FOS Technologies Roller 7R User manual

1
FOS Roller 7R

2
PRODUCT SPECIFICATIONS
TECHNICAL SPECIFICATION
Voltage: 110/240 Volt AC, 50/60 Hz.
Power Consumption: 230 Watt.
Light Source: 7R 230 Watt lamp.
Effects: Radial beam effects, with different colors & gobos, variable speed of the barrel and Pan / Tilt
barrel movement.
Colors: 13 dichroic filters + Open White, with bicolor function and rainbow effect.
Gobos: 14 gobos + Open, with shake and scroll functions.
Control: DMX, Auto & Sound control modes.
DMX Channels: 8.
Protection Class: IP20 (for indoor use only)
Dimensions: 440 x 230 x 280 mm
Weight: 6,9 Kg
SAFETY WARNING
This product must be installed by a qualified professional. All maintenance must be carried out by a
qualified electrician. Always disconnect the power before carrying out any maintenance. The earth must
always be connected to the ground. Ensure that all parts of the equipment are kept clean and free of
dust.
The product is designed for indoor use only. Keep it away from water, moisture, extensive
heat, humidity and dust. Do not install the product directly on to flammable objects.

3
Always connect the product to nominal voltage and frequency. Do not connect the device to
dimmers.
PROTECTION AGAINST SOLIDS AND
WATER
Only for IP-rated fixtures
The protection level of a housing is set by applied standards. For classification there is used the IP-Code.
It contains the declaration „IP“and two following numbers. The first number characterizes the protection
against harmful effects of solids, the second is rating the water protection. It is important to distinguish
whether encapsulation and harmful effect! There can be housing that is not capsuled completely but still
avoids harmful effect of solids or water.
PROTECTION EXAMPLES:
IP20: Protection against intruding objects >12,5mm „Finger protected “; No waterproofing. TYPICAL
PROTECTION FOR INDOOR USE FIXTURES
IP33: Protection against intruding objects >2,5mm; Falling water within an angle of 60° has no harmful
effect TYPICAL PROTECTION OF LED-LIGHTS USING RECESSED POWERCON AND DMX SOCKET. This
protection is linked to the mounting position of the fixture and always refers to typical mounting situation
like a Floor spot used standing on the ground.
IP54: complete protection against solids and low-pressure water from any side THIS TYPE OF FIXTURES
CAN BE USED UNDER NORMAL OUTDOOR CONDITIONS.
IP65: shielded against dust and pressurized water from any side. TYPICAL PROTECTION FOR OUTDOOR
RATED EVENTFIXTURES USING WATERPROOFED POWER AND SIGNAL LINK.
IP67: shielded against dust and protected for accidental briefly submerge. PROTECTION AGAINST
ACCIDENTIAL SUBMERGING ON TEMPORARY FLOODED AREA.
TEMPORARY USE
Event equipment is designed for temporary use. This are typical purpose as concerts, festivals, theatre,
clubs and disco use and referable venues. Long-term use, specially under outdoor conditions and fixed
outdoor installation can bring damage in aging materials and affect the coated surface. Sealings as well

4
as cables are made from rubber material and will age by long-term UV-emission as sunlight and should
be checked frequently.
LIMITATIONS OF IP PROTECTION
IP-Rating doesn´t mean unlimited outdoor use and protection against any kind of environmental
influence! Especially sunlight and included UV will bring accelerated aging. Some fixtures need special
parts or processes to fit the rated IP-Protection, like mounting covers or caps or similar. Sealings and
other plastic or rubber materials are aging parts. They must be checked frequently to ensure the
protection and safety of the fixtures. Also specified torque of screws can affect protection!
Warning
NOTE!If the signal cable is over 60 m between the DMX512 controller and fixture or between
two fixtures, then a DMX signal amplifier is needed as well.
Menu Screen
You can easily navigate through menu’s options with the four buttons under the screen. Navigating in the
menu is simple! With the Up / Down buttons, you are moving through menu’s choices, pressing Enter,
you are entering the sub menu of the option you have chosen, with the Up / Down buttons you’re moving
through the sub menu’s options, with Enter, you are confirming your choice. The FOS Roller 7R offers the
following options:
Main Menu:
System Setting:

5
1. DMX Address
2. Lamp Control
•On
•Off
3. Lamp Power
•On
•Off
4. No Signal
•Auto Program
•Sound Mode
•Hold
•Close Shutter
5. Pan Reverse
•Yes
•No
6. Tilt Reverse
•Yes
•No
7.Mic. Level
8.Display Reverse
•Yes
•No
9.Language
•English
•Chinese
10. Factory Settings
•Yes
•No
Information
1. Current Hours
2. Life Hours
3. Last Run Hours
4. Timer Password
5. Clear Time
6. Temperature
Reset

6
1. Reset All
2. Reset Scan
3. Reset Other
Manual Control:
1. Manual DMX:
•Auto Program
•Pan
•Tilt
•Color
•Gobo
•Rot. Barrel
•Strobe
•Dimmer
2. Fix Position
3. Internal Program:
•Alone
•Master
Channel Modes
8 Channels
1. Pan
2. Tilt
3. Barrel Rotation
•0 – 7 No rotation.
•8 – 127 CW Rotation from fast to slow.
•128 – 135 No rotation.
•136 – 255 CCW Rotation from slow to fast.
4. Color Wheel
•0 – 4 Open White
•5 – 9 Red
•10 – 14 Red & Orange
•15 – 19 Orange

7
•20 – 24 Orange & Cyan
•25 -29 Cyan
•30 – 34 Cyan & Green
•35 – 39 Green
•40 – 44 Green & Light Green
•45 – 49 Light Green
•50 – 54 Light Green & Pink
•55 – 59 Pink
•60 – 64 Pink & Yellow
•65 – 69 Yellow
•70 – 74 Yellow & Magenta
•75 – 79 Magenta
•80 – 84 Magenta & Deep Blue
•85 – 89 Deep Blue
•90 – 94 Deep Blue & Warm
•95 – 99 Warm
•100 – 104 Warm & CTO
•105 – 109 CTO
•110 – 114 CTO & CTB
•115 – 119 CTB
•120 – 124 CTB & Dewberry
•125 – 127 Dewberry
•128 – 189 CW Rainbow from fast to slow
•190 – 193 Rotation Stops
•194 – 255 CCW Rainbow from slow to fast
5. Gobo Wheel
•0 – 7 Open
•8 – 15 Gobo 1
•16 – 23 Gobo 2
•24 – 31 Gobo 3
•32 – 39 Gobo 4
•40 – 47 Gobo 5
•48 – 55 Gobo 6
•56 – 63 Gobo 7
•64 – 71 Gobo 8
•72 – 79 Gobo 9
•80 – 87 Gobo 10
•88 – 95 Gobo 11
•96 – 103 Gobo 12
•104 – 111 Gobo 13
•112 – 119 Gobo 14

8
•120 – 126 Gobo 1 Shake
•127 – 133 Gobo 2 Shake
•134 – 140 Gobo 3 Shake
•141 – 147 Gobo 4 Shake
•148 – 154 Gobo 5 Shake
•155 – 161 Gobo 6 Shake
•162 – 168 Gobo 7 Shake
•169 – 175 Gobo 8 Shake
•176 – 182 Gobo 9 Shake
•183 – 189 Gobo 10 Shake
•190 – 196 Gobo 11 Shake
•197 – 203 Gobo 12 Shake
•204 – 210 Gobo 13 Shake
•211 – 217 Gobo 14 Shake
•218 – 255 CW Rotation
6. Shutter
•0 – 127 Shutter closed
•128 – 191 Strobe Effect from slow to fast
•192 – 255 Shutter Open
7. Dimmer
8. Functions
•0 – 15 No function
•16 – 31 Lamp On
•32 – 47 Lamp Off
•48 – 63 All motor reset
•64 – 79 Mirror motors reset
•80 – 95 Wheels motor reset
•96 – 111 Linear color change
•112 – 127 Linear gobo change
•128 – 143 Program 1
•144 – 159 Program 2
•160 – 175 Program 3
•176 – 191 Program 4
•192 – 207 Program 5
•208 – 223 Program 6
•224 – 239 Program 7
•240 – 255 No function

9
