Forever Redwood THE LATTICE PERGOLA KIT User manual

ASSEMBLY INSTRUCTIONS FOR
THE LATTICE PERGOLA KIT
866.332.2403 (TOLL FREE); 7am –7pm Pacific Time, Monday-Saturday

P| 1
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
CONTENT OF BOXES
No.
1
2
3
4
5
6
7
8
9
10
Drawing
Hurricane
Gale Wind
Standard
Description
Posts
Single Supports
Supports with
In-Between Blocking
Single Rafters
Rafters with
In-Between Blocking
Main Knee Braces
Secondary Knee Braces
Lattice Panels
Boots
If ordered
Standard, Gale Wind or
Hurricane Anchors Bases.
If ordered
Qty.
Will vary
Note: Part numbers in the Content of Boxes Table are for reference only. These do not match to the numbers marked on the parts sent.

P| 2
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
HARDWARE LIST
No.
A
B
C
D
E
F
Drawing
Description
½´´ X 4´´ Anchor Bolts
(To attach the anchor bases to the ground).
½´´ X 4´´ Lag Bolts
(To attach the anchor bases to the ground).
5/16´´ X 3´´ Lag Bolts
(To attach the anchor bases to the posts).
3/8´´ X 7´´ Bolts
(To attach the supports and the rafters to
the posts. / To attach the supports together.
/ To attach the rafters together. / To attach
the main knee braces to the supports. / To
attach the secondary knee braces to the
rafters).
3´´ Deck Screws
(To attach the rafters to the supports. / To
attach the lattice panels to the supports and
to the rafters. /To attach the boots to the
posts).
3/8´´ X 9´´ Bolts
(To attach the knee braces to the posts).
Note: Dimensions of your hardware will vary depending on size.

P| 3
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
No.
.
1
2
3
4
5
6
7
8
9
10
DESCRIPTION
Posts
Single Supports
Supports with
In-Between Blocking
Single Rafters
Rafters with
In-Between Blocking
Main Knee Braces
Secondary Knee Braces
Lattice Panels
Boots
Anchor Bases
Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent.

P| 4
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
NOTE: In order to know where the post needs to be placed, check the numbers on them. If the post is not marked, then place the
single Supports on the ground to locate the markings for each post position and clearly set your bearings. (“Don´t attach yet, only
place them on the ground to begin with”).
Step 1: Install the anchor bases (10) with ½´´ X 4´´ anchor bolts (A) (for concrete deck) or ½´´ x 4´´ lag bolts (B) (for wood
deck). Please see the “How to anchor your pergola document” for all details. Set your post (1) in the saddle of the anchor bases.
Drill a ø ¼´´ hole in the post prior to anchoring to facilitate the ratcheting of the hardware. After that, use 5/16´´ X 3´´ lag bolts
(C) to attach each post to its respective anchor base.
Step 2: Use 3/8´´ X 7´´ bolts (D) to attach the single supports (2) to the posts. Each part has a series of numbers that indicate
where to attach the part with the corresponding number.
1
1
1
1
2
2
10
5/16´´ X 3´´ Lag Bolts
3/8´´ X 7´´ Bolts

P| 5
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
Step 3: Place the supports with in-between blocking (3), into the post notches as shown and attach to the post with the single
support bolts. Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 4: Attach the single supports to the supports with in-between blocking (3), use 3/8´´ X 7´´ bolts (D).
3/8´´ X 7´´ Bolts
3
3
3
3

P| 6
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
Step 5: Use 3/8´´ x 7´´ bolts (D) to attach the perimeter single rafters (4) to the posts and 3´´ deck screws (F) to attach to the
supports. Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 6: Place the rafters with in-between blocking (5), into the post notches as shown and attach to the post with the single rafter
bolts. Each part has a series of numbers that indicate where to attach the part with the corresponding number.
4
4
3´´ Deck Screws
3/8´´ X 7´´ Bolts
5
5

P| 7
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
Step 7: Attach the single rafters to the rafters with in-between blocking (5), use 3/8´´ X 7´´ bolts (D).
Step 8: Attach the main knee braces (6) to the supports with 3/8´´ x 7´´ bolts (D) and to the posts with 3/8´´ x 9´´ bolts (F). Each
part has a series of numbers that indicate where to attach the part with the corresponding number.
6
6
6
6
3/8´´ X 7´´ Bolts
5
3/8´´ X 7´´ Bolts
3/8´´ X 9´´ Bolts

P| 8
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
Step 9: Attach the Secondary knee braces (7) to the rafters with 3/8´´ x 7´´ bolts bolts (D) and to the posts with 3/8´´ x 9´´ bolts
(F). Each part has a series of numbers that indicate where to attach the part with the corresponding number.
Step 10: Check you set of drawings and see if on the center top there is a lattice panel (8) or a rafter (4). You must attach this
piece first with 8´´ X 3´´ deck screws (E). Each part has a series of numbers that indicate where to attach the part with the
corresponding number.
7
7
7
7
3/8´´ X 7´´ Bolts
3/8´´ X 9´´ Bolts
3´´ Deck Screws
8

P| 9
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
Step 11: Continue attaching the lattice panels (8) and the rafters (4).
Step 11.1: Attach the rafters (4) to the supports and to the lattice panels with 8´´ x 3´´ deck screw (E). Each part has a series of
numbers that indicate where to attach the part with the corresponding number.
Step 11.2: Attach the lattice panels (8) to the rafters and to the supports with 8´´ x 3´´ deck screw (E). Each part has a series of
numbers that indicate where to attach the part with the corresponding number.
3´´ Deck Screws
4
3´´ Deck Screws
8

P| 10
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
Step 12: Finally, use 8´´ x 3´´ deck screws (E) to attach the boots (9) to the posts. Each part has a series of numbers that indicate
where to attach the part with the corresponding number.
3´´ Deck Screws
9
9
9
9

P| 11
THE LATTICE PERGOLA KIT
www.ForeverRedwood.com
This completes the Pergola assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question,
don't hesitate to call us (866 332 2403) or email us. We are here to support you.
