Forever Redwood THE ROUND PERGOLA User manual

ASSEMBLY INSTRUCTIONS FOR
THE ROUND PERGOLA
866.332.2403 (TOLL FREE); 7am –7pm Pacific Time, Monday-Saturday

P| 1
THE ROUND PERGOLA
www.ForeverRedwood.com
CONTENT OF BOXES
No.
1
2
3
4
5
6
7
8
9
Drawing
Hurricane
Gale Wind
Standard
Description
Posts
Single Supports
Supports with
In-Between Blocking
Rafters
Secondary Knee Braces
Main Knee Braces
Slats
Boots
Standard, Gale Wind or
Hurricane Anchors Bases.
If ordered.
Qty.
Will
vary.
Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on the parts sent.

P| 2
THE ROUND PERGOLA
www.ForeverRedwood.com
HARDWARE LIST
No.
A
B
C
D
E
F
G
Drawing
Description
½´´ X 3 ½´´ Anchor Bolts
(To attach the anchor bases to the ground).
5/16´´ X 3´´ Lag Bolts
(To attach the anchor bases to the post).
3/8´´ X 7´´ Bolts
(To attach the supports to the posts. / To attach the
supports together. / To attach the main knee braces to
the supports).
3/8´´ X 6´´ Bolts
(To attach the perimeter rafters to the posts).
8´´ X 3´´ Deck Screws
(To attach the rafters and the roof lattice panels to the
supports. / To attach the slats to the rafters./ To attach
the boots to the posts).
3/8´´ X 9´´ Bolts
(To attach the knee braces to the posts).
3/8´´ X 5´´ Bolts
(To attach the secondary knee braces to the rafters).
Note: Dimensions of your hardware will vary depending on size.

P| 3
THE ROUND PERGOLA
www.ForeverRedwood.com
No.
.
1
2
3
4
5
6
7
8
9
DESCRIPTION
Posts
Single Supports
Supports with
In-Between Blocking
Rafters
Secondary Knee
Braces
Main Knee Braces
Slats
Boots
Anchors Bases
Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent.

P| 4
THE ROUND PERGOLA
www.ForeverRedwood.com
NOTE: In order to know where the post needs to be placed, check the numbers on them. If the post is not marked, then place the
single Supports on the ground to locate the markings for each post position and clearly set your bearings. (“Don´t attach yet, only
place them on the ground to begin with”).
Step 1: Install the anchor base (9)with ½´´ X 3 ½´´ anchor bolts (A) or lag bolts. Please see the “How to anchor your pergola
document” for all details. Set your post (1) in the saddle of the anchor bases (9). Drill a ø ¼´´ hole in the post prior to anchoring
to facilitate the ratcheting of the hardware. After that, use a 5/16´´ X 3´´ lag bolts (B) to attach each post to the its respective
anchor base (9).
Step 2: First attach the single supports (2) to the posts with 3/8´´ X 7´´ bolts (C). Each part has a series of numbers that indicate
where to attach the part with the corresponding number.
1
1
1
1
9
2
2
5/16´´ X 3´´ Lag Bolts
3/8´´ X 7´´ Bolts

P| 5
THE ROUND PERGOLA
www.ForeverRedwood.com
Step 3: Put up the supports with in-between blocking (3), into the post notches as shown and attach to the posts with the single
support bolts. Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 4: Attach the single supports (2) to the supports with in-between blocking (3), use 3/8´´ X 7´´bolts (C). The quantity of bolts
depends on the length of the supports.
3
3
3/8´´ X 7´´ Bolts

P| 6
THE ROUND PERGOLA
www.ForeverRedwood.com
Step 5: Attach the perimeter rafters first (4) to the posts with 3/8´´ X 6´´ bolts (D) and to the supports with 8´´ x 3´´ deck screws
(E). Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 6: Attach the main knee braces (5) to the posts with 3/8´´ x 9´´ bolts (F) and to the supports with 3/8´´ X 7´´ bolts (G). Each
part has a series of numbers that indicate where to attach the part with the corresponding number.
3/8´´ X 6´´ Bolts
8´´ X 3´´ Deck Screws
4
4
5
5
5
3/8´´ X 7´´ Bolts
5
3/8´´ X 9´´ Bolts

P| 7
THE ROUND PERGOLA
www.ForeverRedwood.com
Step 7: Attach the secondary knee braces (6) to the posts with 3/8´´ x 9´´ bolts (F) and to the rafters with 3/8´´ x 5´´ bolts (C).
Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 8: Use 8´´ x 3´´ deck screws (E) to attach the rest of the rafters (4) to the supports. Each part has a series of numbers that
indicate where to attach the part with the corresponding number.
6
6
4
3/8´´ X 9´´ Bolts
8´´ X 3´Deck Screws
6
6
3/8´´ X 5´´ Bolts
4
4

P| 8
THE ROUND PERGOLA
www.ForeverRedwood.com
Step 9: Use 8´´ x 3´´ deck screws (E)to attach each slats (7) to the rafters. Each part has a series of numbers that indicate where
to attach the part with the corresponding number.
Step 10: Finally, attach the boots (8) to the posts with 8´´ x 3´´ deck screws (E). Each part has a series of numbers that indicate
where to attach the part with the corresponding number.
7
3´´ Deck Screws
8
3´´ Deck Screws

P| 9
THE ROUND PERGOLA
www.ForeverRedwood.com
This completes the Pergola assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question,
don't hesitate to call us (866 332 2403) or email us. We are here to support you.
