Forest garden BASEMSFP User manual

SHED BASE
DRILL
POZI DRIVE SCREWDRIVER
SPIRIT LEVEL
TAPE MEASURE
HAMMER
REQUIRED TOOLS : (NOT SUPPLIED)
TRELLIS
Thank you for choosing this product manufactured by the UK's largest manufacturer of timber garden products. In order to gain the most benefit from it, please note the
following:
- Exercise particular care and follow instructions.
- This base is pressure treated to ensure the longevity of all timber components and protect against rot. This may leave a colour difference on some parts that will even
out as the moisture contents stabilises.
- In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be acceptance and this may affect the
remedies you are entitled to. If the product is not constructed in accordance with the instructions, or is altered in anyway (e.g painted), the manufacturer cannot be held
liable for any resulting damage.
- Timber is a natural material. It will shrink and swell as a result of varying moisture content.
- Please keep all plastic bags and small parts away from children in order to reduce the risk of suffocation.
- If there are any technical queries with the product, please contact our customer help line on 0333 7777 089 between the hours of 8.30 am and 5.00 pm Monday to
Friday.
MUST PRE DRILL
METAL STAKE (SHEDBASEMFP)
LONG BATTEN SHORT BATTEN
Issue 0414
90mm
Important :
Assembly of this
product requires two
people.
50mm
30
14
6 x 4
8 x 6
70471415TR
70472038PTR
70471935PTR
70471790PTR
70472038PTR
70472250PTR
70471935PTR
70471935PTR
70471935PTR
70471935PTR
70471935PTR
7 x 7
90mm
14
Fix the Battens together as shown
making sure the middle (short
battens) are equally spaced. Fix in
place using 90mm screws. Use
2x90mm screws for each end of the
two (short battens) as shown. This
applies only for the 7x7, 8x6 and the
7x5 bases.
7 x 7
BASEMSFP (FIXING PACK)
JE
70471040PTR
70471790PTR
7 x 5
1
(6x4) 4x70471040PTR
(7x5) 5x70471415PTR
(7x7) 5x70471935PTR
(8x6) 2x70471790PTR
(6x4) 2x70471790PTR
(7x5) 2x70472038PTR
(7x7) 2x70472038PTR
(8x6) 5x70472250PTR
(6X4) Qty 6
(7x5) (7x7) (8x6) Qty 9
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. MUST PRE DRILL
BASEMSFP
Attention:
You may need to move the two end (shorter) battens inwards to make
sure that the floor bearers of your shed are in contact and supported.

3
2
50mm
30
Ground level
Position the base in the desired
area. Fix a metal stake at the
highest corner using 50mm screws.
(Make sure the holes are pre-
drilled).
Using a spirit level to keep the base
level, position the remaining metal
stakes into the ground in the correct
positions with in the frame. Mark
and pre-drill holes on base.
You may need to move the metal
stakes as required due to ground
obstructions and to keep the base
level.
8 x 6
6 x 4
Forest Garden plc.Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire,DY10 4JB
70472250PTR
70472250PTR
70472250PTR
70472250PTR
70471790PTR
70472250PTR
70471790PTR
70471790PTR
70471790PTR
70472250PTR
70472250PTR
70472250PTR
70472250PTR
70472250PTR
70471040PTR
70471040PTR
70471040PTR
70471040PTR
70471790PTR
70471790PTR
Fix the Battens together as shown
making sure the two middle
70471040PTR (short battens) are
equally spaced. Fix in place using
90mm screws. 2x90mm screws for
each end of the middle
70471040PTR (short battens).
1
8 x 6
MUST PRE DRILL
MUST PRE DRILL
Biocidal Product Regulation (EU 528/2012) Article 58 Information
This article contains timber treated with Celcure AC-500, incorporating biocidal products to give protection against wood destroying insects &
wood rotting fungi.
Contains: Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1)), Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or untreated wood. Dispose of off-cuts responsibly –
