Fluke i430-Flexi-TF User manual

LIMITED WARRANTY & LIMITATION OF LIABILITY
Each Fluke product is warranted to be
free from defects in material and
workmanship under normal use and service. The warranty period is one year
and begins on the date of shipment. Parts, product repairs and services are
warranted for 90 days. This warranty extends only to the original buyer
or end-
user customer of a Fluke authorized reseller, and does not apply to fuses,
disposable batteries or to any product which, in Fluke's opinion, has been
misused, altered, neglected or damaged by accident or abnormal conditions of
operation or handling. Fluke warrants that software will operate substantially in
accordance with its functional specifications for 90 days and that it has been
properly recorded on non
-defective media. Fluke does not warrant that
software will be error free or operate without
interruption.
Fluke authorized resellers shall extend this warranty on new and unused products
to end
-
user customers only but have no authority to extend a greater or different
warranty on behalf of Fluke. Warranty support is available if product is purchased
through a Fluke authorized sales outlet or Buyer has paid the applicable
international price. Fluke reserves the right to invoice Buyer for importation costs
of repair/replacement parts when product purchased in one country is submitted
for repair i
n another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase
price, free of charge repair, or replacement of a defective product which is returned
to a Fluke authorized service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center
or send the product, with a description of the difficulty, postage and insurance
prepaid (FOB Destination), to the nearest Fluke authorized service center. Fluke
assumes no risk for damage in transit. Following warranty repair, the product will
be returned to Buyer, transportation prepaid (FOB Destination). If Fluke
determines that the failure was caused by misuse, alteration, accident or abnormal
condi
tion of operation or handling,
Fluke will provide an estimate of repair costs
and obtain authorization before commencing the work. Following repair, the
product will be returned to the Buyer transportation prepaid and the Buyer will be
billed for the repair and return transportat
ion charges (FOB Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. FLUKE SHALL NOT BE LIABLE
FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, WHETHER ARISING
FROM BREACH OF WARRANTY OR BASED ON CONTRACT, TORT,
RELIANCE OR ANY OTHER THEORY.
Since some countries or states do not
allow limitation of the term of an implied
warranty, or exclusion or limitation of incidental or consequential damages, the
limitations and exclusions of this warranty may not apply to every buyer. If any
provision of this Warranty is held invalid or unenforceable by a court of competent
jurisdiction, such holding will not affect the validity or enforceability of any other
provision.
Fluke Corporation Fluke Industrial B.V.
P.O. Box 9090 P.O. Box 90
Everett WA 7600 AB Almelo
98206-9090, USA The Netherlands
SERVICE CENTERS
To locate an authorized service center,
visit us on the World Wide Web:
http://www.fluke.com
or call Fluke using any of the phone numbers listed below:
[phone] in U.S.A. and Canada
[phone] in Europe
[phone] from other countries
i430-Flexi-TF
6000 A Flexible AC Current Probe
Instruction Sheet
Introducing the i430-Flexi-TF
The i430-Flexi-TF is a flexible AC current probe for use with the Fluke
430 series Power Quality Analyzers including Series II. The i430-
Flexi-TF is optimized for current measurement on thick and hard to
reach conductors.
Unpacking
The following items should be included in the package:
xi430-Flexi-TF Current Probe(s)
xInstruction Sheet (this paper)
Check the contents of the shipping box for completeness. If
something in the box has been damaged or missing, contact your
distributor or the nearest FLUKE sales or service office immediately.
Safety Information
Read First: Safety Information
To prevent possible electrical shock, fire, or personal injury:
xRead all safety information before you use the Product.
xCarefully read all instructions.
xUse the Product only as specified, or the protection supplied
by the Product can be compromised.
xComply with local and national safety codes. Use personal
protective equipment (approved rubber gloves, face
protection, and flame-resistant clothes) to prevent shock and
arc blast injury where hazardous live conductors are
exposed.
xLimit operation to the specified measurement category,
voltage, or amperage ratings.
xDe-energize the circuit or wear personal protective
equipment in compliance with local requirements before you
apply or remove the Flexible Current Probe.
xDo not touch voltages >30 V ac, 42 V ac peak, or 60 V dc.
xDo not use the Product around explosive gas, vapor, or in
damp or wet environments.
xDo not use the Product if it operates incorrectly.
xBefore each use, examine the Product. Look for cracks or
missing pieces of the clamp housing or output cable
insulation. Also look for loose or weakened components.
Carefully examine the insulation around the jaws.
xDo not use a current measurement as an indication that a
circuit is safe to touch. A voltage measurement is necessary
to know if a circuit is hazardous.
xDo not use the Product if it is damaged.
PN 4426307
December
20
11, Rev.1, 12/13
© 20
11-2013
Fluke Corporation.
All rights reserved.
Printed in the EU
.
All product
names are trademarks of their
respective companies.

Symbols
b
Do not apply around or remove from HAZARDOUS
LIVE conductors.

Product is protected by double insulation.

Risk of Danger. Important information.
See Instruction Sheet.

Risk of Electric Shock.

Conforms to relevant European standards.
^
Conforms to relevant North American Safety
Standards.

Conforms to relevant Australian standards.
U
Do not dispose of this product as unsorted
municipal waste. Go to Fluke’s website for
recycling
information.

Examined and licensed by TÜV Product Services.
k
ROHS China
Specifications
SAFETY
The i430-Flexi-TF complies with:
IEC 61010-1: Pollution degree 2
IEC 61010-2-
032: 1000V CAT III/ 600V CAT IV
IEC 61010-031
ELECTRICAL SPECIFICATIONS
Measuring range
0.5 to 6000 A ac
Maximum non-destructive
current
100 kA (50/60 Hz)
Output signal
86.6 mV at 1000A/50Hz (on 1 MΩ)
85.0 mV at 1000A/50Hz (on 50 kΩ)
Basic accuracy
±1% of reading at 25 qC, 50 Hz
Linearity
±0.2% of reading at 10%...100% of
range
Noise
<1 mV rms at 10 Hz …10 kHz
Additional errors:
●temperature coefficient
over operating temperature
range
0.05 % of reading /°C,
0.09
% of reading /°F
●with position of conductor
in the probe window
(see
Figure 1)
:
A = 12.7 mm (0.5 in)
B = 20.3 mm (0.8 in)
C = 35.6 mm (1.4 in)
●
0.5 to 30 A
±0.5
% of reading
±1.0
% of reading
±2.0
% of reading
±1 count or 0.1 A
(whichever is
greater)
External magnetic field
rejection in reference to
external current
40 dB (with cable >100 mm from the
head coupling and r
-coil)
Phase shift (fundamental
frequency)
< ±1°
Bandwidth (-3 dB)
10 Hz to 10 kHz
Frequency derating
I x f ≤385 kA Hz
Working voltage
1000V CAT III, 600V CAT IV
GENERAL SPECIFICATIONS
Weight
195 g
Transducer length
610 mm (24 in)
Transducer diameter
7.5 mm (0.3 in)
Minimum bending radius
38 mm (1.5 in)
Cable length from
transducer to BNC
2.5 m (98.4 in)
Temperature, operating
-20 °C to +70 °C (-4 °F to +158 °F)
Temperature of conductor under test
shall not exceed 80 °C (176 °F)
Temperature, non-operating
-40°C to + 80 °C (-40 °F to +176 °F)
Relative Humidity, operating
15 to 85 %, non condensing
Altitude, operating
3000 m
Altitude, storage
12 km
Instrument Compatibility
The
i430-Flexi-TF can only be used with the Fluke 433/434/435
/434-
II/
435
-II/437-II Power Quality Analyzers.
Maximum measurement range
on all models: 600
0 A. Minimum measurement range on Fluke
433/434/435: 30
A.
Using the
i430-Flexi-TF
To use the
i430-Flexi-TF, follow these instructions:
1.
Connect the BNC connector of the i430-Flexi-TF
to the desired
input on the Fluke 430 series Power Quality Analyzer.
hqg01.eps
Figure 1. Connecting the flexible probe around the conductor.
2.
Connect the flexible probe around the conductor (See Figure
1.)
3. Center the conductor perpendicularly inside the flexible probe
area. If this is not possible, an additional measurement error of
±2 % of reading can occur.
4.
Avoid taking measurements close to other current-carrying
conductors if possible.
5. Make sure that the arrow marked on the probe coupling points
toward the correct orientation for correct phase display on the
instrument. See also the setup screen of the instrument.
6. Keep the probe coupling more than 2.5 cm (1 inch) away from
the conductor.
7. Observe the current value and waveform on the instrument’s
display.
8. Observe the safety instructions when applying and using the
i430-Flexi-TF.
Warning
If the selected current probe of the Fluke 430 series
Power Quality Analyzer is not the i430 Flex (on Fluke
430 series I) or i430-Flexi-TF (on Fluke 430 series II)
, the
Fluke 430 will display false and misleading readings.
Maintenance
Before each use, assure continued safety by inspecting the flexible
probe and its latching system for any damage. Pay particular attention
to the insulation surrounding the flexible probe. An
i430-Flexi-TF
under warranty will be promptly repaired or replaced (at Fluke's
discretion) and returned at no charge.
 Warning
To prevent possible electrical shock, fire, or personal
injury:
xRemove the input signals before you clean the
Product.
xHave an approved technician repair the Product.
Cleaning and Storage
xThe flexible probe and its latching system require no special
care. Ensure that no foreign body obstructs the latching
mechanism.
x
Clean the i430-Flexi-TF
with a damp cloth and a mild detergent.
Do not use abrasives, solvents, or alcohol.
If your
i430-Flexi-TF does not work
If the
i430-Flexi-TF
does not perform properly, use the following steps
to help isolate the problem:
x
Inspect the coupling system for any damage. If any foreign
material is present, the coupling system will not close properly
and errors will result.
x
Inspect the cable between the flexible probe and the Power
Quality Analyzer for any damage.
x
Check if the i430-Flexi-TF is the selected curren
t probe on the
Power Quality Analyzer (Clamp i430-Flexi-TF).
xVerify that the function and range selection on the Power Quality
Analyzer is correct.
