Fomei LED BAR 17W User manual

LED BAR 17W
LED BAR WITH HANDLE

Thank you for purchasing FOMEI’products.
Please read this user manual carefully before using this product.
E-mail: [email protected]om
Website: www.fomei.com
Warning before use:
1. In case of damage, contact a professional service FOMEI.
2. Keep the environment dry and ventilated when using the product.
3. For the best performance of the product, keep the product clean by clean.
4. Do not scratch or apply pressure to the product
5. For long battery life is needed at least once a month to charge it.
Safety warning:
1. Keep this product out of reach the rain or humidity to avoid damage or injury.
2. Do not disassemble the product. In case of damage contact a service FOMEI or contractual
service with trained professionals.
3. In the event that the product is disassembled, you will not be covered under warranty.
4. Do not use the product in extreme temperatures (+ 50C).
5. The product is not suitable for children.

A) Product overview
1. Kit bag
2. Connectors
3. Handle
4. Charger
5. LED BAR
6. Color temperature button
7. Switch
8. Power socket
9. Light intensity button
10. Channel button
11. Working indication
12. Battery slot

B) About product
LED BAR is a handheld LED light stick with the new technology lights with built-in receivers, so you
can easily control multiple channels / lights suddenly. There are three groups control channels (A, B,
C) in order to adjust multiple lights simultaneously or in groups with dimmable power output. The
product is designed to be user-friendly, it comprises four most used color temperature
3200/5000/5600/8000K as quick selection for comfortable photoshoot. The product has a battery
which is included, aluminum housing, grid handle, kit bag, charger and the system which enables
multiple connections lights. The product is very handy and flexible, we can easily take it anywhere
and it is also suitable as an additional light.
First start
1. Light with accessories pull out of the bag.
2. Screw a handle on any end of the light.
3. Before turning on we decide, if we will charge the light from the mains or batteries.
4. If we decide for battery, we will move the lever to the battery symbol on the selection panel.
In case we choose AC power supply, we will move the lever on the symbol of cable.
5. If we have more lights and we want to manage them simultaneously, we have to choose the
same channel for all. If we have more lights and we want to manage them individually, we
set „Off“ with the „Channel button“ (it will light the „Off“ indicator).
6. We change color temperature with the „Color temperature button“. If we will switch
between the color temperatures, the light indicator of chosen color turns on.
Operating instruction
Color temperature
3200 K –yellow color of light
5000 K - white color of light
5600 K –white day light
8000 K - blue color of light
The user can switch to the desired color temperature by press „Color temperature button“,
the corresponding light turns on.
Multiple connections lights system
1. LED BAR uses function of multiple connections lights system on three channels: A, B, C.
The lights which are set to the same channel can be controlled simultaneously. For
example: Set all the lights on A channel and control them through the first LED BAR. Or
set the other lights on channel B and C and you can manage these lights individually.
2. Press the „Channel button“ to change the channel or you can turn off the multiple
connections lights system that you set „Off“ with „Channel button“ and corresponding
indicator light turns on.

C) Specifications
Model number
LED BAR 17W
LED diodes
288pcs
Power
17W
Color temperature
3200K, 5000K, 5600K, 8000K
Voltage
9V 3A
Li-ion battery
7,4V 4600mAh
Dimensions
50,5 x 6 x 6cm
Weight
1kg
