Fluke 867B User manual

4822 872 00894
November 1997 , Rev. 3, 10/98
© 1997, 1998 Fluke Corporation. All rights reserved. Printed in the Netherlands.
All product names are trademarks of their respective companies.
®
867B/863
Graphical Multimeter
Users Manual

LIMITED WARRANTY & LIMITATION OF LIABILITY
Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is three years and
begins on the date of shipment. Parts, product repairs and services are warranted for 90 days. This warranty extends only to the original buyer or end-user
customer of a Fluke authorized reseller, and does not apply to fuses, disposable batteries or to any product which, in Fluke's opinion, has been misused, altered,
neglected or damaged by accident or abnormal conditions of operation or handling. Fluke warrants that software will operate substantially in accordance with its
functional specifications for 90 days and that it has been properly recorded on non-defective media. Fluke does not warrant that software will be error free or
operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different
warranty on behalf of Fluke. Warranty support is available if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable
international price. Fluke reserves the right to invoice Buyer for importation costs of repair/replacement parts when product purchased in one country is submitted
for repair in another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of charge repair, or replacement of a defective product which is
returned to a Fluke authorized service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center or send the product, with a description of the difficulty, postage and insurance
prepaid (FOB Destination), to the nearest Fluke authorized service center. Fluke assumes no risk for damage in transit. Following warranty repair, the product will
be returned to Buyer, transportation prepaid (FOB Destination). If Fluke determines that the failure was caused by misuse, alteration, accident or abnormal
condition of operation or handling, Fluke will provide an estimate of repair costs and obtain authorization before commencing the work.
Following repair, the product will be returned to the Buyer transportation prepaid and the Buyer will be billed for the repair and return transportation charges (FOB
Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE SHALL NOT BE LIABLE FOR
ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, WHETHER ARISING FROM
BREACH OF WARRANTY OR BASED ON CONTRACT, TORT, RELIANCE OR ANY OTHER THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or consequential damages, the
limitations and exclusions of this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court of competent
jurisdiction, such holding will not affect the validity or enforceability of any other provision.
Fluke Corporation, P.O. Box 9090, Everett, WA 98206-9090 USA or Fluke Europe B.V., P.O. Box 1186, 5602 B.D., Eindhoven, The Netherlands

SERVICE CENTERS
To locate an authorized service center, visit us on the World Wide Web:
http://www.fluke.com
or call Fluke using any of the phone numbers listed below:
[phone] in U.S.A. and Canada
[phone] in Europe
[phone] from other countries

i
Table of Contents
Chapter Title Page
1 A Quick Tour .................................................................................................... 1-1
Your Graphical Multimeter................................................................................. 1-1
About This Manual............................................................................................. 1-8
Combo Mode ..................................................................................................... 1-9
Meter Mode ...................................................................................................... 1-9
View Mode......................................................................................................... 1-9
Trend Mode ....................................................................................................... 1-9
Auto Diode Test Mode....................................................................................... 1-10
Logic Test Mode ................................................................................................ 1-10
Component Test Mode ...................................................................................... 1-10
Sleep Mode........................................................................................................ 1-10
2 Making Measurements .................................................................................... 2-1
Introduction........................................................................................................ 2-1
Measuring AC Volts........................................................................................... 2-4

867B/863
Users Manual
ii
Measuring DC Volts ........................................................................................... 2-6
Measuring DC Millivolts...................................................................................... 2-8
Measuring Ohms, Continuity, and Conductance................................................ 2-9
Testing Diodes and Measuring Capacitance ..................................................... 2-11
Measuring AC and DC Amps ............................................................................. 2-13
Measuring AC and DC Milliamps and Microamps.............................................. 2-15
Using Component Test ...................................................................................... 2-17
Testing for Logic Activity .................................................................................... 2-20
Measuring Frequency ........................................................................................ 2-22
3 Some General Descriptions ............................................................................ 3-1
Introduction ........................................................................................................ 3-1
Battery Considerations....................................................................................... 3-1
Display Blanking (Sleep Mode) .......................................................................... 3-1
Using the ............................................................................................................ 3-2
Backlight (Model 867B) ...................................................................................... 3-2
Adjusting Contrast.............................................................................................. 3-2
General Features ............................................................................................... 3-2
Understanding Display Features........................................................................ 3-7
Measurement Connections ................................................................................ 3-10
4 Using the Hardkeys.......................................................................................... 4-1
Introduction ........................................................................................................ 4-1
Using Display Mode Softkeys ............................................................................ 4-1
Using Frequency Softkeys ................................................................................. 4-2
Save/Print Softkeys............................................................................................ 4-3

Contents
(continued)
Min Max Softkeys .............................................................................................. 4-4
Range Softkeys ................................................................................................. 4-5
Touch Hold ........................................................................................................ 4-6
5 Using View and Trend Display Modes........................................................... 5-1
Introduction........................................................................................................ 5-1
View Display Mode Basics ................................................................................ 5-1
Using View Mode Softkeys................................................................................ 5-2
Setting Up the Time Base.................................................................................. 5-3
Setting Up the Trigger ....................................................................................... 5-4
Choosing the Acquisition Type .......................................................................... 5-7
Trend Display Mode Basics............................................................................... 5-10
Using Trend Mode Softkeys .............................................................................. 5-10
6 Using Save, Recall, Print, and Set Up............................................................ 6-1
Introduction........................................................................................................ 6-1
Using the Save/Print Softkeys ........................................................................... 6-1
Saving Screen and Configuration...................................................................... 6-3
Recalling Screen or Configuration..................................................................... 6-4
Previewing Screen or Configuration.................................................................................. 6-4
Saving the Present Configuration...................................................................... 6-5
Printing............................................................................................................... 6-6
Changing the Configuration............................................................................... 6-8
7 User Maintenance............................................................................................ 7-1
Introduction........................................................................................................ 7-1

867B/863
Users Manual
iv
Cleaning ............................................................................................................. 7-1
Testing the Fuses............................................................................................... 7-1
Replacing the Batteries ...................................................................................... 7-2
Replacing the 440 mA Fuses ............................................................................. 7-2
Replacing the 11A (High Energy) Fuse.............................................................. 7-2
Reassembly ....................................................................................................... 7-3
Operational Test................................................................................................. 7-5
Self Test ............................................................................................................. 7-5
If Your GMM Does Not Work ............................................................................. 7-8
8 Specifications................................................................................................... 8-1
General Specifications ....................................................................................... 8-1

v
List of Tables
Table Title Page
1-1. Introducing Your Graphical Multimeter .................................................................. 1-2
1-2. A Practice Session................................................................................................. 1-6
1-3. Functions and Display Modes................................................................................ 1-11
2-1. Common Combo/Meter Mode Softkeys................................................................. 2-2
2-2. Component Testing (Capacitance) ........................................................................ 2-18
3-1. General Features ................................................................................................... 3-4
3-2. Upper Status Line .................................................................................................. 3-9
6-1. Set Up Selections .................................................................................................. 6-9

867B/863
Users Manual
vi

vii
List of Figures
Figure Title Page
1-1. Graphical Multimeter Features............................................................................... 1-1
1-2. RS232 and AC Power Connections....................................................................... 1-1
1-3. Test Leads and Measurement Connections .......................................................... 1-4
1-4. Using the Battery Eliminator .................................................................................. 1-5
1-5. Volts and Amps Measurement Map....................................................................... 1-12
1-6. Ohms, Conductance, Diode Test, Capacitance Map............................................. 1-13
1-7. Logic Test, Component Test, and Set Up.............................................................. 1-14
1-8. Hz Min Max, and Range Map ................................................................................ 1-14
2-1. AC Volts Measurements ........................................................................................ 2-4
2-2. DC Volts Measurements ........................................................................................ 2-6
2-3. Millivolt Measurements .......................................................................................... 2-8
2-4. Ohms, Continuity, and Conductance Measurements ............................................ 2-9
2-5. Diode Test and Capacitance Measurements......................................................... 2-11
2-6. Amps Measurements ............................................................................................. 2-13

867B/863
Users Manual
viii
2-7. Milliamp and Microamp Measurements.................................................................. 2-15
2-8. Component Testing ................................................................................................ 2-17
2-9. Component Test Patterns....................................................................................... 2-19
2-10. LOGIC Testing........................................................................................................ 2-20
2-11. Frequency Measurements...................................................................................... 2-22
3-1. General Features.................................................................................................... 3-3
3-2. Input Connections Screen ...................................................................................... 3-7
3-3. Display Features..................................................................................................... 3-8
3-4. General Measurement Connections....................................................................... 3-10
3-5. Amps Measurement Connections .......................................................................... 3-10
3-6. Milliamp and Microamp Connections...................................................................... 3-11
3-7. LOGIC Testing Connections................................................................................... 3-11
5-1. Time Base Selection............................................................................................... 5-3
5-2. Trigger Icons........................................................................................................... 5-5
5-3. Setting Up the Trigger ............................................................................................ 5-6
5-4. Viewable Time Divisions (Single Shot and Glitch Capture).................................... 5-9
6-1. Freeze (Print/Save) Softkey Map ........................................................................... 6-2
6-2. PC and Printer Connections ................................................................................... 6-7
7-1. Replacing the 11A (High Energy) Fuse .................................................................. 7-4
7-2. Replacing the Batteries .......................................................................................... 7-6
7-3. Replacing the 440 mA Fuse ................................................................................... 7-7

ix
m
Safety
In this manual, the word “WARNING” identifies
conditions and actions that pose hazard(s) to the
user. The word “CAUTION” refers to conditions
and/or actions that can damage the instrument. Use
of the instrument in a manner not specified may im-
pair safety. Read the following safety information
carefully before attempting to operate or service the
instrument.
• Avoid working alone.
• Disconnect the power and discharge high-
voltage capacitors before testing in Ohms
Continuity, Diode, Capacitance, and COMPO-
NENT Test.
• Inspect the test leads for damaged insulation or
exposed metal. Check test lead continuity.
Damaged leads should be replaced.
• Do not use the GMM if it looks damaged.
• Select the proper function and range for your
measurement.
• Use caution when working above 60V dc or 30V
ac rms. Such voltages pose a shock hazard.
• When using the probes, keep your fingers away
from probe contacts. Keep your fingers behind
the finger guards on the probes.
• Place test leads in proper input terminals.
• Disconnect the live test lead before disconnect-
ing the common test lead.
• When measuring current, turn the power off to
the circuit being tested before connecting the
GMM test tool in that circuit.
• Check GMM test tool fuses before measuring
current transformer secondary or motor winding
current. (See Testing the Fuses in the User
Maintenance chapter.) An open fuse may allow
high voltage buildup, which is potentially haz-
ardous.
• Use clamp-on probes (current clamps) when
measuring currents exceeding 10A.

867B/863
Users Manual
x
m
WARNING
m
Hazardous voltages are present on
the External Trigger input terminal
and any attached probe when the
GMM is measuring voltages greater
than 30V rms or 60V dc.
Replacing Fuses
The following fuses should be used:
• F 440 mA, 1000V, Minimum Interrupt Rating
10,000A.
• F 11A, 1000V, Minimum Interrupt Rating
17,000A.
Warning
Use of fuses with voltage ratings
below 1000V reduces protection.
Do not replace the 440 mA 1000V
fuse with a 4/10A 600V fuse.
$WARNING risk of electric shock.
mCAUTION see explanation in manual.
sEquipment protected throughout by DOUBLE
INSULATION or REINFORCED INSULA-
TION.
m
Overload Protection
Voltage or Current Input: 1000V
Surge Protection: 8 kV
Maximum Voltage Isolation to Ground: 1000V
Protection Levels: per IEC 1010-1; 1000V CAT III
(fixed distribution-level installations which can
experience peak voltage transients up to
8000V.)
Protection Class: II
s

1-1
Chapter 1
A Quick Tour
Note
The NiCd battery pack must be fully charged before using the 867B. See Chapter 3.
Your Graphical Multimeter
A COM
V mA/ A EXT TRIG
A
COMPONENT
TEST
SET UP
mV
V
V
OFF
LOGIC
HiZ
FREEZE
DISPLAY
MODE
SAVE
PRINT
MIN
MAX RANGE
WAKE UP
HZ
TOUCH
HOLD
12345
mA
A
B
A
C
E
D
rita0091.eps
Figure 1-1. Graphical Multimeter Features
F
G
rita0092.eps
Figure 1-2. RS232 and AC Power Connections

867B/863
Users Manual
1-2
Table 1-1. Introducing Your Graphical Multimeter
ITEM SYMBOL DESCRIPTION
Aj
W
TURN THE GMM ON BY ROTATING THE SELECTOR TO ANY FUNCTION. Turn the rotary
selector to the AC Volts (
v
)position. The input connections screen appears for a few seconds,
then the screen sets up for this function, and you are ready to begin. You can toggle the backlight
power level (Model 867B only) by pressing W. Also note that the screen goes dark if you do not
change any controls for about 20 minutes and the GMM is on battery power; pressing Wwakes
up the screen (all models.)
BCombo
Meter
View
Trend
THE SCREEN. In AC Volts, the initial screen presents a primary display of large digits, a
secondary display of smaller digits, and a graphical window showing either a waveform or an
analog NeedleGraph™representation of the primary display. In addition, the upper screen line
displays status information. The bottom screen line (immediately above the softkey labels) shows
the display mode, range, and other information. For example, “Combo” appears on this line if a
waveform appears in the graphical window: the GMM is in Combo Mode.
C1
2
3
4
5
THE SOFTKEYS. Most control settings (selector change or key press) change the softkey labels
along the bottom of the screen. These labels define the present uses for the five blue keys that
are positioned immediately below the screen. Together, the labels and the keys form a set of
Softkeys. These changing softkey definitions allow direct access to a wealth of GMM capabilities.
Refer to Figures 1-6, 1-7, and 1-8 at the end of this chapter for a roadmap to softkey use.

A Quick Tour
Your Graphical Multimeter
1
1-3
Table 1-1. Introducing Your Graphical Multimeter (cont)
ITEM SYMBOL DESCRIPTION
Dd
F
P
M
r
H
THE HARDKEYS. Hardkeys appear immediately below the softkeys. Hardkeys perform the same
operations in all functions. Pressing Wwakes up the screen from Sleep Mode (all models) and toggles
the backlight power level on Model 867B. Although hardkeys can generally be pressed at any time,
certain feature combinations are not allowed. The GMM test tool rejects any hardkey press that is not
allowed; a long beep sounds. Chapter 4 explains each hardkey in detail.
EV
C
X
A
a
MEASUREMENT CONNECTIONS. Review the input connection scheme now only for
familiarization: no actual connections are necessary during the Quick Tour. Volts, Ohms,
Continuity, Conductance, Diode Test, Capacitance, and Component Test measurements use
Vfor the Red lead. Amps measurements use Afor the Red lead. mAμA measurements
use afor the Red lead. LOGIC Test measurements use Xfor the Red lead. All
functions use Cfor the Black lead. Refer to Figure 1-3 for TL70A test lead connection
views.
FBLINE POWER OR BATTERY POWER. You can power the GMM with batteries or from ac line
power through the Battery Eliminator. New alkaline (AA) cells provide a minimum of 4 hours
operation. A fully charged BP7217 NiCd battery pack typically provides a minimum of 8 hours
operation. The battery eliminator recharges the NiCd battery pack on Model 867B. Refer to
Figure 1-4.
GRS232 SERIAL PC OR PRINTER CONNECTION. Your GMM can use an optional optical serial
interface cable to communicate with a PC or printer. Refer to Chapter 6.

867B/863
Users Manual
1-4
TL70A
Test Leads
rita0740.eps
Figure 1-3. Test Leads and Measurement Connections

A Quick Tour
Your Graphical Multimeter
1
1-5
Europe PN 942602 US PN 942599
JP PN 942610
UK PN 942607AU NZ
PN 944595
rita0770.eps
Figure 1-4. Using the Battery Eliminator

867B/863
Users Manual
1-6
Table 1-2. A Practice Session
STEP ACTION DESCRIPTION
1dCHANGE THE DISPLAY MODE
With the GMM still in AC Volts, press first d, then 3to change the display mode. The
screen changes to the View Mode, where the entire screen is used for displaying a waveform.
You can repeat this procedure to select any of the display modes available in AC Volts (Combo,
Meter, View, and Trend.) Refer to Table 1-3 for an overview of display modes available in each
function. Examples of all display modes (Combo, Meter, View, Trend, Logic Test, Auto Diode
Test, Component Test, and Sleep) follow this table. Along with the flexibility provided by multiple
softkey definitions, display modes increase the versatility of your GMM considerably.
Many operations activated in one display mode are retained when you select a new mode. For
example, “Rel”, “dB”, Min Max, range, and frequency measurement type are retained.
2JCHANGE THE FUNCTION
Rotate the selector to DC Volts (E). Observe that the display shifts back to Combo Display Mode.
(This is the default mode, as established on the screen you see when you turn the selector to
SET UP.)
31USE THE SOFTKEYS
With DC Volts and Combo Mode still active, you can use the DC Volts Softkeys. For example,
press 1to activate “Rel”: difference readings only are now displayed. Press 1 again to
deactivate “Rel”. Explore all five softkeys in this fashion. Press a key first to activate a selection
(label highlighted) and second to disable the selection.
