Forest garden TRADSUMV2FP User manual

199cm
115cm
229cm
BGMV2BAL
baluster panel
Qty 2
TRADSUMV2PLUG
plug qty 1
TRADSUMV2UP
post Qty 6
profile
TRADSUMV2FS
floor section Qty 6
AGMV2TREL
trellis panel
Qty 2
TRADSUMV2SB
bench side brace 330mm
qty 12
TRADSUMV2BB
bench back brace 1078mm
qty 3
TRADSUMV2SLAT830
bench slat 830mm
qty 3
TRADSUMV2FB
bench front brace 735mm
qty 3
TRADSUMV2SLAT1080
bench slat 1080mm
qty 3
TRADSUMV2SLEG
bench leg Qty 12
TRADSUMV2SLAT955
bench slat 955mm
qty 3
TRADSUMV2BBRA
bottom brace Qty 3
TRADSUMV2FIN
finial Qty 1
BEPV2PP
plain panel
Qty 3
BGMV2LAT
lattice panel
Qty 3
Generic Parts
HBGV2RF
roof section
Qty 6
TRADSUMV2RAF
rafter Qty 6
BGM
AGM
100191182A2GTRI
loose roof board Qty 6
(stapled to roof assembly)
SHARCH
arch section
Qty 3
TRADSUMV2FP
Fixing pack code
POZI DRIVE SCREWDRIVER
TAPE MEASURE DRILL HAMMER
REQUIRED TOOLS : (NOT SUPPLIED)
Issue 0214
BASE PLAN
RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Important : Assembly of this
arbour requires a minimum
of three adults.
Tack
Silicon Gun Qty 1
120mm Screws Qty 7
45mm Screws Qty 246 70mm Screws Qty 84
Silicon Tube Qty 1
- This building is pressure treated to ensure
the longevity of all timber components and
protect against rot. This may leave a colour
difference on some parts that will even out
as the moisture contents stabilize.
- In line with your statutory rights, please
check all parts prior to assembly, as
assembly of damaged parts may be deemed
to be acceptance and this may affect the
remedies you are entitled to. If the product is
not constructed in accordance with the
instructions, or is altered in anyway (e.g.
painted), the manufacturer cannot be held
liable for any resulting damage.
- Timber is a natural material. It will shrink
and swell as a result of varying moisture
content.
- Please keep all plastic bags and small
parts away from children in order to reduce
the risk of suffocation.
- This product must be built on a solid level
base.
- Important Note : Do not lean or stand on
roof during assembly. The roof is not load
bearing.
- If there are any technical queries with the
product, please contact our customer help
line on 0333 7777 089 between the hours
of 8.30 am and 5.00 pm Monday to Friday.

PLUG
Place the floor sections together
and so that they are tight. Place the
floor plug in the centre.
A
MUST PRE DRILL
ARCH
C
B
Fix the arch section in place using 70mm
screws, at an angle, on each side.
Fix the uprights to the panels using 4x70mm
screws for each side screwing through the
panels framework.
Place all panels onto the floor so that
everything is flush.
FULL PANEL
TRELLIS PANEL
Forest Garden Ltd, Unit 288, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB

Fix each panel to the floor
sections using 4x70mm screws,
screwing through the panel
framing.
D
Place the rafter assembly on
to the building so that the
rafters sit in the top of the
uprights. Further secure the
rafters by using 2x70mm
screws for each.
F
Slot the rafters into the finial and fix
using 1x120mm screws screwing
through the rafter into the finial for each
rafter as shown.
E
Place the roof sections so
that they sit in the grooves of
the rafters. Fix each in place
using 4x45mm screws for
each side, screwing through
the roof into the rafter.
G
MUST PRE DRILL
Issue 0214
iNSIDE VIEW
Attention:
Take care when lifting the rafters into
position and use a minimum of two
adults
Be careful not to trap fingers in the
notches
Attention:
Take care when lifting
the roof sections into
position and use a
minimum of two
adults
Be careful not to trap
fingers

BOTTOM BRACE
BENCH LEG
BENCH SIDE BRACE
BENCH BACK BRACE
BENCH FRONT BRACE
955mm SLAT
830mm SLAT
1080mm SLAT
Fit each of the loose roof boards
into the ends of the roof sections.
Fix each board using 2x45mm
screws for each end
Assemble each bench as shown.
Fix each board using 2x45mm
screws for each end
Use the silicon to seal along the
edges of the roof panels.
H
I
MUST PRE DRILL
SILICON BEAD
Maintenance:
- Regularly check that all fixings are tight and secure.
- Regularly check for structural parts for damage.
This article contains biocidal products to give protection against wood destroying insects & wood rotting fungi. Contents may vary.
May contain : Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1), Cupric oxide, Copper hydroxide carbonate,
oxyethyl, ammoniumpropionate, Copper HDO, Propiconazole, Tebuconazole, Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or untreated wood. Dispose of off-cuts
responsibly – do not burn.
Forest Garden Ltd, Unit 288, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
