Forest garden ODR86 User manual

8’ x 6’ Overlap Reverse Apex
Shed
Fixing Pack (OPA68FP)
This fixing pack is used for several products.
There may be additional fixings.
Not to Scale
Important :
Assembly of this
shed requires a
minimum of two
adults. MUST PRE-DRILL
Issue 0115
FELT
B
ODR6PE
PLAIN END QTY 2
ODR8FP
FRONT PANEL
ODA8BP
PLAIN SIDE
236510708
ROOF BOARD QTY 2
FELT78BL QTY 1
CD E G
F
37282275
2275mm BATTEN QTY 4
A
ODR86 PARTS LIST
1
4
SFL46 FLOOR
QTY 2
SDRDT
DOOR QTY 1
37282365
2365mm BATTEN QTY 2
44161798DT
1798mm CORNER STRIP QTY 4
H J K
L
I
Top View
2B
B
Z’ bracket Qty 8
30mm Screw Qty 19
50mm Screw Qty 26
25mm Screw Qty 27
10mm Felt tacks Qty 100
Ridge Plate
30mm Nail Qty 82
PCWIN1
WINDOW
59121110PAII62DT
1110mm ANGLED BARGE BOARD QTY 4
20121695PDT
20 x 1695mm STRIP QTY 1
M
84996
675mm PLASTIC STRIP QTY 4
N
Fix both of the floors together using 2x50mm
screws, screwing through the floor bearers
as shown.
Place the panels on top of the completed floor. Make sure that all the panels are
tight and flush before fixing them to each other using 3x50mm screws.
When the panels are secured to each other, make sure they are square and fix
them to the floor using 3x50mm screws for each panel. Make sure that the screws
are positioned so that they locate into the bearers underneath.
Fix the 20 x 1695mm strip to the side
of the door frame so that it is tight
with the cladding and flush with the
frame. Use 3 x 30mm screws.
3
Flush Hinge
Qty 2
Hasp &
Staple
D
5
Place the corner strips so that they cover the joins between
the panels. Fix each in place using 3x30mm screws.
40mm Screw Qty 12
25mm Security Screws
Screws Qty 12
REQUIRED TOOLS :
(NOT SUPPLIED)
POZI DRIVE
SCREWDRIVER TAPE MEASURE HAMMER
SHARP KNIFE
FLAT HEAD
SCREWDRIVER
SCISSORS
B
E
M
C
MLML
IMPORTANT, RETAIN FOR FUTURE REFERENCE; READ
CAREFULLY
This building is pre-treated with a factory base coat for
protection during storage and transit. We recommend that
you treat your new building as soon as possible after
assembly using a wood preservative treatment. Apply in
accordance with the manufacturers instructions.
- This product must be built on a solid level base.
- The roof of this building is not a load bearing structure.
- Timber is a natural material. It will shrink and swell as a
result of varying moisture content.
- Due to the nature of the material the doors may need some
trimming for a neater fit.
- Please keep all plastic bags and small parts away from
children
Technical Helpline: 0333 7777 089 8.30 am and 5.00
pm Monday to Friday.
Please check all parts prior to assembly
Assembly of damaged parts may be deemed to be
acceptance and this may affect the remedies you are entitled
to.
If the product is not constructed in accordance with the
instructions, or is altered in any way (e.g. painted), the
manufacturer cannot be held liable for any resulting damage.
Place the hinge against the inside of the door frame and position the large section
of the hinge so that it is flush with the inside of the framing as shown. Fix with
25mm screws.
Open the hinge and fix the smaller section to the door framing. Again make sure
that the hinge is flush and that the holes are positioned so that the 25mm screws
locate correctly into the batten.
H
FIN20010512DT
QTY 2

8
9 11
7
Forest Garden Ltd, Unit 288 Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
Fix the ridge plate from inside the shed so that it bridges the two battens at the
apex together. Fix using 2 x 25mm screws
10
Biocidal Product Regulation (EU 528/2012) Article 58 Information
This article contains timber treated with Celcure AC-500, incorporating biocidal products to give protection against wood destroying insects & wood rotting fungi.
Contains: Basic copper carbonate (Copper (II) carbonate – Copper (II) hydroxide (1:1)), Boric acid, Benzalkonium chloride.
Wear gloves when handling freshly treated wood. Avoid breathing dust when cutting treated or untreated wood. Dispose of off-cuts responsibly – do not burn.
Before fixing the Hasp to the door make sure that it is in line with the framing on the
reverse of the door and closes over the Staple. Fix this in place using 2 x 25mm screws.
Position the Staple opposite, again making sure that it is in line with the framing behind
and fix it in place using 3 x 25mm screws.
Nailing through the roof sheet (G) in to the battens. Position the battens as shown.
1.The 2365mm batten (I) should be flush on all sides.
2.Place a 2275mm batten (J) so that it is offset 45mm on either side and has a 15mm offset on
the long side.
3.Place another 2275mm batten (J) in between, again with a 45mm offset on both sides.
Fix each batten in place using 30mm nails spaced in 300mm intervals.
Place the window from the outside so that the lip sits on the bottom board as shown.
Place the plastic strips around the window so that one side butts up against the cladding.
Fix the strips and the window in place using 2 x security screws for each strip and one for
the top of the window.
Lift the roof sections into place, making sure that they are in line with the apex and
the front and back panels of the shed.
Fix the roof in place using 30mm nails spaced in approximately 300mm intervals
(Make sure the nails locate into the framework of the side and end panels)
Unroll the felt and cut it into three equal lengths. Place a section on each eaves so that
there is a 50mm overhang on each edge as shown. Fix this to the roof using felt nails
spaced in 150mm intervals. Cut and fold the corners securing with a single felt nail for
each.
Place the remaining section as shown making sure that the it overlaps the others. Again
secure each sheet in place using felt nails spaced in 150mm intervals.
Staple
Staple
Fix a Z’ bracket to
each end of the
2275mm battens
using a 25mm
screw for each.
B
J15mm Offset
I
G
J
45mm Offset
F
pencil line
6
N
Lip
Board
Attention:
Take care when placing
the screws. These can
not be backed out.
Using scissors
(carefully) cut the
plastic strips to
size.
G
Attention
Take care when
cutting and
trimming the roof
felt.
Attention
Take care when
cutting and
trimming the roof
felt.
K
Maintenance.
We recommend that you treat your shed at the beginning of each season with wood preservative treatment. Apply in
accordance with the manufacturers instructions.
Regularly check (1) All fixings are secure (2) Roofing felt is free of holes and tears (3) Sand off any rough/sharp edges.
Place the barge boards against the ends of the building so that they are flush with
the overhang of the roof and in line with the top. Fix each in place using 3x40mm
screws.
Position the finial against each end of the shed so that they cover up the joins
where the barge boards meet. Secure each in place using 2 x 30mm screws.
