Forever Redwood TI AMO BENCHES User manual

ASSEMBLY INSTRUCTIONS FOR THE
TI AMO BENCHES
866.332.2403 (TOLL FREE) (707) 640.29.05 (Option 4) Direct Line for the Design
Department; 7am –7pm Pacific Time, Monday-Saturday

P| 1
TI AMO BENCHES
www.ForeverRedwood.com
NOTE: Assembly is best done by two people. To assemble your product, you need a Hammer, a Ratch or a wrench and if
required a Drill.
PROCESS TO INSTALL THE HARDWARE PROVIDED.
Required Tools (Are not included in your hardware packing).
To install the bolts.
Insert the carriage bolts into the holes and lightly tap with a hammer until the square neck fit in the wood piece and the bolt
head must flush with the wood piece. Finally, place the washer and the nut and carefully tighten it using a ratchet with the
necessary socket or a wrench.

P| 2
TI AMO BENCHES
www.ForeverRedwood.com
To install the lag bolts.
Place the washers in their lag bolts. After that, insert the lag bolts into the holes and carefully tighten it using a ratchet with
the necessary socket.
Use the washers only for the Wood Pieces.
To install the deck screws.
Insert the deck screws into the holes and carefully tighten it using a drill.

P| 3
TI AMO BENCHES
www.ForeverRedwood.com
CONTENT OF BOXES
Qty.
Description
Drawing
No.
2
Legs
1
1
Seat
2
1
Backrest
3
2
Front Support
4
2
Diagonal Supports
5
HARDWARE LIST
Description
Drawing
No.
3/8´´ X 4 ½´´ Bolts
BL1
3/8´´ X 5 ½´´ Bolts
BL2
3/8´´ X 3 ½´´ Bolts
BL3
Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on
the parts sent.
Note: Dimensions of your hardware will vary depending on size.

P| 4
TI AMO BENCHES
www.ForeverRedwood.com
DESCRIPTION
No.
Legs
1
Seat
2
Backrest
3
Front Support
4
Diagonal Supports
5
Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent.

P| 5
TI AMO BENCHES
www.ForeverRedwood.com
Step 1: Use 5/16´´ x 4 ½´´ bolts (BL1) to attach the legs (1) to the seat (2). Each part has a series of numbers that indicate
where to attach the part with the corresponding number.
Step 2: Attach the backrest (3) to the legs with 5/16´´ x 4 ½´´ bolts (BL1). Each part has a series of numbers that indicate
where toattach the part with the corresponding number.
1
1
2
3
BL1
BL1

P| 6
TI AMO BENCHES
www.ForeverRedwood.com
Step 3: Attach the frontal support (4) to the legs with 5/16´´ x 5 ½´´ bolts (BL2). Each part has a series of numbers that
indicate where to attach the part with the corresponding number.
Step 4: Use 5/16´´ x 3 ½´´ bolts (BL3) to attach the diagonal supports (5) to the seat. After that, use 5/16´´ x 5 ½´´ bolts
(BL2) bolts to attachto the legs. Each part has a series of numbers that indicate where to attach the part with the
corresponding number.
4
5
5
BL3
BL2
BL2

P| 7
TI AMO BENCHES
www.ForeverRedwood.com
This completes the outdoor assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question,
don't hesitate to call us (866 332 2403) or email us. We are here to support you.
