRAM izjavlja, da ta izdelek izpolnjuje osnovne zahteve in ustrezna določila
evropskih smernic. TR CE işareti: OSRAM, bu urunun Avrupa kılavuz ilkelerinin ilgili
hukumleri ve temel gerekliliklerine uygun olduğunu beyan eder. HR Oznaka CE:
tvrtka OSRAM ovim izjavljuje da je ovaj proizvod u skladu s osnovnim zahtjevima
i relevantnim odredbama europskih direktiva. RO Marcaj CE: OSRAM declară că
acest produs respectă cerinţele de bază şi prevederile relevante ale standardelor
europene. BG Маркировка „CE”: OSRAM декларира, че този продукт съответства
на основните изисквания и приложимите разпоредби на европейските насоки.
EST CE-margis: OSRAM kinnitab, et antud toode vastab Euroopa suuniste pohi-
nouetele ja asjakohastele satetele. LT CE ženklinimas: OSRAM pareiškia, kad šis
prietaisas atitinka pagrindinius Europos gairių reikalavimus ir atitinkamas nuostatas.
LV CE marķējums: OSRAM paziņo, ka šis produkts atbilst Eiropas vadlīniju pamata
prasībām un saistītiem nosacījumiem. SRB CE označavanje: OSRAM izjavljuje da je
ovaj proizvod u saglasnosti sa osnovnim zahtevima i važećim propisima evropskih
smernica. UA Маркування СЕ: компанія OSRAM засвідчує,
Horticulture Use
CAUTIONS AND WARNINGS

PRODUCT GUARANTEE & WARRANTY
Every Fluence Lighting system is engineered and built by Fluence Bioengineering
using state-of-the-art robotics and hand craftsmanship. All Fluence Lighting
systems are guaranteed against manufacturing defects for five years from date
of purchase. Fluence lighting systems comply with applicable standards and are
intended to be used with Fluence power supplies, cables and mounting hardware.
The use of Fluence lighting systems with power supplies, cables and mounting
hardware by others will limit specifications and void the warranty. Contact us at
[email protected] for more warranty information.
We stand behind our research, we stand behind our technology and we stand behind our
clients. www.fluence.science/warranty/
fluence.science
© Copyright 2023. Fluence Bioengineering, Inc.
062023 •100-820-00A
Review our products, share your grow and stay
abreast of the latest Fluence news and product
releases through the channels below:
