Fluke 9040 User manual

PN 2438546
April 2005, Rev. 3, 11/21
© 2005-2021 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
9040
Phase Rotation Indicator
Users Manual

LIMITED WARRANTY AND LIMITATION OF LIABILITY
This Fluke product will be free from defects in material and workmanship for one year
from the date of purchase. This warranty does not cover fuses, disposable batteries,
or damage from accident, neglect, misuse, alteration, contamination, or abnormal
conditions of operation or handling. Resellers are not authorized to extend any other
warranty on Fluke’s behalf. To obtain service during the warranty period, contact your
nearest Fluke authorized service center to obtain return authorization information,
then send the product to that Service Center with a description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH
AS FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED.
FLUKE IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSE-
QUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY.
Since some states or countries do not allow the exclusion or limitation of an implied
warranty or of incidental or consequential damages, this limitation of liability may not
apply to you.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
11/99

i
Table of Contents
Title Page
Introduction..........................................................................................................1
How to Contact Fluke..........................................................................................1
Unpacking the 9040 ............................................................................................2
Safety Information ...............................................................................................3
Symbols...............................................................................................................5
Elements of the 9040 ..........................................................................................7
Determine the Rotary Field Direction..................................................................8
Maintaining the 9040...........................................................................................9
Replacing the Fuse (9040UK only) .....................................................................10
Specifications ......................................................................................................11

ii

1
Introduction
The Fluke 9040 Phase Rotation Indicator (the 9040 or the Product) is a handheld
instrument designed to detect the rotary field of three-phase systems.
How to Contact Fluke
Fluke Corporation operates worldwide. For local contact information, go to our website:
www.fluke.com
To register your product, view, print, or download the latest manual or manual supplement,
go to our website.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
[phone]
[email protected]

9040
Users Manual
2
Unpacking the 9040
The 9040 is available in three configurations. Depending on your purchase, the 9040 ships
with these items:
•9040
o3 self-retaining test probes, 1000 V CAT II
o3 alligator clips, 1000 V CAT III/600 V CAT IV
oUsers Manual
•9040UK
o3 fused test probes, 1000 V CAT III
o3 alligator clips, 1000 V CAT III/600 V CAT IV
oUsers Manual
•9040EUR
o3 Slim-Reach™ test probes (black) 1000 V CAT III/600 V CAT IV
o3 self-retaining test probes, 1000 V CAT II
o3 alligator clips, 1000 V CAT III/600 V CAT IV
oUsers Manual XW Warning
To prevent possible electrical shock, fire, or personal injury, do not exceed
the Measurement Category (CAT) rating of the lowest rated individual
component of a product, probe, or accessory.
If an item is damaged or missing, contact the place of purchase immediately.

Phase Rotation Indicator
Safety Information
3
Safety Information
Caution identifies conditions and actions that may damage the 9040.
Warning identifies conditions and actions that pose hazard(s) to the user.
XW Warning
To prevent possible electrical shock, fire, or personal injury:
•Read all safety information before you use the Product.
•Carefully read all instructions.
•Use this Product indoors only.
•Use only current probes, test leads, and adapters supplied with the
Product.
•Do not use the Product above its rated frequency.
•Do not apply more than the rated voltage, between the terminals or
between each terminal and earth ground.
•Do not keep the Product in operation and unattended at high
temperatures.

9040
Users Manual
4
•Comply with local and national safety codes. Use personal protective
equipment (approved rubber gloves, face protection, and flame-
resistant clothes) to prevent shock and arc blast injury where
hazardous live conductors are exposed.
•Use the product only as specified, or the protection supplied by the
product can be compromised.
•Do not work alone.
•Do not use test leads if they are damaged. Examine the test leads for
damaged insulation or exposed metal. Check test lead continuity.
•Do not touch voltages >30 V ac rms, 42 V ac peak, or 60 V dc.
•Keep fingers behind the finger guards on the probes.
•Measurements can be adversely affected by impedances of additional
operating circuits connected in parallel or by transient currents.
•Verify operation prior to measuring hazardous voltages (voltages above
30 V ac rms, 42 V ac peak and 60 V dc).
•Do not use the 9040 with any of the parts removed.
•Do not use the product around explosive gas, vapor, or in damp or wet
environments.

Phase Rotation Indicator
Symbols
5
Symbols
The following symbols appear on the 9040 or in this manual.
Table 1. Symbols
WWARNING. RISK OF DANGER. JEarth ground.
XHazardous voltage. Risk of
electric shock. TDouble Insulated.
»Consult user documentation. PConforms to requirements of
European Union.
¼
Measurement Category II is
applicable to test and measuring
circuits connected directly to
utilization points (socket outlets
and similar points) of the low-
voltage MAINS installation.
½
Measurement Category III is
applicable to test and measuring
circuits connected to the distribution
part of the building’s low-voltage
MAINS installation.

9040
Users Manual
6
Table 1. Symbols (cont.)
¾
Measurement Category IV is
applicable to test and measuring
circuits connected at the source
of the building’s low-voltage
MAINS installation.
~
This product complies with the
WEEE Directive marking
requirements. The affixed label
indicates that you must not discard
this electrical/electronic product in
domestic household waste. Product
Category: With reference to the
equipment types in the WEEE
Directive Annex I, this product is
classed as category 9 "Monitoring
and Control Instrumentation"
product. Do not dispose of this
product as unsorted municipal
waste.

Phase Rotation Indicator
Elements of the 9040
7
Elements of the 9040
Indicators, buttons, and jacks are shown in Figure 1.
bbx02f.tif
Figure 1. The 9040 Phase Rotation Indicator

9040
Users Manual
8
Determine the Rotary Field Direction
To determine the rotary field direction:
1. Connect the test probes to the end of the test leads.
2. Connect the test probes to the three mains phases.
3. Either the clockwise or counter-clockwise rotary indicator illuminates showing the type
of rotary field direction present.
XW Warning
The rotary indicator lights even if the neutral conductor, N, is connected
instead of L1, L2, or L3. Refer to the back of the 9040 for more information.
Note
The 9040 is powered from the installation under test.

Phase Rotation Indicator
Maintaining the 9040
9
Maintaining the 9040
XWWarning
To prevent possible electrical shock, fire, or personal injury, do not operate
the Product with covers removed or the case open. Hazardous voltage
exposure is possible.
WCaution
To prevent damage to the 9040:
•Do not attempt to repair or service the 9040 unless qualified to do so.
•Make sure that the relevant calibration, performance test, and service
information is being used.
•Do not use abrasives or solvents. Abrasives or solvents will damage
the 9040 case.
The only maintenance the 9040 requires is inspection and cleaning. Periodically wipe the
case with a damp cloth and mild detergent. Clean only with soap and water and remove any
residue afterwards.

9040
Users Manual
10
Replacing the Fuse (9040UK only)
XW Warning
For safe operation and maintenance of the product:
•Use only specified replacement fuses. See Specifications section.
•Before you replace the fuse, disconnect the accessory (cable or probe)
at both ends.
To replace the fuse:
1. Check the fuse using a simple continuity test.
2. Hold the probe in front of the finger guard and unscrew the tip in a counter-
clockwise direction.
3. Remove the defective fuse from the fuse holder.
4. Insert a new fuse in the fuse holder and reassemble the probe.

Phase Rotation Indicator
Specifications
11
Specifications
Maximum voltage between any
Terminal and Earth Ground: 600 V
Power: Supplied by circuit under test.
Fuse: (9040 UK model only) 0.5 A,
1000 V, 50 kA, 6.3 mm x 32 mm
Determine Rotary Field Direction:
Nominal Voltage: 40 V to 690 V ac
(Ume)
Frequency Range (fn): 15 Hz to
400 Hz
Current Pickup: 1 mA
Nominal Test Current (in each phase):
1 mA
Temperature:
Operating: -10 °C to +40 °C
Storage: -40 °C to +60 °C
Operating Relative Humidity:
15 % to 80 %
Altitude:
Operating: ≤2000 m
Storage: ≤2000 m
Size: 12.4 cm x 6.1 cm x 2.7 cm
Weight: 200 g
Safety:
IEC 61010-1: Pollution Degree 2
IEC 61010-2-030: Measurement CAT III
600 V/CAT IV 300 V
IEC 60925: IP40 (non-operating)
IEC 61557-7: Phase sequence

9040
Users Manual
12
Electromagnetic Compatibility:
International: IEC 61326-1: Industrial Electromagnetic Environment
CISPR 11: Group 1, Class A
Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio
frequency energy that is necessary for the internal function of the equipment itself.
Class A: Equipment is suitable for use in all establishments other than domestic and
those directly connected to a low-voltage power supply network that supplies buildings
used for domestic purposes. There may be potential difficulties in ensuring
electromagnetic compatibility in other environments due to conducted and radiated
disturbances.
Caution: This equipment is not intended for use in residential environments and may not
provide adequate protection to radio reception in such environments.
Emissions that exceed the levels required by CISPR 11 can occur when the equipment
is connected to a test object.
The equipment may not meet the immunity requirements of this standard when test
leads and/or test probes are connected.
Korea (KCC):Class A Equipment (Industrial Broadcasting & Communication Equipment)
Class A: Equipment meets requirements for industrial electromagnetic wave equipment
and the seller or user should take notice of it. This equipment is intended for use in
business environments and not to be used in homes.
USA (FCC): 47 CFR 15 subpart B. This product is considered an exempt device per clause
15.103.
