FOR-A TD-3261G User manual

Ownerʼs Manual
FORA TD-3261G
Blood Glucose Plus Blood Pressure Monitoring
System

2

3
Dear TD-3261GSystem Owner:
Thank you for purchasing the TD-3261GBlood Glucose plus Blood
Pressure Monitoring System. This manual provides important
information which helps you to operate this system smoothly.
Before using this product, please read the following contents
thoroughly and carefully.
According to the clinical studies from American Diabetes
Association, elevated blood pressure often accompanies adult
diabetes patients. These studies also suggest that diabetes
patients could reduce the risk of cardiovascular diseases
by managing their blood glucose levels and blood pressure.
Therefore, with easy operation of this TD-3261GBlood Glucose
plus Blood Pressure Monitoring System, you can easily monitor
your blood glucose levels and blood pressure by yourself at any
place, any time. In addition, this system can help you and your
healthcare professionals to monitor and adjust your treatment
plans, and keep your diabetes and blood pressure under control.
If you have other questions regarding this product, please contact
the place of purchase.
Version 3.0 2019/02 311-3261000-XXX
English

4
IMPORTANT SAFTY INSTRUCTIONS
READ BEFORE USE
1. Use this device ONLY for the intended use described in this
manual.
2. Do NOT use accessories which are not specied by the
manufacturer.
3. Do NOT use the device if it is not working properly or
damaged.
4. Do NOT use the equipment where aerosol sprays are being
used or where oxygen is being administered.
5. This device does NOT serve as a cure for any symptoms
or diseases. The data measured is for reference only.
Always consult your physician to have the results interpreted.
6. Before using this device to test blood glucose, read all
instructions thoroughly and practice the test. Do all quality
control checks as directed.
7. Keep the device and testing supplies away from young
children. Small items such as the battery cover, batteries,
test strips, lancets and vial caps are choking hazards.
8. Keep the equipment and its exible cord away from hot
surfaces.
9. Do NOT apply the cuff to areas other than the place
directed.

5
KEEP THESE INSTRUCTIONS IN A SAFE PLACE
10. Use of this instrument in a dry environment, especially if
synthetic materials are present (synthetic clothing, carpets
etc.) may cause damaging static discharges that may cause
erroneous results.
11. Do NOT use this instrument in close proximity to sources of
strong electromagnetic radiation, as these may interfere with
the correct operation.
12. Proper maintenance and periodically control solution test
are essential to the longevity of your device. If you are
concerned about your accuracy of measurement, please
contact local customer service for help.
13. Always contact the manufacturer or the manufacturer's
representative to report unexpected operation or event. Do not
try to fix it by yourself.
14. When using the thermometer, stay away from electromag
netic radiation, such as the mobile in use.
15. Used in close proximity to others, EMC must be tested and
verified.
16. The accessible materials used in the device will not cause the
potential allergic reactions to skin.

6
TABLE OF CONTENTS
IMPORTANT SAFETY PRECAUTIONS 04
BEFORE YOU BEGIN 08
Important Information 08
Intended Use 09
Test Principle 09
Monitor Overview 10
Screen Display 12
Test Strip 13
Features 14
SETTING THE MONITOR 15
TESTING YOUR BLOOD GLUCOSE 19
The Four Measuring Modes 19
QUALITY CONTROL TESTING 21
Performing a Control Solution Test 21
TESTING WITH BLOOD SAMPLE 24
Preparing the Lancing Device for Blood Testing 24
Preparing the Puncture Site 24
Alternative Site Testing 26
Performing a Blood Glucose Test 27

7
TESTING YOUR BLOOD PRESSURE 30
Before Measurement 30
Taking a Single Measurement 33
Average Mode Measurement 34
Auto Cycle Mode 35
MONITOR MEMORY 37
Reviewing Test Results 37
Reviewing Day Average Results 38
DATA TRANSMISSION VIA BLUETOOTH 40
DATA TRANSMISSION VIA 4G 42
MAINTENANCE 45
Battery 45
Using AC Adapter 46
Caring for Your Monitor 47
Caring for Your Test Strips 48
Important Control Solution Information 49
SYSTEM TROUBLESHOOTING 50
Result Readings 50
Error Messages 52
Troubleshooting 54
DETAILED INFORMATION 57
Reference Values 57
SYMBOL INFORMATION 59
SPECIFICATIONS 60

8
BEFORE YOU BEGIN
Important Information
• Severe dehydration and excessive water loss may cause readings
which are lower than actual values. If you believe you are suffering
from severe dehydration, consult a healthcare professional
immediately.
• If your blood glucose results are lower or higher than usual, and
you do not have symptoms of illness, rst repeat the test. If you
have symptoms or continue to get results higher or lower than
usual, follow the treatment advice of your healthcare professional.
• Use only fresh whole blood sample to test your blood glucose.
Using other substances will lead to incorrect results.
• If you are experiencing symptoms that are inconsistent with your
blood glucose test results and you have followed all instructions
described in this owner’s manual, call your healthcare professional.
• We do not recommend using this product on severely hypotensive
individuals or patients in shock. Please consult the healthcare
professional before use.

9
Intended Use
This system is a 2 in 1 system designed to measure blood glucose
outside the human body (in vitro diagnostic use) and to measure
blood pressure non-invasively. It is intended for use at home and in
clinical settings as an aid to monitoring the effectiveness of diabetes
control. It uses fresh whole blood samples from the nger, palm,
forearm and upper arm.The device is intended for use of all ages for
home and professional use by one with a good understanding of the
operation instruction, where the patient may be an operator.
It shall not be used for the diagnosis of diabetes and hypertension.
This system has voice function, but is not designed for the visually
impaired.
Test Principle
Your system measures the amount of sugar (glucose) in whole blood.
The glucose testing is based on the measurement of electrical current
generated by the reaction of glucose with the reagent of the strip.
Your monitor measures the current, calculates the blood glucose level,
and displays the result. The strength of the current produced by the
reaction depends on the amount of glucose in the blood sample.
The blood pressure is measured non-invasively at the arm based on
the Oscillometric method.
This device is NOT able to take measurements in the presence of
common arrhythmia, such as arterial or ventricular premature beats or
arterial brillation. It may produce reading errors.

10
Monitor Overview
Front
Side
Back
Pressure Cuff
1
2
3
4
5
6
7
8
9
10
11
12 13
14
15
16
17
18

11
TEST SLOT
Insert test strip here to turn the
monitor on for testing.
DISPLAY SCREEN
RF BUTTON
Assists you with wireless data
transmission.
S BUTTON
Enter and conrm the monitor
settings.
M BUTTON
Enter the monitor memory.
ON/OFF BUTTON
To start a single blood pressure
measurement.
AVERAGE BUTTON
Assists you with blood pressure
average mode.
Speaker
RF INDICATOR
Indicates a wireless data
transmission.
1
3
4
2
6
11
10
15
12
16
13
17
14
8
9
5
7
POWER INDICATOR
Indicates the power status of
the device.
BATTERY
COMPARTMENT
STRIP EJECTOR
Eject the used strip by
pushing up this button.
AC/DC ADAPTER PORT
Connect to a power supply.
PRESSURE CUFF
AIR TUBE
AIR PLUG
Connect to air jack.
AIR JACK
18 USB PORT
For maintenance
and engineering only

12
Screen Display
Date
Systolic Pressure Symbol
Measurement Mode
Systolic Pressure Value
Diastolic Pressure Symbol
Diastolic Pressure Value
Volume Symbol
Face/Low/High Symbol
Ketone Warning
Heart Symbol - for IHB
Detection (Irregular Heart
Beat)
Pulse Rate
Day Average
Result Indicator
Low Battery Symbol
Memory Symbol
Unit for Blood Pressure
Unit for Blood Glucose
Time
Test Strip Symbol
Blood Drop Symbol
1
1
2
3
4
5
6
7
8
9
10
18
1920
17
16
15
14
13
12
11
8
6
4
7
5
3
2
9
10
12
11
13
14
15
16
17
18
19
20

13
Test Strip
NOTE
The TD-3261Gmonitor should only be used with TD-3261GTest Strips.
Using other test strips with this meter can produce inaccurate results.
ATTENTION:
The front side of test strip should face up
when inserting test strip.
Test results might be wrong if the contact bar
is not fully inserted into the test slot.
Front
Absorbent Hole
Apply a drop of blood here.
The blood will be automatically absorbed.
Conrmation Window
This is where you conrm if enough blood
has been applied to the absorbent hole in
the strip.
Test Strip Handle
Hold this part to insert the test strip into
the slot.
Contact Bars
Insert this end of the test strip into the
meter. Push it in rmly until it will go no
further.
1
4
3
2

14
Features
Model Data Transmission Function
For TD-3261G
Test results can be viewed
through a wireless connection
by using 4G.
For TD-3261B
Test results can be viewed
through a wireless connection
by using Bluetooth.

15
Before using your monitor for the rst time or if you change the meter
battery, check and update these settings. Make sure you complete the
steps below and have your desired settings saved.
► Entering the setting mode
Start with the monitor off (no test strip
inserted). Press until the monitor turns
on.
Step 1
Setting the date.
With the year ashing, press until the
correct year appears. Press .
With the month ashing, press until
the correct month appears. Press .
SETTING THE MONITOR

16
With the day ashing, press until
the correct day appears. Press .
Step 2
Setting the time
With the hour ashing, press until
the correct hour appears. Press .
With the minute ashing, press until
the correct minute appears. Press .
Step 3
Setting the time format
Press to select the desired time
format --- 12h or 24h. Press .

17
Step 4
Setting the measurement unit
Press to select the desired blood
glucose measurement unit- mg/dL or
mmol/L. Press .
This function is referring to the 4G or Bluetooth service. If “On” is
selected, your result will be transmitted right after the test.
Step 6
Setting the auto-send
Press to select the auto-send On or OFF. Press .
Step 5
Setting a language
Press to select L1 / L2. The default language for the meter is L1,
which is English; L2 is French. To conrm your selection, press .

18
Step 7
Deleting the memory
While “dEL” and a ashing “ ” symbol appear on the display along
with user numbers, if you do not wish to delete the saved results,
press to skip this step. If you wish to delete ALL the results, press
twice.
Step 8
Setting the cycle mode
Press to choose the desired blood pressure cycle mode from the
following time interval selections: OFF, 5, 10, 15, 20, 30, 40 or 60
minutes. Press to turn off the meter.
Congratulations! You have completed all settings!
NOTE
• These parameters can ONLY be changed in the setting mode.
• If the monitor is idle for 3 minutes during the setting mode, it will turn off
automatically.

19
TESTING YOUR BLOOD GLUCOSE
Modes Use when
any time of day without regard to time since last
meal
no food intake for at least 8 hours
2 hours after a meal
testing with the control solution
You can switch between each mode by:
Step 1
Start with the monitor switched off. Insert a test strip to turn on the
monitor.
The Four Measuring Modes
The monitor provides you with four modes for measuring, General, AC,
PC and QC.
(not displayed)
Gen

20
Step 2
Press to switch between General, AC, PC and QC mode.
