Four-Faith F-R200 User manual

F-R200 User Manual--Industrial Router
11/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
F-R200
Industrial Router
User Manual
Product Version
Page
V1.0.0
Product Name：F-R200
Total:81
F-R200 Industrial Router User Manual

F-R200 User Manual--Industrial Router
22/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Files Revised Record
Date
Version
Remark
Author
2016.05.24
V1.0.0
Initial version
Cm.chen/WT
Copyright Notice
All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen
Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial
use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc.,
but non-commercial purpose, downloaded or printed by individual (all files shall be not revised,
and the copyright and other proprietorship notice shall be reserved) are welcome.
Trademark Notice
Four-Faith 、 四 信 、 、 、 are all registered trademarks of Xiamen
Four-Faith Communication Technology Co., Ltd., illegal use of the name of Four-Faith,
trademarks and other marks of Four-Faith is forbidden, unless written permission is authorized in
advance.

F-R200 User Manual--Industrial Router
33/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Contents
Contents
Chapter 1 Brief Introduction of Product............................................................................................. 5
1.1 General............................................................................................................................... 5
1.2 Features and Benefits.........................................................................................................6
1.3 Working Principle.............................................................................................................. 7
1.4 Specifications..................................................................................................................... 7
Chapter 2 Installation Introduction................................................................................................... 12
2.1 General............................................................................................................................. 12
2.2 Encasement List............................................................................................................... 12
2.3 Installation and Cable Connection...................................................................................12
2.4 Power................................................................................................................................16
2.5 Indicator Lights Introduction........................................................................................... 16
2.6 Reset Button Introduction................................................................................................17
Chapter 3 Configuration and Management.......................................................................................18
3.1 Configuration Connection................................................................................................18
3.2 Access the Configuration Web Page................................................................................18
3.3 Management and configuration....................................................................................... 20
3.3.1 Setting............................................................................................................... 20
3.3.9.1 Basic Setting............................................................................................. 20
3.3.9.2 Dynamic DNS...........................................................................................26
3.3.9.3 Clone MAC Address.................................................................................27
3.3.9.4 Advanced Router...................................................................................... 27
3.3.9.5 VLANs......................................................................................................28
3.3.9.6 Networking............................................................................................... 29
3.3.2 Wireless.............................................................................................................32
3.3.2.1 Basic Settings............................................................................................32
3.3.2.2 Wireless Security...................................................................................... 34
3.3.3 Services............................................................................................................. 36
3.3.4.1 Services.....................................................................................................36
3.3.4 VPN...................................................................................................................39
3.3.6.1 PPTP......................................................................................................... 39
3.3.6.2 L2TP......................................................................................................... 41
3.3.6.3 OPENVPN................................................................................................ 42
3.3.6.4 IPSEC........................................................................................................47
3.3.6.5 GRE...........................................................................................................49
3.3.5 Security............................................................................................................. 51
3.3.5.1 Firewall..................................................................................................... 51
3.3.6 Access Restrictions........................................................................................... 53
3.3.6.1 WAN Access............................................................................................. 53
3.3.6.2 URL Filter.................................................................................................56
3.3.6.3 Packet Filter.............................................................................................. 56
3.3.7 NAT...................................................................................................................57

F-R200 User Manual--Industrial Router
44/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
3.3.1.1 Port Forwarding........................................................................................ 57
3.3.1.2 Port Range Forward..................................................................................58
3.3.1.3 DMZ..........................................................................................................59
3.3.8 QoS Setting....................................................................................................... 59
3.3.8.1 Basic..........................................................................................................59
3.3.8.2 Classify..................................................................................................... 60
3.3.9 Applications...................................................................................................... 60
3.3.2.1 Serial Applications....................................................................................60
3.3.10 Administration.................................................................................................. 62
3.3.10.1 Management..................................................................................... 62
3.3.10.2 Keep Alive........................................................................................ 64
3.3.10.3 Commands........................................................................................ 65
3.3.10.4 Factory Defaults................................................................................65
3.3.10.5 Firmware Upgrade............................................................................66
3.3.10.6 Backup.............................................................................................. 66
3.3.11 Status.................................................................................................................67
3.3.11.1 Router................................................................................................67
3.3.11.2 WAN................................................................................................. 69
3.3.11.3 LAN.................................................................................................. 71
3.3.11.4 Wireless.............................................................................................74
3.3.11.5 Bandwidth.........................................................................................75
3.3.11.6 Sys-Info.............................................................................................77
Appendix........................................................................................................................................... 80

F-R200 User Manual--Industrial Router
55/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Chapter 1 Brief Introduction of Product
1.1 General
Four-Faith Industrial Router F-R200 is an intelligent 4G LTE routers to provide the necessary
M2M applications for all types of terminals.
It adopts high-powered industrial 32-bits CPU and embedded real time operating system. It
supports RS232 (or RS485/RS422), Ethernet and WIFI port that can conveniently and
transparently connect one device to a cellular network, allowing you to connect to your existing
serial, Ethernet and WIFI devices with only basic configuration.
It has been widely used on M2M fields, such as self-service terminal industry, intelligent
transportation, smart grid, smart home, industrial automation, intelligent building, public security,
fire protection, environment protection, telemetry, finance, POS, water supply, meteorology,
remote sensing, digital medical, military, space exploration, agriculture, forestry, petrochemical
and other fields etc..

F-R200 User Manual--Industrial Router
66/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
1.2 Features and Benefits
Design for Industrial Application
High-powered industrial cellular module
High-powered industrial 32bits CPU
Adapt dual SIM design to ensure the stable and reliable of the router
Support low-consumption mode, including sleep mode, scheduled online/offline mode,
scheduled power-on/power-off mode(optional)
Housing: iron, providing IP30 protection.
Power range: DC 5~36V
Stability and Reliability
Support hardware and software WDT
Support auto recovery mechanism, including online detect, auto redial when offline to make
router always online
Ethernet port: 1.5KV magnetic isolation protection
RS232/RS485/RS422 port: 15KV ESD protection
SIM/UIM port: 15KV ESD protection
Power port: reverse-voltage and over-voltage protection
Antenna port: lightning protection(optional)
Standard and Convenience
Support standard RS232(or RS485/RS422), Ethernet and WIFI port that can connect to serial,
Ethernet and WIFI devices directly
Support standard WAN port and PPPOE protocol that can connect to ADSL directly
Support intellectual mode, enter into communication state automatically when powered
Provide management software for remote management
Support several work modes
Convenient configuration and maintenance interface（WEB or CLI）
High-performance
Dual SIM redundancy for continuous cellular connections supports 2G/3G/4G.
5 Ethernet ports(4 LAN ports and 1 WAN port).
(6) pin 3.5mm terminal block.
Support double link backup between cellular and WAN(PPPOE, ADSL) (optional)
Support VPN client(PPTP, L2TP, OPENVPN, IPSEC and GRE)(only for VPN version)
Support VPN server(PPTP, L2TP, OPENVPN, IPSEC and GRE)(only for VPN version)
Support local and remote firmware upgrade,import and export configure file
Support NTP, RTC embedded
Support multiple DDNS provider service
Support VLANs, MAC Address clone, PPPoE Server
WIFI support 802.11b/g/n and 802.11ac(5GHz) dual-band Wi-Fi, support AP, client, Adhoc,
Repeater, Repeater Bridge and WDS(optional) mode
WIFI support WEP,WPA,WPA2 encryption,Support RADIUS authentication and MAC
address filter

F-R200 User Manual--Industrial Router
77/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Support multi online trigger ways, including SMS, ring and data. Support link disconnection
when timeout
Support APN/VPDN
Support DHCP server and client, firewall, NAT, DMZ host , URL block, QoS, ttraff,statistics,
real time link speed statistics etc
Full protocol support , such as TCP/IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET,
FTP, SNMP, SSHD, etc
Schedule Reboot, Schedule Online and Offline,etc
Supports Four-Faith Cloud Platform (Centralized M2M management platform, to remote
monitor, remote configure, update firmware etc.).
1.3 Working Principle
The principle chart of the router is as following:
1.4 Specifications
Cellular Specification
ITEM
CONTENT
F-R200-W WCDMA WIFI Router
Standard and
Band
UMTS/WCDMA/HSDPA/HSUPA 850/1900/2100MHz,
850/900/1900/2100MHz(optional)
GSM850/900/1800/1900MHz
WCDMA/HSDPA/HSUPA/EDGE CLASS 12
Bandwidth
HSDPA:7.2Mbps(DL),HSUPA:5.76Mbps(UL)
UMTS:384Kbps (DL), 384Kbps (UL)
Embedded processing
system
Cellular
Module
Power
RS232
Indicator
lights
DATA Interface
User interface
4 ports
switch
WIFI
AP
10/100M
WAN
USB
HOST
Embedded processing
system
Cellular
Module
Indicator
lights
DATA Interface
User interface
WIFI
AP

F-R200 User Manual--Industrial Router
88/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
TX power
<24dBm
RX sensitivity
<-109dBm
F-R200-V CDMA2000 1X EVDO WIFI Router
Standard and
Band
CDMA2000 1X EVDO Rev A 800MHz,800/1900MHz(optional),
450MHz (optional)
CDMA2000 1X RTT, IS-95 A/B
Bandwidth
3.1Mbps(DL),1.8Mbps(UL)
TX power
<23dBm
RX sensitivity
<-104dBm
F-R200-TL LTE/TD-SCDMA WIFI Router
Standard and
Band
LTE TDD 2600/1900/2300MHz(Band 38/39/40)
(800/1400/1800MHz(Band27/61/62)(optional)
TD-SCDMA 2010/1900MHz(A/F frequency band,Band 34/39)
GSM/GPRS/EDGE 900/1800/1900MHz
Bandwidth
LTE TDD:61Mbps(DL),18Mbps(UL)
TD-SCDMA:2.8Mbps(DL),2.2Mbps(UL)
TX power
<23dBm
RX sensitivity
<-97dBm
F-R200-FL LTE/WCDMA WIFI Router
Standard and
Band
LTE FDD 2600/2100/1800/900/800MHz（Band 1/3/7/8/20）
700/850/1700/1900/2100MHz (Band 2/4/5/13/17/25)(optional)
DC-HSPA+/HSPA+/HSDPA/ HSUPA/WCDMA/UMTS
2100/1900/900/850/800MHz(Band 1/2/5/6/8）
EDGE/GPRS/GSM 850/900/1800/1900MHz
Bandwidth
LTE FDD:100Mbps(DL),50Mbps(UL)
HSDPA:7.2Mbps(DL),HSUPA:5.76Mbps(UL)
UMTS:384Kbps (DL), 384Kbps (DL)
HSPA+:42Mbps(DL),5.76Mbps(UL)
TX power
<23dBm
RX sensitivity
<-97dBm
F-R200-L LTE WIFI Router
Standard and
Band
TDD-LTE、FDD-LTE、EVDO、WCDMA、TD-SCDMA、CDMA1X、
GPRS/EDGE
Bandwidth
FDD-LTE :100Mbps(DL),50Mbps(UL)
TDD-LTE :61Mbps(DL),18Mbps(UL)
CDMA2000 1X EVDO Rev A :3.1Mbps(DL),1.8Mbps(UL)
WCDMA:42Mbps(DL),5.76Mbps(UL)
TD-SCDMA:4.2Mbps(DL),2.2Mbps(UL)
TX power
<23dBm
RX sensitivity
<-97dBm
WIFI Specification

F-R200 User Manual--Industrial Router
99/81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Item
Content
Standard
IEEE802.11b/g/n and 802.11ac(5GHz) dual-band Wi-Fi
Bandwidth
IEEE802.11b/g: 54Mbps (max)
IEEE802.11n: 150Mbps (max)
IEEE802.11ac: 867Mbps (max)
Security
WEP, WPA, WPA2, etc
WPS (optional)
TX power
20dBm(11n),24dBm(11g),26dBm(11b)
RX sensitivity
<-72dBm@54Mpbs
Hardware System
Item
Content
CPU
Industrial 32bits CPU
FLASH
16MB(Extendable to 32MB)
DDR2
128MB
Interface Type
Item
Content
WAN
1 10/100/1000 Mbps WAN port(RJ45,with LED), auto MDI/MDIX,
1.5KV magnetic isolation protection
LAN
4 10/100/1000 Mbps Ethernet ports(RJ45,with LED), auto MDI/MDIX,
1.5KV magnetic isolation protection
Serial
1 RS232, RS485(RS422) port, 15KV ESD protection
Data bits: 5, 6, 7, 8
Stop bits: 1, 1.5(optional), 2
Parity: none, even, odd, space(optional), mark(optional)
Baud rate: 2400~115200 bps
Indicator
"PWR", "SYS", "WIFI", "SIM", "Online","Signal Strength"
Input/Output
(6) pin 3.5mm terminal block
(2) DI, (1) DO, (1) Relay
Input ON Voltage: 5 to 30 VDC
Input OFF Voltage: 0 to 3 VDC
Output < 50mA @ 30VDC
Relay:1A 250VAC/30VDC
Antenna
Cellular:2 Standard SMA female interface, 50 ohm, lighting
protection(optional)
WIFI: 1 Standard SMA male interface, 50 ohm, lighting
protection(optional)
GPS:1 Standard SMA female interface, 50 ohm, lighting
protection(optional)
SIM/UIM
Standard 3V/1.8V user card interface, 15KV ESD protection
Power
2PIN Terminal block reverse-voltage and over-voltage protection

F-R200 User Manual--Industrial Router
10 10 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Reset
Restore the router to its original factory default settings
F-R200 without GPS
F-R200 with GPS
Power Input
Item
Content
Standard Power
DC 12V/1.5A
Power Range
DC 5~36V
Consumption
Working
condition
Consumption
Schedule
shutdown
2.57~4.2mA@12DVC
F-R200-W WCDMA WIFI Router
Standby
272~295mA@12VDC
Communication
283~360mA@12VDC
F-R200-V CDMA2000 1X EVDO WIFI Router
Standby
268~293mA@12VDC
Communication
279~355mA@12VDC
F-R200-TL LTE/TD-SCDMA WIFI Router
Standby
281~328mA@12VDC
Communication
322~563mA@12VDC
F-R200-FL LTE/WCDMA WIFI Router
Standby
280~330mA@12VDC

F-R200 User Manual--Industrial Router
11 11 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Communication
325~562mA@12VDC
F-R200-L LTE WIFI Router
Standby
293~326mA@12VDC
Communication
310~554mA@12VDC
Physical Characteristics
Item
Content
Housing
Iron, providing IP30 protection
Dimensions
113x115.7x45 mm
Weight
520 g
Environmental Limits
Item
Content
Operating
Temperature
-35~+75ºC(-31~+167℉)
Storage
Temperature
-40~+85ºC(-40~+185℉)
Operating
Humidity
95% (Non-condensing)

F-R200 User Manual--Industrial Router
12 12 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Chapter 2 Installation Introduction
2.1 General
The router must be installed correctly to make it work properly.
Warning: Forbid to install the router when powered!
2.2 Encasement List
Name
Quantity
Remark
Router host
1
Cellular antenna (Male SMA)
2
WIFI antenna (Female SMA)
1
GPS antenna(Male SMA)
1
optional
Network cable
1
Console cable
1
optional
RS485 Console cable
1
optional
Power adapter
1
Manual CD
1
Certification card
1
Maintenance card
1
2.3 Installation and Cable Connection
Stator and routing equipment of screw specification for: M3 * 5 mm countersunk head screws
(black)

F-R200 User Manual--Industrial Router
13 13 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Fixed Size
Router Size
Installation of SIM/UIM card:
1、Firstly power off the router
2、Unscrewed the screw
3、Press the out button of the SIM/UIM card outlet with a needle object. Then the SIM/UIM card
sheath will flick out at once
4、Put SIM/UIM card into the card sheath (Pay attention to put the side which has metal point
outside), and insert card sheath back to the SIM/UIM card outlet.
5、Screwed the screw
Warning: Forbid to install SIM/UIM card when powered!
Step 2

F-R200 User Manual--Industrial Router
14 14 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Step 3
Step 4
Step 5
Installation of antenna:
Screw the SMA male pin of the cellular antenna to the female SMA interface of the Router with
sign “ANT-1” and “ANT-2”.
Screw the SMA female pin of the WIFI antenna to the male SMA interface of the router with sign

F-R200 User Manual--Industrial Router
15 15 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
“WIFI”.
Warning: The cellular antenna and the WIFI antenna can not be connected wrongly. And the
antennas must be screwed tightly, or the signal quality of antenna will be influenced!
Installation of cable:
Insert one end of the network cable into the switch interface with sign“LAN1/LAN2/LAN3/
LAN4”, and insert the other end into the Ethernet interface of user’s device. The signal connection
of network direct cable is as follows:
RJ45-1
RJ45-2
Color
1
1
White/Orange
2
2
Orange
3
3
White/Green
4
4
Blue
5
5
White/Blue
6
6
Green
7
7
White/Brown
8
8
Brown
Insert the RJ45 end of the console cable into the RJ45 outlet with sign “console”, and insert the
DB9F end of the console cable into the RS232 serial interface of user’s device.
The signal connection of the console cable is as follows:
Console line definition (RS232)
RJ45
Color
Signal
DB9F
Description
Dir (Router
1
White/
Orange
A
8
RS485-A
Input/Output
2
Orange
B
6
RS485-B
Input/Output
3
White/
Green
RXD
2
Receive Data
Output

F-R200 User Manual--Industrial Router
16 16 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
4
Blue
DCD
1
Data Carrier Detect
Output
5
White/
Blue
GND
5
System Ground
6
Green
TXD
3
Transmit Data
Input
7
White/
Brown
DTR
4
Data Terminal Ready
Input
8
Brown
RTS
7
Request To Send
Input
2.4 Power
The power range of the router is DC 5~36V.
Warning: When we use other power, we should make sure that the power can supply power above
8W.
We recommend user to use the standard DC 12V/1.5A power.
2.5 Indicator Lights Introduction
The router provides following indicator lights: “Power”, “System”, “Online”, “SIM”, “LAN”,
“WAN”, “WIFI”, “Signal Strength”.
Indicator
Light
State
Introduction
PWR
ON
Router is powered on
OFF
Router is powered off
SYS
BLINK
System works properly
OFF
System does not work
Online
ON
Router has logged on network

F-R200 User Manual--Industrial Router
17 17 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
OFF
Router hasn’t logged on network
SIM
ON
The SIM card has been identified
OFF
The SIM card is not recognized
LAN
OFF
The corresponding interface of switch is not connected
ON /
BLINK
The corresponding interface of switch is connected
/Communicating
WAN
OFF
The interface of WAN is not connected
ON /
BLINK
The interface of WAN is connected /Communicating
WIFI
OFF
WIFI is not active
ON
WIFI is active
Signal
Strength
One Light
ON
Signal strength is weak
Two Lights
ON
Signal strength is medium
Three
Lights ON
Signal strength is good
2.6 Reset Button Introduction
The router has a “Reset” button to restore it to its original factory default settings. When user press
the “Reset” button for up to 15s, the router will restore to its original factory default settings and restart
automatically.

F-R200 User Manual--Industrial Router
18 18 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Chapter 3 Configuration and Management
This chapter describes how to configure and manage the router.
3.1 Configuration Connection
Before configuration, you should connect the router and your configuration PC with the supplied
network cable. Plug the cable’s one end into the Local Network port of the router, and another end into
your configure PC’s Ethernet port. The connection diagram is as following:
Please modify the IP address of PC as the same network segment address of the router, for instance,
192.168.1.9. Modify the mask code of PC as 255.255.255.0 and set the default gateway of PC as the
router’s IP address (192.168.1.1).
3.2 Access the Configuration Web Page
The chapter is to present main functions of each page. Users visit page tool via web browser after
connect users' PC to the Router. There are eleven main pages: Setting, Wireless, Service, VPN, Security,
Access Restrictions, NAT, QoS Setting, Applications, Management and Status. Users enable to browse
slave pages by click one main page..
Users can open IE or other explorers and enter the Router's default IP address of 192.168.1.1 on
address bar, then press the bottom of Enter to visit page Web management tool of the Router. The users
login in the web page at the first name, there will display a page shows as blow to tip users to modify the
default user name and password of the Router. Users have to click "change password" to make it work if
they modify user name and password.
After access to the information main page

F-R200 User Manual--Industrial Router
19 19 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Users need to input user name and password if it is their first time to login.

F-R200 User Manual--Industrial Router
20 20 /81
Email: [e-mail] Tel: [phone] Web: www.four-faith.hk
Add: Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen, China
Input correct user name and password to visit relevant menu page. Default user name is admin,
password is admin. (available to modify user name and password on management page, then click
submit)
3.3 Management and configuration
3.3.1 Setting
The Setup screen is the first screen users will see when accessing the Router. Most users will be able to
configure the Router and get it work properly using only the settings on this screen. Some Internet
Service Providers (ISPs) will require users to enter specific information, such as User Name, Password,
IP Address, Default Gateway Address, or DNS IP Address. These information can be obtained from your
ISP, if required.
3.3.9.1 Basic Setting
WAN Connection Type
Seven Ways: Disabled, Static IP, Automatic Configuration-DHCP, PPPOE, 3G/UNMTS/4G/LTE,
DHCP-4G.
Disabled
