Flymo GARDENVAC 220 TURBO User manual

GB
IMPORTANT INFORMATION
Read before use and retain for future
reference
D
WICHTIGE INFORMATION
Bitte vor dem Benutzen des Gerätes
durchlesen und gut aufbewahren
F
RENSEIGNEMENTS IMPORTANTS
A lire avant usage et à conserver pour
référence ultérieure
NL
BELANGRIJKE INFORMATIE
Leest u deze informatie voor het gebruik en
bewaar ze voor toekomstige raadpleging
N
VIKTIG INFORMASJON
Les bruksanvisningen n ye f r bruk og
oppbevar den for senere bruk
S
VIKTIG INFORMATION
Läs anvisningarna före användningen och
spara dem för framtida behov
DK
VIGTIGE OPLYSNINGER
Du b r læse brugsanvisningen f r brug og
gemme til senere henvisning
E
INFORMACIÓN IMPORTANTE
Léase antes de utilizar y consérvela como
referencia en el futuro
P
INFORMAÇÕES IMPORTANTES
Leia antes de utilizar e guarde para consulta
futura
I
INFORMAZIONI IMPORTANTI
Leggere prima dell’uso e conservare per
ulteriore consultazione
SF
TÄRKEÄÄ TIETOA
Lue tämä ennen käyttöä ja säilytä myöhempää
tarvetta varten
SK
Záruka na tento produkt nebude uznaná v
prípade porúch spôsobených nesprávnou
obsluhou alebo používaním výrobku na iný
účel alebo iným spôsobom, ako je uvedené
Pred začatím práce si prosím dôkladne
prečítajte návod na obsluhu a tento si aj pre
prípad potreby uschovajte
SL
Garancija ne velja ob nepravilni uporabi
proizvoda in/ali ob uporabi za drugi namen
kot je izdelan Prosimo, da pred uporabo,
preverite pazljivo navodila za obratovanje in
jih shranite za kasnejšo rabo
HU
Jótállást vállalni csak rendeltetésszerűen
használatba vett gépekre tudunk Kérjük,
hogy a gép használatba vétele elött
gondosan olvassa el a kezelési utasításokat
PL
Gwarancja traci ważność w przypadku
używania urządzenia do celów innych niż
wymienione w instrukcji obsługi Prosimy o
uważne przeczytanie instrukcji oraz o
stosowanie się do zaleceń i wskazówek w
niej zawartych
CZ
Záruka se nebude vztahovat na závady
způsobené nesprávným používáním, nebo
jestliže bude výrobek použit pro jiné účely
než pro jaké byl vyroben, nebo také jinak
než je uvedeno v návodu k obsluze Tento
návod si přečtěte, prosím, velmi pozorně a
uchovejte jej pro možné budoucí odkazy

A B
C D
1
2
E
3
4
2
F
G H
J K
1
1
1

L
✔✕
R1 R2Q
R3 R4 R5 R6
M N P
1 2 3 4

GB - CONTENTS
1. Trigger
2. 2 Handle Knobs
3. 2 Handle Bolts
4. Air inlets
5. Debris Bag Frame
6. Debris Bag
7. Cutting Lines
8. Instruction Manual
9. Adjustable Shoulder
Harness
10. Nozzle
11. Mode Indicator
12. Adjustable Handle
13. Warning Label
14. Product Rating Label
15. Wheel Assembly (if
applicable)
D - INHALT
1. Drücker
2. 2 Griffknöpfe
3. 2 Griffbolzen
4. Lufteinlässe
5. Auffangsackrahmen
6. Auffangsack
7. Schnüre
8. Bedienungsanweisung
9. Einstellbarer Schultergurt
10. Düse
11. Betriebsart-Anzeige
12. Einstellbarer Griff
13. Warnetikett
14. Produkttypenschild
15. Laufrad (wenn
anwendbar)
F - TABLE DES MATIÈRES
1. Gâchette
2. 2 boutons de poignée
3. 2 boulons de poignée
4. Prises d’air
5. Porte-sac de ramassage
6. Sac de ramassage
7. Fils de coupe
8. Manuel d’instructions
9. Bandoulière réglable
10. Buse
11. Bouton de mode
12. Poignée réglable
13. Etiquette d’avertissement
14. Plaquette des
Caractéristiques du
Produit
15. Ensemble route (si
applicable)
NL - INHOUD
1. Trekker
2. 2 handgreepknoppen
3. 2 handgreepbouten
4. Luchtinlaatopeningen
5. Frame van afvalzak
6. Afvalzak
7. Snijdraden
8. Handleiding
9. Afstelbaar
schouderbanden
10. Mondstuk
11. Standindicatie
12. Afstelbare handgreep
13. Waarschuwingsetiket
14. Product-informatielabel
15. Wiel (wanneer
toepasselijk)
N - INNHOLD
1. Avtrekker (Utl ser)
2. 2 håndtaksknotter (2
runde håndtak)
3. 2 håndtaksbolter
4. Luftinntak
5. Avfallsposens ramme
6. Avfallspose
7. Skjœresnorer
8. Bruksanvisning
9. Justerbar skuldersele
10. Tut
11. Modusindikator
12. Justerbart håndtak
13. Advarselsetikett
14. Produktmerking
15. Hjul-monteringsett (hvis
anvendelig)
SF - SISÄLTÖ
1. Liipasin
2. 2 kahvan nuppia
3. 2 kahvan pulttia
4. Ilmanottoaukot
5. Roskapussin kehikko
6. Roskapussi
7. Leikkauslangat
8. Käyttöopas
9. Säädettävät olkaremmit
10. Suutin
11. Tilan ilmaisin
12. Säädettävä kahva
13. Varoitusnimike
14. Ruohonleikkurin arvokilpi
15. Pyöräkokoonpano (tokko
soveltuva)
S - INNEHÅLL
1. Utlösare
2. 2 handtagsknoppar
3. 2 handtagsbultar
4. Luftintag
5. Ram för
skräpuppsamlingspåse
6. Skräpuppsamlingspåse
7. Skärlinor
8. Bruksanvisning
9. Justerbar axelsele
10. Munstycke
11. Indikator för arbetssätt
12. Justerbart handtag
13. Varningsetikett
14. Produktmärkning
15. Hjulenhet (om
användbar)
DK - INDHOLD
1. Udl ser
2. 2 håndtagsgreb
3. 2 håndtagsbolte
4. Luftindtag
5. Græsposeramme
6. Græspose
7. Skæretråde
8. Brugsvejledning
9. Justerbar skuldersele
10. Dyse
11. Tilstandsindikator
12. Justerbart håndtag
13. Advarselsmœrkat
14. Produktets mærkeskilt
15. Hjulmontering (selv om
anvendelig)
E - CONTENIDO
1. Disparador
2. 2 pomos de tirar
3. 2 pernos del mango
4. Entradas de aire
5. Soporte de la bolsa de
desechos
6. Bolsa de desechos
7. Cordel de corte
8. Manual de Instrucciones
9. Correaje ajustable del
hombro
10. Boquilla
11. Indicador del modo
12. Mango ajustable
13. Etiqueta de Advertencia
14. Placa de Características
del Producto
15. Ensemble de ruedas (si
aplicable)
P - LEGENDA
1. Gatilho
2. 2 Botões da Pega
3. 2 Parafusos da Pega
4. Entradas de Ar
5. Armação do Saco de
Detritos
6. Saco de Detritos
7. Linhas de Corte
8. Manual de Instruções
9. Alça de Ombro Ajustável
10. Bocal
11. Indicador de Modo
12. Pega Ajustável
13. Etiqueta de Aviso
14. Rótulo de Avaliação do
Produto
15. Kit de roda (se aplicável)
I - NOMENCLATURA
1. Pulsante
2. 2 manopole impugnatura
3. 2 bulloni impugnatura
4. Bocchette aria
5. Telaio sacco raccolta
6. Sacco raccolta
7. Fili di taglio
8. Manuale di istruzioni
9. Tracolla regolabile
10. Ugello
11. Indicatore modalità
12. Impugnatura regolabile
13. Etichetta di pericolo
14. Etichetta dati del prodotto
15. Ruota (se applicabile)
HU - TARTALOMJEGYZÉK
1. Kapcsoló
2. 2db fogantyú
3. 2db csavar kézikarhoz
4. Leveg befúvó szerkezetek
5. Keret hulladéktároló
zsákhoz
6. Hulladéktároló zsák
7. Vágózsinórok
8. Kezelési útmutató
9. Igazítható vállszíj
10. Szívófej
11. Üzemmód-jelz
12. Igazítható kar
13. Figgelmeztetµ címke
14. Termékmin sít címke
15. Kerék-összeállítás
(feltéve, hogy
alkalmazható)
PL - ZAWARTOSC
KARTONU
1. Starter
2. 2 gałki uchwytu
3. 2 śruby uchwytu
4. Wloty powietrza
5. Rama worka na odpady
6. Worek na ścinki
7. Linki tnące
8. Instrukcja Obsługi
9. Regulowana uprząż na
ramiona
10. Dysza
11. Wskaźnik trybu
12. Regulowana rączka
13. Znaki bezpieczeństwa
14. Tabliczka znamionowa
15. Koła (jeśli stosowny)
CZ - POPIS STROJE
1. Spouš<
2. 2 Tlačítka na rukojeti
3. 2 Šrouby na rukojeti
4. Vstupy vzduchu
5. Rám vaku na odpad
6. Vak na odpad
7. Řezná lanka
8. Návod k obsluze
9. Nastavitelný ramenní
popruh
10. Tryska
11. Ukazatel režimu
12. Nastavitelná rukoje<
13. Výstražný štítek
14. Typový štĺtek výrobku
15. Sestava kol (li použitelný)
SK - OBSAH
1. Spúš<
2. 2 skrutky na rúčke
3. 2 závity na rúčke
4. Vzduchové vstupy
5. Rám na odpadový vak
6. Odpadový vak
7. Rezné lanká
8. Príručka
9. NastaviteFný pás na
plece
10. Koncovka
11. Indikátor funkcie
12. NastaviteFná rúčka
13. Varovný štítok
14. Prístrojový štítok
15. Kolesová súprava
SL - VSEBINA
1. Sprožilec
2. 2 gumba za ročaj
3. 2 vijaka za ročaj
4. zračni vhod
5. okvir za vrečo z odpadki
6. vreča z odpadki
7. rezalna nit
8. Priročnik
9. Prilagodljiv pas za
ramena
10. ustnik
11. kazalec načina delovanja
12. prilagodljiv ročaj
13. Opozorilna Oznaka
14. Napisna Tablica
15. Sestavnia kolesa (če
prosilec)

1
(GB) CARTON CONTENTS
(D) KARTONINHALT
(F) CONTENU DU CARTON
(NL) INHOUD
(N) KARTONGEN
INNEHOLDER
(SF) PAKETIN SISÄLTÖ
(S) FÖRPACKNINGENS
INNEHÅLL
(DK) KARTONINDHOLD
(E) CONTENIDO DEL
CARTON
(P) LEGENDAS DOS
DESENHOS
(I) CONTENUTO
(HU) A DOBOZ TARTALMA
(PL) ZAWARTOŚĆ KARTONU
(CZ) OBSAH KRABICE
(SK) OBSAH BALENIA
(SL) VSEBINA ŠKATLE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

SAFETY PRECAUTIONS
Explanation of Symbols on the Gardenvac
Warning
Read the user instructions
carefully to make sure you
understand all the controls and
what they do.
Do not operate in the rain or leave
the Gardenvac outdoors while
raining.
BEFORE USING YOUR GARDENVAC FOR
THE FIRST TIME
Assemble debris bag to bag
frame.
EVERY TIME YOU USE YOUR GARDENVAC
Switch off and disconnect from the
mains electricity supply BEFORE
fitting cutting line to cutting head &
clipping into place and BEFORE
REMOVING cutting line.
Switch off and disconnect from the
mains electricity supply BEFORE
FITTING fully assembled debris
bag to product and BEFORE
REMOVING fully assembled
debris bag from product.
NEVER CONNECT THE
PRODUCT TO THE MAINS
ELECTRICITY SUPPLY UNTIL
THE FULLY ASSEMBLED
DEBRIS BAG IS FITTED
CORRECTLY
General
1. Never allow children or people unfamiliar
with these instructions to use the Gardenvac.
Local regulations may restrict the age of the
operator.
2. Only use the Gardenvac in the manner and
for the functions described in these
instructions.
3. Never operate the Gardenvac when you are
tired, ill or under the influence of alcohol,
drugs or medicine.
4. The operator or user is responsible for
accidents or hazards occurring to other
people or their property.
Electrical
1. The use of a Residual Current Device (R.C.D.)
with a tripping current of not more than 30mA
is recommended. Even with a R.C.D. installed
100% safety cannot be guaranteed and safe
working practice must be followed at all times.
Check your R.C.D. every time you use it.
2. Before use, examine cable for damage, replace
it if there are signs of damage or ageing.
3. Do not use the Gardenvac if the electric
cables are damaged or worn.
4. Immediately disconnect from the mains
electricity supply if the cable is cut, or the
insulation is damaged. Do not touch the
electric cable until the electrical supply has
been disconnected. Do not repair a cut or
damaged cable. Replace it with a new one.
5. Your electric cable must be uncoiled, coiled
cables can overheat and reduce the
efficiency of the Gardenvac.
6. Do not pull cable around sharp objects.
7. Always switch off at the mains before
disconnecting any plug, cable connector or
extension cable.
8. Switch off, remove plug from mains and
examine electric supply cable for damage or
ageing beforewinding cable for storage. Do
not repair a damaged cable, replace it with a
new one. Use only Flymo replacement cable.
9. Always wind cable carefully, avoiding
kinking.
10. Never carry the product by the cable.
11. Never pull on the cable to disconnect any of
the plugs.
12. Use only on AC mains supply voltage shown
on the product rating label.
13. Our products are double insulated to
EN60335. Under no circumstance should an
earth be connected to any part of the
product.
If not used properly this Gardenvac can be dangerous.
The warnings and safety instructions must be followed to ensure reasonable safety
and efficiency in using this product. The operator is responsible for following the
warnings and instructions in this manual and on the product.
ENGLISH - 1
1
2

SAFETY PRECAUTIONS
Preparation
1. Always wear suitable clothing, gloves, and
stout shoes.
2. The use of eye protection is recommended.
3. The use of ear protection is recommended.
4. To prevent dust irritation, the wearing of a
face mask is recommended.
5. Do not wear loose clothing or jewellery that
can be drawn into the air inlet.
6. Do not wear clothing with attachments, i.e.
toggles or drawstrings that can be drawn into
the air inlet.
7. Inspect your Gardenvac before each use,
especially the parts of the cutting head.
Replace cutting line if worn or damaged.
8. Do not use if any part is damaged or broken
or if any of the screws are loose. Have it
repaired by an authorised repairer.
9. Always check your Gardenvac is in a safe
operating condition before use.
Use
1. Use the Gardenvac only in daylight or good
artificial light.
2. Do not use the Gardenvac when it is raining
or in damp and wet areas.
3. Never use the Gardenvac in or near water or
ponds.
4. Know how to stop the Gardenvac quickly in
an emergency.
5. On slopes, be extra careful of your footing
and wear non-slip footwear.
6. Never pick up or carry the Gardenvac by the
cable.
7. Keep children, pets and bystanders at a safe
distance when using your Gardenvac.
8. Keep long hair away from air inlet.
9. Keep all inlets clear of debris.
10. Always remain alert.
11. Do not attempt to use your Gardenvac
without the fully assembled debris bag fitted.
12. Never blow debris in the direction of
bystanders.
13. Do not overreach. Keep proper footing and
balance at all times.
14. The cutting head and cutting line continue to
rotate after your Gardenvac has been
switched off.
15. Remove the plug from the mains :-
- before removing or replacing cutting line;
- before removing or replacing fully assembled
debris bag;
- before leaving the Gardenvac unattended for
any period;
- before clearing a blockage;
- before checking, cleaning or working on the
appliance;
- if the Gardenvac starts to vibrate abnormally.
Check immediately. Excessive vibration can
cause injury.
Maintenance and storage
1. Keep all nuts, bolts and screws tight to be
sure the Gardenvac is in a safe working
condition.
2. Replace worn or damaged parts for safety.
3. Always store the product in a dry place
ensuring the cable is not likely to be
damaged on sharp edges etc.
4. Inspect the collection bag regularly. If the
collection bag becomes worn or damaged,
replace.
ASSEMBLY INSTRUCTIONS
To Attach Debris Bag to Bag Frame
With bag frame on the ground:-
1. Fit first two holes on the plastic trim of the
debris bag to the first two location points on
the front of the bag frame (where debris fin
is attached). See Fig. A
2. Fit next hole on the plastic trim to next
location point on bag frame. See Fig. B
3. ...until all holes on the plastic trim of the
debris bag are securely located to bag
frame. See Fig C
• ENSURE THE DEBRIS BAG IS FITTED
SECURELY TO THE BAG FRAME.
To Fit the Cutting Line to the Cutting Head
(D)
• Switch off and disconnect from the mains
electricity supply BEFORE removing or
fitting the cutting line.
• Handle the cutting line with care - sharp
edges can cause injury.
1. Place the cutting line into the slot in the
cutting head and click into place as
illustrated in Figure D.
• Ensure the cutting line is correctly
located.
•ONLY USE CUTTING LINE SPECIFIED FOR THIS
PRODUCT. SEE PRODUCT RATING LABEL FOR
MODEL DETAILS
ENGLISH - 2

ENGLISH - 3
ASSEMBLY INSRUCTIONS
• Switch off and disconnect from the mains
electricity supply BEFORE REMOVING OR
REPLACING the fully assembled debris
bag.
• The cutting head and cutting line
continue to rotate after your Gardenvac
has been switched off.
To Fit Assembled Debris Bag To Product (E)
IMPORTANT Do not squeeze the trigger
when fitting the debris bag (E1)
1. Ensure debris fin is horizontal (E2) as
illustrated in fig E.
2. Locate bag frame into clip on the underside
of product. (E3).
3. Lift handle towards product until bag latch
locates and click into place (E4).
To Remove Debris Bag From Product (F)
1. Gently press bag latch (F1) down. See fig F.
2. Lower handle of bag frame away from
product.
3. Move bag frame forward.
Fitting the Handle Bolt (G)
1. Place handle bolt into the location slot on the
product and slide into place.
See Fig. G.
2. Repeat on the other side.
Fitting the Handle (H)
1. Locate handle onto handle bolts on each
side of the product.
2. Secure handle by turning handle knobs
clockwise. See Fig H.
3. The handle can be adjusted by turning
handle knobs 3 full turns anti-clockwise,
moving handle to position required and
re-securing handle as described in 2.
Fitting The Shoulder Harness (J), (K) & (L).
1. Thread strap through the slots in the handle
See fig J.
2. Thread strap through the buckle. See fig K1.
HOW TO USE
WARNING The use of eye protection is
recommended. The use of ear protection is
recommended. To prevent dust irritation, the
wearing of a face-mask is recommended.
Never point your Gardenvac at bystanders.
Do not use your Gardenvac in the rain. Do
not leave your Gardenvac outdoors while it is
raining.
IMPORTANT!: YOUR GARDENVAC WILL NOT
OPERATE UNTIL THE FULLY ASSEMBLED
DEBRIS BAG AND FRAME ARE PROPERLY
FITTED.
BEFORE USE: ENSURE THERE ARE NO GAPS
BETWEEN THE DEBRIS BAG AND THE PRODUCT.
•The Gardenvac has 3 modes of operation.
•These can be selected by moving the mode
indicator to adjust the nozzle position for
blow, vacuum or jet vacuum mode.
•In vacuum and jet vacuum modes the
Gardenvac will shred leaves etc.
M - BLOW
Position 1 - Blow Mode
The Gardenvac will blow debris from patios,
paths, driveways, lawns, bushes, borders etc.
Using As A Blower
1. Select position 1 on the mode indicator. See
fig M.
2. Point nozzle towards the ground.
3. To start squeeze trigger.
4. Stand back from debris to be cleared.
5. Point nozzle towards the debris and slowly
approach.
6. To stop release trigger.
N- VACUUM
Position 2 - Vacuum Mode
In this position your Gardenvac will pick up
leaves, paper, rubbish, cans etc.
IMPORTANT: REMOVE NYLON LINE BEFORE
VACUUMING CANS
Using As A Vacuum
1. Select position 2 on the mode indicator. See
fig N.
2. Position nozzle slightly above the debris,
squeeze the trigger and move slowly back
and forth.
3. Do not force the nozzle into the debris as
this will impair performance.
4. To stop release the trigger.
P - JET VACUUM
Position 3 - Jet Vacuum Mode
This position is intended to be used to collect
debris which is damp or stubborn. It directs
a small jet of air towards the ground which
will loosen stubborn material.
Using As A Jet Vacuum
1. Select position 3 on the mode indicator. See
fig P.
2. Position the nozzle above and slightly
forward of the debris and squeeze the
trigger.
3. Slowly move the nozzle back over the
debris. This allows a jet of air to lift the
debris from the ground.
4. To stop release the trigger.

ENGLISH - 4
EMPTYING YOUR GARDENVAC
• Switch off and disconnect from the mains
electricity supply BEFORE REMOVING OR
REPLACING the fully assembled debris
bag.
Emptying Your Gardenvac
1. Remove debris bag as described on page 3.
2. Empty debris bag holding the moulded
handle at the top of the bag and the fabric
handle at the bottom of the bag. See fig Q.
DO NOT PLACE HANDS IN BAG WHEN EMPTYING,
SHARP DEBRIS CAN CAUSE INJURY
3. Flip the debris fin back into place before re-
fitting as described on page 3.
CARING FOR YOUR GARDENVAC
WARNING
Never use water for cleaning your
Gardenvac, use only a dry cloth. Do not
clean with chemicals or solvents, some can
destroy critical plastic parts.
After Using Your Gardenvac (R1, 2, 3 & 4)
1. Switch off and disconnect from the mains
electricity supply before cleaning your
Gardenvac.
2. Always empty the debris bag.
3. Take extra care to clean around the cutting
area, the cutting head and the collection
chute (R1).
• Take care when cleaning around the
cutting line area - sharp edges can cause
injury.
4. Inspect the cutting line and replace if worn or
damaged
5. Using a soft brush remove debris from all air
inlets. See fig R2.
6. Remove dirt and debris from debris fin.with a
suitable tool. See fig R3.
7. Wipe over your Gardenvac with a soft dry
cloth. See fig R4.
Replacing the Cutting Line (R5 & 6)
• Switch off and disconnect from the mains
electricity supply before replacing the
cutting line
• Handle the cutting line with care - sharp
edges can cause injury.
1. Remove debris bag from product. See Page
3.
2. Remove cutting line, See Fig R5, and discard
safely.
3. If the cutting line becomes broken during use
- use a suitable tool to lever the line out of
location. See Fig R6.
4. Place the cutting line into the slot in the
cutting head. Ensure the cutting line is
correctly located. See Page 2.
5. Re-fit debris bag to product. See Page 3.
Storing Your Gardenvac
Always store the product in a dry place ensuring
the cable is not likely to be damaged on sharp
edges etc.
FAULT FINDING HINTS
Fails To Operate
1. Is the power turned on?
2. Is the fully assembled debris bag correctly
fitted to the product?
3. Check the fuse in the plug, if blown replace.
4. Fuse continues to blow?
Immediately disconnect from the mains
electricity supply and consult your local
approved Service Centre.
Poor Blowing
1. The air inlets are blocked, clean all air inlets.
2. Mode indicator not in the right position?
3. If poor blowing persists?
Immediately disconnect from the mains
electricity supply and consult your local
approved Service Centre.
Poor Vacuum/Jet Vacuum
1. The air inlets are blocked, clean all air inlets.
2. Mode indicator not in the right position?
3. If poor vacuuming persists?
Immediately disconnect from the mains
electricity supply and consult your local
approved Service Centre.
Excessive Vibration
1. The cutting line is damaged - replace with
new cutting line.
2. Ensure the fully assembled debris bag is
correctly fitted to the product.
3. If excessive vibration persists?
Immediately disconnect from the mains
electricity supply and consult your local
approved Service Centre.
Poor Shredding
1. The cutting line is damaged - replace with
new cutting line.
2. TO PROLONG CUTTING LINE LIFE
The Gardenvac has been designed to shred
leaves. If collecting large amounts of any
other debris - remove the cutting line.

ENGLISH - 5
SERVICE RECOMMENDATIONS
• Your product is uniquely identified by a silver and black product rating label.
• We strongly recommend that your product is serviced at least every twelve months, more
often in a professional application.
GUARANTEE AND GUARANTEE POLICY
If any part is found to be defective due to faulty
manufacture within two years of original
purchase, Electrolux Outdoor Products, through
its Authorised Service Repairers will effect the
repair or replacement to the customer free of
charge providing:
(a) The fault is reported directly to the
Authorised Repairer.
(b) Proof of purchase is provided.
(c) The fault is not caused by misuse, neglect or
faulty adjustment by the user.
(d) The failure has not occurred through fair
wear and tear.
(e) The machine has not been serviced or
repaired, taken apart or tampered with by
any person not authorised by Electrolux
Outdoor Products.
(f) The machine has not been used for hire.
(g) The machine is owned by the original
purchaser.
(h) The machine has not been used outside of
the country for which it was specified.
(i) The machine has not been used
commercially.
* This guarantee is additional to, and in no
way diminishes the customers statutory
rights.
Failures due to the following are not covered,
therefore it is important that you read the
instructions contained in this Operator's Manual
and understand how to operate and maintain
your machine:
Failures not covered by guarantee
* Replacing Cutting Line.
* Failures as a result of not reporting an initial
fault.
* Failures as a result of sudden impact.
* Failures as a result of not using the product
in accordance with the instructions and
recommendations contained in this
Operator's Manual.
* Machines used for hire are not covered by
this guarantee.
* The following items listed are considered as
wearing parts and their life is dependent on
regular maintenance and are, therefore not
normally subject to a valid warranty claim:
Cutting Line, Electric Mains cable, Debris
Bag.
*Caution!
Electrolux Outdoor Products does not accept
liability under the warranty for defects caused
in whole or part, directly or indirectly by the
fitting of replacement parts or additional parts
that are not either manufactured or approved
by Electrolux Outdoor Products, or by the
machine having been modified in any way
ENVIRONMENTAL INFORMATION
Electrolux Outdoor Products are manufactured
under an Environmental Management System
(ISO 14001) using, where practical, components
manufactured in the most environmentally
responsible manner, according to company
procedures, and with the potential for recycling
at the end of the products’ life.
• Packaging is recyclable and plastic
components have been labelled (where
practical) for categorised recycling.
• Awareness of the environment must be
considered when disposing of ‘end-of-life’
product.
• If necessary, contact your local authority for
disposal information.

I, the undersigned M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. Certify that the Lawnmower:-
Category........ Gardenvac
Make.............. Electrolux Outdoor
Products
Conforms to the specifications of Directive
2000/14/EEC
I, the undersigned M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP Certify that a sample of the above
product has been tested using directive
81/1051/EEC as a guide. The maximum A-
weighted sound pressure level recorded at
operator position under free field semi
anechoic chamber conditions was :-
I, the undersigned M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP Certify that a sample
of the above product has been tested
using ISO 5349 as a guide. The maximum
weighted root mean square value of
vibration recorded at operator’s hand
position was:-
Identification of Series......See Product Rating Label
Conformity Assesment Procedure....ANNEX VI
Notified Body....................I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Other Directives:-.............98/37/EEC, 89/336/EEC, 73/23/EEC
& applicable standards:-.EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Type............................................................................ A
Guaranteed sound power level................................... B
Measured Sound Power Level.................................... C
Level............................................................................ D
Value........................................................................... E
Nominal Air flow........................................................... F
Weight......................................................................... G
Ich, der Unterzeichner M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. bescheinige hiermit,
dass der Rasenmäher:-
Kategorie.... Laubsauger
Fabrikat....... Electrolux Outdoor Products
die Spezifikationen der Direktive
2000/14/EG erfüllt
Ich, der Unterzeichner M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5 6UP,
bescheinige hiermit, daß eine Probe des obigen
Produkts getestet wurde und dabei Direktive
81/1051/EWG als Richtschnur verwendet wurde.
Der maximale A-gewichtete Schalldruckpegel,
der an der Bedienerposition unter Freifeld-
Halbschalltot-Kammerbedingungen gemessen
wurde, betrug:-
Ich, der Unterzeichner M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5 6UP,
bescheinige hiermit, daß eine Probe des
obigen Produkts getestet wurde und dabei ISO
5349 als Richtschnur verwendet wurde. Der
maximale gewichtete Vibrationseffektivwert, der
an der Handposition des Bedieners gemessen
wurde, betrug:-
Identifizierung der reihe.....................Siehe Produkttypenschild
Konformitätsbestätigungsverfahren..ANNEX VI
Benachrichtigte Behörde.................I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Andere Direktiven-............................. 98/37/EEC, 89/336/EEC,
73/23/EEC
und Normen:-..................................... EN60555-2:1987, EN60555-
3:1987, EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Typ............................................................................... A
Garantierter Geräuschpegel........................................ B
Gemessener Geräuschpegel...................................... C
Höhe ........................................................................... D
Wert............................................................................. E
Nennluftstrom.............................................................. F
Gewicht....................................................................... G
Je soussigné M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. certifie que la tondeuse:-
Catégorie..... Gardenvac
Marque........ Electrolux Outdoor Products
est conforme aux spécifications de la
Directive 2000/14/EEC
Je soussigné M. Bowden, Electrolux Outdoor
Products, Aycliffe Industrial Park, NEWTON
AYCLIFFE, Co. Durham, DL5 6UP, Grande-
Bretagne, certifie qu’un échantillon du produit ci-
dessus a été essayé selon les indications de la
directive 81/1051/EEC. Le niveau maximum
pondéré de pression acoustique enregistré à la
position de l’opérateur en champ libre en
chambre demi-sourde était de:-
Je soussigné M. Bowden, Electrolux Outdoor
Products, Aycliffe Industrial Park, NEWTON
AYCLIFFE, Co. Durham, DL5 6UP, Grande-
Bretagne, certifie qu’un échantillon du produit
ci-dessus a été essayé selon les indications
de la norme ISO 5349. La moyenne
quadratique pondérée des vibrations
enregistrées à la position de la main de
l’opérateur était de:-
Identification de la serie............Voir la Plaquette D’identification
Procédure d'évaluation de la conformité........ANNEX VI
Organisme notifié......................I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Autres directives........................98/37/EEC, 89/336/EEC, 73/23/EEC
et aux normes............................EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Type........................................................................ A
Niveau garanti de puissance sonore...................... B
Niveau mesuré de puissance sonore..................... C
Niveau.................................................................... D
Valeur..................................................................... E
Débit d'air nominal.................................................. F
Poids....................................................................... G
Ik, ondergetekende M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. verklaar dat de
grasmaaimachine:-
Categorie.... Bladblazer
Merk............ Electrolux Outdoor Products
Voldoet aan de specificaties van directief
2000/14/EEC
Ik, ondergetekende M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5 6UP,
verklaar hierbij dat een proefexemplaar van het
bovengenoemde product is getest volgens
richtlijn 81/1051/EEC. Het maximale A-belaste
geluidsdrukniveau dat is geregistreerd bij de
positie van de bediener in een semi geluiddichte
ruimte bij vrije veld condities bedraagt:-
Ik, ondergetekende M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5 6UP,
verklaar hierbij dat een proefexemplaar van
het bovengenoemde product is getest volgens
ISO 5349 als richtlijn. De maximale belaste
effectieve waarde van trilling, geregistreerd bij
de positie van de hand van de bediener,
bedraagt:-
Identificatie van serie....................Zie Productlabel
Procedure voor het beoordelen van conformiteit..........ANNEX VI
Op de hoogte gestelde instantie.I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Andere directieven.........................98/37/EEC, 89/336/EEC, 73/23/EEC
en aan de volgende normen.......EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Type....................................................................... A
Gegarandeerd geluidsvermogen............................ B
Gemeten geluidsvermogen.................................... C
Niveau.................................................................... D
Waarde................................................................... E
Nominale luchtstroom............................................. F
Gewicht................................................................... G
DECLARATION OF CONFORMITY
KONFORMITÄTSERKLÄRUNG
DÉCLARATION DE CONFORMITÉ
CONFORMITEITSVERKLARING

Undertegnede, M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. attesterer at f lgende gressklipper:-
Kategori..... Hagestøvsuger
Merke........ Electrolux Outdoor Products
Svarer til spesifikasjonene i Direktiv
2000/14/EEC
Undertegnede, M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5
6UP bevitner at en pr ve av ovennevnte
produkt er testet, med direktiv 81/1051/EEC
som rettledning. Maksimum A-belastede
lydtrykksnivå, registrert ved brukerens
plassering, under fritt felt halvveis ekkofritt
kammerforhold, var :-
Undertegnede, M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5
6UP bevitner at en pr ve av ovennevnte
produkt er testet, med direktiv ISO 5349
som rettledning. Maksimum belastede
effektivverdi av vibrering, registrert ved
plasseringen av brukerens hånd, var:-
Serieidentifikasjon.....................Se Produktets Klassifiseringsetikett
Prosedyre for konformitetsvurdering.........ANNEX VI
Etat det er meldt fra til...............
I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Andre direktiver......................... 98/37/EEC, 89/336/EEC, 73/23/EEC
og standarder............................ EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Type....................................................................... A
Garantert lydkraftnivå ........................................... B
Målt lydkraftnivå..................................................... C
Nivå........................................................................ D
Verdi....................................................................... E
Nominell luftstr m.................................................. F
Vekt........................................................................ G
Minä allekirjoittanut M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. vakuutan, että
seuraava ruohonleikkuri:-
Luokitus...... Puutarhaimuri
Merkki........ Electrolux Outdoor Products
Vastaa direktiivin 3000/14/ETY vaatimuksia.
Minä allekirjoittanut M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham DL5
6UP, vahvistan, että yllä mainitun tuotteen
näytekappale on tarkastettu käyttäen EU-
direktiiviä 81/1051/ETY viitteenä. Suurin A-
painotettu käyttäjän kohdalla mitattu
äänenpaineen taso puolikaiuttomassa
huoneessa käyttäjän tasolla oli seuraava:-
Minä allekirjoittanut M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham DL5
6UP, vahvistan, että yllä mainitun tuotteen
näytekappale on tarkastettu käyttäen ISO
5349 -standardia viitteenä. Suurin
painotettu käsivarsitärinä käyttäjän käden
kohdalla oli seuraava:-
Sarjan Tunnus.....................Katso Tuotteen Arvokilpeä
Yhdenmukaisuusarviointi...ANNEX VI
Tiedotusosapuoli.................
I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Muut direktiivit......................98/37/EEC, 89/336/EEC, 73/23/EEC
sekä standardeja.................
EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Tyyppi.................................................................... A
Taattu luotettava tehontaso................................... B
Mitattu luotettava tehontaso.................................. C
Taso ...................................................................... D
Arvo........................................................................E
Nimellinen ilmavirtaus............................................ F
Paino...................................................................... G
Jag, undertecknad M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. intygar härmed att
gräsklipparen:-
Kategori.... Trädgårdsdammsugare
Tillverkare.. Electrolux Outdoor Products
överensstämmer med specifikationerna i
direktiv 2000/14/EEC
Jag, undertecknad M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co Durham, DL5 6UP,
betygar att ett exemplar av ovan nämnda
produkt har testats med bestämmelse
81/1051/EEC som riktlinje. Det maximala A-
vägda ljudtrycknivån som uppmättes vid
körplatsen under förhållanden i en frifälts halvt
ekofri kammare var:-
Jag, undertecknad M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co Durham, DL5
6UP, betygar att ett exemplar av ovan
nämnda produkt har testats med
bestämmelse ISO 5349 som riktlinje. Det
maximala vägda kvadratiska medelvärdet
för vibration som uppmätts vid förarens
handläge var::-
Identifiering av serie......... Se Produktidentifieringsetikett
Metod för bedömning av överensstämmelse............ANNEX VI
Notifierat organ................ I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Andra direktiv.................. 98/37/EEC, 89/336/EEC, 73/23/EEC
samt följande standarder..EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Typ......................................................................... A
Garanterad ljudnivå på motor.................................B
Uppmätt ljudnivå på motor..................................... C
Nivå........................................................................ D
Vårde......................................................................E
Nominellt luftflöde...................................................F
Vikt......................................................................... G
Undertegnede, M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. bekræfter hermed, at plæneklipperen::-
Kategori...... Havestøvsuger
Fabrikat...... Electrolux Outdoor Products
over holder specifikationerne i direktivet
2000/14/EØF
Undertegnede, M. Bowden, Electrolux Outdoor
Products, Aycliffe Industrial Park, NEWTON
AYCLIFFE, Co. Durham DL5 6UP, attesterer
herved, at en pr ve af ovenstående produkt er
blevet testet, idet direktiv 81/1051/EØF er blevet
anvendt som vejledning. Det maksimale A-
vægtede lydtryksniveau, som er blevet målt på
brugerpositionen i et frifeltshalvlydd dt rum var:-
Undertegnede, M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham DL5
6UP, attesterer herved, at en pr ve af
ovenstående produkt er blevet testet, idet
ISO 5349 er blevet benyttet som vejledning.
Den maksimale vægtede effektivværdi for
vibration som er blevet registreret ved
brugerens håndposition var:-
Identifikation af serie...... Se Produktmærkat
Fremgangsmåde til vurdering af overensstemmelse.......ANNEX VI
Underrettet organ............
I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Andre direktiver...............98/37/EEC, 89/336/EEC, 73/23/EEC
og standarderne..............
EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Type...................................................................... A
Garanteret lydeffektniveau.................................... B
Målt lydeffektniveau.............................................. C
Niveau................................................................... D
Værdi .................................................................... E
Nominel luftstr mning............................................ F
Vægt...................................................................... G
KONFORMITETSERKLÆRING
VAATIMUSTENMUSTENMUKAISUUSVAKUUTUS
FÖRSÄKRAN OM ÖVERENSSTÄMMELSE
OVERENSSTEMMELSESERKLÆRING

El abajo firmante M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. Certifica que el cortacésped:-
Categoría.... Aspiradora de jardín
Marca......... Electrolux Outdoor Products
Está conforme con las especificaciones de
la Directiva 2000/14/EEC
El abajo firmante M. Bowden, Electrolux Outdoor
Products, Aycliffe Industrial Park, NEWTON
AYCLIFFE, Co. Durham DL5 6UP. Certifico que
ha sido probada una muestra del producto
anteriormente mencionado utilizando la directiva
81/1051/EEC como guía. El máximo nivel de
presión de sonido ponderado Aregistrado en la
posición del operario bajo condiciones de cámara
anecóica de semi campo fue de:-
El abajo firmante M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham DL5
6UP. Certifico que ha sido probada una
muestra del producto anteriormente
mencionado utilizando como guía ISO 5349.
El valor máximo ponderado de la media de
la raíz cuadrada de la vibración registrada en
la posición de la mano del operario fue de-
Identificación de la serie.......... Ver Etiqueta de Identificación Del
Producto
Procedimiento de evaluación de conformidad....ANNEX VI
Organismo notificado........... I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Otras directivas..........98/37/EEC, 89/336/EEC, 73/23/EEC
y con las normativas.EN60555-2:1987, EN60555-3:1987, EN55014-
1:1993, EN55014-2:1995, EN60335-1:1994
Tipo....................................................................... A
Nivel de potencia sonora garantizado................... B
Nivel de potencia sonora medido.......................... C
Nivel...................................................................... D
Valor...................................................................... E
Flujo de aire nominal............................................. F
Peso....................................................................... G
Eu, abaixo assinado, M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5 6UP.
Certifico que a Máquina de Cortar Relva:-
Categoria.. Aspirador de Jardim
Marca....... Electrolux Outdoor Products
Está em conformidade com a Directiva
2000/14/CEE
Eu, abaixo assinado, M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5 6UP,
Certifico que uma amostra do produto acima foi
testada tendo como guia a directiva
81/1051/CEE. O valor máximo da média
pesada Ado nível de pressão do som registado
na posição do operador, em condições de
câmara semi-anecóica de campo livre foi:-
Eu, abaixo assinado, M. Bowden,
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham, DL5 6UP, Certifico que uma
amostra do produto acima foi testada
tendo como guia a norma ISO 5349. O
valor máximo da média quadrática pesada
da vibração registado na posição da mão
do operador foi:-
Identificação da série............... Consulte a Etiqueta de
Especificações do Produto
Procedimento de Avaliação de Conformidade.....ANNEX VI
Órgão Notificado......................I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Outras Directivas.......98/37/EEC, 89/336/EEC, 73/23/EEC
e com as normas...... EN60555-2:1987, EN60555-3:1987, EN55014-
1:1993, EN55014-2:1995, EN60335-1:1994
Tipo ........................................................................... A
Nível de Intensidade de Som Garantido.................... B
Nível de Intensidade de Som Medido........................ C
Nível............................................................................ D
Valor............................................................................ E
Fluxo de Ar Nominal................................................... F
Peso............................................................................ G
Il sottoscritto M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. dichiara che il tagliaerba:-
Categoria.... Gardenvac
Marca......... Electrolux Outdoor Products
è conforme alle normative della Direttiva
2000/14/CEE
Il sottoscritto, M. Bowden, Electrolux Outdoor
Products, Aycliffe Industrial Park, NEWTON
AYCLIFFE, Co. Durham, DL5 6UP, dichiara
che un campione del suddetto prodotto è stato
testato in base alla direttiva 81/1051/CEE. Il
livello massimo di pressione sonora categoria A
rilevato in corrispondenza della posizione di
guida in condizioni di camera semianecoica in
campo libero era di:-
Il sottoscritto, M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham, DL5
6UP, dichiara che un campione del
suddetto prodotto è stato testato in base
alla direttiva ISO 5349. Il valore ponderale
massimo di vibrazione sonora efficace
rilevato in corrispondenza delle mani
dell’operatore era di:-
Identificazione serie......Vedi Etichetta Dati Prodotto
Procedura di valutazione della conformità....................ANNEX VI
Ente notificato...............I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Altre direttive..................98/37/EEC, 89/336/EEC, 73/23/EEC
e alle normative............EN60555-2:1987, EN60555-3:1987, EN55014-
1:1993, EN55014-2:1995, EN60335-1:1994
Tipo....................................................................... A
Livello sonoro garantito......................................... B
Livello sonoro misurato......................................... C
Livello.................................................................... D
Valore.................................................................... E
Portata aria nominale.............................................F
Peso....................................................................... G
Alulírott, M. Bowden of Electrolux Outdoor
Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. hogy a fűnyíró:-
Kategória.... Gardenvac
Gyártmány.. Electrolux Outdoor Products
Megfelel a 2000/14/EEC direktívák
specifikációinak
Alulírott, M. Bowden, Electrolux Outdoor
Products, Aycliffe Industrial Park, NEWTON
AYCLIFFE, Co. Durham. DL5 6UP Igazolom,
hogy a fenti termékmintát a 81/1051/EEC
szabályok szerint tesztelték. A szabad hangtéri,
félig visszhangmentes kamrai körülmények
közötti, kezel i helyzetben rögzített
maximálisan atmoszferikusan-nehezitett
hangnyomásszint:
Alulírott, M. Bowden, Electrolux Outdoor
Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP Igazolom, hogy a fenti termékmintát
az ISO 5349 szabályzat szerint tesztelték.
A kezel kézhelyzetében rögzített vibráció
maximálisan súlyozott effektiv bemeneti
zajh mérséklete:-
Széria azonosítása.......Lásd a TermékminősÍtő Cédulát
Termékmegfelel ség...ANNEX VI
Értesített testület...........I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Egyéb direktívák...........98/37/EEC, 89/336/EEC, 73/23/EEC
valamint az....................EN60555-2:1987, EN60555-3:1987, EN55014-
1:1993, EN55014-2:1995, EN60335-1:1994
Típus............................................................................ A
Garantált hanger szint................................................ B
Mért hanger szint........................................................ C
Szint............................................................................. D
Érték............................................................................ E
Névleges légáramlás.................................................... F
Súly.............................................................................. G
DECLARACIÓN DE CONFORMIDAD
DECLARAÇÃO DE CONFORMIDADE
DICHIARAZIONE DI CONFORMITÀ
MEGFELELŐSÉGI TANÚSÍTVÁNY

Ja, niżej podpisany M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. Zaświadczam że
Kosiarka do strzyżenia trawników:-
Kategoria......
Odkurzacz ogrodowy
Wykonanie...Electrolux Outdoor Products
Odpowiada wymaganiom technicznym Dyrektywy
Europejskiej Wspólnoty Gospodarczej (EWG) nr
2000/14/EEC
Ja, niżej podpisany M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co.Durham DL5 6UP.
Anglia, oświadczam, że próbka powyższego
wyrobu została przebadana stosując dyrektywę
81/1051/EEC jako wzór. Maksymalny poziom
ciśnienia akustycznego, ważonego średnio A,
przy pozycji operatora w warunkach
częściowo bezechowej komory akustycznej
pochłaniającej był:-
Ja, niżej podpisany M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co.Durham DL5 6UP.
Anglia, oświadczam, że próbka powyższego
wyrobu została przebadana stosując ISO 5349
jako wzór. Maksymalna ważona wartośc
średnia kwadratowa wibracji zapisana w
pozycji ręki operatora była:-
Identyfikacja serii..................Patrz Tabliczka Znamionowa Wyrobu
Procedura Oceny Zgodności........ANNEX VI
Organ Rejestrujący...............I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Inne Dyrektywy.....................98/37/EEC, 89/336/EEC, 73/23/EEC
oraz norm..............................EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Typ............................................................................. A
Gwarantowany Poziom Mocy Akustycznej.................B
Mierzony Poziom Mocy Akustycznej.......................... C
Poziom........................................................................ D
Wartość....................................................................... E
Nominalny Przepływ Powietrza...................................F
Odwaznik.................................................................... G
Já, níže podepsaný M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP.
potvrzuji, že sekačka:-
Kategorie......Zahradní vysavač Gardenvac
Značka..........Electrolux Outdoor Products
splňuje specifikace Směrnice
2000/14/EEC
Já, níže podepsaný M. Bowden, Electrolux
Outdoor Products, (Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5 6UP)
prohlašuji, že exemplář svrchu uvedeného
výrobku byl odzkoušen za použití směrnice
81/1051/EEC jako vodítka. Maximální A-vážená
úroveň zvukového tlaku, která byla
zaznamenána pro pozici uživatele za podmínek
volného pole polo-bezdozvukové komory, byla-
Já, níže podepsaný M. Bowden, Electrolux
Outdoor Products, (Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP) prohlašuji, že exemplář svrchu
uvedeného výrobku byl odzkoušen za
použití normy ISO 5349 jako vodítka.
Maximální vážená odmocnina střední
kvadratické hodnoty vibrace, která byla
zaznamenána v pozici ruky uživatele, byla:-
Identifikace Série..............Viz Śtítek Technických Údajů Výrobku
Postup vyhodnocování souladu..........ANNEX VI
Oznámeno orgánu......... I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Jiné směrnice.................. 98/37/EEC, 89/336/EEC, 73/23/EEC
a normy............................ EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Typ........................................................................ A
Zaručená hladina akustického výkonu................. B
Naměřená hladina akustického výkonu.................C
Úroveň................................................................... D
Hodnota................................................................. E
Jmenovitý průtok vzduchu.................................... F
Váha...................................................................... G
Ja, dolupodpísaný, M. Bowden of
Electrolux Outdoor Products, Aycliffe
Industrial Park, NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. týmto potvrdzujem, že
kosačka:-
Kategória... Záhradný vysávač
Výroba....... Electrolux Outdoor Products
Vyhovuje špecifikáciám uvedeným v
Norme 2000/14/EEC
Ja, dopupodpísaný, M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park, v
meste NEWTON AYCLIFFE, Co. Durham, DL5
6UP, týmto potvrdzujem, že vzorka hore
menovaného výrobku bola otestovaná v súlade
s predpisom 81/1051/EEC. Pri maximálnom
za<ažení úroveň tlaku zvuku nameraná u
operátora za podmienok voFného poFového
pôsobenia polo-anechoického priestoru bola:-
Ja, dopupodpísaný, M. Bowden, Electrolux
Outdoor Products Park, Aycliffe Industrial
Park, v meste NEWTON AYCLIFFE, Co.
Durham, DL5 6UP, týmto potvrdzujem, že
vzorka hore menovaného výrobku bola
otestovaná v súlade s predpisom ISO 5349.
Pri maximálnom za<ažení základný priemer
druhej mocniny vibrácie nameraný v
operátorovej ruke bol:-
Identifikácia série......... Vid Štítok Parametrov Výrobku
Postupy určenia právnej spôsobilosti tovaru................ANNEX VI
Informované orgány..... I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Ďalšie nariadenia......... 98/37/EEC, 89/336/EEC, 73/23/EEC
a normám.................... EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Typ.............................................................................. A
Garantovanýstupeňsily zvuku...................................B
Nameranýstupeňsily zvuku...................................... C
Úroveň........................................................................ D
Hodnota...................................................................... E
Nominálny prúd vzduchu........................................... F
Váha........................................................................... G
Spodaj podpisani M. Bowden of Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP. potrjujem, da je kosilnica:-
kategorija.............Vrtni sesalnik
blagovna znamka.. Electrolux Outdoor
Products
v skladu z določbami Direktive 2000/14/EEC
Spodaj podpisani M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham DL5 6UP
potrjujem,da je bil primerek zgornjega
proizvoda testiran glede na pravilnik
81/1051/EEC. Maximalni nivo pritiska zvoka
A-jakosti, ki je bil zabeležen na poziciji
upravnika v pogojih prostega polja semi-
anakoične komore je bil:-
Spodaj podpisani M. Bowden, Electrolux
Outdoor Products, Aycliffe Industrial Park,
NEWTON AYCLIFFE, Co. Durham. DL5
6UP potrjujem, da je bil primerek
zgornjega proizvoda testiran glede na
pravilnik ISO 5349. Maksimalna
povprečna zmerjena vrednost korena na
kvadrat za vibriranje, zabeležena na
poziciji upravnikove je bila roke je bila:-
Identifikacija serije.............. Glej Etiketo Označbe Proizvoda
Postopek ugotavljanja skladnosti........................ANNEX VI
Obveščeno telo.................. I.T.S., Cleeve Road, Leatherhead,
Surrey, KT22 7SB. England.
Druge direktive................... 98/37/EEC, 89/336/EEC, 73/23/EEC
in po standardih ................ EN60555-2:1987, EN60555-3:1987,
EN55014-1:1993, EN55014-2:1995, EN60335-1:1994
Tip.......................................................................... A
Zajamčen nivo hrupa............................................. B
Izmerjen nivo hrupa............................................... C
Nivo....................................................................... D
Vrednost................................................................ E
Nominalen pretok zraka........................................ F
Obtežiti.................................................................. G
DEKLARACJA ZGODNOŚCI
PROHLÁŠENĺ O SOULADU SE SMÉRNICĺ
PREHLÁSENIE O PRÁVNEJ SPÔSOBILOSTI TOVARU
IZJAVA PROIZVAJALCA O SKLADNOSTI PROIZVODA Z STANDARDI

Newton Aycliffe, 2002
M. Bowden,
Research & Development Director
A
MEV1800
B99 dB (A)
C99 dB (A)
D87.9 dB(A)
E2.89 m/s2
F0.1024 m3/s
G5.1 kg
A
MEV2200
B99 dB (A)
C99 dB (A)
D87.9 dB(A)
E2.89 m/s2
F0.1024 m3/s
G5.1 kg
A
MEV1600
B93 dB (A)
C91 dB (A)
D88.3 dB(A)
E6.99 m/s2
F0.0957 m3/s
G4.5 kg
A
MEV1500
B99 dB (A)
C99 dB (A)
D87.9 dB(A)
E2.89 m/s2
F0.1024 m3/s
G5.1 kg
A
MEV750
B93 dB (A)
C91 dB (A)
D88.3 dB(A)
E6.99 m/s2
F0.0957 m3/s
G4.5 kg

5119418-01
Electrolux Outdoor Products
Aycliffe Industrial Park
NEWTON AYCLIFFE
Co.Durham DL5 6UP
ENGLAND
Telephone - (00) 44 1325 300303 Fax - (00) 44 1325 310339
UK Telephone - 01325 300303 Fax - 01325 310339
Our policy of continuous improvement means that the specification of products may be altered from time to time without prior notice.
Electrolux Outdoor Products manufacture products for a number of well known brands under various registered patents, designs and
trademarks in several countries.
© Electrolux Outdoor Products Ltd. Registered Office, Electrolux Works, Oakley Road, Luton LU4 9QQ
Registered number 974979 England
The Electrolux Group. The world’s No.1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million
Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are
sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
BELGIQUE/BELGIË Flymo Belgique/België
Tel: [phone], Fax: [phone]
ČESKÁ REPUBLIKA Electrolux, spol s r o , oz Electrolux Outdoor Products,
Na Křečku 365, Praha 10 - Horní Měcholupy
Tel: [phone], Info-linka: 0800/110 220
Internet: www partner-flymo cz E-mail: info@husqvarna cz
DANMARK Electrolux Outdoor Products, Flymo/Partner A/S,
Lundtoftegaardsvej 93A, DK 2800 Kgs.Lyngby
Tel: [phone], Fax: [phone], www.flymo-partner.dk
DEUTSCHLAND Flymo Deutschland
Tel: [phone], Fax:[phone]
ESTONIA Electrolux Estonia Ltd (Electrolux Eesti AS)
Tel: [phone]
FRANCE Flymo France SNC
Tel [phone], Fax [phone]
FINLAND SUOMI Electrolux Outdoor Products Finland
Tel: [phone], Fax: [phone]
ITALIA McCulloch Italiana s.r.l. - Via Como 72, 23868 Valmadrera
(LECCO) - ITALIA
Tel: [phone], Fax: [phone]
IRELAND Flymo Ireland
Tel: [phone], Fax: [phone]
MAGYARORSZÁG Electrolux Lehel Kft
Tel: [phone]
NORGE Flymo/Partner, div. av Electrolux Motor a.s.
Tel: [phone]
NEDERLAND Flymo Nederland
Tel: [phone], Fax: [phone]
ÖSTERREICH Husqvarna-Ges.m.b.H. Nfg. KG, Industriezeile 36, 4010 LINZ,
Tel: [phone], Fax: [phone],
email: [email protected] Internet: www.husqvarna.at
POLSKA Electrolux Poland Sp z o o Husqvarna, 01-612 Warszawa
Myslowicka 10/2
Tel:- (22) 8332949
SLOVENIJA Husqvarna-Ges.m.b.H. Nfg. KG, Industriezeile 36, 4010 LINZ,
Tel: [phone], Fax: [phone],
email: [email protected] Internet: www.husqvarna.at
SLOVENSKA Electrolux Slovakia s r o , Borova Sihot 211, 033 01 Lipt Hradok
Tel: [phone], Fax: [phone], www flymo-partner sk
SCHWEIZ/SUISSE/SUIZZERA Flymo Schweiz/Suisse/Suizzera
Tel [phone], Fax [phone]
SVERIGE Electrolux Outdoor Products, Sverige
Tel: 036 – 14 67 00, Fax: 036 – 14 60 70
UNITED KINGDOM Electrolux Outdoor Products United Kingdom
Tel: [phone], Fax: [phone]
