Fox-Lux FXSD User manual

40
R75
Warning: never put this luminaire inside its box when
it is in emergency mode. The luminaire can get
damaged due to heat not being able to escape. To
avoid this please disconnect and re-connect the
battery before putting the luminaire back in the box.
FXSD LED EMERGENCY SURFACE DOWNLIGHT
Thank you for purchasing our FXSD LED Emergency Surface Downlight.
Our products have been designed according to therelevant standards and if installed and maintained
correctly they will provide a long service life.
BS EN 60598-1 / BS EN 60598-2-22 / BS EN 50172 / BS EN 1838 / BS EN 62034 / ISO 7010 / ISO 3864
Installation, Maintenance and Servicing Notes
•Ensure that the mains supply is switched off before installing, maintaining or
servicing the luminaire.
•Luminaires should only be installed by qualified personnel.
•
•
•
The LED light source and control gear are non-replaceable. Once end-of-life is
reached, the luminaire should be replaced.
In case of mains supply failure, the battery will automatically energise the
emergency light for a minimum 3hr period. After 3hrs 5m the luminaire will
enter standby mode to protect the battery from over-discharge. The battery
must be recharged within 6 months of full discharge.
Self-test emergency luminaires are programmed to carry out functional and
full duration tests according to BS EN 50172:2004.
•First battery charge will take up to 16hrs.
•Battery re-charge takes up to 8hrs. Note that full cycle (discharge and recharge)
takes up to 12hrs.
•Contact Fox Lux if a battery replacement is required.
•Warranty terms apply. See website for details.
Standard
Self-test
Functional test is carried out automatically once a week and runs for 30s. Full duration test is carried
out automatically every 52 weeks. First full duration test is carried out automatically within the first
4 weeks after the luminaire being connected to mains.
This luminaire can be used with the optional Remote Control (REM10) which adds extra features to
Fox Lux emergency luminaires. Please refer to the REM10 user g uide.
Testing and commissioning must be carried out manually according to BS EN 50172:2004.
Testing Options
3 hour
Self
Test
Ensure this product is disposed
responsibly according to WEEE
directive 2002/96/EC
Test
Button
LED Status Indications
Normal flash = 1Hz (once/second)
Fast flash = 2Hz (twice/second)
Solid ON
Normal Flash
OFF
Fast Flash
Normal Flash
OFF
OFF
OFF
Solid ON
OFF
Normal Flash
Normal Flash
OK
Charging
Battery disconnected /
Duration test failure
Functional/Duration test in progress
Battery temperature
Light source fault
Connect battery /
Replace battery
Contact Fox Lux
Replace luminaire
GREEN LED RED LED Green Red STATUS ACTION REQUIRED
t | [phone] | e | [email protected] | w | www.fox-lux.co.uk

Product Variants and Part Numbers
FXSD02-1.5/O/3
FXSD02S-1.5/O/3
FXSD02-1.5/C/3
FXSD02S-1.5/C/3
FXSD02-3/O/3
FXSD02S-3/O/3
Ceiling mounted LED downlight NM 1.5W 150lm open area lens
Ceiling mounted LED downlight NM 1.5W 150lm open area lens SELF-TEST
Ceiling mounted LED downlight NM 1.5W 140lm corridor lens
Ceiling mounted LED downlight NM 1.5W 140lm corridor SELF-TEST
Ceiling mounted LED downlight NM 3W 270lm open area lens
Ceiling mounted LED downlight NM 3W 270lm open area lens SELF-TEST
Manual
Self-test
Manual
Self-test
Manual
Self-test
REM10*
REM10*
REM10*
Part no. Description Operating
temp. ta
Net
weight
Remote control
Testing
Installation
Blue
(Permanent)
0.75 -1.5mm2 8+1mm
Brown
N
L
Ensure that the mains supply is switched off
before installing, maintaining or servicing the
emergency luminaire.
1: Isolate mains 2: Remove front cover 3: Install base
4: Cable size and strip length 5: Connect mains
8: Restore mains supply
Click!
Drill where indicated and use
wall plugs and screws*
Remove lid on the side if connected
to 20mm conduit
Use screwdriver to
press the small hole on
the side, then lift up the
mounting base.
3-4mm
0.5Nm
0°C - 40°C 0.3kg
6: Complete lablels
Part No.:
Input voltage: 220-240V AC 50Hz
X 0 180
Installation date: __ / __ / ____
7: Re-attach front cover
Click!
•
•
FXSD LED Emergency Surface Downlight
*Remote Control REM10 allows the competent user to carry out functional tests and/or full duration tests at any time and to check system status. Please refer to REM10 user guide.
*supplied screws and wall plugs are suitable for masonry only.
Please purchase alternative fixings if required.
-Enter installation date on battery label
-Enter the appropriate code on the luminaire label
This product is classified as Class II.
Earth connection not required
Secure mains cable by using cable clip and screws supplied
lssue V1: 5/1/2020
